EECE631 Microcomputer System Design

1
EECE631 Microcomputer System Design

• Spring 2008
• Lecture 1 Introduction
• Chris Lewis
• clewis_at_ksu.edu
• www.eece.ksu.edu/clewis

2
Misc

• Grades
• Worst Case
• 90,80,70,60

• Work Hard
• Learn from your mistakes
• Dont Cheat
• Yourself
• Your classmates

3
Outline

• Course Outline
• Course Emphasis
• Lab outline
• References - where to get more info.
• Terminology
• Software

4
Course Outline

• Software (5 weeks)
• - Hardware and Assembly language
• - Debugging and Debuggers
• - C programming for Microprocessors
• Hardware (5 weeks)
• - Exceptions and Interrupts Testing
• - onboard peripherals
• Systems (4 weeks)
• - Timing
• - Other Micros and future trends
• Exams (1 week)

5
Outline

• Course Outline
• Course Emphasis
• Lab outline
• References - where to get more info.
• Terminology
• Software

6
Course Emphasis

• Course Objectives
• - Embedded System Emphasis
• Program can reside in ROM
• Software interface to outside world
• - Overall project framework
• - Hands On
• Demonstrate programs work

7
Outline

• Course Outline
• Course Emphasis
• Lab Outline
• References - where to get more info.
• Terminology
• Software

8
Lab Outline

• Software - Emphasis on C Programming
• - Assembly
• - Debuggers
• - C programming and assembly relationship
• Hardware
• - Testing
• - MIOS and Discrete I/O
• - A/D and D/A conversion
• - SPI
• - PWM and wave form capture
• Project
• - 2 person combines hardware and software
• - Program in C

9
Outline

• Course Outline
• Course Emphasis
• Lab outline
• References - where to get more info.
• Terminology
• Software

10
References

• Course Web Site
• - http//www.eece.ksu.edu/clewis
• Books
• -Users and Reference Manuals for Processor
• - Any C programming book
• - Michael Barr, Programming Embedded Systems in
  C and C ,1999, OReilly Associates,
  Inc.(Pub) (Recommended)
• - Any ARM Programming Book

11
Outline

• Course Outline
• Course Emphasis
• Lab outline
• References - where to get more info.
• Terminology
• Software

12
Cycle Terminology
Clock Cycle - time for the internal clock to
complete one cycle Bus Cycle - Time for processor
to bring a word from memory. Shown as two clock
cycles in drawing. May include wait states making
for a variable number of clock cycles Instruction
cycle - time for an instruction to complete.
Shown as two bus cycles or four clock cycles.
Time may depend on instruction.
clock cycle


-----------
Bus cycle
Instruction cycle
13
Terminology

• RISC
• CISC
• SOC
• ASIC
• Nibble
• Byte
• Half-Word
• Word
• Double Word
• Quad Word

14
Terminology

• RISC Reduced Instruction Set Computer
• CISC
• SOC
• ASIC
• Nibble
• Byte
• Half-Word
• Word
• Double Word
• Quad Word

15
Terminology

• RISC Reduced Instruction Set Computer
• CISC Complex Instruction Set Computer
• SOC
• ASIC
• Nibble
• Byte
• Half-Word
• Word
• Double Word
• Quad Word

16
Terminology

• RISC Reduced Instruction Set Computer
• CISC Complex Instruction Set Computer
• SOC System on a Chip
• ASIC
• Nibble
• Byte
• Half-Word
• Word
• Double Word
• Quad Word

17
Terminology

• RISC Reduced Instruction Set Computer
• CISC Complex Instruction Set Computer
• SOC System on a Chip
• ASIC Application Specific Integrated Circuit
• Nibble
• Byte
• Half-Word
• Word
• Double Word
• Quad Word

18
Terminology

• RISC Reduced Instruction Set Computer
• CISC Complex Instruction Set Computer
• SOC System on a Chip
• ASIC Application Specific Integrated Circuit
• Nibble 4 bits
• Byte
• Half-Word
• Word
• Double Word
• Quad Word

19
Terminology

• RISC Reduced Instruction Set Computer
• CISC Complex Instruction Set Computer
• SOC System on a Chip
• ASIC Application Specific Integrated Circuit
• Nibble 4 bits
• Byte 8 bits
• Half-Word
• Word
• Double Word
• Quad Word

20
Terminology

• RISC Reduced Instruction Set Computer
• CISC Complex Instruction Set Computer
• SOC System on a Chip
• ASIC Application Specific Integrated Circuit
• Nibble 4 bits
• Byte 8 bits
• Half-Word 16 bits (on a 32 bit machine only)
• Word
• Double Word
• Quad Word

21
Terminology

• RISC Reduced Instruction Set Computer
• CISC Complex Instruction Set Computer
• SOC System on a Chip
• ASIC Application Specific Integrated Circuit
• Nibble 4 bits
• Byte 8 bits
• Half-Word 16 bits (on a 32 bit machine only)
• Word 32 bits (Normally internal data bus size)
• Double Word
• Quad Word

22
Terminology

• RISC Reduced Instruction Set Computer
• CISC Complex Instruction Set Computer
• SOC System on a Chip
• ASIC Application Specific Integrated Circuit
• Nibble 4 bits
• Byte 8 bits
• Half-Word 16 bits (on a 32 bit machine only)
• Word 32 bits (Normally internal data bus size)
• Double Word 64 bits (on a 32 bit machine only)
• Quad Word

23
Terminology

• CISC Complex Instruction Set Computer
• SOC System on a Chip
• ASIC Application Specific Integrated Circuit
• Nibble 4 bits
• Byte 8 bits
• Half-Word 16 bits (on a 32 bit machine only)
• Word 32 bits (Normally internal data bus size)
• Double Word 64 bits (on a 32 bit machine only)
• Quad Word 128 bits (on a 32 bit machine only)

24
Terminology

• Big-Endian Bit Ordering
• Big-Endian Byte Ordering
• Little-Endian Bit Ordering
• Little-Endian Byte Ordering

25
Terminology

• Big-Endian Bit Ordering left most bit is bit 0,
  right most bit is N-1 on N bit Machine (The ARM
  default)
• Big-Endian Byte Ordering - byte 0 is stored in
  the lowest address, byte N-1 is stored in the
  highest address on N byte transfer (The ARM
  default)
• Little-Endian Bit Ordering
• Little-Endian Byte Ordering

26
Care about Endians

• Define a C style data structure on your embedded
  processor.
• Transmit each byte to a PC via a serial port
• Receive these bytes in a buffer on a PC
• Cast the buffer to the same structure
• Result Garbage

27
Big-Endian
28
Big-Endian
29
Terminology

• Big-Endian Bit Ordering left most bit is bit 0,
  right most bit is N-1 on N bit Machine
• Big-Endian Byte Ordering - byte 0 is stored in
  the lowest address, byte N-1 is stored in the
  highest address on N byte transfer
• Little-Endian Bit Ordering - left most bit is bit
  N-1, right most bit is 0 on N bit Machine (Like
  MC68HC11)
• Little-Endian Byte Ordering - byte N-1 is stored
  in the lowest address, byte 0 is stored in the
  highest address on N byte transfer (The MC68HC11)

30
Little Endian
31
Little-Endian
32
Outline

• Course Outline
• Course Emphasis
• Lab outline
• References - where to get more info.
• Terminology
• Software Terminology

33
Software Terminology

• Machine Language
• Assembly Language
• High Level Language
• Assembler
• Compiler
• Linker
• Emulator
• Debugger
• Source File
• Listing File
• Object File
• Download File

34
Software Terminology

• Machine Language The language of 1s and 0s.
  Only language the computer understands. Lowest
  level programming language.

35
Software Terminology

• Assembly Language A programming language that
  allows the use of mnemonics in place of binary
  machine language instructions
• Assembler A program that allows the computer to
  translate assembly language to machine language
• Object file A machine language program that is
  the result of assembly process performed by an
  assembler

36
Assembly Language Statement

• Standard format
• Label Mnemonic Operand(s) Comments
• Optional
• As required, separated by commas
• Optional and may require special beginning
  character
• The four fields are separated by one or more
  spaces or tabs.

37
Software Terminology

• High Level Language Programming language that
  uses English language words and mathematical
  symbols, requires no knowledge of the computer
• Compiler A program that translates a complete
  high-level language program to a machine language
  object program. Goes through an assembler. The
  results of the assembler may or may not be
  visible
• Linker A program that combines source-file
  object code with object code from library files
  and other related files and places the completed
  code in specified memory for specific processor.

38
Software Flow
Compiler
Asm Code
Source Code C
Assembler
File.c
File.lst File.s
File.elf
Debugger
Object Code
Linker
Executable
File.o
File.hex
39
Software Terminology

• Source File A program written in either
  assembly or a high-level language. Normally the
  top level file.
• Listing File A text file that is generated by
  either the assembler or compiler that shows the
  source code instructions and any error messages
  that might have been detected during the
  compilation and/or assembly process.
• Download File The machine code in the proper
  format to download into a specific machine

40
Software Terminology

• Emulator A computer program that simulates a
  specific microprocessor and allows you to run
  object code generated by an assembler or compiler
  to test it without having to have the specific
  microprocessor hardware
• Debugger A computer program that controls
  program execution on specific hardware and shows
  the internal operation of the computer.

41
Summary

• Course description
• lecture
• Lab
• Project
• Terminology
• Hardware
• Software
• Homework Assignment

42
Next Time

• Homework 1 due at beginning of class
