OMIs Science team activities

1
First OMI Measurements of Volcanic and
Anthropogenic SO2
S.A. Carn1, N.A. Krotkov2, A.J. Krueger1, K.
Yang3 1. Joint Center for Earth Systems
Technology (NASA/UMBC), UMBC, Baltimore, MD
scarn_at_umbc.edu 2. Goddard Earth Sciences and
Technology (GEST) Center, UMBC, Baltimore, MD 3.
SSAI, Greenbelt, MD With thanks to all the OMI
Science and Support Teams
2
Overview

• Maximum Likelihood SO2 PGE (OMSO2) code still in
  development
• Band Residual Difference (BRD) algorithm
  developed
• Volcanic SO2 data examples
• Anthropogenic SO2 examples

3
Band Residual Difference (BRD) algorithm
(off-line)

• Uses OMTO3 residuals at 4 wavelengths sensitive
  to SO2
• SO2 Index Pair 1 res311.9 - res310.8 (min - max
  lt0 where SO2 present)
• SO2 Index Pair 2 res313.2 - res311.9 (max - min
  gt0 where SO2 present)
• SO2 Index Pair 3 res314.4 - res313.2 (min - max
  lt0 where SO2 present)

?pj, ?pj total column SO2 and differential SO2
absorption coefficient for pair j ?pj
differential O3 absorption coefficient for pair
j ?o solar zenith angle ? satellite zenith
angle k 100/ln10 (scaling factor) respj
OMTO3 residual difference for pair j gpj
estimated AMF mg geometric path H? SO2 cloud
height Npj N(?j1) - N(?j2)
4
Global Sulfur Sources
Bluth et al., 1993 Pyle et al., 1996 Graf et
al., 1997 Andres Kasgnoc, 1998
5
Global Anthropogenic SO2 Emissions in 1985
6
Copper smelting

• At least 1 ton of SO2 released per ton of Cu
  produced.
• 50 of smelters capture lt84 of SO2 10 capture
  none at all.
• Most of the latter are in Australasia, South
  America, Africa and China.

7
Global Volcanic SO2 Emissions in 1997
Volcanoes 15 of S emissions but 36 of global
sulfate aerosol burden
Andres Kasgnoc, 1998
8
Manam eruption - Jan 28-31, 2005 - OMI SO2
9
Manam eruption - Jan 28, 2005 - Aqua/AIRS
Courtesy F. Prata, CSIRO, Australia
10
Manam eruption - Jan 28, 2005 - Aqua/AIRS
Courtesy F. Prata, CSIRO, Australia
Aqua/AIRS 0.235Tg at 0353UT Aura/OMI 0.222Tg at
0411UT
11
SW Pacific volcanic SO2 emissions
Nov 2004 Ambrym 7400 td-1 Bagana
170 td-1 New Britain 100 td-1
Dec 2004 Ambrym 17000 td-1 Bagana
250 td-1 New Britain 340 td-1
Jan 2005 Ambrym 12000 td-1 Bagana
430 td-1 New Britain 700 td-1
McGonigle et al., GRL 2004 Bagana
2000 td-1 Ulawun 640 td-1 Tavurvur
100 td-1 Pago 100 td-1
12
(No Transcript)
13
February 2005 Poor air quality in S. Mariana
Islands
14
Anatahan volcanic plume movie
15
Anatahan volcanic plume covers Guam
16
Colombia, Ecuador and Peru - a-priori SO2
emissions
17
Colombia, Ecuador and Peru - OMI SO2 measurements
Oct 2004 GT 2200 td-1 Or 2600 td-1 Ilo
3500 td-1
Sep 2004 GT 1150 td-1 Or 2150 td-1 Ilo
4100 td-1
Nov 2004 GT 4550 td-1 Or 750 td-1 Ilo
3600 td-1
Dec 2004 GT 10850 td-1 Or 750 td-1 Ilo
3500 td-1
Jan 2005 GT 5300 td-1 Or 500 td-1 Ilo
1250 td-1
18
Hawaii (Kilauea volcano) - Jan 2005
19
E. China - Dec 2004

• Box contains 50,000 tons of SO2
• 65,000 tons/day emitted in 1995 Streets
  Waldhof, 2000

70 of Chinas energy is derived from coal burning
Chinas SO2 emissions set to increase from 12 Tg
(1995) to 31 Tg (2020)
20
Summary of initial OMI SO2 analysis

• Explosive eruption clouds detected.
• Passive volcanic degassing measured.
• Preliminary validation suggests BRD algorithm
  produces realistic results.
• Anthropogenic SO2 emissions measured over China,
  Peru, USA (Ohio Valley), Europe, Central America,
  Uzbekistan.
• Sources generally in agreement with 1985 GEIA
  database.
• Anthropogenic emissions in Central South
  America and China appear similar to 1985-1995,
  with possible recent improvements.
• Need to distinguish volcanic from anthropogenic
  SO2 where mixing occurs, and account for the
  effects of clouds on emission measurements.

21
Next steps

• BRD algorithm to be implemented as PGE
• Reflectivity corrections and error budget
• Validation of UTLS SO2 using Aqua/AIRS IR
  retrievals and MLS data
• Comparisons with TES SO2 retrievals?
• Validation of passive volcanic degassing using
  ground-based DOAS
• Volcanic plumes known to contain BrO, OH at
  ppb-ppm levels Bobrowski et al., Nature, 2003
  Gerlach, 2004 - implicated in destruction of
  ozone in troposphere and stratosphere

22
Applications of OMI SO2 data

• Global SO2 (and other gas) budgets and sources
• Volcano monitoring
• Air quality forecasts (combined with models)
• Trajectory model validation
• Aircraft hazard mitigation (eruption alarm)
• Near real-time system (pending) will produce OMI
  SO2 data 100 minutes or less after overpass for
  aviation hazard mitigation

23
(No Transcript)
24
(No Transcript)
25
Importance of SO2 measurements

• Volcanological
• Easiest to measure of main volcanic gases (H2O,
  CO2, SO2)
• Distinguishes magmatic from phreatic/hydrothermal
  activity
• X/SO2 ratios used to derive fluxes of other
  species
• Track drifting volcanic clouds - mitigate
  aviation hazards
• Environmental
• Causes acid rain - damage to plants and crops
• Contributes to poor air quality - affects humans
  and plants
• Precursor of sulfate aerosol which can impact
  climate
• Acidification of dust storms and dissolution of
  iron for phytoplankton uptake Meskhidze et al.,
  JGR, 2005
