Case Presentations

1
Case Presentations

• Ermos Nicolaou
• Fetal Medicine Centre
• C H Baragwanath Hospital

2
Case 1

• Mrs S B A
• 32 year old patient, P1G2
• LNMP 22/10/2003
• Triple Trimester Screening AFP 2 MOM ( screen
  positive for NTD)
• Repeat AFP 1 week later confirms result
• Referred to FMC

3

• On scan
• Normal growth, Gest age 17 w 5d
• Male fetus
• Lemon sign
• Prominent posterior ventricles
• Spine

4
Head and Brain
5
(No Transcript)
6
(No Transcript)
7
(No Transcript)
8
(No Transcript)
9
NEURAL TUBE DEFECTS- Discussion

• These include
• Anencephaly
• Spina bifida
• Encephalocoele
• In anencephaly there is absence of the cranial
  vault  (acrania) with secondary degeneration of
  the brain
• Encephaloceles are cranial defects, usually
  occipital, with herniated fluid-filled or
  brain-filled cysts

10
NEURAL TUBE DEFECTS Spina Bifida

• In spina bifida the neural arch, usually in the
  lumbosacral region, is incomplete with secondary
  damage to the exposed nerves

11
Spina Bifida Prevalence

• Subject to large geographical and temporal
  variations
• In the UK the prevalence is about 5 per 1,000
  births
• Anencephaly and spina bifida, with an
  approximately equal prevalence, account for 95
  of the cases and encephalocele for the remaining
  5

12
Spina Bifida - etiology

• Chromosomal abnormalities,
• single mutant genes,
• maternal diabetes mellitus
• ingestion of teratogens, such as antiepileptic
  drugs, are implicated in about 10 of the cases
• precise etiology for the majority of these
  defects is unknown

13
Spina Bifida -Prevalence

• When a parent or previous sibling has had a
  neural tube defect, the risk of recurrence is
  5-10.
• Periconceptual supplementation of the maternal
  diet with folate ( 5mg daily) reduces the risk
  of developing these defects by about 50

14
Spina bifida

• Diagnosis of spina bifida requires the systematic
  examination of each neural arch from the cervical
  to the sacral region both transversely and
  longitudinally
• In the transverse scan the normal neural arch
  appears as a closed circle with an intact skin
  covering, whereas in spina bifida the arch is "U"
  shaped and there is an associated bulging
  meningocoele (thin-walled cyst) or
  myelomeningocoele

15
Spina bifida
16
Spina bifida

• The diagnosis of spina bifida has been greatly
  enhanced by the recognition of associated
  abnormalities in the skull and brain
• secondary to the Arnold-Chiari malformation and
  include frontal bone scalloping (lemon sign), and
  obliteration of the cisterna magna with either an
  "absent" cerebellum or abnormal anterior
  curvature of the cerebellar hemispheres (banana
  sign).

17
NEURAL TUBE DEFECTSSpina bifida
18
NEURAL TUBE DEFECTSSpina bifida
19
NEURAL TUBE DEFECTSSpina bifida

• A variable degree of ventricular enlargement is
  present in virtually all cases of open spina
  bifida at birth, but in only about 70 of cases
  in the midtrimester

20
Prenatal Diagnosis

• elevated maternal serum alpha-feto-protein (AFP)
• level II ultrasound
• amniocentesis - elevated AFP and
  acetylcholinesterase

21
MANAGEMENT

• 1. Surgery
• There is some experimental evidence that in-utero
  closure of spina bifida may reduce the risk of
  handicap because the amniotic fluid in the third
  trimester is thought to be neurotoxic
• 2. Supportive
• for complications
• physiotherapy
• anticonvulsants
• ophthalmology follow-up

22
Prognosis

• In spina bifida the surviving infants are often
  severely handicapped, with paralysis in the lower
  limbs and double incontinence
• In male fetuses there may be sexual dysfunction.
• Despite the associated hydrocephalus requiring
  surgery, intelligence may be normal

23

• Parents are undecided regarding the way forward.
• Possibly opt for TOP

24
Case No 2

• Mrs T L B
• 26 year old patient P2 G3
• Presenting at 34 weeks with an intrabdominal
  solid- cystic mass
• So far the pregnancy was uneventful

25
Scan

• Normal growth
• Normal amniotic fluid
• Normal liver, stomach, spleen, kidneys, bladder
• GIT appears normal
• Female fetus

26
34 weeks
27
(No Transcript)
28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
Management

• Due to advanced gest age and EFW of 2.5Kg no
  invasive testing was done
• DD
• Ovarian cyst/ haemorrhagic cyst/ torsion/dermoid
  cyst (unlikely)
• GIT related mass (meconium pseudocyst)
• MRI performed 1 week later
• Strong suspicion of Ovarian pathology

32
Fetal ovarian cysts

• Definition
• Fetal ovarian cysts represent cystic lesions
  confined to the lower abdomen of a female fetus,
  when the stomach, bladder and both kidneys appear
  normal.
• The diagnosis is made by exclusion of other
  cystic lesions of fetal abdomen. The cysts may
  achieve a considerable size, reaching up to 5 cm
  for large cysts.
• The cysts can be unilateral or bilateral,
  unilocular or multilocular

33
Etiology

• There is controversy with respect to the cause of
  these cysts.
• ? excessive stimulation of the fetal ovary by hCG
  from the placenta may be a significant factor in
  cyst formation.

34
Ultrasound features

• These criteria are diagnostic of fetal ovarian
  cysts in most cases
• 1. Presence of a cystic structure that is
  regular in shape and located at one side of the
  fetal abdomen.
• 2. Integrity of the urinary and gastrointestinal
  tracts.
• 3. Female sex of the fetus.
• The diagnosis is always presumptive.
• Torsion can be suspected when  intracystic
  flocculation is observed followed by
  sedimentation on the sloping part of the cyst.

• Most cases of fetal ovarian cysts are diagnosed
  in late second trimester of pregnancy or in early
  third trimester.

35
Prognosis

• Continuous ultrasound monitoring of antenatally
  diagnosed fetal ovarian cysts is recommended.
• The tendency of simple cysts to regress near term
  or in the early neonatal period does not justify
  in-utero therapy.
• In cases where fetal ovarian cysts show evidence
  of in-utero torsion, induction of labor may be
  considered provided lung maturity has been
  established.

36
Case No 3

• Ms C B
• 23 year old patient
• P0G1, presenting at 24 weeks for ? IUGR
• On scan No IUGR
• But Prominent Gallbladder in the fetus
• Otherwise normal scan with normal growth

37
25w
38

• Patient went to Jhb Gen Hospital
• Referred back to C H B with ? Gall bladder
  pathology

39
36w
40
(No Transcript)
41
(No Transcript)
42
Discussion

• Whether all echogenic foci in the fetal
  gallbladder represent true gallstones remains
  unknown.
• Echogenic foci are usually seen in the fetal
  gallbladder during the third trimester.
• No predisposing fetal risk factors or clinical
  sequelae are usually evidemt.
• Many echogenic foci, but not all, will resolve.

43
Discussion

• Series of 26 fetuses (Brown D L et al, Radiology,
  182 (1)73-6)
• The echogenic foci were associated with
• distal shadowing in eight fetuses (30),
• comet-tail artifact in nine (35),
• and no distal artifact in nine (35).

44
Discussion

• Postnatal sonographic or pathologic follow-up
  studies were available in 17 cases.
• In nine of these 17 infants, the echogenic foci
  had resolved.
• In three, the foci have persisted, but none of
  the children have become symptomatic
• the longest period of follow-up with stones still
  present is
• 4 1/2 years
