Peace River Cumulative Impact Study and Resource Management Plan

1
Peace River Cumulative Impact Study and Resource
Management Plan
2
2003 Legislation

• Omnibus Phosphate Legislation codified in Chapter
  2003-423, Laws of Florida
• Law provided
• Increase in phosphate severance tax and
  redistribution of tax revenues
• Priority for reclamation of Old Lands that
  provide significant benefits to surface waters
  and public supplies sunset new applications
• Variance from reclamation standards for projects
  that provide water supply or water resource
  development
• Strengthen financial responsibility and
  operational requirements for phosphogypsum stack
  systems
• Funding for FIPR research on rapid dewatering of
  clay settling areas
• Cumulative Impact Study and Resource Management
  Plan for Peace River Basin

3
Study and Plan Objectives

• Study cumulative impacts of changes in landform
  and hydrology on water resources of Peace River
  Basin
• Evaluate Floodplain Buffers, including Myakka
  River
• Prepare and adopt a Resource Management Plan to
  minimize identified impacts
• Identify regulatory and non-regulatory actions
  needed
• Recommend statutory changes needed
• 750,000 in funding provided

4
Consultants

• Post Buckley, Schuh and Jernigan (Lead)
• HydroGeologic
• The Nature Conservancy (Brian Richter)
• EarthBalance
• Lewis, Longman and Walker, P.A.
• Avineon
• W. Dexter Bender (Tom Fraser)

5
Study Tasks

• Task 1
  Literature Review and Data Collection
• Task 2
  Description of Historical Changes
• Task 3
  Identification and Analysis of Factors Causing
  Changes
• Task 4
  Evaluating Regulatory Effectiveness

6
Public Meetings

• Bartow May 24
• Arcadia - June 21
• Punta Gorda July 26
• Wauchula August 9

7
Sub-basin Based Study
8
Watershed Stressor and Metrics

• Stressors
• Urbanization
• Agriculture
• Mining
• Long-term Climate Patterns

• Metrics
• Streamflow
• Water quality
• Groundwater elevations
• Miles of streambed
• Acres of floodplain
• Acres of wetlands
• Acres of mined lands
• Acres of agricultural lands
• Acres of urban lands

9
Landform Changes 1940s - 1999
10
Changes at Watershed Level
11
Changes Due to Development
1940s Developed Land Use

• Actively Mined Lands 0.5 of watershed
• Urban Land Use 1
• Improved Pasture 3
• Intense Agriculture 8

12
Changes Due to Development
1999 Developed Land Use

• Actively Mined Lands 10
• of watershed
• Urban Land Use 10
• Improved Pasture 27
• Intense Agriculture 17

13
Hydrology Changes

• Land-use changes (changes in hydroperiod)
• Hydrological structural alterations, changes in
  surface flows
• Historical changes in groundwater elevations
  (withdrawals)
• Natural climatic cycles (rainfall)

14
Changes in Rainfall/Flow Patterns

• There have been changes in long-term
  rainfall/flow patterns in the Peace River
  Watershed
• The observed changes in rainfall (and flow) seem
  to be accounted for by the recently proposed AMO
  theory

15
(No Transcript)
16
Changes in Low Flow Characteristics

• There have been significant long-term changes in
  low/base flow not related to rainfall patterns
• Upper watershed declines caused by
• Loss of spring flows
• Declines in groundwater levels
• Declines in discharges
• Payne Creek
• Lower watershed subbasins (Horse, Joshua, Shell
  and Prairie Creeks)
• increases due to agricultural groundwater
  discharges

17
(No Transcript)
18
Increasing GW Use in Polk
Leads to aquifer drawdown.
19
Kissingen Spring

• Flow of approx.15 to 20 Mgd prior to 1940.
• By 1950s flow was only intermittent.
• Ceased all flow after late 1950s.

• Kissingen spring is the canary in the coal mine
  for the onset of losing conditions in Upper Peace
  River.

20
Polk County Artesian Well
Near Eagle Lake, 1911
21
Recharge / Discharge Trends
22

• Water Quality
• Trends and Status
• Long-term patterns and changes in parameters at
  40 watershed and estuarine sites
• Comparisons of current status among selected
  characteristic sites for key constituents

23
? Large Change ? Intermediate Change ?
Small Change ? No Change Blank No
Data
24
Summary of Water Quality

• Upper river historically received direct
  discharges from both phosphate mining/beneficiatio
  n and urban sewage treatment
• Water quality trends show large declines in
  ortho-phosphate, fluoride, and sulfate levels
  associated with changes in mining practices.
• Water color has increased, reflecting declines in
  spring flow and reduced mining discharges (loss
  of eel grass in spring runs)
• Different spatial long-term patterns
• Relative improvements in water quality northern
  watershed
• Significant degradation of surface water quality
  in southern basins

25
Next Step Resource Management Plan

• The Peace River Basin Resource Management Plan
• Must identify regulatory and non-regulatory
  actions to minimize cumulative impact.
• Will consider both regulatory and non-regulatory
  recommendations.

26
Soliciting Ideas from Stakeholders

• Stakeholder meetings
• July 13 Wauchula
• September 7 Wauchula
• Representatives of
• DEP, SWFWMD, FWCC, RPC, IFAS
• Local Governments and Water Supply Authority
• Environmental Groups
• Phosphate, Citrus, Agriculture

27
Strawman Recommendations

• Fully implement SWUCA Recovery Strategy
• Identify re-connection and re-hydration
  opportunities
• Discuss competing applications
• Prioritize wetland systems for restoration, fix
  mitigation rule glitches
• Pursue mineralization abatement
• Cradle to Grave phosphate mining and
  reclamation permitting, off-site mitigation
• Fully fund Old Lands Program
• Create incentives to protect floodplains
• Fund floodplain acquisition
• Need for better data
• Convene Standing Workgroup

28
What is the Integrated Habitat Network?

• The Integrated Habitat Network lies within the
  Central Florida Phosphate Mining District
• Guide for management and protection of greenways,
  wildlife habitat and riparian buffers.
• Guide for permitting and reclamation
• A combination of undisturbed and reclaimed lands

29
What areas are in the IHN?

• Coastal Settlement Areas
• Conservation Easements
• Donations
• Acquisitions

30
(No Transcript)
31
How does the DEP implement the IHN?

• Through the Regulatory Process (WRP/ERP and
  Conceptual Plan Approvals), the Department can
  encourage the applicant to consider concepts in
  the IHN.

32
EXAMPLES

• Proposed Conservation Easements using the IHN
  Concept
• Ft. Green Ona Extension (525 acres)
• Four Corners Altman Tract (559.6 acres)

33
(No Transcript)
34
(No Transcript)
35
(No Transcript)
36
Fort Green Historical
37
Fort Green 1994
38
Fort Green 1999
39
Fort Green 2004
40
Questions?

• More Info at
• http//www.dep.state.fl.us/water/mines/prcis.htm
• and
• http//www.swfwmd.state.fl.us/waterman/peaceriver/
