Designing a Field Project

1
Designing a Field Project

• Michael J. Conroy

2
PURPOSES OF SAMPLING

• ESTIMATE ATTRIBUTES (PARAMETERS)
• Abundance/ density
• Survival
• Home range size
• ALLOW LEGITIMATE EXTRAPOLATION FROM DATA TO
  POPULATIONS
• PROVIDE MEASURES OF STATISTICAL RELIABILITY

3
SAMPLING NEEDS TO BE

• ACCURATE LEADING TO UNBIASED ESTIMATES
• REPEATABLE ESTIMATES LEAD TO SIMILAR ANSWERS
• EFFICIENT DO NOT WASTE RESOURCES

4
BIAS

• HOW GOOD ON AVERAGE AN ESTIMATE IS
• CANNOT TELL FROM A SINGLE SAMPLE
• DEPENDS ON SAMPLING DESIGN, ESTIMATOR, AND
  ASSUMPTIONS

5
UNBIASED
TRUE VALUE
SAMPLE ESTIMATE








AVERAGE ESTIMATE
6
BIASED
TRUE VALUE
SAMPLE ESTIMATE








BIAS
AVERAGE ESTIMATE
7
REPEATABLE (PRECISE)
SAMPLE ESTIMATE








8
NOT REPEATABLE (IMPRECISE)



SAMPLE ESTIMATE





9
CAN BE IMPRECISE BUT UNBIASED.. OR

AVERAGE ESTIMATE


SAMPLE ESTIMATE





TRUE VALUE
10
PRECISELY BIASED..OR
TRUE VALUE
SAMPLE ESTIMATE








AVERAGE ESTIMATE
11
IMPRECISE AND BIASED!
AVERAGE ESTIMATE


SAMPLE ESTIMATE






TRUE VALUE
12
ACCURATEUNBIASED PRECISE
TRUE VALUE
SAMPLE ESTIMATE








AVERAGE ESTIMATE
13
HOW DO WE MAKE ESTIMATES ACCURATE ?

• KEEP BIAS LOW
• SAMPLE TO ADEQUATELY REPRESENT POPULATION
• ACCOUNT FOR DETECTION
• KEEP VARIANCE LOW
• REPLICATION (ADEQUATE SAMPLE SIZE)
• STRATIFICATION, RECORDING OF COVARIATES, BLOCKING

14
Key Issues

• Spatial sampling
• Proper consideration and incorporation of
  detectability

15
Sampling principles

• What is the objective?
• What is the target population?
• What are the appropriate sampling units?
• Size, shape, placement
• Quantities measured

16
Remember

• Field sampling must be representative of the
  population of inference
• Incomplete detection MUST be accounted for in
  sampling and estimation

17
Example- Pheasants in Corbett National Park
18
What is the objective?

• Unbiased estimate of population density of
  pheasants on Corbett National Park
• Coefficient of variation of estimate lt 20
• As cost efficient as possible

19
What is the target population?Population in CNP
20
What are the appropriate sampling units?

• Quadrats?
• Point samples?
• Line transects?

21
Sampling units- nonrandom placement
Road
22
Nonrandom placement

• Advantages
• Easy to lay out
• More convenient to sample
• Disadvantage
• Do not represent other (off road) habitats
• Road may attract (or repel) pheasants

23
OR- redefine the target
Road
24
Sampling units- random placement
25
Random placement

• Advantages
• Valid statistical design
• Represents study area
• Replication allows variance estimation
• Disadvantage
• May be logistically difficult
• Harder to lay out
• May not work well in heterogeneous study areas

26
Stratified sampling
27
Stratified sampling

• Advantages
• Controls for heterogeneous study area
• Allows estimation of density by strata
• More precise estimate of overall density
• Disadvantages
• More complex design
• May require larger total sample

28
Single, unreplicated line
29
Are these hard rules NO!

• Some violations of assumptions can be OK and
  even necessary (idea of robustness)
• These are ideals to strive toward
• Good if you can achieve them
• If you cant, you cant but study results may
  need different interpretation

30
Estimation from Count Data to Population (I)

• Geographic variation (cant look everywhere)
• Frequently counts/observations cannot be
  conducted over entire area of interest
• Proper inference requires a spatial sampling
  design that permits inference about entire area,
  based on a sample

31
A valid sampling design

• Allows valid probability inference about the
  population
• Statistical model
• Allows estimates of precision
• Replication, independence

32
Other Spatial Sampling Designs

• Systematic sampling
• Can approximate random sampling in some cases
• Cluster sampling
• When the biological units come in clusters
• Double sampling
• Very useful for detection calibration
• Adaptive sampling
• More efficient when populations are distributed
  clumpily
• Dual-frame sampling

33
Remember

• Incomplete detection MUST be accounted for in
  sampling and estimation

34
Estimation from Count to Population (II)

• Detectability (cant see everything in places
  where you do look)
• Counts represent some unknown fraction of animals
  in sampled area
• Proper inference requires information on
  detection probability

35
Flushed 2 pheasants from quadrat but there were
4!
36
Detectability Conceptual Basis

• N abundance
• C count statistic
• p detection probability P(member of N appears
  in C)

37
Detectability Inference

• Inferences about N require inferences about p

38
Above example p0.5

• If you know p you can get N (for the sample unit)

• If you ignore p then C 2 is biased
• Usually we have to collect other data to estimate
  p!

39
Abundance estimation

• Distance sampling
• Mark-recapture
• Multiple observers
• Independent
• Dependent
• Temporal removal
• Marked subsample
• Sighting probability models
• Bounded counts

40
I(ndices)!
I
41
INDICES

• Assumed relationship of index to N
• Usually assumed linear through zero
• Assumed homogeneous over time,space
• Practically never tested!

42
Linear index
43
Nonlinear index
44
Indices Assume Equal Detectability (p)!

• Over time (this sample and next sample)
• But observers change, conditions change!
• Over space
• Conditions may differ (e.g., differ amounts of
  cover)

45
Nonhomogeneous index
46
Indices Assume Equal Detectability!

• N1 abundance for area 1 4
• N2 abundance for area 2 8
• p1 detection for area 1 0.50
• p2 detection for area 2 0.25
• C1 4 X .50 2
• C2 8 X .25 2
• Index says N1 N2 !
• \

47
Indices Assume Equal Detectability (p)!

• Heterogeneous detection can mask real differences
• Heterogeneous detection can reveal false
  differences
• You cant possibly know without estimating p or
  at least testing for heterogeneity!

48
Uncalibrated indices

• Are unsound scientifically
• Cannot be made sound by standardisation!

49
Double sampling

• Large sample provides biased estimate of
  abundance
• Smaller (calibration) sample provides unbiased
  (or less biased) estimate

50
Aerial survey of elephants
51
Aerial surveys

• Effective for covering large expanse of terrain
• Known to undercount elephants by ???
• Calibrate with counts by ground observers

52
Double survey design
Aerial only
Aerial ground
53
Estimation

• Aerial survey estimate 40 elephants
• Double survey estimate of p 20 air/ 30
  ground0.67
• Revised survey estimate 40/0.67 60

54
TAKE HOME MESSAGES

• Field sampling must be designed to meet study or
  conservation objectives
• Field sampling must be representative of the
  population of inference
• Incomplete detection MUST be accounted for in
  sampling and estimation
