Real Time Models in 3KEYMASTER Simulation Environment

1

• Real Time Models in 3KEYMASTER Simulation
  Environment

2
Quick Overview

• Projects
• Bruce Power
• PPL Susquehanna
• Technology
• R3K
• Control Interpreter
• Relap xml-based Editor
• Relap IDE
• Demo

3
BruceB - Primary Heat Transport System
4
BruceB - Moderator System
Real Time 3 X 8 X 1
Verification 8 X 8 X 6
5
BruceB 16 channels core map
Iw Inner West Ie Inner East Ow
Outer west Oe Outer East
6
BruceB - Heat Structures
Pressure Tube
Fuel Pin
PHT Coolant
Cooling Gas
Moderator Fluid
7
BruceB - Boilers and Main Steam
8
BruceB Verification Model
9
BruceB - Model Highlights

• NESTLE - Cartesian geometry of 30X30 with 13
  axial nodes
• TH total number of volumes 764
• Interstitials and Feedback
• 4 control absorbers
• 32 shut-off rods
• 25 core adjusters
• 14 liquid zone controllers
• moderator heavy water purity
• gadolinium concentration
• WSC FlowBase code models
• Calandria cover gas system
• Main moderator system
• Feed and Bleed system
• Maintenance cooling system

10
BruceB - Scenarios

• Normal operations shut-down, startup
• from 100 power to hot shutdown condition
• Condenser Steam Discharge system down to 160 C
• Shutdown Cooling System to 90 C
• Turn off main pumps and turn on Maintenance
  Cooling System to 60 C
• Drainage of the PHT
• Xenon decay in fast time
• Disconnect/Connect Pressurizer
• Turn on pumps, warm-up in fast time
• Reach criticality
• power increase for turbine roll up
• generator synchronization
• power increase to 100

11
BruceB - Scenarios

• Transients
• pumps trips
• turbine trip
• shut-down
• BOP systems transients
• Accidents
• LOCA
• LOMA
• On-power refueling

12
BruceB pump trip

Verification Model Core coolant temperature 4
seconds after one pump trip
13
PPL Reactor Vessel

14
PPL Level Instrumentation

15
PPL - Refueling Model

16
PPL - Model Highlights

• NESTLE 32X32X12 mesh for X, Y, Z
• Cross-Sections are generated using NESLINK-MB
  code which processes MICROBURN and CASMO4 files
• Cross-Sections are stored in new FTB file
• Feed Water, Main Steam and CleanUp systems are
  simulated using WSC FlowBase code
• GE experimental data are used for separators
  carry-under effect
• 13 TH core channels hydraulics is tuned using MB
  printout

17
PPL - LBLOCA 1 minute

80 bar
Leak Flow
Upper Plenum Pressure
20 bar
Pump Discharge Flow
Shutdown Range
18
PPL LBLOCA 1 minute

RHR Flow
Separators void
Fuel Temperature
Core Void
19
PPL LBLOCA 2 minutes

RHR Flow
60 bar
Upper Plenum Pressure
6 bar
Pump Discharge Flow
Core Void
20
PPL LBLOCA 15 minutes

Leak Flow
Upper Plenum Pressure
Core Void
Wide Range
21
R3K

• all interactions between 3KeyMaster and RELAP5
• no need to change RELAP5 source code
• possibility to run RELAP5 in stand alone mode
• solid ground for further development stages

22
RELAP5 as a 3KeyMaster Task

• Flexible RELAP5 Time Step Adjustment
• Flexible RELAP5 Task CPU Assignment
• RELAP5 Data Presentation in form of Trends,
  Tables and Dynamic Drawings
• Possibility to run several Real-Time RELAP5 Tasks
  under same simulator load
• Full control through Instructor Station
• Real-time change of boundary conditions
• Access to all RELAP5 ME variables

23
R3K Functional Specification

• make time advancement
• write restart file
• read restart file
• setup model time
• setup mode
• steady-state / transient
• components to run (hydro, htadv, rkin)
• print major edit
• debug mode on/off
• generate list of ME variables
• output specified variables
• input parameters of TDC and control variables
• programming features
• LAG input/output parameter
• change heat capacity of specified material
• change fouling factor of specified HS
• change form loss coefficients of specified
  junction

24
R3K- shared memory
sh-in
RELAP5
R3K
sh-out
r3k.tdcomp
ltname of variablegt ltcomponent numbergt
ltLag timegt
r3k.medit
ltname of variablegt ltcomponent numbergt
ltLag timegt
25
R3K shared memory
26
R3K shared memory

27
R3K C access

if (rlp_th_refuel)
OPENPVLV(cntrlvar645, 0.1) double
addLevel (MAXVOID - voidg670010000)
MAXLEVEL if (addLevel gt MAXLEVEL)
addLevel MAXLEVEL
cntrlvar10 cntrlvar10 addLevel else
CLOSEPVLV(cntrlvar645, 0.1)
28
R3K snap/reset file

• each restart in separate file
• file name generation compatible with 3KeyMaster
• fully compatible with stand alone RELAP5
• possibility to replace RELAP5 components after
  restart
• shared memory is stored in 3KeyMaster
• possibility to change model time after restart
• backtrack options
• run in separate thread
• run on another CPU
• automatic compress

29
R3K time advancement
30
R3K Fixed Frequencies

31
R3K Floating Frequencies

32
R3K Control System Interpreter

• Options to develop Control System
• RELAP5 Input Deck
• boring
• complex when logics involved
• changes require re-snap ICs
• 3KeyMaster task C program
• have to build task
• Symbolic Calculations and Transfer - SCATER
• implemented in YACC
• invoked on every time step
• no declarations, simple and handy

33
R3K SCATER Example

• density
• 80.0, 1011.838 \
• 100.0, 1005.543 \
• 150.0, 988.4994 \
• 300.0, 922.7115 \
• dp50 (p052020000 rho052010000 15.93) -
  (p050010000 rho050010000 4.006)
• dp50lag lag(dp50, 1.5)
• reftemp 0.09 tempg050010000 cntrlvar6761
  0.91
• level50 densityreftemp 25.2 dp50
• cntrlvar50 nconvlevel50
• if (aa gt 1.5 2.4 lt dd)

34
RELAP5 Input Deck Editor

• XML definition in external file
• First Version - Validator
• ltPIPEgt
• ltCardNo0001 MaxNumber"0001" option"Required"
  wno"1" help"pg_0070"gt
• ltW1 name"Vol num" type"int" range"GT 0
  AND LT 100" update"var" value"0" N"1"
  help"pg_0070"/gt
• lt/CardNo0001gt
• ltCardNo0003 MaxNumber"0003"
  option"Optional" wno"5" help"pg_0072"gt
• ltW1 name"Magnetic f str" type"float"
  range"GE 0" update"var" value"0"
  help"pg_0072"/gt
• ltW2 name"Duct wall cond" type"float"
  range"GE 0" update"var" value"0"
  help"pg_0072"/gt
• ltW3 name"Duct wall thickness" type"float"
  range"GE 0" update"var" value"0"
  help"pg_0072"/gt
• ltW4 name"Duct geometry type" type"int"
  range"EQ 1 AND EQ 2" update"var" value"1"
  wopt"opt help"pg_0072"/gt
• ltW5 name"Fringle volume flag" type"int"
  range"GE -1 AND LE 2" update"var" value"0"
  wopt"opt" help"pg_0072"/gt
• lt/CardNo0003gt
• ltCardNo0101 MaxNumber"0199"
  option"Required" wno"2" help"pg_0073"gt
• ltW1 name"Area X" type"float" range"GE 0"
  update"var" value"0.0" help"pg_0073"/gt
• ltW2 name"Vol No" type"int" range"GT 0"
  update"var" value"1" help"pg_0073"/gt

35
RELAP5 Input Deck Editor
36
RELAP5 IDE

• We may use UNIX machines but development stays on
  PC
• Stay with RELAP5 Input Deck
• Edit, run and see results from the same screen
• Easy to customize and extend
• Rich and fast graphics
• Demo
