Title: By Erick O


1
GSM GPRS Primer
  • By Erick OConnor
  • February 2005

2
Topics
  • Background
  • The history of cellular communications
  • Key statistics
  • Worldwide subscribers
  • Top 20 global mobile operators
  • Global System for Mobile (GSM)
  • The Radio environment
  • Basestation Network subsystems
  • Subscriber data addressing
  • Circuit-switched network architecture
  • Overview of PDH transmission
  • Common Channel Signalling GSM MAP
  • General Packet Radio System (GPRS)
  • Protocol layers
  • Key information
  • Dimensioning a Network
  • Mobility Management
  • Third-Generation Systems (UMTS)
  • Evolution paths
  • Core components

The following symbol indicates that the slide
contains animations. Press the space bar to
advance the animation
A
3
History of Cellular Communications
  • 1960s to the Present Day

4
the early years
  • 1960 1970s
  • Idea of a cell-based mobile radio system
    developed by ATTs Bell Labs in late 1960s
  • First commercial analogue mobile cellular systems
    deployed 1978
  • 1980s (1st Generation Analogue Systems)
  • Usage in N.America grows rapidly
  • Advanced Mobile Phone System (AMPS) becoming the
    de facto standard
  • Europe, run by the PTTs, characterised by
    multiple incompatible analogue standards
  • Nordic Mobile Telecommunications (NMT-450)
  • Total Access Communications (TAC) United
    Kingdom
  • C-Netz West Germany
  • Radiocom 2000 France
  • RTM / RTMS Italy etc. etc.
  • Capacity limitations already becoming apparent by
    end of decade.

5
going digital
  • Late 1980s to early 1990s (2nd Generation Digital
    Systems)
  • N.America relies on de facto let the best
    technology win standardisation
  • By contrast Europe decides to rely on
    standardisation co-operation
  • Huge pent-up demand for mobility can not be met
    by upgrading existing purely analogue systems.
    Parallel advances in digital techniques and Very
    Large Scale Integration (VLSI) chipset
    manufacture suggest a new way forward
  • However European domestic markets individually
    too small to achieve the economies of scale
    necessary for vendors to take the risk of
    developing such a risky new solution
  • Enter the European Commission with a political
    agenda demonstrate Europes technology
    leadership and ensure European manufacturers can
    compete globally
  • New spectrum auctions in USA in early 1990 (PCS
    1900) lead to plethora of standards
  • D-AMPS IS-54 Motorola sponsored, TDMA IS-136,
    CDMA IS-95 Qualcomm sponsored
  • Plus, limited GSM
  • Meanwhile in Europe

6
GSM is born
  • Late 1980s to early 1990s (2nd Generation Digital
    Systems)
  • Guided by European Commission European
    Telecommunications Standard Institute
  • 26 European telecommunication administrations
    establish the Groupe Spéciale Mobile (GSM) in
    1982 with aim to develop a new specification for
    a fully digital pan-European mobile
    communications network
  • The Group notes that the new industrys economic
    future will rely on unprecedented levels of
    pan-European co-operation
  • Political decision to force member countries to
  • allocate frequencies at 900 MHz in every EC
    country (later 1800 MHz)
  • specify the exact technology to be used and
  • deploy systems by 1991
  • First commercial GSM networks deployed in 1992
  • Denmark / Finland / France / Germany / Italy /
    Portugal / Sweden / United Kingdom

7
beginning of the GSM success story
  • By End of 1993
  • One million subscribers using GSM
  • GSM Association has 70 members, 48 countries
  • First non-European operator, Telstra of Australia

And, by technology.
www.gsmworld.com
.Subscribers
8
the turn of the century 3rd generation services
  • Multiple operators per country worldwide (800)
  • intense price based competition
  • Huge growth in subscribers thanks to pre-paid but
    falling ARPU high churn (c.25)
  • Market close to saturation slowing subscriber
    penetration growth rates (c.85)
  • The challenge what to do in future?
  • Europe keen to replicate commercial success of
    GSM but, Americans Japanese had different views
    and needs
  • Japan had run out of spectrum for voice
  • Americans unhappy at being dictated to by a
    European standard
  • European vision of always on data rich value
    added content services
  • America Japan jointly force Europe to open up
    standardisation process so as not to once again
    lock-out other trading blocs vendors
  • Creation of 3rd Gen Partnership Programme (3GPP)
    body
  • Heated standardisation on Wideband CDMA (Qualcomm
    vs Ericsson)
  • Final agreement on Universal Mobile
    Telecommunications Standard (UMTS) in 1998.

9
The market today key statistics
10
GSM design
  • Radio Network subsystems, Signalling
    Transmission

11
Basic GSM network elements
A
AUC Authentication Centre BSC Basestation
Controller BTS Basestation Transceiver EIR Equipme
nt Identity Register GMSC Gateway Mobile
Switching Centre HLR Home Location
Register ISC International Switching
Centre ISDN Integrated Services Digital
Network MSC Mobile Switching Centre PDN Packet
Data Network (X25) PSTN Public Switched Telephony
Network SIWF Shared Interworking
Function VLR Visitor Location Register XCDR Transc
oder (16 / 64kbps coding)
12
GSM air interface design
  • Access Techniques
  • Time Division Multiple Access
  • Frequency Division Multiple Access
  • Space Division Multiple Access
  • Radio characteristics
  • Gaussian Minimum Shift Keying (GMSK)
  • Slow Frequency Hopping
  • Logical structure
  • 8 Timeslots per Carrier
  • 1 Downlink Timeslot reserved for signalling
  • 3 timeslot difference between uplink downlink
  • Frame structure used for synchronisation
  • 51-frame Multiframe (235.4 ms)
  • 51 or 26 Multiframe Superframe (6.12 sec)
  • 2048 Superframe Hyperframe (3 hr 28 mins)

13
Radio subsystem (i)
  • Basestation Transceiver (BTS) provides radio
    channels for signalling user data
  • A BTS has 1 to 6 RF carriers per sector and
    1(omni) to 6 sectors
  • e.g. 3/3/3 3 sector with 3 carriers per sector
  • 3 x 7 Timeslots x 3 63 Timeslots total
  • c.52 Erlangs _at_ 2 Grade of Service
  • c.2,000 users per BTS _at_ 25 mErl / User (90
    seconds)
  • Frequency reuse depends on terrain, frequencies
    available etc.
  • Paired spectrum shared by Operators
  • 900 / 1800 MHz in Europe / Asia (25 75 MHz)
  • 1900 MHz in N.America
  • 200 kHz channel separation
  • 125 Channels _at_ 900 MHz

Frequency reuse cluster formation
14
Radio subsystem (ii)
  • Basestation Controller (BSC) controls a number of
    BTS
  • Acts as a small switch
  • Assists in handover between cells and between BTS
  • Manages the Radio Resource, allocating channels
    on the air interface
  • Transcoding (XCDR) function is logically
    associated with BTS
  • But, typically located at BSC to save on
    transmission costs
  • XCDR provides 13 kbps Coding / Decoding between
    GSM Codec standard 64 kbps A-law encoded voice
  • Interfaces
  • Abis BTS to BSC interface (never fully
    standardised so vendor-specific variants exist)
  • A BSC to MSC interface carrying voice, BSC
    signalling and Radio
  • Traffic Channels are mapped one-to-one between
    BTS and Transcoder
  • BTS can be connected in Star or Daisy-chain
    arrangement to BSC (max. 15)

15
Network subsystem (i)
  • Core component is Mobile Switching Centre (MSC)
  • Performs all switching functions of a
    fixed-network switch
  • Allocates and administers radio resources
    controls mobility of users
  • Multiple BSC hosted by one MSC
  • Gateway MSC (GMSC) provide interworking with
    other fixed mobile networks
  • Crucial role in delivering in-coming call to
    mobile user in association with Home Location
    Register (HLR) interrogation
  • Shared Interworking Function (SIWF)
  • Bearer Services are defined in GSM including 3.1
    kHz Voice, ISDN, 9.6 kbps Data 14.4 kbps
  • IWF provides modem capabilities to convert
    between digital bearer PSTN, ISDN PDN
  • International Switching Centre (ISC)
  • Provides switching of calls internationally.
    Switch may be provided by another carrier

16
Network subsystem (ii)
  • Home Location Register (HLR) holds master
    database of all subscribers
  • Stores all permanent subscriber data relevant
    temporary data including
  • MS-ISDN (Mobile Subscribers telephone no.)
  • MSRN (Mobile Station Roaming no.)
  • Current Mobile Location Area
  • Actively involved in incoming call set-up
    supplementary services
  • Visitor Location Register (VLR) associated with
    individual MSCs
  • VLR stores temporary subscriber information
    obtained from HLR of mobiles currently registered
    in serving area of MSC
  • Involved in registration of mobiles
  • Assists in delivery of supplementary service
    features such as Call Waiting / Call Hold
  • Authentication Centre (AUC) Equipment Identity
    Register (EIR)
  • GSM is inherently secure using encryption over
    the air-interface and for authentication /
    registration
  • AUC holds each subscribers secret key (Ki)
    calculates triplet for challenge / respond
    authentication with mobile
  • SIM is sent data and must calculate appropriate
    response
  • EIR is used to store mobile terminals serial
    numbers

17
GSM call setup Signalling
18
Signalling Air interface
  • Air Interface Signalling
  • Downlink signalling (to Mobile Station)
  • Relies on Bearer Control Channel (BCCH) set at
    fixed frequency per cell
  • Mobile Stations use this to lock-on to network
  • Mobile Stations periodically scan environment and
    report back other BCCH power levels to BSC to
    assist in handover
  • Access Grant Channel (AGCH) used to assign a
    Control or Traffic Channel to the mobile
  • Paging Channel (PCH) paging to find specific
    mobiles
  • Uplink signalling (from MS) more complicated
  • Random Access Channel (RACH) competitive
    multi-access mode using slotted ALOHA to request
    dedicated signalling channel (SDCCH)
  • Bidirectional channels include
  • Traffic Channels (TCH) Carrying full rate voice
    _at_ 13 kbps / half-rate voice
  • Standalone Dedicated Control Channel (SDCCH)
    used for updating location information or parts
    of connection set-up
  • Slow Associated Control Channel (SACCH) used to
    report radio conditions measurement reports
  • Fast Associated Control Channel (FACCH) uses
    stolen traffic channel capacity to add extra
    signalling capacity

19
Signalling Mobile Application Part interfaces
Network Signalling Um Air interface
signalling Abis Radio management A BSS
management, connection control mobility
management B Subscriber data, location
information, supplementary service
settings C Routing information requests D Exchange
of location-dependent subscriber data
subscriber management E Inter-MSC handover
signalling F Subscriber equipment identity
check G Inter-MSC handover, transfer of
subscriber data
20
ITU-T Common Channel Signalling System Number 7
A
Application Parts Actually carry the specific
messages for Mobile (MAP), Intelligent Network
(INAP) or Operations Maintenance (OMAP)
GSM interfaces B, C, D, E G carried as Mobile
Application Part
Standard Telephone User Part (TUP) Most basic
CSS7 signalling
Transaction Control Application Part component
responsible for carrying higher level
Application Parts to their correct destinations
ISO Layers 1 thro 7
Signalling Connection Control Part Functionally
equivalent to TCP layer, carries Connectionless
messages between Network elements
ISDN User Part Add functionality to permit ISDN
signalling (i.e. fully digital) between networks
  • Signalling 101
  • Line signalling tell the other end you want to
    make call
  • Register signalling tell the other end the
    destination of the call

Message Transfer Part Lowest level, permits
interconnection with underlying physical
transmission medium
21
PDH transmission composition of 32 channel E1
bearer
TS 0 Synchronisation Header
TS16 Signalling
ITU-T G.703 E1 link 2048 kbps 32 x 64 kbps
Timeslots
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
140 Mbps
Plesiochronous Digital Hierarchy (PDH)
34 Mbps
Voice / Data Timeslot
2 Mbps
Abis - Voice GSM Codec 4 x 13 kbps Timeslots
STM-16
Synchronous Digital Hierarchy (SDH) (SONET - USA)
STM-4
STM-1
22
Circuit-switched network architecture(Transmissio
n Signalling planes)
A
BSS Basestation Subsystem CCS7 Common Channel
Signalling 7 CO Central Office HLR Home Location
Register MSC Mobile Switching Centre SDH Synchrono
us Digital Hierarchy SSP Service Switching
Point STP Signalling Transfer Point
23
Call setup
A
  • Data held in HLR
  • Subscriber Subscription Data
  • International Mobile Subscriber Identity (IMSI)
  • Mobile Station ISDN (MS-ISDN)
  • Bearer teleservice subscriptions
  • Service restrictions
  • Parameters for additional services
  • Information on subscriber equipment
  • Authentication data
  • Tracking Routing Information
  • Mobile Station Roaming Number (MSRN)
  • Temporary Mobile Subscriber Identity (TMSI)
  • Current VLR address
  • Current MSC address
  • Local Mobile Subscriber Identity

24
GPRS Design
25
GPRS network elements
A
BG Border Gateway BSC Basestation
Controller BTS Basestation Transceiver GGSN Gatewa
y GPRS Support Node HLR Home Location
Register PCU Packet Control Unit PDN Packet Data
Network (X25) PLMN Public Land Mobile
Network SM-SC Short Message Service
Centre SGSN Serving GPRS Support Node VLR Visitor
Location Register
26
How GSM GPRS co-exist
A
OSS
BSC Basestation Controller BTS Basestation
Transceiver CCS7 Common Channel Signalling
7 CG Charging Gateway DHCP Dynamic Host
Configuration Protocol DNS Domain Name
Server GSN GPRS Serving Node (Serving /
Gateway) HLR Home Location Register IWF Interworki
ng Function (Circuit / Packet) LIAN Legal
Intercept Attendance Node MAP Mobile Application
Part (CCS7) MSC Mobile Switching Centre (Serving
/ Gateway) OSS Operational Support System
PCU Packet Control Unit PSTN Public Switched
Telephony Network VLR Visitor Location
Register XCDR Transcoder (16 / 64kbps coding)
Voice or Data link
Signalling Name of Interface
27
GPRS key information
  • Four Coding Schemes defined
  • CS1 9.05 kbit / second per timeslot
  • CS2 13.40
  • CS3 15.60
  • CS4 21.40
  • Higher speed Trade off of Forward Error
    Correction hence quality
  • Three Handset Types defined
  • Class A simultaneous voice data
  • Class B voice or data only at one time
  • Class C data only
  • GSM offsets uplink timeslots (Ts) from downlink
    by 3 to save on radio transmit / receive hardware
  • Therefore todays handsets are typically
  • 1 Ts downlink
  • 2 to 3 Ts uplink
  • Class B
  • CS1 CS2 capable
  • Equals 3 x 13.40 40.20 kbit/s maximum
  • Handsets can exceed this limit
  • But cost more
  • Use more power etc,

Downlink
Uplink
28
Protocol layers in GPRS
BSSGP Basestation System GPRS Protocol GSM
RF Radio Frequency GTP Gateway Tunnelling
Protocol LLC Logical Link Control MAC Medium
Access Control RLC Radio Link Control SNDCP Subnet
work Dependent Convergence Protocol
29
Mobility management
  • Mobility management
  • Attach
  • Know who is the MS
  • Know what the user is allowed to do
  • Detach
  • Leave the system
  • Location updates
  • Know location of MS
  • Route mobile terminated (MT) packets to MS
  • GPRS Service Descriptions
  • Point-to-Point
  • Connection-orientated (X25)
  • Connection-less (IPv4 / IPv6)
  • Point-to-Multipoint (Release 2)
  • Multicast
  • Groupcast
  • Short Message Service (SMS)
  • Packet Data Protocol (PDP) Contexts
  • Every mobile must have an address for each PDP
    Context in use
  • Addresses are statically or dynamically assigned
  • Context information includes
  • PDP Type
  • PDP address (optional)
  • Quality of Service (5 classes Service
    Precedence / Reliability / Delay / Throughput
    Maximum Mean)
  • SGSN has main control of QoS

30
GPRS dimensioning
  • 900MHz UK Network
  • 7 Timeslots per Carrier
  • 1 to 6 RF carriers / cell
  • 1 to 3 cells / BTS
  • 5,000 BTS
  • 250 BSC
  • 50 MSC
  • 10 GMSC
  • GPRS
  • SGSN c.10,000 simultaneous users
  • GGSN c.45,000 simultaneous users
  • 10 to 1 contention ratio
  • Dimensioning
  • 8 million subscribers
  • 10 GPRS handset penetration
  • 800,000 users
  • 101 Activity factor
  • 101 x 800,000 80,000 simultaneous users
  • 8 SGSN / 2 GGSN
  • Exact dimensioning depends on
  • Number of users
  • Geography
  • Population density
  • Data profile activity
  • GPRS growth

31
Evolution towards UMTS All IP core
GSM GPRS
Packet Gateway
Circuit Gateway
All IP Packet Network
Call Control Server
BTS
RNC Server
BTS
BSC
UMTS Node B
BTS
3rd Generation UMTS
32
Further Reading
  • GSM Switching, Services and Protocols Jörg
    Eberspöcher Hans-Jörg Vögel, John Wiley Sons,
    2000
  • GPRS General Packet Radio Service Regis J.
    Bud Bates, McGraw-Hill Telecom Professional,
    2002
  • GPRS Networks Geoff Sanders, Lionel Thorens,
    Manfred Reisky, Oliver Rulik, Stefan Deylitz,
    John Wiley Sons, 2003
Write a Comment
User Comments (0)
About PowerShow.com
