Grid Security and VO Management

1
Grid Security andVO Management

• Andrew McNab
• University of Manchester

2
Outline

• Defining VOs
• VO Pull vs Push
• Pool Accounts
• VOMS
• GridSite components
• Web service support
• VO practicalities

13 December 2005
Grid Security
3
Perspective

• GridPP is the UK's High Energy Physics grid
  project
• 15 university sites RAL
• largest is a 2000 processor farm at Manchester
• Participates in deployment of LHC Computing Grid
• 160 sites worldside, led by CERN
• Contributes to EGEE middleware development
• info system, data management and security
• I co-ordinate the GridPP security middleware work
• this is principally the GridSite system

13 December 2005
Grid Security
4
(No Transcript)
5
Virtual Organisations

• Within LCG/EGEE, VOs are essentially
  authorization domains
• access rights to resources and datasets owned by
  a group of people
• So the central VO problem becomes how to prove
  individuals are members of that VO, subgroup etc
• There are two classic ways of doing this
• Pull and Push

13 December 2005
Grid Security
6
VO by Pull

• EU DataGrid developed a way of publishing lists
  of VO members
• Authentication based on X.509 DNs ie VO DN
  List
• LDAP(S) used, but can also be done by HTTPS
• Sites subscribe to VO lists and pull them
  periodically
• daily or every few hours
• Advantage is that user's software doesn't need to
  know
• Disadvantage is that hundreds of service machines
  need to pull lists of thousands of users several
  times a day

13 December 2005
Grid Security
7
Pool accounts

• The other half of the EU DataGrid system was Pool
  Accounts, developed in Manchester
• Unix accounts created and assigned to users as
  they submit jobs, access files on that site.
• Local copy of VO membership list decides whether
  a mapping can be created
• May direct user to a special pool of accounts for
  their VO
• Now used by LCG and UK NGS
• Surprisingly successful for a temporary fix!

13 December 2005
Grid Security
8
VO by push

• LCG and EGEE are now deploying VOMS
• Users are given short-lived X.509 Attribute
  Certificates which prove their VO and group
  membership
• Users then present these ACs to services,
  currently in the form of extensions to GSI Proxy
  certificates
• Advantages no need for sites to pull all VO
  lists users can choose which group/role to use.
• Disadvantages clients need to be aware of VOMS
  need to add X.509 AC support to services' SSL/TLS.

13 December 2005
Grid Security
9
Access Policies

• DN Lists (eg grid-mapfile) are simplest access
  policies
• LCG/EGEE also uses references to VOMS groups, and
  XML policy files both GridSite's GACL and XAMCL
• GridSite GACL/XACML policy files support
• multiple credential types individual DN, DN
  List, VOMS AC and DNS domain
• AND OR of conditions
• Read, List, Write, Exec, Admin permissions
• Allows virtualisation of access not just tied
  to a (pool) unix account, and easy to dynamically
  manage

13 December 2005
Grid Security
10
GridSite components

• libgridsite C/C toolkit provides utility
  functions
• based on OpenSSL, libxml2, gSOAP
• parse GSI Proxies and VOMS X.509 attribute certs
• evaluate GACL and XACML access policies
• generate new GSI Proxies
• mod_gridsite adds support for GSI Proxies, VOMS
  attributes, DN List groups, GACL/XAMCL policies
  and Onetime Passcodes to Apache
• htcp, htls, htdelegate, ... provide command line
  tools

13 December 2005
Grid Security
11
Module architecture
13 December 2005
Grid Security
12
Web Service support

• GridSite architecture can provide security for
  Web Service tools like gSOAP, with CGI Web
  Services
• We also provide the C/C implementation of the
  GridSite / EGEE Delegation portType
• Java implementation by other members of EGEE
• mod_gridsite delegation CGI used by EGEE WMS
• Apache/FastCGI GridSite (security) gSOAP (WS)
• Delegated credentials stored in the filesystem
• Allows sharing between different CGI languages

13 December 2005
Grid Security
13
suexec and gsexec

• Apache has traditionally provided a wrapper to
  run CGIs as other Unix users
• Start as root, process as apache, CGI as joeuser
• We've modified this to run CGI scripts and
  services as pool Unix users, similar to LCG/EGEE
  and NGS
• Either per-client the cert in the client program
  determines which pool user
• Or per-directory all the CGIs in my directory
  run as the same pool user

13 Decmber 2005
Grid Security
14
suexec / gsexec (2)

• This allows us to sandbox CGI-based services by
  ensuring that the pool users are of sufficiently
  low privilege
• Different clients or service owners can't
  interfere with each other
• Access control is still via GACL/XACML policy
  files
• X.509, GSI Proxy, VOMS, DN List credentials
• We can now offer third-party service hosting
• Give a user or VO access to a privileged
  directory
• They deploy their C/C/Perl/Python services
  remotely

13 December 2005
Grid Security
15
GRACE

• In adding support for Web Services to GridSite,
  we started to offer non-Java ways of building
  service-orientated grids
• This provides another way of deploying Web
  Services
• GRACE GRidsite - Apache - CGI Executables
• Allows services to be written in any language
• Can be deployed remotely
• Deployment rights controlled by GACL/XACML
  policies
• Different VOs/individuals are sandboxed via Unix
  UIDs

13 December 2005
Grid Security
16
Deployment Issues

• Panel question How can we deploy a Grid
  security infrastructure that is scalable,
  hierarchical, capable of dynamic VOs and easy to
  use?
• I think that practical Grid infrastructures will
  follow most of the established patterns of
  practical Web infrastructures
• Many lessons already learnt on the Web
• Also, users/admins are already familiar with the
  Web
• Key lession is to be as loosely-coupled as
  possible
• Use clearly defined interfaces and avoid
  reinvention

13 December 2005
Grid Security
17
Software Issues

• Most significant security issue for existing
  internet services is patching vulnerabilities
• Keeping up to date has resulted in automated
  update services for major operating systems
• The more you deviate from off-the-shelf software,
  the more of this you have to do yourself for your
  users
• So want to reuse Apache, OpenSSL etc as much as
  possible, ideally without making own versions, to
  benefit from OS updates

13 December 2005
Grid Security
18
Authentication

• This is largely dealt with by the CAs, and the
  international CA co-ordination bodies (EUgridPMA
  and now the IGTF)
• However, users are very aware of authentication
  (I forgot my password! etc) and so it has a
  large impact on ease of use of the whole system
• Can already use X.509 certs in browsers as simple
  single-signon to HTTPS websites (GridSite,
  GridSiteWiki etc)
• But X.509 handling is itself cumbersome for some
  users
• May need to go to online CAs, merging CAs and
  university Shibboleth infrastructures etc

13 December 2005
Grid Security
19
Authorization

• Creation of VOs, subgroups, roles etc
• assigning users to these groups/roles
• binding credentials to resources, dataset rights
  etc
• Scalability drives design decisions
• Can't keep asking VO if a local operation is
  permitted
• Pull and Push models already cover most use cases
• Dynamic VOs are a natural extension of current
  systems
• Static CA infrastructure means trust can be
  described by dynamic policies in terms of
  certificate identities

13 December 2005
Grid Security
20
Local enforcement

• Can easily be the Cinderella of a grid security
  architecture
• easy to implement shiny new authorization systems
  in purely Grid software that your project is
  creating
• but what about file access, SQL database queries,
  execution of native binaries?
• Either use virtual machines (Java etc)
• Or map grid identity to local identity (Unix pool
  account, MySQL user etc) and then grant it rights
  derived from grid policies
• Getting this right has significant performance
  advantages

13 December 2005
Grid Security
21
More information

• www.gridsite.org is the GridSite project
  website
• Open Source, bug tracker, CVS, links to LCG/EGEE
• Includes the new GridSiteWiki
• Derived from MediaWiki but uses X.509 instead of
  usernames / passwords
• www.gridpp.ac.uk is the largest site using
  GridSite
• and includes it's own Wiki, which is pulling in
  info
• You can also find GridSites at NGS, GOC, CERN,
  LCG, TCD.IE, ... by searching for GridSite with
  Google!

13 December 2005
Grid Security
22
Summary

• LCG/EGEE have deployed multiple VOs to 160 sites
  using Pull, and are moving to Push via VOMS
• Pool accounts allow a simple way of using Unix
  accounts
• Access policies tie VOs Authorization to
  resources
• GridSite provides libgridsite Grid security
  toolkit for C/C
• mod_gridsite adds support for GSI Proxies, VOMS,
  GACL, XAMCL, and HTTP PUT,MOVE,DELETE to Apache
• We can now build secured Web Services for Grids
  as CGI programs

13 December 2005
