Title: Ballinger Independent School District


1
Ballinger Independent School District
Facilities Evaluation
2
  • FACT An undisputed fact is that any educational
    facility constructed prior to 2004 will not and
    cannot be in total compliance with all aspects of
    current building standards and codes.
  • What portions of building codes are meaningful
    when pertaining to the original given purpose of
    saving lives, property, and avoidance of hazards?
  • FACT The reality for the majority of building
    owners is that constantly maintaining buildings
    to comply with every change in building codes or
    design standards is not an available option, nor
    is it even possible.

3
  • Codes and Standards Used for Analysis
  • Texas Education Agency (TEA), Commissioners
    Rules on School Facilities, 61.1036, School
    Facilities Standards for Construction on or
    after January 1, 2004.
  • Texas Accessibility Standards (TAS), Revised
    March 31, 1999
  • International Building Code, Latest Published
    Edition
  • International Energy Code, Latest Published
    Edition
  • International Plumbing Code, Latest Published
    Edition
  • International Mechanical Code, Latest Published
    Edition
  • National Electrical Code, Latest Published Edition

4
  • Educational Standards
  • Classroom size / number of students for each
    defined function (e.g. PK-12)
  • Science lecture / lab size including minimum
    design standards
  • Library size as compared to the number of
    students served.

5
  • Elementary School

6
  • The Elementary School Buildings

Circa 1950, 18,875 S.F. Circa 1955, 33,191
S.F. Circa 1990, 4476 S.F. Circa 1995, 19,697 S.F.
7
  • Texas Education Standards

Existing instructional areas constructed prior to
1992 that have not had major space renovation on
or after that date are exempt from complying with
current school facility standards. The
elementary schools gymnasium, 1950 original
construction, 1955 addition, and the two 1990
addition are not required to meet minimum TEA
facility design standards. Both the 1995
classroom / cafeteria addition and 1997
renovation of the 1953 cafeteria building are
required to meet minimum TEA facility design
standards.
8
  • Texas Education Standards
  • Grades PK through 1 classrooms at 800 square feet
    (maximum 22 students _at_ 36sf/student).
  • Grades 2 through 5 classrooms at 700 square feet
    (maximum 22 students _at_ 32sf/student).
  • Science (elementary) classrooms at minimum 900
    square feet (41 s.f./student).
  • Computer (dedicated classroom) at minimum 900
    square feet 36 s.f./student for each computer
    station greater than 25
  • Library (all grade levels)
  • 101 to 500 students minimum 1,400 square feet
    4.0 sf for each student in excess of 100
  • 501 to 2,000 students minimum 3,000 square
    feet 3.0 sf for each student in excess of 500

9
  • Schedule of Existing Instructional Areas
  • Elementary Campus

10
(No Transcript)
11
(No Transcript)
12
  • Texas Education Standards
  • PK 30 students x 2 assigned classrooms 15
    students average/classroom (acceptable - maximum
    of 22 students allowed at present assigned
    classroom per TEA Standards).
  • K 70 students x 4 assigned classrooms 18
    students average/classroom (acceptable - maximum
    of 20 students allowed at present assigned
    classroom per TEA Standards).
  • 1st 70 students x 4 assigned classrooms 18
    students average/classroom (acceptable - maximum
    of 20 students allowed at present assigned
    classroom per TEA Standards).

13
  • Texas Education Standards
  • 2nd 88 students x 4 assigned classrooms 22
    students average/classroom (acceptable - maximum
    of 22 students allowed at present assigned
    classroom per TEA Standards).
  • 3rd 75 students x 5 assigned classrooms 15
    students average/classroom (acceptable - maximum
    of 22 students allowed at present assigned
    classroom per TEA Standards).
  • 4th 72 students x 4 assigned classrooms 18
    students average/classroom (acceptable - maximum
    of 20 students allowed at present assigned
    classroom per TEA Standards).
  • 5th 70 students x 4 assigned classrooms 18
    students average/classroom (acceptable - maximum
    of 20 students allowed at present assigned
    classroom per TEA Standards).

14
  • Question
  • Is the 1950 original construction, 1955 addition,
    and the 1990 additions short-term life-cycle or
    long-term life-cycle buildings?

Fact 85 of a buildings life-cycle costs are
operation and maintenance.
15
Short term life-cycle commitment to Gym, 1950,
1955, 1990 campus construction This does not
require any expenditure of funds or effort by
Ballinger I.S.D. and that is, to do nothing.
This is the easiest approach and should be
considered only if the commitment to implementing
improvements is taken with the attitude of doing
as little as possible to, "just get by."
16
Long term life-cycle commitment to Gym, 1950,
1955 campus construction Circa 1938 Campus
Construction gymnasium has some minor historical
value due to age, construction type, and material
utilized. It is in average condition for a
building of more than 70 years. Except for
minimum life safety and/or handicap compliance
that the District may identify as appropriate,
any additional capital improvement investments
should be thoroughly evaluated with historical
restoration being an option for consideration.
Circa 1950-1955 Campus Construction appears to
have structurally sound exterior building
envelopes consisting of foundation, walls, roof,
and structure. Significant and major renovation
can be justified with an expected additional
life-cycle of 20 to 25 years.
17
Long term life-cycle commitment to 1990 campus
construction Circa 1990 Campus Construction
additions structural components are of low
budget construction but acceptable. Due to roof
construction using light weight structural
framing at the north wing with a pour gypsum deck
system, future roof deflection is inevitable
causing water ponding and roof leaks. Except
for life safety and/or handicap compliance that
the District may identify as appropriate, any
additional capital improvement investments should
be carefully considered.
18
Life Safety (building code standards) 1. Provide
fully compliant fire alarm system to include
audible/visual flashers at each classroom,
corridor, and occupied space (library,
administration, nurse, janitor, etc.). 2. At
1950-1955 and 1990 construction, replace existing
corridor doors with 20 minute fire rated doors,
hardware, and frames. 3. At 1950-1955
construction, enclose open transom ventilation
windows at corridor side of classrooms with fire
rated construction. 4. At 1990 construction,
install 90 minute fire-rated doors and frames
with closers and panic hardware at intersection
with 1950-1955 construction. Direction of
travel for emergency egress and door opening
shall be into 1950-1955 construction. Existing
corridors at 1990 construction shall not be used
as means of emergency exit from 1950- 1955
construction unless corridor walls and door
openings at 1990 construction are replaced with
fire-rated assemblies.
19
Texas Education Agency Facility
Standards 5. Expand library to meet TEA
standards for 450 student elementary
campus. 6. Provide computer lab with minimum of
900 square feet including lighting, power, data
outlets, and cooling designed specifically for
computer applications. Could be included as a
part of the library expansion for accessibility
and utilization in conjunction with library
activities
20
Texas Accessibility Standards 7. Provide fully
compliant fire alarm system to include
audible/visual flashers at each classroom,
corridor, and occupied space (library,
administration). 8. Provide handicap
accessibility at gym, 1950, 1955 building
entrances and exits to include properly
designed ramps, landings, and hand railing. 9. At
1950-1955 construction, renovate existing student
gang restrooms to meet handicap standards. 10.
Renovation of individual classroom toilets at
1955 construction to meet current handicap
standards is not feasible in terms of cost or
more importantly, classroom space which is at a
premium in grade levels kindergarten through
first. Therefore, strong consideration should
be given to making existing room 138" a gang
toilet meeting the handicap standards for grade
levels K-2nd. 11. Provide handicap accessible
staff toilet(s) at 1950-1955 construction.
21
Design 12. The main entrance to the school is at
the 1955 construction and is undistinguishable
from other school entrances except the 1995
addition which overpowers all other entrances.
All schools should have a well defined main
entrance which visually directs the public where
to enter. Not only is a dominate main school
entrance convenient for the public, but also
offers enhance student security with all persons
entering at the schools administrative area.
13. Remove existing plywood covering at windows
and replace existing windows with new 1"
insulated glass window units 14. Provide
electrical power and technology upgrades at all
classrooms. An aesthetic solution to avoiding
exposed conduit is the construction of drywall
(metal studs with sheetrock) columns and/or
walls at conduit drops for power and technology
which will then provide a concealed and finished
appearance in the classroom. 15. Upgrade
existing vinyl wall covering and vinyl
composition tile flooring at Pre-K buildings
gang restrooms with ceramic tile. 16. Convert
existing classroom toilets at grade levels K-2
into teachers storage closets (i.e. remove and
cap existing plumbing fixtures).
22
Engineered Systems 17. Provide code
compliant disconnect for primary electrical
service at rooftop air conditioning equipment (2
locations thus) - - relocate disconnect from
rooftop to not more than 6'-7" above grade
level. Provide appropriate permanent plaque at
each disconnect location for primary electrical
service.
23
(No Transcript)
24
Estimated Cost for Elementary School
Improvements 1,290,000.00
25
Life Safety (320,000.00) 1. At 1950-1990
construction provide fully compliant fire alarm
system to include audible/visual flashers at
each classroom, corridor, and occupied space _at_
2.75/sf x 56,631sf 155,000.00 2. At
1950-1955 and 1990 construction, replace existing
corridor doors with 20 minute fire rated doors,
hardware, and frames, including minor repair of
existing wall _at_ 2,900.00/door x 50 doors
145,000.00. 3. At 1950-1955 construction,
enclose open transom ventilation windows at
corridor side of classrooms with fire rated
construction - - not including replacement of
existing ceilings ._at_ 10,000.00 4. Install 90
minute fire-rated doors and frames with closers
and panic hardware at intersection with
1950-1955 construction. Direction of travel for
emergency egress and door opening shall be into
1950-1955 construction - - including minor repair
of existing wall _at_ 10,000.00
26
Texas Education Agency Facility Standards
(435,000.00) 5. Expand library to meet TEA
standards for 450 student elementary campus
enrollment _at_ 380,000.00. 5.1 Library
shelving allowance to include circulation desk
and shelving _at_ 35,000.00. 5.2 Renovate
existing library (1,129sf) to include increasing
capacity of air condition, ceiling, lighting,
electrical, flooring, provide office/workroom,
etc., including HVAC _at_ 62.00/sf
70,000.00. 5.3 Expand existing library size
(1,672sf), elevated foundation, _at_ 165.00/sf
275,000.00. 6. Provide computer lab with
minimum of 900 square feet including lighting,
power, data outlets, and cooling designed
specifically for computer applications _at_
60.00/sf x 900sf 55,000.00.
27
Texas Accessibility Standards (170,000.00) 7. Pr
ovide fully compliant fire alarm system to
include audible/visual flashers at each
classroom, corridor, and occupied space
(library, administration) - - Refer to Item
Number 1. 8. Provide handicap accessibility at
gym, 1950, 1955 building entrances and exits to
include properly designed ramps slopes not
exceeding 1'-0" of ramp length for each 1" of
elevation change, landings, and hand railing _at_
30,000.00. 9. At 1950-1955 construction,
renovate existing student gang restrooms (4 thus)
to meet handicap standards _at_ 20,000.00. 9.1 Re
novation required for handicap compliance would
be minimal and limited to converting two
toilets into single stall, new stall, and new
lavatory - - add to renovate/refurbish
remainder of restrooms to include new fixtures,
stalls, finishes, etc. _at_ 70,000.00 (cost not
included in total estimated cost for general
handicap compliance - - included in optional
design work).
28
Texas Accessibility Standards (170,000.00),
continued 10. Renovation of existing classroom
138" (719sf) to a gang toilet meeting the
handicap standards for grade levels K-2nd
(contingent upon service available shown per
existing plans) _at_ 80,000.00. 11. Handicap
accessible staff toilet (2 thus) at 1950-1955
construction (additional handicap staff
toilets provided at PK buildings staff
workroom) to be located at existing office area
adjacent to ramp leading to 1995 construction
and existing office area adjacent to 1950
construction main entrance _at_ 40,000.00.
29
Design (350,000.00) 12. Provide new main
entrance to school is included within the scope
of new construction noted per Items 5.3 -
addition to library and 8 - handicap accessible
ramps. 13. Provide new 1" insulated tempered
glass window units (4,575 sf new glazing) _at_
160,000.00. 14. Provide electrical power and
technology upgrades at all classrooms, not
including Owner furnished and installed data
wiring (24,416sf), _at_ 160,000.00. 15. Upgrade
floor and wall finishes at PK gang toilets to
ceramic tile _at_ 10,000.00. 16. Convert existing
classroom toilets at grade levels K-2(14thus)
into teachers storage closets, remove and cap
existing plumbing fixtures, paint walls, new
flooring _at_ 20,000.00.
30
Engineered Systems (15,000.00) 17. Upgrade
electrical service for new additions and/or
modification of existing electrical work,
relocated primary electrical service disconnects
from rooftop, permanent signage at each
electrical service disconnect indicating
locations of other service disconnects (lump sum
amount) _at_ 15,000.00. Note without additional
detailed engineering study, most likely the cost
for adding additional electrical capacity to the
system for upgrades or building expansion will
not be necessary due to the excess service that
is probably available when the air conditioning
system was converted from electric heat pump
with supplementary resistant heating to gas.
31
Estimated Costs for Optional Elementary School
Improvements 1. Replace and/or provide grade
level K-5 classrooms casework at 24 lineal feet
per room x 24 rooms _at_ 130,000.00. 2. Provide
new double tier lockers at 12 double tier units
per room (locate at corridor or classroom) x 24
rooms _at_ 50,000.00. 3. Replace existing corridor
and classroom flooring with combination of
carpeting and/or vinyl composition tile with
accent pattern at tile (36,203sf) _at_
75,000.00. 4. Renovate/refurbish existing gang
restrooms at 1950 construction, beyond scope of
minimum handicap compliance, to include new
fixtures, stalls, finishes, etc. _at_
70,000.00. 5. Update wall finishes at 1950-1955
corridor construction to include 4'x8' tack
boards (1 at each classroom entrance x 25 thus
7,800.00), painting at concrete block above
wainscoting (19,500sf 36,000.00), and
continuous tack strip with metal trim at top of
glazed tile corridor wainscoting (75 of total
l.f. of corridor x 3,250lf 8,525.00) _at_
50,000.00. 6. Replace 1950's era electrical
panels and switchboards _at_ 150,000.00.
32
Estimated Cost for Optional Elementary School
Improvements at the 1950-1955 Construction 525,0
00.00
33
  • Junior and Senior High School

34
  • The Junior and Senior High School Buildings

Circa 1971, 90,805 S.F. Circa 1991, 76,505 S.F.
35
  • Schedule of Existing Instructional Areas
  • Junior Senior High Campus

36
SCHEDULE of EXISTING INSTRUCTIONAL AREAS JUNIOR
- SENIOR HIGH CAMPUS
37
SCHEDULE of EXISTING INSTRUCTIONAL AREAS JUNIOR
- SENIOR HIGH CAMPUS
38
Foundation There did not appear to be any visual
evidence of foundation settlement or failure at
any of the campus structures completed between
1971 and 1991. However, some masonry movement at
the exterior along the north walls of Classrooms
235-238" was observed as shown in the photographs
below.
There does not appear to be an visual evidence of
structural failure at any of the observed campus
load bearing walls or roof structures.
Outside corner of classroom showing corner of
brick veneer missing, bottom corner.
Roof drain downspout termination and missing
masonry grout at classroom 238.
Outside corner of classroom 245 showing masonry
cracks below camera.
39
Mechanical The original 1971 construction and
the 1990 addition to the Junior - Senior High
School campus utilized packaged rooftop units
equipped with gas heating and DX cooling. In the
original 1971 building, the classroom areas were
served with multi-zone packaged rooftop units
with a common return air system at the corridor
utilizing an oversized return air grille at each
classroom corridor door (except at science labs
where return air is not transferred into the
corridor). This 1970's air conditioning design
using multi-zone HVAC units allowed for three to
four classrooms to be conditioned by supply air
ducts connected to a single packaged rooftop
unit. In the early 1990's the multi-zone type
units were replaced with single zone packaged
rooftop units for each individual classroom which
were then connected to the original air
conditioning supply ductwork. As a cost saving
measure, in lieu of new direct ducted return air
to each classrooms HVAC unit, the common return
air system into the corridor was maintained
through grilles located adjacent to each
classroom door.
40
Although there are deficiencies in both the 1971
and 1991 construction, the cost for correcting
these items will be a small percentage of the
cost for comparable new replacement construction.
Significant and major renovation can be
justified with an expected additional life-cycle
of 30 to 35 years. If implemented by Ballinger
I.S.D., the resulting Junior-Senior High School
Campus will be very close in many areas to the
equivalent of new construction at a fraction of
the cost. Comments and considerations
presented will be directed to achieving
modernization of the existing Junior-Senior High
School building to the greatest extent possible
to meet current building codes, educational
standards, handicap compliance, and functional
needs.
41
Life Safety (building code standards) 1. Junior
and Senior High Provide fully compliant fire
alarm system to include audible/visual flashers
at each classroom, corridor, and occupied space
(library, administration, janitor). 2. Senior
High Delete classroom return air grilles
located adjacent to each corridor leading into
classroom to prevent the transfer of smoke from
HVAC units into or out of a classroom during a
fire. 3. Senior High Provide fire-rated egress
system comprised of either a one hour fire-rated
corridor system (including replacement of
existing corridor doors with 20 minute
fire- rated doors, frames, and hardware) or an
automatic fire sprinkler system (does not
require new doors and frames) depending on least
expensive method of fire-protection.
42
Life Safety (building code standards),
continued 4. Junior and Senior High Remove
and/or encapsulate plywood panels used as finish
wall material at corridors due to potential
issues with flame spread rating and/or smoke
contribution. 5. Senior High Provide secondary
means of egress from Chemistry Lab 139" to
protected exit - - exit through adjoining
classroom is not acceptable. 6. Senior High
Provide fire-rated walls at each science lab and
ancillary science room.
43
  • Texas Education Agency Facility Standards
  • Junior High Provide computer labs of 900 square
    feet (reference Classrooms 205" and 207").
  • Texas Accessibility Standards
  • 8. Junior and Senior High Provide fully
    compliant fire alarm system to include
    audible/visual flashers at each classroom,
    corridor, and occupied space (library,
    administration, janitor).
  • 9. Junior and Senior High Provide handicap
    accessibility at building entrances, exits, and
    essential features (e.g. cafeteria) required
    for fire egress to include properly designed
    ramps, landings, and hand railing.
  • 10. Senior High Provide handicap accessible
    ramps to Visitors seating at competition
    gymnasium.
  • 11. Senior High Renovate student gang
    restrooms, including athletic dressing areas, to
    meet handicap standards.
  • 12. Junior High Renovate athletic dressing
    areas, to meet handicap standards.
  • 13. Junior and Senior High Provide handicap
    accessible staff toilets.

44
Recommended Design 14. Senior High Redesign
student commons with gang lockers to eliminate
congestion occurring at lockers between classes
- - install existing new lockers at one side only
of existing high school corridors. Provide
minimum 275 (current total is 290) single tier
lockers (12" wide x 12" deep x 60" high) in lieu
of 340 existing 12" wide x 12" deep x 30" high
(double stacked) lockers. Arrange lockers to
facilitate separate 9th, 10th, 11th, and 12th
grade locker areas. 15. Senior High Provide
additional classrooms at existing student commons
area with gang lockers. 16. Senior High Modify
existing male and female restrooms serving
auditorium (and cafeteria) to accommodate an
auditorium occupancy of 700 9 fixtures at
female (current 3) and 5 fixtures at male
(current 4).
45
Engineered Systems and Design Options 17. Senior
High Correct storm water drainage ponding at
elevated area between main high school entrance
and competition gymnasium entrance (reference
Images 1 and 2, page 43). 18. Senior High
Correct areas where brick ledge is improperly
sized to provide adequate support of brick
veneer (reference Image 1, page 42). 19. Senior
High Repoint masonry veneer and replace damaged
brick where noted (reference Image 2, page
42). 20. Senior High Upgrade main entrance
(lobby area adjacent to auditoriums foyer) to
include auditorium entrance from vestibule,
remove existing wood ceiling construction at
foyer, new flooring over exposed aggregate
concrete at vestibule area, etc. 21. Senior
High Develop area for male coaching staff at
athletic dressing area - - use existing storage
(former weight room). Include separate toilet,
dressing, and shower. Accommodate 6-8
staff. 22. Senior High Provide office for
Athletic Director/Head Coach at athletic dressing
area.
46
Engineered Systems and Design Options
continued 23. Junior High Provide accessible
restroom with shower at life skills class
(reference room 209) 24. Junior High Provide
single tier lockers to accommodate student
backpacks in lieu of smaller double tier
lockers 25. Senior High Replace existing
backstage curtains. 26. Junior and Senior High
Provide ceramic wall tile x 7'-2" high (painted
gypsum board above) at new corridor wall or
corridor wall veneer. 27. Junior High Provide
handicap accessible restroom with handicap shower
at life skills classroom. 28. Senior High
Reconfigure administration area for more
functional arrangement. 29. Senior High Replace
existing suspended asbestos ceiling tile - -
note existing ceiling tile is not a hazard
unless material becomes friable. 30. Senior
High Provide elevated and fixed stadium
seating at visitor side of varsity gymnasium.
47
(No Transcript)
48
Estimated Costs for Recommended Junior Senior
High School Improvements 1,390,000.00
49
Life Safety (740,000.00) 1. Junior and Senior
High Provide fully compliant fire alarm system
to include audible/visual flashers at each
classroom, corridor, and occupied space, exposed
low voltage wiring above existing ceilings,
conduit only at walls and exposed locations _at_
2.25/sf x 167,310 sf 375,000.00. 2. Senior
High Delete classroom return air grilles
located adjacent to each corridor leading into
classroom to prevent the transfer of smoke from
HVAC units into or out of a classroom during a
fire - - will require providing each classroom
with ducted return air system to HVAC unit _at_
2,750.00/classroom x 19 locations 55,000.00
new ceiling panels at existing corridors due to
HVAC ductwork construction _at_ 1.75/sf x 8,000sf
14,000.00 70,000.00. 3. Senior High
Provide one hour fire-rated corridor system, 3?
metal studs, painted gypsum board, continuous
wall bumper system x 2 rows, encapsulate existing
plywood paneling, replace existing corridor
doors with 20 minute fire-rated doors, frames,
and hardware _at_ 81.50/lf new corridor wall x
1,316lf 110,000.00 36 fire-rated replacement
doors and frames _at_ 2,900.00 each x 36
105,000.00 215,000.00.
50
Life Safety (740,000.00), continued 4. Junior
and Senior High Remove and/or encapsulate
plywood panels used as finish wall material at
corridors due to potential issues with flame
spread rating and/or smoke contribution. Cost
at senior high included in Item 3. At junior
high, attach new painted gypsum board to direct
to existing plywood paneling and continue to
bottom of existing ceiling, continuous wall
bumper system x 2 rows _at_ 45.25/lf x 1,082lf
50,000.00. 5. Senior High Provide secondary
means of egress from Chemistry Lab 139" to
protected exit _at_ 5,000.00. 6. Senior High
Provide fire-rated walls at each science lab and
ancillary science room, extend existing wall to
roof deck with gypsum board each side, tape and
bed _at_ 42.00/lf x 249lf 10,000.00.
51
Texas Education Agency Facility Standards
(0.00) 7. Junior High In lieu of new computer
labs at 900 square feet (reference Classrooms
205" and 207"), maintain existing computer
classrooms with a maximum of 19 stations each
per TEA Standards _at_ 0.00.
52
Texas Accessibility Standards (220,000.00) 8. Ju
nior and Senior High Provide fully compliant
fire alarm system to include audible/visual
flashers at each classroom, corridor, and
occupied space (library, administration, janitor)
- - Refer to Item Number 1. 9. Junior and
Senior High Provide handicap accessibility at
building entrances, exits, and essential
features (e.g. cafeteria) required for fire
egress to include properly designed ramps,
landings, and hand railing _at_ 15,000.00. 10. Senio
r High Provide handicap accessible ramps to
Visitors seating at competition gymnasium _at_
205.00/sf x 370sf 75,000.00.
53
Texas Accessibility Standards (220,000.00) 11. S
enior High Renovate student gang restrooms,
including restrooms at athletic dressing areas,
to meet handicap standards _at_ 5,000.00 each x 8
locations 40,000.00. 11.1 Renovation
required for handicap compliance would be minimal
and limited to converting two toilets (or one
toilet and one urinal) into single stall, new
stall, and new lavatory. 11.2 At
athletic dressing areas, handicap compliance at
toilets will require the reconfiguration of
existing toilets (plumbing lines) located in
concrete block alcoves x 3
locations. 11.3 At male athletic dressing
areas, relocation of toilets for handicap
compliance will result in the partial or
total elimination of adjacent urinals. 12.
Junior High Renovate athletic dressing areas,
to meet handicap standards _at_ 5,000.00 each x 3
locations 15,000.00. 12.1 Renovation
required for handicap compliance would be minimal
and limited to converting two toilets (or one
toilet and one urinal) into single stall, new
stall, and new lavatory. 13. Junior and
Senior High Provide handicap accessible staff
toilets for male and female (4 thus) _at_
80,000.00.
54
Design (405,000.00), continued 14. Senior High
Provide minimum 275 single tier lockers _at_
125.00 each, including continuous base x 275
35,000.00. 15. Senior High Provide additional
classrooms at existing student locker area,
including individual air conditioning units,
lighting, electrical, ceilings, door/frame,
fire-rated walls at corridor, fire alarm, etc. _at_
50.00/sf x 4,913sf (less 1,537sf at corridor)
250,000.00 corridor including ceiling,
lighting, flooring (except at existing terrazzo
floors) _at_ 25.00/sf x 1,537sf 40,000.00
290,000.00. 16. Senior High Modify existing
male and female restrooms serving auditorium (and
cafeteria) to accommodate an auditorium
occupancy of 700 9 fixtures at female and 5
fixtures at male (713sf) 80,000.00.
55
Engineered Systems (20,000.00) 17. Senior High
Provide concrete slab with decorative scoring x
10'-0" (minimum) out from face of building to
provide positive storm water drainage where water
ponding occurs at elevated area between main
high school entrance and competition gymnasium
entrance (reference Images 1 and 2, page 43),
extend concrete below existing brick veneer where
brick ledge is not providing full support of
brick veneer _at_ 7.50/sf x 2,500sf
15,000.00. 18. Senior High Correct areas
where brick ledge is improperly sized to provide
adequate support of brick veneer (reference
Image 1, page 42) - - refer Item 17. 19. Senior
High Repoint masonry veneer and replace damaged
brick where noted (reference Image 2, page 42)
5,000.00.
56
Estimated Costs for Optional Junior-Senior High
School Improvements (690,000.00) 20. Senior
High Upgrade main entrance (lobby area adjacent
to auditoriums foyer) to include auditorium
entrance from vestibule, remove existing wood
ceiling construction at foyer, new flooring over
exposed aggregate concrete at vestibule area,
etc. _at_ 30.00/sf x 1,205sf 35,000.00. 21. Seni
or High Develop area for 6-8 male coaching
staff at athletic dressing area - - use
existing storage (existing female weight room)
including toilet, dressing, shower, built-in
desks, overhead cabinets, storage cabinets _at_
50.00/sf x 1,150sf 60,000.00 25,000.00
toilet and shower (125sf) 85,000.00. 22. Senior
High Provide office for Athletic Director/Head
Coach at athletic dressing area - - space to
classified as existing function, renovation for
handicap compliance at dressing not necessary
0.00. 23. Junior High Provide accessible
restroom with shower at life skills class
(reference room 209) 25,000.00.
57
Estimated Costs for Optional Junior-Senior High
School Improvements (690,000.00),
continued 24. Junior High Remove existing
double tier lockers and elevated bench seat in
front of lockers and provide single tier lockers
to accommodate student backpacks _at_ 125.00 each,
including continuous base x 264
35,000.00. 25. Senior High Replace existing
backstage masking curtains including traveling
leg, wing, and borders _at_ 65.00/sy x 435 sy
30,000.00. 26. Junior and Senior High Provide
ceramic wall tile x 7'-2" high (painted gypsum
board above) at new corridor wall or corridor
wall veneer, including premium color accent band
x 3 rows _at_ 6.85/sf x 7'-2" 49.11/lf x
2,398lf 120,000.00. 27. Junior High Provide
handicap toilet and shower at life skills
classroom _at_ 25,000.00.
58
Estimated Costs for Optional Junior-Senior High
School Improvements (690,000.00),
continued 28. Senior High Reconfigure
administration area to address current staffing
and functional requirements _at_ 65.00/sf x
1,850sf 120,000.00. 29. Senior High Replace
existing suspended asbestos ceiling tile at
original construction (note existing ceiling
tile is not a hazard unless material becomes
friable or disturbed) including
abatement/disposal of existing tile, new 6" batt
insulation above tile, 2'-0" x 4'-0", use
existing grid, 10 year sag warranty for ceiling
tile _at_ 4.25/sf x 50,636sf 215,000.00.
30. Senior High Provide elevated and fixed
stadium seating at visitor side of varsity
gymnasium is not a consideration due to a
maximum of 150 fixed seats at existing seating
area (reduction of 50 seats) and an estimated
cost exceeding 2,000.00/seat.
59
It is apparent that the approach used by
Ballinger I.S.D. in the past is to place a
priority upon the quality of facilities beginning
with the 1950 elementary building.
Summary of Costs
1. Life safety upgrades _at_ 1,060,000.00. 2. Handic
ap accessibility _at_ 390,000.00. 3. Texas
Education Agency Facility Standards _at_
435,000.00. 4. Engineered systems _at_
35,000.00. 5. Recommended facility functional
design improvements _at_ 755,000.00. 6. Optional
facility aesthetics design improvements _at_
1,215,000.00.
Estimated Cost of All Items 3,890,000.00
60
Ballinger Independent School District
Facilities Evaluation
61
CADCO Architects - Engineers, Inc., especially
wishes to thank Mr. Scot Goen, Superintendent and
the Districts staff for their cooperation and to
all who assisted CADCO with this Master Plan
Study. Furthermore, the Districts Board of
Trustees should be commended for their
commissioning of this Master Plan Study
indicating their commitment to ensure that
students of Ballinger I.S.D. will continue to
have quality educational facilities into the
future.
Write a Comment
User Comments (0)
About PowerShow.com
