USB 2.0 Test Modesand Their Application

• Jon LuekerIntel Corporation

3
Link Integrity Strategy

• Define necessary and sufficient set of
  specifications for cables, upstream-facingports,
  and downstream-facing ports
• Define reproducible tests which allow testingof
  each element in isolation
• Define required test modes which allow teststo
  be performed with standardized equipmentand
  techniques

4
Specifications for aHigh-Speed Transmitter

• Source impedance
• Clock frequency
• DC Levels into reference load
• Transmit eye pattern into reference load
• At pins of transceiver (guideline)
• At USB receptacle (if no captive cable)
• At end of cable (if cable is captive)
• Minimum allowable rise/fall time

5
Specifications for aHigh-Speed Receiver

• DC termination voltage and resistance
• Squelch threshold level
• Disconnect threshold level
• TDR (AC loading) limits
• Worst case eye patterns which mustbe recoverable
• At pins of transceiver (guideline)
• At USB receptacle (if no captive cable)
• At end of cable (if cable is captive)

6
Specifications for USB Cable

• Maximum length and delay per meter(delay spec
  added in USB 1.1 ECN)
• Differential and common mode impedance (common
  mode spec added in ECN)
• Skew (tightened to 100 ps from 400 ps in ECN)
• Maximum allowable loss (added 200MHzand 400MHz
  points in ECN)

USB 1.1 cable specification was updated in
November, 1999, to guarantee specs which were
being met typically
7
Test Modes

• High-speed capable devices/hubs must support test
  modes
• Test modes enable repeatable testing
• SetFeature(TEST_MODE) and SetPortFeature(PORT_TEST
  ) requests provide standard means of entering
  mode
• Exit action is also standardized
• Upstream facing port power cycle
• Downstream facing port hub reset

8
Test Mode Test_SE0_NAK

• Port enters and remains in the high-speedidle
  state
• Regular actions, such as suspending,are
  inhibited
• Upstream-facing ports must respond to anyIN
  token packet with a NAK handshake(if CRC is
  correct)

Allows Testing of Output Impedance (AC and DC),
Termination Voltage, and Receiver Sensitivity
9
Test Modes Test_Jand Test_K

• Port enters and remains in the high-speedJ or K
  state
• Regular actions, such as suspending,are inhibited

Allows Testing of Output Voltage and Output
Impedance When Each Output Is High or Low
10
Test Mode Test_Packet

• Port repetitively transmits defined test packet
• Packet is designed to contain the full range of
  pattern frequencies and duty factors

Allows Testing of Output Eye Patterns, Jitter,
Waveform Parameters, and Frequency
11
Test Mode Test_Force_Enable

• Applies only to downstreamfacing hub ports
• Required behaviors apply even if no deviceis
  attached
• Port must be enabled in high-speed mode
• Downstream packets must be repeated to the port

Allows Testing of Disconnect Threshold
12
Example Testing aSelf-Powered Device

• Testing Input Impedance and Termination Voltage
• Testing Output Levels
• Testing Transmit Waveforms
• Testing Receiver Sensitivity
• Testing Squelch Threshold

13
Example Testing Input Impedance and Termination
Voltage

• Attach DUT to USB 2.0 host controller
• Reset the device and then issue request to place
  device in Test_SE0_NAK mode
• Unplug cable from device and replace it with test
  cable/fixture
• Measure DC output voltage on each line
• Measure DC resistance on each line
• Perform differential TDR test on outputs

14
Example TestingOutput Levels

• Attach DUT to USB 2.0 host controller
• Reset the device and then issue request to place
  device in Test_J mode
• Unplug cable from device and replace it with test
  cable/fixture
• Measure output voltages into 45 Ohm loadsto
  ground
• Repeat using Test_K

15
Eye Pattern Test Fixture
Transmitter/Receiver Test Fixture
Transmitter Test Attenuation Voltage at Scope
Inputs 0.760 Voltage at Transmitter
OutputsReceiver Test Attenuation Voltage at
Receiver Inputs 0.684 Voltage at Data
Generator Outputs
16
Example TestingTransmit Waveforms

• Attach DUT to USB 2.0 host controller
• Reset the device and then issue request to place
  device in Test_Packet mode
• Unplug cable from device and replace it
  withhigh-frequency test cable/fixture
• Measure rise/fall time
• Capture single, complete occurrence of
  testpacket on a transient capture instrument
• Perform eye pattern analysis on waveform record

17
Example Testing Receiver Sensitivity and Squelch
Threshold

• Attach DUT to USB 2.0 host controller
• Reset the device and then issue request to
  placedevice in Test_SE0_NAK mode
• Unplug cable from device and replace it with test
  cable/fixture
• Using data generator, apply IN token packet while
  varying amplitude, frequency, and injected jitter
• Using a differential high-impedance probe,
  monitor the cable to see under which conditions
  device responds with NAK handshake

18
