Title: The Dawn of the LHC ERA


1
The Dawn of the LHC ERA
  • A Confrontation with Fundamental Questions

Michael Dine Quarknet, UCSC, 2008
2
Aerial view of LHC
3
Size of LHC
In a magnetic field B, a particle of charge q and
momentum momentum p travels in a circle of radius
R given by
At the LHC, the desired beam energy is 7 TeV and
the state of the art dipole magnets have a field
of 8 Tesla. Plugging in and converting units
gives a radius of 3 km and a circumference of 18
km. Addition of quadrupoles, RF cavities, etc.,
increases the circumference of LHC to 27 km.
4
Magnet Pictures
2 in 1 superconducting dipole magnet
being installed in the CERN tunnel
LHC dipoles waiting to be installed.
5
ATLAS Detector
6
Tracker Pictures
Tracker
Inserting silicon detector into tracker
Inserting solenoid into calorimeter
7
Calorimeter Installation
8
Muon Toroids
Muon superconducting toroids.
9
Endcap muon sector
Endcap Muon Sectors
10
SCALE OF THE PROJECT
  • The stored energy in the beams is equivalent
    roughly to the kinetic energy of an aircraft
    carrier at 10 knots (stored in magnets about 16
    times larger)
  • There will be about a billion collisions per
    second in each detector.
  • The detectors will record and store only
    approx. 100 collisions per second.
  • The total amount of data to be stored will be 15
    petabytes (15 million gigabytes) a year.
  • It would take a stack of CDs 20Km tall per year
    this much data.

11
Today A Theorists View of the LHC
  • Why is this machine, perhaps the largest
    scientific instrument ever built, interesting?
  • What do we expect to learn? What questions might
    we hope to answer?

12
The Standard Model
By 1980, the Standard Model of particle physics
offered a nearly complete picture of the
elementary particles and their interactions. Quar
ks and leptons, interacting through exchange of
gauge particles (photon, W, Zo, gluons).
13
  • quantum field theory, describing interactions
    between
  • pointlike spin-1/2 particles (quarks and
    leptons)
  • via exchange of spin-1 vector bosons (photon, W
    and Z, gluon)
  • fundamental particles (fermions)
  • 2 (particle pair)
  • 3 (generations)
  • 2 (anti-particles)

14
(No Transcript)
15
By 1995, the strong and weak interactions were
understood at the sort of precision level of QED
in 1960. the Standard Model was triumphant no
interesting discrepancies. All questions in our
list answered (except general relativity)!
16
time year
  • Last missing particle in SM
  • (EW symmetry breaking mass)
  • Light SM Higgs preferred

MH 126 73 -48 GeV lt 280 GeV
(95 CL)
17
Puzzles of the Standard Model
  • The Standard Model possesses many parameters.
    Some are extremely peculiar e.g. me/mt 3 x
    10-6.
  • The electric charges of the quarks and leptons
    are exact rational multiples of one another (e.g.
    QeQp). Why?
  • General relativity cannot be combined sensibly
    with the Standard Model, without some significant
    modification.
  • The Standard Model cannot account for most of the
    energy density of the universe. About 20 dark
    matter about 75 dark energy only 5 baryons.
  • The Standard Model cannot explain why there are
    baryons at all (baryogenesis).

18
(No Transcript)
19
The Hierarchy Problem (or the failure of
dimensional analysis)
  • But, apart from our failure to discover it up
    to now, the Higgs field presents a deeper puzzle.
    It may be too heavy to see without an LHC but
    the real puzzle is that it is so light. Problem
    is one of dimensional analysis. We know there
    are large energy scales in nature. Biggest is
    the Planck mass, Mp GN1/2 1019 GeV
  • Why isnt MH C Mp, where C 1?

g
H
e pi
e pi
20
... doubled particle spectrum ... ?
21
Solves hierarchy problem
  • Now dimensional analysis requires greater care.
    It turns out that because of the symmetry,
  • MH C Ms
  • New physics at TeV (LHC!) scales
  • Explains dark matter
  • Gives prediction of strong interaction strength

22
o
without SUSY
  • ... BUT some of our puzzles
  • solved ...
  • Successful unification of
  • forces
  • Lightest susy particle stable, and
  • produced in abundance to be dark matter
  • Readily explains baryon asymmetry

with SUSY
Interaction energy in GeV
23
l
c
l
c
l
c
q
q
l
l
c
g
q
l
q
Production and decay of superparticles at the
LHC. Here, jets, Leptons, missing energy.
24
(No Transcript)
25
(No Transcript)
26
  • I am a fan of the supersymmetry hypothesis I'm
    not alone. About 12,000 papers in the SPIRES
    data base (also a good fraction of your faculty).
    If true, quite exciting a new symmetry of
    physics, closely tied to the very nature of space
    and time. Dramatic experimental signatures. A
    whole new phenomenology, new questions. But
    neither the limited evidence nor these sorts of
    arguments make it true there is good
    experimental as well as theoretical reason for
    skepticism.
  • This is not the only explanation offered for the
    hierarchy, and all predict dramatic phenomena in
    this energy range.
  • Large extra dimensions
  • Warped extra dimensions
  • Technicolor
  • Its just that way (anthropic?)

27
Hypothetical answers to our fundamental questions
  • Too many parameters
  • Hierarchy
  • Charge quantization
  • Quantum general relativity
  • Dark Matter
  • Dark energy
  • Baryogenesis

Other proposals have some success with each of
the starred items perhaps fair to see that
supersymmetry does best.
28
STRING THEORY
  • String theory, an extension of the ideas of grand
    unification, has pretensions to attack the
    remaining problems on this list
  • A consistent theory of quantum gravity
  • Incorporates gauge interactions, quarks and
    leptons, and other features of the Standard
    Model.
  • Parameters of the model can be calculated, in
    principle.
  • Low energy supersymmetry emerges naturally all
    of this proliferation, which seemed artificial,
    almost automatic.

29
Has string theory delivered?
  • String theory is hard. We dont have a
    well-understood set of principles. Some
    problems of quantum gravity are resolved, but
    many of the challenges remain.
  • String theory seems able to describe a vast
    number of possible universes, only a small
    fraction of which are like ours.
  • Until recently, no progress on one of the most
    difficult challenges to particle physics the
    dark energy.

30
Dark Energy/Cosmological Constant
  • About 3/4 of energy of universe. Satisfies
  • p -r
  • an energy density of the vacuum.
  • Dimensional analysis L M4.

Mp4? MW4? (1076,108) Measured 10-47!
31
Progress and Controversy
  • Many states of string theory now known with
    properties close to those of the Standard Model.
    Possibly 10500 or more!
  • Among these, a uniform distribution of L. So
    many consistent with observation.
  • Banks, Weinberg in such a circumstance, only
    form galaxies in those states with L close to
    observation. Perhaps universe, in its history,
    samples all? (This argument actually predicted
    the observed value of the dark energy).

32
Can string theorists make other predictions?
  • Supersymmetry at LHC, or not?
  • If yes, spectrum of superpartners?
  • If no, alternatives (just a Higgs, large extra
    dimensions, warping?)
  • Cosmology?

33
We are at the dawn of a very exciting era. We
may resolve some of our fundamental questions.
34
Popular Treatments of String Theory
Rhapsodic about string theory
Denounces string theory
35
Should the public care?
  • Green too focused on the mathematics of string
    theory, too little on what we actually see,
    observe in nature. Given string theorys limited
    successes, seems to me this should be end of
    the book material.
  • Smolin some valid criticisms, but promoting his
    own agenda no more interest in physical
    phenomena than Green.

36
Dine rant
  • See handout. Not yet prepared to put on my
    website.
