Improving Software Security with Precise Static and Runtime Analysis

1
Improving Software Security with Precise Static
and Runtime Analysis

• Benjamin Livshits
• SUIF Compiler Group
• Computer Systems Lab
• Stanford University

http//suif.stanford.edu/livshits/work/griffin/
2
Security Vulnerabilities Last 10 Years
Source NIST/DHS Vulnerability DB
3
Which Security Vulnerabilities are Most Prevalent?

• Analyzed 500 vulnerability reports, one week in
  November 2005

294 vuln. or 58
Source securityfocus.com
4
Focusing on Input Validation Issues
Web application vulnerabilities
Source securityfocus.com
5
SQL Injection Example

• Web form allows user to look up account details
• Underneath Java J2EE Web application serving
  requests

String username req.getParameter(user) String
password req.getParameter(pwd) String query
SELECT FROM Users WHERE username
user AND Password password con.execut
eQuery(query)
6
Injecting Malicious Data (1)
submit

• ...
• ...
• String query SELECT FROM Users WHERE
• username 'bob'
• AND password
• ...

7
Injecting Malicious Data (2)
submit

• ...
• ...
• String query SELECT FROM Users WHERE
• username 'bob--
• AND password
• ...

8
Injecting Malicious Data (3)
submit
... ... String query SELECT FROM Users WHERE
username 'bob DROP Users-- AND
password ...
9
Attack Techniques for Taint-Style Vulnerabilities

• 1. Sources (inject)
• Parameter manipulation
• Hidden field manipulation
• Header manipulation
• Cookie poisoning
• Second-level injection

• 2. Sinks (exploit)
• SQL injections
• Cross-site scripting
• HTTP request splitting
• Path traversal
• Command injection

1. Parameter manipulation 2. SQL injection
vulnerability
10
Goals of the Griffin Software Security Project
2000
2001
2002
2003
2004
2005
2006

• Financial impact
• Cost per incident 300,000
• Total cost of online fraud 400B/year
• Griffin Project goals
• Address vulnerabilities in Web applications
• Focus on large Java J2EE Web applications

11
Griffin Project Contributions

• Effective solution addressing a large range of
  real life problem in domain of Web Application
  Security
• Pushed state of the art in global static/pointer
  analysis precisely handle large modern
  applications
• Design of an efficient dynamic techniques that
  recover from security exploits at runtime
• Comprehensive, large scale evaluation of problem
  complexity and analysis features discovered many
  previously unknown vulnerabilities

Effective solution of Web App Sec problems
Static analysis
Runtime analysis
Experimental validation
12
Overview of the Griffin Project
Overview
Static
Extensions
Dynamic
Experiments
Conclusions
Future
13
Griffin Project Framework Architecture
Vulnerability specification
Application bytecode
Provided by user
Static analysis
Dynamic analysis
Livshits and Lam, Usenix Security 05
Martin, Livshits, and Lam, OOPSLA 05
Vulnerability warnings
Instrumented application

• Pros
• Find vulnerabilities early
• Explores all program executions
• Sound, finds all vuln. of particular kind

• Pros
• Keeps vulnerabilities from doing harm
• Can recover from exploits
• No false positives, but has overhead

14
Following Unsafe Information Flow / Taint Flow
How do we know what these are?
sanitizer
String.substring

sink
Servlet.getParameter(user) (source)
Security violation
Statement.executeQuery(...) (sink)
15
Vulnerability Specification

• User needs to specify
• Source methods
• Sink methods
• Derivation methods
• Sanitization methods
• PQL Program Query Language Martin, Livshits,
  and Lam OOPSLA05
• General language for describing events on objects
• Real queries are longer
• 100 lines of PQL
• Captures all vulnerabilities
• Suitable for all J2EE applications

query simpleSQLInjection returns object
String param, derived uses object
HttpServletRequest req object Connection
con object StringBuffer
temp matches param
req.getParameter(_) temp.append(param)
derived temp.toString()
con.executeQuery(derived)
16
Static Analysis
Overview
Static
Extensions
Dynamic
Experiments
Conclusions
Future
17
Motivation Why Pointer Analysis?
String username req.getParameter(user")
list1.addFirst(username) ... String str
(String) list2.getFirst() con.executeQuery(str)

• What objects do username and str point to?
• Question answered by pointer analysis
• A classic compiler problem for 20 years
• Rely on context-sensitive inclusion-based pointer
  analysis Whaley and Lam PLDI04

18
Pointer Analysis Precision
Runtime heap
Static representation
Static approximation
h
o1
o2
o3

• Imprecision of pointer analysis ? false positives
• Precision-enhancing pointer analysis features
• Context sensitivity Whaley and Lam, PLDI04
  (not enough)
• Object sensitivity
• Map sensitivity

19
Importance of Context Sensitivity
Imprecision ? Excessive tainting ? false positives
c1
tainted
tainted
c1
String id(String str) return str
c2
untainted
tainted
c2
points-to(vc VarContext, v Var, h Heap)
points-to(v Var, h Heap)
Context sensitivity
Context insensitive
20
Handling Containers Object Sensitivity

• 1. String s1 new String() // h1
• 2. String s2 new String() // h2
• 3.
• 4. Map map1 new HashMap()
• 5. Map map2 new HashMap()
• 6.
• 7. map1.put(key, s1)
• 8. map2.put(key, s2)
• 9.
• 10. String s (String) map2.get(key)

points-to(, s, h1) points-to(, s, h2)
points-to(, s, )
points-to(vc VarContext, v Var, h Heap)
points-to(vo1 Heap, vo2 Heap, v Var,
ho Heap, h Heap)
points-to(vc VarContext, vo1 Heap, vo2 Heap,
v Var, ho Heap, h Heap)
points-to(vo Heap, v Var, h Heap)
Context sensitivity
Object sensitivity
1-level object sensitivity
1-level object sensitivity context sensitivity
21
Inlining Poor Mans Object Sensitivity

• Call graph inlining is a practical alternative
• Inline selected allocations sites
• Containers HashMap, Vector, LinkedList,
• String factories String.toLowerCase(),
  StringBuffer.toString(), ...
• Generally, gives precise object sensitive results
• Need to know what to inline determining that is
  hard
• Inlining too much ? doesnt scale
• Inlining too little ? false positives
• Iterative process
• Cant always do inlining
• Recursion
• Virtual methods with gt1 target

22
Map Sensitivity
1. ... 2. String username request.getParameter(
user) 3. map.put(USER_NAME,
username) ... 4. String query (String)
map.get(SEARCH_QUERY) 5. stmt.executeQuery(quer
y) 6. ...
USER_NAME ? SEARCH_QUERY

• Maps with constant string keys are common
• Map sensitivity augment pointer analysis
• Model HashMap.put/get operations specially

23
Analysis Hierarchy
Context sensitivity
Object sensitivity
Map sensitivity
Flow sensitivity
None
None
None
None
1-OS
Local flow
k-CFA
k-OS
Constant keys
Predicate- sensitive
8-CFA
8-OS
Interprocedural predicate-sensitive
Symbolic analysis of keys
8-CFA
Partial 1-OS
Constant string keys
Local flow
24
PQL into Datalog Translation
PQL Query
Datalog Query
Whaley, Avots, Carbin, Lam, APLAS 05
query simpleSQLInjection returns object
String param, derived uses object
ServletRequest req object Connection
con object StringBuffer temp
matches param req.getParameter(_)
temp.append(param) derived
temp.toString() con.executeQuery(derived)

simpleSQLInjection(hparam, hderived )
ret(i1, v1), call(c1, i2, "ServletRequest.getPar
ameter"), pointsto(c1, v1, hparam),
actual(i2, v2, 0), actual(i2, v3, 1), call(c2,
i2, "StringBuffer.append"), pointsto(c2, v2,
htemp), pointsto(c2, v3, hparam),
actual(i3, v4, 0), ret(i3, v5), call(c3, i3,
"StringBuffer.toString"), pointsto(c3, v4,
htemp), pointsto(c3, v5, hderived),
actual(i4, v6, 0), actual(i4, v7, 1), call(c4,
i4, "Connection.execute"), pointsto(c4, v6,
hcon), pointsto(c4, v7, hderived).
Relevant instrumentation points
Datalog solver
Vulnerability warnings
25
Eclipse Interface to Analysis Results

• Vulnerability traces are exported into Eclipse
  for review
• source ? o1 ? o2 ? ? on ? sink

26
Importance of a Sound Solution

• Soundness
• only way to provide guarantees on applications
  security posture
• allows us to remove instrumentation points for
  runtime analysis
• Soundness claim

Our analysis finds all vulnerabilities
in
statically analyzed code that are captured
by the specification
27
Static Analysis Extensions
Overview
Static
Extensions
Dynamic
Experiments
Conclusions
Future
28
Towards Completeness

• Completeness goal
• analyze all code that may be executed at runtime

specify roots
discover the rest
29
Generating a Static Analysis Harness
ltservletgt ltservlet-namegtblojsomcommentapilt
/servlet-namegt ltservlet-classgt
org.blojsom.extension.comment.CommentAPIServlet lt
/servlet-classgt ltinit-paramgt
ltparam-namegtblojsom-configurationlt/param-namegt
lt/init-paramgt ltinit-paramgt
ltparam-namegtsmtp-serverlt/param-namegt
ltparam-valuegtlocalhostlt/param-valuegt
lt/init-paramgt ltload-on-startupgt3lt/load-on-
startupgt lt/servletgt
public class Harness public static void
main(String args) processServlets()
processActions() processTags()
processFilters() ...
App
App
App
500,000 lines of code
web.xml
web.xml
web.xml
Application Server (JBoss)
1,500,000 lines of code
2M lines of code
30
Reflection Resolution
Constants
Specification points
1. String className ... 2. Class c
Class.forName(className) 3. Object o
c.newInstance() 4. T t (T) o
Q what object does this create?
1. String className ... 2. Class c
Class.forName(className) Object o new
T1() Object o new T2() Object o new
T3() 4. T t (T) o
Livshits, Whaley, and Lam, APLAS05
31
Reflection Resolution Results

• Applied to 6 large Java apps, 190,000 lines
  combined

Call graph sizes compared
Methods
32
Dynamic Analysis
Overview
Static
Extensions
Dynamic
Experiments
Conclusions
Future
33
Runtime Vulnerability Prevention
Martin, Livshits, and Lam, OOPSLA05
App

• Detect and stop
• Detect and recover

App
Vulnerability specification
App
Application Server (JBoss)
34
Runtime Instrumentation Engine

• PQL spec ? into state machines
• Run alongside program, keep track of partial
  matches
• Run recovery code before match

xyo3
xo3
y x
e
e
e
tx.toString()
y derived(t)
e
e
xyo3
xo3
e
xo3
t.append(x)
y derived(t)
xo3
sanitizer
35
Reducing Instrumentation Overhead
query simpleSQLInjection returns object
String param, derived uses object
ServletRequest req object Connection
con object StringBuffer temp
matches param req.getParameter(_)
temp.append(param) derived
temp.toString() con.executeQuery(derived)

1. String name req.getParameter(name) 2.
StringBuffer buf1 new StringBuffer() 3.
StringBuffer buf2 new StringBuffer(def) 4.
buf2.append(abc) 5. buf1.append(name) 6.
con.executeQuery(buf1.toString()) 7.
con.executeQuery(buf2.toString())

• Instrument events on objects that may be part of
  a match
• Soundness allows to remove instrumentation points

36
Experimental Results
Overview
Static
Extensions
Dynamic
Experiments
Conclusions
Future
37
Experimental Evaluation

• Comprehensive evaluation
• SecuriBench Macro SoftSecTools 05
• SecuriBench Micro
• Google SecuriBench
• Compare Griffin to a commercially available tool
• Griffin vs. Secure Software CodeAssure
• CodeAssure March 2006 version

38
Benchmark Statistics
Lines of Code
39
SecuriBench Macro Static Summary
40
Vulnerability Classification

• Reported issues back to program maintainers
• Most of them responded, most confirmed as
  exploitable
• Vulnerability advisories issued

41
SecuriBench Micro Static Summary
42
A Study of False Positives in blojsom
Base
114
With context sensitivity

• Q How important are analysis features for
  avoiding false positives?

84
With object sensitivity
43
With map sensitivity
5
43
Griffin vs. CodeAssure
SecuriBench Macro
80
Q What is the relationship between false
positives and false negatives?
SecuriBench Micro
40
44
Deep vs. Shallow Vulnerability Traces

• Q How complex are the vulnerabilities we find?

45
Analyzing personalblog
Hibernate library code
Application code
sinks
sf.hibernate.Session.find()

• Q What is the connectivity between sources and
  sinks?

sources
objects
roller
1 falsely tainted object ? 100 false positives
46
Runtime Analysis Results

• Experimental confirmation
• Blocked exploits at runtime in our experiments
• Naïve implementation
• Instrument every string operation ? high overhead
• Optimized implementation
• 82-99 of all instrumentation points are removed

lt 1
47
Related Work Conclusions
Overview
Static
Extensions
Dynamic
Experiments
Conclusions
Future
48
Lessons Learned

• Context sensitivity is good. Object sensitivity
  is great, but hard to scale. Scaling it
  important open problem
• Cant ignore reflection in large programs
  reflection makes the call graph much bigger
• Many of the bugs are pretty shallow there are,
  however, complex bugs, especially in library code
• Practical tools tend to introduce false negatives
  to avoid false positives not necessarily a good
  choice
• Automatic recovery from vulnerabilities is a very
  attractive approach overhead can be reduced

49
Related Work

• Web application security work
• Penetration testing tools (black box testing)
• Application firewalls (listen on the wire and
  find patterns)
• Practical automatic static error detection tools
• WebSSARI (static and dynamic analysis of PHP)
  Huang,... 04
• JDBC checker (analysis of Java strings)
  Wasserman, Su 04
• SQLRand (SQL keyword randomization) Boyd and
  Keromytis 04

Usenix 05
OOSPLA 05
Source http//suif.stanford.edu/livshits/work/g
riffin/lit.html
50
Future Work

• Applying Model-checking to Web applications
  (Michael Martin)
• Learning Specification from Runtime Histories
  (with Naeim)
• Partitioned BDDs to Scale bddbddb Better (with
  Jean-Gabriel/Prof. Dill)
• Analyze Sources of Imprecision in Datalog
• Analyzing Sanitization Routines
• Attack Vectors in Library Code
• Type Qualifiers in Java (with Dave
  Greenfieldboyce at UMD)
• Using Model Checking to Break Sanitizers

51
Special Thanks

• Stella, My parents, My sister
• Monica
• Alex, Dan, Dawson, Elizabeth
• Ramesh Chandra, Darlene Hadding, David Heine,
  Michael Martin, Brian Murphy, Joel Sandin,
  Constantine Sapuntzakis, Chris Unkel, John
  Whaley, Kolya Zeldovich
• Dzintars Avots, Ron Burg, Mark Dilman, Craig
  Foster, Chris Kaelin, Amit Klein, Ted Kremenek,
  Iddo Lev, John Mitchell, Carrie Nielsen, David
  Pecora, Ayal Pincus, Jai Ranganathan, Noam
  Rinetzky, Mooly Sagiv, Elena Spector, Jeff
  Ullman, Eran Yahav, Gaylin Yee, Andreas Zeller,
  Tom Zimmerman
• National Science Foundation

52
The End.
Griffin Security Project
http//suif.stanford.edu/livshits/work/g
riffin/ Stanford SecuriBench
http//suif.stanford.edu/livshits
/securibench/ Stanford SecuriBench Micro
http//suif.stanford.edu/livshit
s/work/securibench-micro/ PQL language

http//pql.sourceforge.net/

• Finding Security Vulnerabilities in Java
  Applications with Static Analysis, Livshits and
  Lam, 2005.
• Finding Application Errors and Security Flaws
  Using PQL, Martin, Livshits, and Lam, 2005.
• Defining a Set of Common Benchmarks for Web
  Application Security, Livshits, 2005.
• Reflection Analysis for Java, Livshits, Whaley
  and Lam, 2005.
• DynaMine Finding Common Error Patterns by
  Mining Software Revision Histories, Livshits and
  Zimmermann, 2005.
• Locating Matching Method Calls by Mining
  Revision History Data, Livshits and Zimmermann,
  2005.
• Turning Eclipse Against Itself Finding Bugs in
  Eclipse Code Using Lightweight Static Analysis,
  2005.
• Context-Sensitive Program Analysis as Database
  Queries, Lam, Whaley, Livshits, Martin, Avots,
  Carbin, Unkel, 2005.
• Improving Software Security with a C Pointer
  Analysis, Avots, Dalton, Livshits, M.S. Lam,
  2005.
• Findings Security Errors in Java Applications
  Using Lightweight Static Analysis, Livshits,
  2004.
• Tracking Pointers with Path and Context
  Sensitivity for Bug Detection in C Programs,
  Livshits and Lam, 2003.
• Mining Additions of Method Calls in ArgoUML,
  Zimmerman, Breu, Lindig, and Livshits, 2006.
