CPSC 668 Distributed Algorithms and Systems

1
CPSC 668Distributed Algorithms and Systems

• Fall 2006
• Prof. Jennifer Welch

2
Problems Solvable in Failure-Prone Asynchronous
Systems

• Although consensus is not solvable in
  failure-prone asynchronous systems (neither
  message passing nor read/write shared memory),
  there are some interesting problems that are
  solvable
• set consensus
• approximate agreement
• renaming
• k-exclusion

weakenings of consensus
- "opposite" of consensus
- fault-tolerant variant of mutex
3
Model Assumptions

• asynchronous
• shared memory with read/write registers
• at most f crash failures of procs.
• results can be translated to message passing if f
  lt n/2 (cf. Chapter 10)
• may be a few asides into message passing

4
Set Consensus Motivation

• By judiciously weakening the definition of the
  consensus problem, we can overcome the
  asynchronous impossibility
• We've already seen a weakening of consensus
• weaker termination condition for randomized
  algorithms
• How about weakening the agreement condition?
• One weakening is to allow more than one decision
  value
• allow a set of decisions

5
Set Consensus Definition

• Termination Eventually, each nonfaulty
  processor decides.
• k-Agreement The number of different values
  decided on by nonfaulty processors is at most k.
• Validity Every nonfaulty processor decides on a
  value that is the input of some processor.

new
6
Set Consensus Algorithm

• Uses a shared atomic snapshot object X
• can be implemented with read/write registers
• update your segment of X with your input
• repeatedly scan X until there are at least n - f
  nonempty segments
• decide on minimum value appearing in any segment

7
Correctness of Set Consensus Algorithm

• Termination at most f crashes.
• Validity every decision is some proc's input
• Why does k-agreement hold?
• We'll show it does as long as k gt f.
• Sanity check When k 1, we have standard
  consensus. As long as there is less than 1
  failure, we can solve the problem.

8
k-Set Agreement Condition

• Let S be set of min values in final scan of each
  nf proc these are the nf decisions
• Suppose in contradiction S gt f 1.
• Let v be largest value in S, the decision of pi.
• So pi's final scan misses at least f 1 values,
  contradicting the code.

9
Set Consensus Lower Bound

• Theorem There is no algorithm for solving k-set
  consensus in the presents of f failures, if f
  k.
• Straightforward extensions of consensus
  impossibility result fail even proving the
  existence of an initial bivalent configuration is
  quite involved.
• Original proof of set-consensus impossibility
  used concepts from algebraic topology
• Textbook's proof uses more elementary machinery,
  but still rather involved

10
Approximate Agreement Motivation

• An alternative way to weaken the agreement
  condition for consensus
• Require that the decisions be close to each
  other, but not necessarily equal
• Seems appropriate for continuous-valued problems
  (as opposed to discrete)

11
Approximate Agreement Definition

• Termination Eventually, each nonfaulty
  processor decides.
• ?-Agreement All nonfaulty decisions are within
  ? of each other.
• Validity Every nonfaulty decision is within the
  range of the input values.

new
new
12
Approximate Agreement Algorithm

• Assume procs know the range from which input
  values are drawn
• let D be the length of this range
• up to n - 1 procs can fail
• algorithm is structured as a series of
  "asynchronous rounds"
• exchange values via a snapshot object, one per
  round
• compute midpoint for next round
• continue until spread of values is within ?,
  which requires about log2 D/? rounds

13
Approximate Agreement Algorithm

• Initially local variable v pi's input
• Initially local variable r 1
• update pi's segment of ASOr to be v
• let scan be set of values obtained by scanning
  ASOr
• v midpoint(scan)
• if r ?log2 (D/?)? 1 then decide v and
  terminate
• else r

14
Analysis of Algorithm

• Definitions w.r.t. a particular execution
• M ?log2 (D/?)? 1
• U0 set of input values
• Ur set of all values ever written to
  ASOr

15
Helpful Lemma

• Lemma (16.8) Consider any round r lt M. Let u be
  the first value written to ASOr. Then the
  values written to ASOr1 are in this range

u
min(Ur)
max(Ur)
(min(Ur)u)/2
(max(Ur)u)/2
elements of Ur1 are in here
16
Implications of Lemma

• The range of values written to the ASO object for
  round r 1 is contained within the range of
  values written to the ASO object for round r.
• range(Ur1) ? range(Ur)
• The spread (max - min) of values written to the
  ASO object for round r 1 is at most half the
  spread of values written to the ASO object for
  round r.
• spread(Ur1) spread(Ur)/2

17
Correctness of Algorithm

• Termination Each proc executes M asynchronous
  rounds.
• Validity The range at each round is contained
  in the range at the previous round.
• ?-Agreement
• spread(UM) spread(U0)/2M
• D/2M
• ?

18
Handling Unknown Input Range

• Range might not be known.
• Actual range in an execution might be much
  smaller than maximum possible range.
• First idea have a preprocessing phase in which
  procs try to determine input range
• but asynchrony and possible failures makes this
  approach problematic

19
Handling Unknown Input Range

• Use just one atomic snapshot object
• Dynamically recalculate how many rounds are
  needed as more inputs are revealed
• Skip over rounds to try to catch up to maximum
  observed round
• Only consider values associated with maximum
  observed round
• Still use midpoint

20
Unknown Input Range Algorithm

• shared atomic snapshot object A initially all
  segments ?
• updatei(A,x,1,x), where x is pi's input
• repeat
• scan A
• let S be spread of all inputs in non-?
  segments
• if S 0 then maxRound 0
• else maxRound log2(S/?)
• let rmax be largest round in non-? segments
• let values be set of candidates in segments
  with round
• number rmax
• update pi's segment in A with
  x,rmax1,midpt(values)
• until rmax maxRound
• decide midpoint(values)

21
Analysis of Unknown Input Range Algorithm

• Definitions w.r.t. a particular execution
• U0 set of all input values
• Ur set of all values ever written to A with
  round number r
• M largest r s.t. Ur is not empty
• With these changes, correctness proof is similar
  to that for known input range algorithm.

22
Key Differences in Proof

• Why does termination hold?
• a proc's local maxRound variable can only
  increase if another proc wakes up and increases
  the spread of the observable inputs. This can
  happen at most n - 1 times.
• Why does ?-agreement hold?
• If pi's input is observed by pj the last time pj
  computes its maxRound, same argument as before.
• Otherwise, when pi wakes up, it ignores its own
  input and uses values from maxRound or later.

23
Renaming

• Procs start with unique names from a large domain
• Procs should pick new names that are still
  distinct but that are from a smaller domain
• Motivation Suppose original names are serial
  numbers (many digits), but we'd like the procs to
  do some kind of time slicing based on their ids

24
Renaming Problem Definition

• Termination Eventually every nonfaulty proc pi
  decides on a new name yi
• Uniqueness If pi and pj are distinct nonfaulty
  procs, then yi ? yj.
• We are interested in anonymous algorithms procs
  don't have access to their indices, just to their
  original names. Code depends only on your
  original name.

25
Performance of Renaming Algorithm

• New names should be drawn from 1,2,,M.
• We would like M to be as small as possible.
• Uniqueness implies M must be at least n.
• Due to the possibility of failures, M will
  actually be larger than n.

26
Renaming Results

• Algorithm for wait-free case (f n - 1) with M
  n f 2n - 1.
• Algorithm for general f with M n f.
• Lower bound that M must be at least n 1, for
  wait-free case.
• Proof similar to impossibility of wait-free
  consensus
• Stronger lower bound that M must be at least n
  f, if f is the number of failures
• Proof uses algebraic topology and is related to
  lower bound for set consensus

27
Wait-Free Renaming Algorithm

• Shared atomic snapshot object A initially all
  segments ?
• s 1 // suggestion for my new name
• while true do
• update pi's segment of A to be x,s, where x
  is pi's
• original name
• scan A
• if s is also someone else's suggestion then
• let r be rank of x among original names
  of non-?
• segments
• let s be r-th smallest positive integer
  not currently
• suggested by another proc
• else decide on s for new name and terminate

28
Analysis of Renaming Algorithm

• Uniqueness Suppose in contradiction pi and pj
  choose same new name, s.

pj's last scan before deciding s
pi's last update before deciding suggests s
pi's last scan before deciding s
sees s as pi's suggestion and doesn't decide s
contradiction!
29
Analysis of Renaming Algorithm

• New name space is 1,,2n - 1.
• Why?
• rank of a proc pi's original name is at most n
  (the largest one)
• worst case is when each of the n - 1 other procs
  has suggested a different new name for itself,
  say 1,,n - 1.
• Then pi suggests n n - 1 2n - 1.

30
Analysis of Renaming Algorithm

• Termination Suppose in contradiction some set T
  of nonfaulty procs never decide in some
  execution.
• Consider the suffix ? of the execution in which
• each proc in T has already done at least one
  update and
• only procs in T take steps (others have either
  already crashed or decided).

31
Analysis of Renaming Algorithm

• Let F be the set of new names that are free (not
  suggested at the beginning of ? by any proc not
  in T) -- the trying procs need to choose new
  names from this set.
• Let z1, z2, be the names in F in order.
• By the definition of ?, no proc wakes up during ?
  and reveals an additional original name, so all
  procs in T are working with the same set of
  original names during ?.
• Let pi be proc whose original name has smallest
  rank (among this set of original names). Let r
  be this rank.

32
Analysis of Renaming Algorithm

• Eventually procs other than pi stop suggesting zr
  as a new name
• After ? starts, every scan indicates a set of
  free names that is no larger than F.
• Every trying proc other than pi has a larger rank
  and thus continually suggests a new name for
  itself that is larger than zr, once it does the
  first scan in ?.

33
Analysis of Renaming Algorithm

• Eventually pi does suggest zr as its new name
• By choice of zr as r-th smallest free new name,
  and fact that eventually other trying procs stop
  suggesting z1 through zr, eventually pi sees zr
  as free name with r-th smallest rank.
• Contradicts assumption that pi is trying (i.e.,
  stuck).
• So termination holds.

34
General Renaming

• Suppose we know that at most f procs will fail,
  where f is not necessarily n - 1.
• We can use the wait-free algorithm, but it is
  wasteful in the size of the new name space, 2n -
  1, if f lt n - 1.
• We can do better (if f lt n - 1) with a slightly
  different algorithm
• keep track in the snapshot object of whether you
  have decided
• an undecided proc suggests a new name only if its
  original name is among the f 1 lowest names of
  procs that have not yet decided.

35
k-Exclusion Problem

• A fault-tolerant version of mutual exclusion.
• Processors can fail by crashing, even in the
  critical section (stay there forever).
• Allow up to k processors to be in the critical
  section simultaneously.
• If lt k processors fail, then any nonfaulty
  processor that wishes to enter the critical
  section eventually does so.

36
k-Exclusion Algorithm

• cf. paper by Afek et al. 5.

37
k-Assignment Problem

• A specialization of k-Exclusion to include
• Uniqueness Each proc in the critical section
  has a variable called slot, which is an integer
  between 1 and m. If pi and pj are in the C.S.
  concurrently, then they have different slots.
• Models situation when there is a pool of
  identical resources, each of which must be used
  exclusively
• k is number of procs that can be in the pool
  concurrently
• m is the number of resources
• To handle failures, m should be larger than k

38
k-Assignment Algorithm Schema
k-assignment entry section
k-exclusion entry section
renaming using m 2k-1 names
what about repeated invocations?
k-assignment exit section
39
k-Assignment Algorithm Schema
k-assignment entry section
k-exclusion entry section
k-assignment exit section
k-exclusion entry section
