Prosodic Fortification in Error Resolution

1
Prosodic Fortificationin Error Resolution

• UW/Microsoft Symposium
• Lesley Carmichael
• January 23, 2004
• This research was conducted at the
• Center for Human-Computer Communication,
• OGI School of Science Engineering (Beaverton,
  OR)

2
Prosody Speech Technologies

• Prosodic information not widely used
• No consistent framework
• Normalization (f0 range, speech rate, etc.)
• Bundles of prosodic features
• Not just f0
• How do features interact?

3
Speech Synthesizers

• Current systems sound reasonable
• Corpus-based generation
• Im a synthetic voice yet I know just how to
  intone my speech like a human
• Enhanced prosodic markup could provide some
  benefit
• Special domain, concept-to-speech, e.g., weather
  reports

4
Speech Recognizers

• Typically dont use prosodic information
• Calculate probability of phones, words, phrases
• Possible gains?
• Classify dialog acts
• Identify boundaries
• Identify discourse-level structure
• Identify emotion

5
Background

• Hyperarticulate speech is common in error
  resolution (e.g., Oviatt et al. 1998)
• Clearer pronunciation of segments
• Slower speech
• Pauses

6
Prosodic Fortification

• Changing and/or augmenting the prosody of an
  utterance
• Making words phrasally prominent
• Grouping words together with boundaries
• Changing tonal features
• Analogous to segmental hyperarticulation
• Adds clarification and organization to signal

7
Pitch Accents

• Phonetic features indicating prominence
• Relatively High or Low fundamental frequency
• Can be simple (one tone) or complex (bitonal)
• Associated with a particular syllable
• Used to emphasize certain words relative to others

8
Breaks

• Perceptible disjuncture between adjacent words
• Can be indicated with pausing, tonal features,
  and/or segmental hyperarticulation
• Indicate phrase boundaries
• Used to group information

9
Present Study

• Investigates whether speakers substantially
  fortify prosody in an attempt to resolve errors
• Adding new prosodic events
• Categorically changing quality of prosodic events

10
Hypotheses

• In error resolution (as compared to original
  input), speakers will
• 1 Use more pitch accents
• 2 Use more complex pitch accents
• 3 Use more breaks
• 4 Use more total disjuncture strength
• 5 Change tone types

11
Speech Data

• Children interacting with computing device to
  learn about marine biology
• Children received occasional system recognition
  errors (Wizard of Oz)
• In some cases, children produced a lexically
  verbatim utterance after the error

12

• 103 lexically verbatim utterance pairs
• Pre-error and post-error speech
• 2-8 pairs per speaker
• 22 speakers
• MLU 3.2, range 1-11 words
• Provides opportunity to examine prosodic changes
  in spoken error resolution

13
Model for Analysis

• Tones and Break Indices (ToBI) (Silverman, et
  al. 1992)
• Analyzes intonation into series of discrete
  events
• Small set of event types
• Measures changes of kind rather than degree

14
Evaluation Metrics

• Categorical changes
• Presence vs. absence of pitch accent
• Complexity of pitch accent
• Presence vs. absence of breaks
• Level of break
• Type of base tone (H or L)
• Discrete intonation events, not continuous

15
ToBI Pitch Accents

• Identified by the presence and timing of
  relatively High and Low fundamental frequency
  values
• 3 Simple tones
• H, !H, L
• 5 Complex tones
• LH, L!H, LH, L!H, H!H

16
ToBI Breaks

• Identified by the perceived degree of disjuncture
  between words
• 5 levels
• 0 clitic grouping
• 1 standard word boundary
• 2 slight break, no tonal marking
• 3 intermediate phrase boundary, with tone mark
• 4 full intonational phrase boundary, with tone
  mark

17

• Tone values of breaks
• Level 2 (none)
• Level 3 H- or L-
• Level 4 L-L, L-H, H-L, H-H, !H-L, !H-H

18
Examples
Original
Repeat
Original
Repeat
19
Original
Repeat
20
Original
Repeat
21
Results

• Hypothesis 1 Speakers will use more pitch
  accents in repeats than original input
• Original 2.20 mean accents per utterance
• Repeat 2.56 mean accents per utterance
• 16 more accents in repeats
• Significant by Wilcoxon Signed Ranks Test, z3.39
  (N16) p lt .0005, one-tailed.

22

• Hypothesis 2 Speakers will use more complex
  pitch accents on repeats than original input.
• Original 17.7 of accents were complex
• Repeat 25.3 of accents were complex
• 43 more complex tones in repeats
• Significant by Wilcoxon Signed Ranks Test, z2.21
  (N19) p lt .015, one-tailed.

23

• Hypothesis 3 Speakers will use more breaks on
  repeats than original input
• Original 1.39 mean breaks per utterance
• Repeat 1.70 mean breaks per utterance
• 22 more breaks in repeats
• Significant by Wilcoxon Signed Ranks Test, z3.18
  (N13) p lt .0005, one-tailed.

24

• Hypothesis 4 Speakers will use more total
  disjuncture strength on repeats than original
  input
• Original mean break magnitude 3.98
• Repeat mean break magnitude 4.66
• 17 greater total break strength in repeats
• Significant by Wilcoxon Signed Ranks Test, z3.30
  (N14) p lt .0005, one-tailed.
• (used scale 1-5 to represent breaks 0-4)

25

• Hypothesis 5 Speakers will change the tone type
  of pitch accents and breaks on repeats as
  compared to original input
• 19 of pitch accents changed tone type
• 38 49 of level 4 breaks changed tone type
  (depending on of level 4 breaks in the
  utterance)

26

• Hypothesis 5 cannot be statistically verified
• Need rate of spontaneous tone shift as baseline

27
Discussion

• Speakers systematically manipulate prosody to aid
  in recognition
• Speech is fortified
• Many strategies available new accents, new
  breaks, accent complexity, break strength, tone
  type
• Interactions?
• Do some strategies complement or supplant others?

28
Quantity vs. Quality

• Accents
• 79 of accent tone changes occurred in utterances
  with NO new accents
• 72 of new accents occurred in utterances with
  NO tone changes
• Tend toward complementarity?

29

• Breaks
• 38 of level 4 break tones changed across all
  utterances
• Utterances with
• More than one level 4 break 10 changed
• Only 1 level 4 break (but 2s, 3s ok) 42 changed
• Only 1 level 4 break (no other breaks) 49
  changed
• More tone changes when fewer breaks are available
  to organize information?

30
Prosody in Automatic Speech Processing

• Data-driven prosody modeling
• Acoustic/phonetic
• Application of prosody models improved results
  for
• Structural tagging (sentence boundaries,
  disfluencies)
• Pragmatic, paralinguistic tagging (dialog act
  classification, emotion)
• Speaker recognition
• Word recognition
• (Shriberg Stolcke, 2004)

31
Prosodic Knowledge Sources

• 3 prosody models used to rescore N-best list for
  word recognition
• Word duration
• Word and pause duration/interaction
• Other events boundaries, disfluencies
• Each one improved scores independently
• All 3 combined increased improvement
• (Vergyri et al., 2003)

32
Hot Spots in Meetings

• High involvement heated discussion, etc.
• Auto processing of meetings
• Summarize, find important information
• Prosodic features automatically extracted
• Humans judge hot spots reliably
• F0 and energy correlation between human judgments
  and prosodic features of hot spots
• (Wrede Shriberg, 2003)

33
Emotion Detection

• Prosodic model predicts neutral vs. annoyed or
  frustrated
• Accuracy close to human labelers
• Duration and speaking rate had most impact
• Hyperarticulation and pauses were not useful
• (Ang et al., 2002)

34
Future Work

• Investigate possible weighting of prosodic
  fortification strategies
• Repeat analyses with adult speech
• Segmental and prosodic hyperarticulation
• Compare error correction and hot spot speech
• Assess prosodic-syntactic boundary alignment in
  regular vs. error-correction speech

35
References

• Ang, J., Dhillon, R., Krupski, A., Shriberg, E.
  and Stolcke, A. (2002), Prosody-Based Automatic
  Detection of Annoyance and Frustration in
  Human-Computer Dialog. Proc. Intl. Conf. on
  Spoken Language Processing, vol. 3, pp.
  2037-2040, Denver.
• Carmichael, L. (submitted). Intonation
  categories and continua.
• Oviatt, S.L., M. MacEachern, G. Levow. (1998).
  Predicting hyperarticulate speech during
  human-computer error resolution. Speech
  Communication, 24, 87-110.
• Pierrehumbert, J. J. Hirschberg. (1990). The
  meaning of intonational contours in the
  interpretation of discourse. In Cohen, P.R.,
  Morgan, J., Pollack, M.E. (eds.), Intentions in
  Communication. Cambridge, MA MIT Press, 271-323.
• Pitrelli, J., M.E. Beckman, J. Hirschberg.
  (1994). Evalution of prosodic transcription
  labeling reliability in the ToBI framework. In
  Proc. ICSLP, 123-126.
• Shriberg, E. and Stolcke, A. (2004). Direct
  Modeling of Prosody An Overview of Applications
  in Automatic Speech Processing. To appear in
  Proc. International Conference on Speech Prosody
  2004 Nara, Japan.
• Silverman, K., M.E. Beckman, J. Pitrelli, M.
  Ostendorf, C. Wightman, P. Price, J.
  Pierrehumbert, J. Hirschberg. (1992). ToBI a
  standard for labeling English prosody. In Proc.
  ICSLP, 2, 867-870.
• Vergyri, D., Stolcke, A., Gadde, V.R.R., Ferrer,
  L. and Shriberg, E. (2003), Prosodic Knowledge
  Sources for Automatic Speech Recognition. Proc.
  IEEE Intl. Conf. on Acoustics, Speech and Signal
  Processing, Hong Kong.
• Wrede, B. and Shriberg, E. (2003), Spotting
  "Hotspots" in Meetings Human Judgments and
  Prosodic Cues. Proc. Eurospeech, Geneva.
• http//www.ling.ohio-state.edu/tobi
