Workshop on Data Derivation

1
Workshop on Data Derivation ProvenanceWorkflow
Session

• Rick Cavanaugh, Rick Hull, Miron Livny, Mike
  Wilde
• 17 October 2002
• Chicago

2
Workflow Session Agenda

• 20 min - Overview  5 - workflow research - Rick
  Hull
•   5 - workflow needs - Rick Cavanaugh
• 5 provenance -gt workflow - Mike Wilde  5
  - workflow and the grid - Miron Livny
• 70 min Discussion
• What can provenance learn from workflow?

3
Rick Hull Workflow Overview
4
Workflow Essentials

• Terminology
• Workflow model the building blocks for workflow
  schemas
• Workflow schema (typically) a graph, showing
  control flow and processing steps
• Workflow enactment an instance/occurrence/run
  through a workflow schema
• Key abstraction focus on flow, not processing
  steps
• Interpret the workflow schema
• What you see is what you get unlike query
  optimization
• Few workflow schemas many workflow enactments
• Many workflow enactments are pushed through same
  schema
• Main issues
• Systems Persistence recovery logging audits
  pushing work items to human agents finishing
  workflow steps on time
• Formal analysis of schemas, e.g., reachability,
  termination
• Unresolved exceptions schema evolution

5
Workflow Models

• Variety of commercial and academic workflow
  models
• Process flow x-flowcharts, petri-nets, WSFL,
• Finite State Automaton, state charts
• Action Workflow based on model of
  conversations
• Wil van der Aalst patterns in workflow models
• Focus on process flow models, covering all major
  commercial workflow systems
• About 24 patterns identified (no surprises)
• flowchart constructs, parallelism, variants on
  choice (e.g., do m out of the n choices
• Things not modeled
• The data being processed, the internals of the
  process steps
• Query language for workflow schemas
• similarity, composition, evolution
• Aggregations of multiple enactments

There is some recent work
6
Rick Cavanaugh HEP Application
7
Generator
Formator
Simulator
Digitiser
writeESD
writeAOD
writeTAG
ODBMS
Analysis Scripts
Calib. DB
writeESD
writeAOD
writeTAG
8
Combined Ntuple
Re-formated
Simulated
Digitised
Ntuple
Generated
OODBMS
...
...
...
...
...
OODBMS
OODBMS
9
Combined Ntuples
Re-formated
Simulated
Digitised
Generated
...
...
OODBMS
10
Mike Virtual Data Interface
11
Virtual Data in the Science Process
12
Virtual Data Language XML
(Older version. Latest at http//www.griphyn.org/
workspace/VDS/vdl-1.20/vdl-1.20.png)
13
Managing Dependencies
file1

• TR tr1( out a2, in a1 )
• profile hints.exec-pfn "/usr/bin/app1"
• argument stdin a1
• argument stdout a2
• TR tr2( out a2, in a1 )
• profile hints.exec-pfn "/usr/bin/app2"
• argument stdin a1
• argument stdout a2
• DV x1-gttr1( a2_at_outfile2, a1_at_infile1)
• DV x2-gttr2( a2_at_outfile3, a1_at_infile2)

x1
file2
x2
file3
14
Workflow in the Virtual Data Grid
15
Miron Running Workflow on the Grid
16
Workflow execution on the Grid
17
Discussion Topics

• What can provenance learn from workflow?
• There are several workflow models - what is the
  right data derivation model?
• Expanding the p-schema to handle the temporal
  declarions that are provided by workflow system
• More Triggers error handling/recovery and
  propagation recovery. Tracking manual workflow
  (eg, Excel, SAS, ROOT)
• Viewpoint focus on the provenance schema object

18
Derivation Schema as anew Abstract Data Type

• What are the right building blocks to construct
  Derivation Schemas (composite transformations,
  derivation dags, )

Workflow Model Workflow Schema
Derivation Model Derivation Schema

• E.g., iteration? Aggregates of derivation
  schemas seem important

. . .
vs.
. . .
19
Key Questions

• What kinds of information should be included?
• What constructs should be included?
• Notions of equivalence, similarity?
• What operators should be included? (query,
  aggregate, compose)
