Model Checking Software with Boolean Programs

1
Model Checking Software with Boolean Programs
Thomas Ball Sriram K. Rajamani
Rupak Majumdar Todd Millstein
http//research.microsoft.com/slam/
2
Hardware Verification
Temporal Safety Properties
Toolset (Model checker)
System Components
3
SLAM Linking Designs to Implementations
Temporal Safety Properties
Toolset
System Components
4
Outline

• What is the model schema?
• Boolean programs
• How do we model-check the model?
• Bebop
• How do we discover the model?
• Iterative refinement
• Future Directions

5
Boolean Programs

• Model for representing abstractions of imperative
  programs in C, C, Java, etc.
• Features
• Boolean variables
• Control-flow sequencing, conditionals, looping,
  GOTOs
• Procedures
• Call-by-value parameter passing
• Recursion
• Control non-determinism

6
Model schema Boolean programs

• bool x,y
• 1 while (true)
• 2 if(x y)
• 3 y !x
• else
• 4 x !x
• 5 y !y
• 6 if (?) break
• 7 if(x y)
• 8 assert (false)

• Intent Each boolean variable represents a
  predicate
• (i lt j)
• (pi) ( (int) p j)
• (p ? T), where T is a shape type that
  describes acyclic linked lists
• Cousot-CousotGraf-Saidi

7
Reachability
bool x,y 1 while (true) 2 if(x y)
3 y !x else 4 x
!x 5 y !y 6 if (?) break
7 if(x y) 8 assert (false)
State (label, valuation to variables) Finite
number of states! Can compute reachable states
using model checking
8
Inter-procedural case

• Explicit stack representation is bad
• Implicitly represent stack instead
• Similar to
• model checking push-down automata
• interprocedural dataflow analysis
• Hopcroft-Ullman Sharir-Pnueli Steffen
  Knoop-Steffen Reps-Horwitz-SagivBouajjani-Esp
  arza-Maler Esparza-Hansel-Rossmanith-Schwoon

9
Results (1)

• Reachability in boolean programs can be reduced
  to context-free language reachability
• Symbolic version of Reps-Horwitz-Sagiv, POPL95
  interprocedural data flow analysis
• Complexity of algorithm is O( E ? 2n)
• E size of interprocedural control flow graph
• n max. number of variables in the scope of
  any label

10
Results (2)

• Program variables control flow
• Exploit locality of variable scoping
• Use standard compiler optimizations
• Bebop uses hybrid representation
• Explicit representation of control flow
• Implicit representation of reachable states via
  BDDs
• Hierarchical trace generation

11

• do
• //get the write lock
• KeAcquireSpinLock(devExt-gtwriteListLock)
• nPacketsOld nPackets
• request devExt-gtWriteListHeadVa
• if(request request-gtstatus)
• devExt-gtWriteListHeadVa request-gtNext
• KeReleaseSpinLock(devExt-gtwriteListLock)
• irp request-gtirp
• if(request-gtstatus gt 0)
• irp-gtIoStatus.Status STATUS_SUCCESS
• irp-gtIoStatus.Information request-gtStatus
• else
• irp-gtIoStatus.Status STATUS_UNSUCCESSFUL
• irp-gtIoStatus.Information request-gtStatus
• SmartDevFreeBlock(request)

12

• do
• //get the write lock
• KeAcquireSpinLock(devExt-gtwriteListLock)
• nPacketsOld nPackets
• request devExt-gtWriteListHeadVa
• if(request request-gtstatus)
• devExt-gtWriteListHeadVa request-gtNext
• KeReleaseSpinLock(devExt-gtwriteListLock)
• irp request-gtirp
• if(request-gtstatus gt 0)
• irp-gtIoStatus.Status STATUS_SUCCESS
• irp-gtIoStatus.Information request-gtStatus
• else
• irp-gtIoStatus.Status STATUS_UNSUCCESSFUL
• irp-gtIoStatus.Information request-gtStatus
• SmartDevFreeBlock(request)

Question Is locking protocol respected?
Dynamic Analysis Dont know
Traditional Static Analysis Dont know
13

• do
• //get the write lock
• KeAcquireSpinLock(devExt-gtwriteListLock)
  FSM(Acquire)
• nPacketsOld nPackets
• request devExt-gtWriteListHeadVa
• if(request request-gtstatus)
• devExt-gtWriteListHeadVa request-gtNext
• KeReleaseSpinLock(devExt-gtwriteListLock)
• FSM(Release)
• irp request-gtirp
• if(request-gtstatus gt 0)
• irp-gtIoStatus.Status STATUS_SUCCESS
• irp-gtIoStatus.Information request-gtStatus
• else
• irp-gtIoStatus.Status STATUS_UNSUCCESSFUL
• irp-gtIoStatus.Information request-gtStatus

do FSM(Acquire) if()
FSM(Release) if() else
while() FSM(Release)

14

• do
• //get the write lock
• KeAcquireSpinLock(devExt-gtwriteListLock)
  FSM(Acquire)
• nPacketsOld nPackets
• request devExt-gtWriteListHeadVa
• if(request request-gtstatus)
• devExt-gtWriteListHeadVa request-gtNext
• KeReleaseSpinLock(devExt-gtwriteListLock)
• FSM(Release)
• irp request-gtirp
• if(request-gtstatus gt 0)
• irp-gtIoStatus.Status STATUS_SUCCESS
• irp-gtIoStatus.Information request-gtStatus
• else
• irp-gtIoStatus.Status STATUS_UNSUCCESSFUL
• irp-gtIoStatus.Information request-gtStatus

do FSM(Acquire) (2) if()
FSM(Release) if() else
while() FSM(Release)

15

• do
• //get the write lock
• KeAcquireSpinLock(devExt-gtwriteListLock)
  FSM(Acquire)
• nPacketsOld nPackets
• request devExt-gtWriteListHeadVa
• if(request request-gtstatus)
• devExt-gtWriteListHeadVa request-gtNext
• KeReleaseSpinLock(devExt-gtwriteListLock)
• FSM(Release)
• irp request-gtirp
• if(request-gtstatus gt 0)
• irp-gtIoStatus.Status STATUS_SUCCESS
• irp-gtIoStatus.Information request-gtStatus
• else
• irp-gtIoStatus.Status STATUS_UNSUCCESSFUL
• irp-gtIoStatus.Information request-gtStatus

do FSM(Acquire) (2) if()
FSM(Release) if() else
while() FSM(Release)

16
/bnPacketsOldnPackets / do
FSM(Acquire) b 1 if()
FSM(Release) if() else
b b ? 0 while( !b )
FSM(Release)
do //get the write lock KeAcquireSpinLock(
devExt-gtwriteListLock) FSM(Acquire)
nPacketsOld nPackets request
devExt-gtWriteListHeadVa if(request
request-gtstatus) devExt-gtWriteListHeadVa
request-gtNext KeReleaseSpinLock(devExt-gtwriteL
istLock) FSM(Release) irp
request-gtirp if(request-gtstatus gt
0) irp-gtIoStatus.Status STATUS_SUCCESS i
rp-gtIoStatus.Information request-gtStatus
else irp-gtIoStatus.Status
STATUS_UNSUCCESSFUL irp-gtIoStatus.Information
request-gtStatus SmartDevFreeBlock(request
) IoCompleteRequest(irp, IO_NO_INCREMENT) nP
ackets while (nPackets !
nPacketsOld) KeReleaseSpinLock(devExt-gtwriteLis
tLock) FSM(Release)
17
P
Is L reachable in P?
Model checker
Abstractor
Path Simulator
18
Discover and Refine Abstractions on Demand

• Given a reachability query in program P
• Check reachability on the boolean program
  abstraction B of P with bebop
• Use path simulation ( ) on P to discover
  spurious counterexamples (in B)
• Use C predicate abstractor (c2bp) to refine B

simcl
sexC
19
Summary Technical

• Boolean Programs
• a model for representing program abstractions
• Bebop
• reachability analysis for boolean programs
• or, a path-sensitive dataflow engine
• Iterative refinement of Boolean programs
• use of path simulation (simcl) and automated
  predicate abstraction (c2bp)
• generate abstract explanations of path
  infeasibility

20
Making Analysis Influential

• Show the analysis addresses a significant problem
• Check correctness of Device Driver Code
• Convince us it really works
• Demonstrate on real code bases
• http//www.microsoft.com/ddk

21
Future DirectionsShort Term

• Summer
• Model check a safety property of an NT driver
• Autumn
• Specification language
• Generate source-level instrumentation directly
  from specification
• Winter
• Model check many drivers automatically, driven by
  a single specification

22
Long Term

• Tackle new domains
• Network protocols
• Protocols for fault-tolerant computing
• ComApps components
• Extensions to framework
• Concurrency (Ball-Chaki-Rajamani)
• Heap data structures

23
The Device Driver Challenge

• Device Driver Code
• http//www.microsoft.com/ddk/
• Device Drivers, Deconstructed
• Description of interfaces/abstractions
• Catalog of temporal properties
• Ball DeLine Rajamani
• Coming, January 2001

24
Open Problems

• Specification language and automatic annotation
  of source programs
• Engler00
• Generation of abstract predicates by widening

25
Conclusions

• Bring reliability guarantees of hardware to
  system software
• Encourage use of specification by linking specs
  to code via analysis
• Build tools to enable design for reliability and
  testing

26

• Software Productivity Tools
• Microsoft Research
• http//research.microsoft.com/slam/

27
Open Questions

• Which analyses are right for which problems?
• How to get difficult analyses to scale well?
• Are there soundness/completeness tradeoffs?
• How can static analysis / common design patterns
  help guide state space search?

28
Open Questions (2)

• Are there opportunities to combine analyses?
• Can we use a cheap flow-insensitive algorithm to
  focus a more expensive algorithm on juicy places?
• Can we use expensive local path-sensitive
  algorithms to improve global flow-insensitive
  algorithms?
