Sensitivity of PCA for Traffic Anomaly Detection

1
Sensitivity of PCA for Traffic Anomaly Detection

• Haakon Ringberg,
• Augustin Soule,
• Jennifer Rexford,
• Christophe Diot
• Princeton University,
• Thomson

2
Outline

• Background and motivation
• Traffic anomaly detection
• PCA and subspace approach
• Problems with methodology
• Future directions
• Conclusion

3
A network in the Internet
4
Network anomalies
We want to be able to detect these anomalies!
5
Network anomaly detectors

• Monitor health of network
• Real-time reporting of anomalies

6
Principal Components Analysis (PCA) Benefits

• Finds correlations across multiple links
• Network-wide analysis
• Lakhina SIGCOMM04
• Demonstrated ability to detect wide variety of
  anomalies
• Lakhina IMC04
• Subspace methodology
• We use same software

7
Principal Component Analysis
Coordinate transformation method
Original Data
X2
X1
8
PCA on OD flows

x

• Each principal axis in the direction of maximum
  (remaining) energy
• Ordered by amount of energy they capture.
• Eigenflow set of OD flows mapped onto a
  principal axis a common trend
• Ordered by most common to least common trend.
• An OD flow is a weighted sum of eigenflows.

9
Pictorial overview of subspace methodology

• Training separate normal anomalous traffic
  patterns
• Detection find spikes
• Identification find original spatial location
  that caused spike (e.g. router, flow)

10
Overview of issues with subspace methodology

• Defining normalcy can be challenging
• Tunable knobs
• Contamination
• PCAs coordinate remapping makes it difficult to
  identify the original location of an anomaly

11
Data used

• Géant and Abilene networks
• IP flow traces
• 21/11 through 28/11 2005
• Anomalies were manually verified

12
Outline

• Background and motivation
• Problems with approach
• Sensitivity to its parameters
• Contamination of normalcy
• Identifying the location of detected anomalies
• Future directions
• Conclusion

13
Sensitivity to topk

• PCA separates normal from anomalous traffic
  patterns
• Works because top PCs captures a large fraction
  of variance
• Most of the variance is due to periodic trends

14
Sensitivity to topk

• Where is the line drawn between normal and
  anomalous?
• What is too anomalous?

15
Sensitivity to topk
Very sensitive to number of principal components
included!
16
Sensitivity to topk

• Sensitivity wouldnt be an issue if we could
  tune topk parameter
• Weve tried many different methods
• - 3s deviation heuristic
• - Cattells Scree Test
• - Humphrey-Ilgen
• - Kaisers Criterion
• None are reliable

17
Contamination of normalcy

• What happens to large anomalies?
• They become part of the normalcy
• Therefore they are included among top PCs
• Pollutes definition of normal
• In our study, the outage to the left affected
  75/77 links
• Only detected on a handful!

18
Identifying anomaly locations

• Spikes when state vector projected on anomaly
  subspace
• But network operators dont care about this
• They want the offending link, router, flow, etc
• How do we find the original location of the
  anomaly?

19
Identifying anomaly locations

• Previous work used a simple heuristic
• Associate detected spike with k flows with the
  largest contribution to the state vector v
• No clear a priori reason for this association
• Causes heavy hitter phenomena

20
Outline

• Background and motivation
• Problems with approach
• Conclusion
• Addressable problems, versus
• Fundamental problems
• Future directions

21
Conclusion addressable

• PCA is sensitive to its parameters
• More robust methodology required
• Training defining normalcy (topk, whichk)
• Detection tuning threshold
• Identification better heuristic
• Previous work used same data and optimized
  parameter settings as Lakhina et al.
• But these concerns might be addressable

22
Conclusion fundamental

• We dont know what normal is
• Disconnect between objective functions
• PCA finds variance
• We seek periodicity
• PCAs strengths can be weaknesses
• Transformation good at detecting correlations
• Causes difficulty in identifying anomaly
  location
• Are other methods are more appropriate?
• We require a standardized evaluation framework

23
Defining normalcy

• Large anomalies can cause a spike in first few
  PCs
• Diminishes effectiveness
• But we can presumably smooth these out (WMA)
• But first PCs arent always periodic
• whichk instead of topk?
• Initial results suggest this might be challenging
  also

24
Fundamental disconnect between objective functions

• PCA is optimal at finding orthogonal vectors
  ordered by captured variance
• But variance need not correspond to normalcy
  (i.e. periodicity)
• When do they coincide?

25
Thanks!Questions?

• Augustin Soule, Thomson
• http//www.thlab.net/asoule
