Design of a Diversified Router: TCAM Usage

1
Design of aDiversified Router TCAM Usage
John DeHartjdd_at_arl.wustl.edu http//www.arl.wust
l.edu/arl
2
TCAM Issues

• CAM Size
• Data 256K 72-bit entries
• Organized into Segments.
• Mask 256K 72-bit entries
• Segments
• Each Segment is 8k 72-bit entries
• 32 Segments
• Minimum database size is therefore 8K 72-bit
  entries.
• Segments are not shared between Databases.
• Do databases wider than 72-bits use multiple
  parallel segments or do they use sequential
  entries in a segment to make up the long entries?
• Sequential entries are used to comprise one
  longer entry.
• 36b DB has 16K entries per segment
• 72b DB has 8K entries per segment
• 144b DB has 4K entries per segment
• 288b DB has 2K entries per segment
• 576b DB has 1K entries per segment
• Can a segment be dynamically added to a Database
  as it grows?
• Yes, more on this feature in a future issue of
  the IDT User Manual

3
TCAM Issues

• Number of Databases available 16
• Database Core Sizes 36b, 72b, 144b, 288b, 576b
• Key and Entry size
• Can be different for each Database.
• lt Database Core Size
• Result Type
• Absolute Index
• Database Relative Index
• Memory Pointer
• TCAM Associated Data of width 32, 64 or 128 bits
• Memory Constraints
• TCAM Associated Data
• 512K x 36 bit ZBT SRAM
• Supports 128K 128-bit Results
• If used for Rx and Tx then 64K in each direction
• IXP QDR SRAM Channel
• 2 x 2Mx18 (effective 4M x 18b)
• 4 times as much as the TCAM ZBT SRAM.
• Supports 512K 128-bit Results

4
TCAM Issues

• Mask Registers
• When are these used?
• I think we will need one of these for each
  database that is to be used in a Multi Database
  Lookup (MDL), where the database entries do not
  actually use all the bits in the corresponding
  core size.
• For example a 32-bit lookup would have a core
  size of 36 bits and so would need a GMR
  configured as 0xFFFFFFFF00 to mask off the low
  order 4 bits when it is used in a MDL where there
  are larger databases also being searched.
• 64 72-bit Global Mask Registers (GMR)
• Can be combined for different database sizes
• 36-bit databases have 31 out of a total of 64
  GMRs
• A bit in the configuration for a database selects
  which half of the GMRs can be used
• A field in each lookup command selects which
  specific GMR is to be used with the lookup key.
• Value of 0x1F (31) is used in command to indicate
  no GMR is to be used. Hence, 36-bit lookups
  cannot use all 32 GMRs in its half.
• 72-bit databases have 31 out of a total of 64
  GMRs
• A bit in the configuration for a database selects
  which half of the GMRs can be used
• A field in each lookup command selects which
  specific GMR is to be used with the lookup key.
• Value of 0x1F (31) is used in command to indicate
  no GMR is to be used. Hence, 72-bit lookups
  cannot use all 32 GMRs in its half.
• 144-bit lookups have 32 GMRs available to it.
• 288-bit lookups have 16 GMRs available to it.
• 576-bit lookups have 8 GMRs available to it.
• Each lookup command can have one GMR associated
  with it.

5
TCAM Issues

• Types of Lookups supported
• Lookup (Direct)
• Multi-Hit Lookup (Direct)
• Simultaneous Multi-Database Lookup (Direct)
• Multi-Database Lookup (Indirect)
• Simultaneous Multi-Database Lookup (Indirect)
• Re-Issue Multi-Database Lookup (Indirect)
• Types of Databases
• Longest Prefix Match (LPM)
• Uses Ternary capability of TCAM
• Exact Match (EM)
• Does not use Ternary capability of TCAM
• Best/Range Match What we typically call General
  Match.
• Uses Ternary capability of TCAM
• LC
• All Databases for RX and TX will be Exact Match
• NP/MR
• Probably will support up to 3 databases
• Route Lookup (LPM)

6
TCAM Issues

• Performance Impacts
• IXP/TCAM Interface
• 16 bits wide
• 200 MHz QDR
• Effective 32bits per clock tick
• Example 128b results from ZBT SRAM via TCAM 4
  ticks ? max of 50M results/sec
• Key Size (200MHz, 16 bit Interface for commands)
• Rates are max PER LA-1 Interface, up to CAM Core
  max rate
• 32b (1W) 50M Lookups/sec (CAM Core
  constraint)
• 36b (2W) 50M Lookups/sec (CAM Core
  constraint)
• 64b (2W)100M Lookups/sec (Interface
  constraint)
• 72b (3W) 67M Lookups/sec (Interface
  constraint)
• 128b (4W) 50M Lookups/sec (Interface
  constraint)

7
TCAM Issues

• Performance Impacts (continued)
• Result Type
• Index or Pointer Types
• Key Size Max CAM Core lookup rate
• 36b 50M/sec
• 72b 100M/sec
• 144b 100M/sec
• 288b 50M/sec
• 576b 25M/sec
• Associated Data CAM Core rates
• These rates are Total across both LA-1 Interfaces
• Key Size (32b Result Rate, 64b Result Rate, 128b
  Result Rate)
• 36b 50, 50, 25
• 72b 100, 50, 25
• 144b 100, 50, 25

8
TCAM Performace Tables
9
TCAM Performace Graphs
10
TCAM Performace Graphs
11
LC Notes on TCAM Lookups

• The following slides show a way to use the TCAM
  for the lookups.
• Slight adjustments might be desirable depending
  on
• Ease of doing operations on non-byte length bit
  fields
• What we learn about methods for using the TCAM.
• Field and Identifier sizes
• MN id 32 bits
• MI id 16 bits (64K Meta Interfaces per Meta
  Router)
• MLI 16 bits (64K Meta Links per Substrate
  Link)
• Port 8 bits (256 Physical Interfaces per
  Line Card)
• QID 17 bits (128K Queues per Queue Manager)
• QM ID 3 bits (8 Queue Managers per LC or PE.)
• We probably can only support 4 QMs (2 bits)
• (64 Q-Array Entries) / (16 CAM entries) ? 4 QMs
  per SRAM Controller.

12
LC Notes on TCAM Lookups

• Lookup Key size options
• 32/36, 64/72, 128/144, 256/288, 512/576 (all in
  bits)
• Lookup Result options
• Absolute Index relative to beginning of TCAM
  array
• Database Relative Index relative to beginning of
  selected database
• Memory Pointer Index points to SRAM location of
  result data
• Associated Data 32, 64 or 128 bits of data
  associated with the lookup result.
• Associated Data is stored in ZBT SRAM attached to
  TCAM.
• TCAM Databases
• How many to use?
• 1 for TX and 1 for RX?
• 1 for TX and 1 for each of the SL Types on Rx (5
  types)?
• Other

13
LC TCAM Lookup Keys on RX

• Each SL Type will use a different Database on RX
• Thus we do not need an SL Type field in the Key
• SL Type ID will be used to identify which
  database to use
• P2P-DC(24b)
• SL Type ID 0x0
• Key Fields Port(8)/MLI(16)
• P2P-Tunnel(IPv4)(72b)
• SL Type ID 0x1
• Key Fields Port(8)/EtherType(16)/IPSrc(32)/MLI(16
  )
• P2P-VLAN0(72b)
• SL Type ID 0x2
• Key Fields Port(8)/EthSAddr(48)/MLI(16)
• MA(24b)
• SL Type ID 0x3
• Key Fields Port(8)/MLI(16)
• Legacy(24b)
• SL Type ID 0x4
• Key Fields Port(8)/EtherType(16)
• Key Fields

14
LC TCAM Lookup Keys on RX
Port(8b)
MLI(16b)
P2P-DC
24 bits
IPv4 Tunnel
72 bits
Port (8b)
MLI (16b)
IP SAddr (32b)
EtherType (16b) 0x0800
MA
Port (8b)
MLI (16b)
Ethernet SAddr (48b)
72 bits
P2P-VLAN0
Port(8b)
MLI(16b)
24 bits
Legacy
24 bits
Port (8b)
EtherType (16b) 0x0800

• Blue Shading Determine SL Type
• Black Outline Key Fields from pkt

DstAddr (6B)
DstAddr (6B)
SrcAddr (6B)
SrcAddr (6B)
Type802.1Q (2B)
Type802.1Q (2B)
TCI ? VLAN0 (2B)
TCI ? VLAN0 (2B)
TypeIP (2B)
TypeIP (2B)
Ver/HLen/Tos/Len (4B)
Ver/HLen/Tos/Len (4B)
ID/Flags/FragOff (4B)
ID/Flags/FragOff (4B)
TTL (1B)
TTL (1B)
ProtocolSubstrate (1B)
Protocol (1B)
Hdr Cksum (2B)
Hdr Cksum (2B)
Src Addr (4B)
Src Addr (4B)
Dst Addr (4B)
Dst Addr (4B)
MLI (2B)
IP Payload
LEN (2B)
Meta Frame
PAD (nB)
PAD (nB)
CRC (4B)
CRC (4B)
P2P-DC Configured
P2P-Tunnel
Legacy
15
LC Packet RX All SL Types
P2P-VLAN0
Multi-Access
P2P-DC
P2P-Tunnel
16
LC TCAM Lookup Results on RX

• Fields (68b/128b)
• It would be advantageous if this was 64 bits. The
  associated data SRAM with the NSE has widths of
  32, 64 or 128 bits.
• VLAN (16b)
• We could probably drop this to 12b since our
  switch is supposed to only support 4K VLANs but
  we might want to leave this open to switches
  supporting larger numbers of VLANs.
• MI (16b)
• Blade Eth Hdr (8b)
• Only needs to have the DAddr.
• We can control the MAC Addresses of the Blades,
  so lets say that 40 of the 48 bits are fixed and
  8 bits are assigned and stored in the Lookup
  Result. Even 8 bits is overkill but it leaves us
  some flexibility.
• SAddr can be configured and constant per LC
• First EtherType can be constant 802.1Q
• Second EtherType can be constant Substrate
• QID (20b)
• MnFlags(8b)
• NhAddr(60b) If needed

17
LC TCAM Lookup Results on RX

• Can we say there will be no Pass Through Meta
  Links where one side will be on a Multi Access
  and hence might need a NhAddr field?
• If so then we can drop the MnFlags and NhAddr
  fields from result
• Result size then becomes 60b
• Pass Through Meta Link Fields
• MnFlags(8b)
• NhAddr(nB)
• We have 60 bits left over that could be used for
  NhAddr
• If we need more, options
• Do a second lookup with the following fields to
  retrieve the Next Hop bits from another Database
  for NH Bits?
• Port (8b)
• VLAN (16b)
• MI (16b)
• If the size indicated in the MnFlags is greater
  than 60 bits, use put an Memory Pointer in the
  bits after the MnFlags and lookup the NhAddr in
  memory.
• We could even include 32 bits of the NhAddr in
  the original TCAM result and still have a memory
  pointer to get the rest. This might cut down on
  memory access time needed to retrieve the NhAddr.

18
Rx Handling NhAddr for Pass-Through MLs

• For Tx to handle Multi-Access Substrate Links we
  need to provide an ARP capability on behalf of
  the MetaNets.
• To do this we need the MRs to give the LCs a MN
  Next Hop Address that the LC-TX will do a lookup
  on to see if we have a MAC address for and if
  not, issue an ARP to request it.
• But, the LC does not know how large the MN NhAddr
  might be.
• Included in the MnFlags fields is the size so Tx
  can handle variable sizes.
• But what is a good limit?
• IPv4 is 32 bits
• IPv6 is 128 bits
• But IPv6 uses Neighbor Discovery to do what ARP
  does, and it does more.
• The MnFlags field has a 6 bit length in bytes, so
  it can be up to 63 bytes
• For Pass Through MetaLinks where one side is MA
  we need the LC-RX to have in its lookup result
  the Next Hop Address so the Tx can do the
  translation to MAC address in the same way.
• Can we assume that this wont happen?
• Actually it is probably fairly likely to happen
  on access links. Perhaps the MetaNet does not
  have a MR located at the first Substrate Router
  but its access MetaLinks pass-through
• If we find that we have to store the MnNhAddr in
  the Rx Result, I think we can make it variable
  sized by using Multi-Hit Lookups (MHL) and
  storing the same Key multiple times with
  different results for each one.
• Each subsequent result would be the additional
  bits to concatenate on to the MnNhAddr.
• In the Results Mailbox for a MHL, we can have at
  most
• 250 bits in 2 128-bit AD Results or 244 bits in 4
  64-bit AD Results or 232 bits in 8 32-bit AD
  Results
• So, lets assume that in general we dont need the
  NhAddr in the Rx entry. (next slide)

19
Rx Handling NhAddr for Pass-Through MLs

• Rx Result (61 bits)
• VLAN (16b)
• MI (16b)
• Blade Eth Hdr (8b)
• QID (20b)
• Continuation bit (1b)
• 0 no need for MnFlags and NhAddr, MHL should
  report MHit of 0
• 1 MnFlags and NhAddr contained in subsequent
  results, MHL should report MHit of 0.
• This then leaves us 3 more possible results to
  the MHL, giving us (361)-8 155 bits of Next
  Hop Address.
• We have to be careful when writing the entries
  for Rx
• We write the main and subsequent entries in the
  right order.
• I assume that the order of the results is based
  on the priority of the entries in the TCAM which
  is determined by order.
• The continuation bit is set correctly.
• Actually this is just a safety check. If we
  always do a MHL then the MH bit in the result
  should tell us if there are subsequent results.

20
LC TCAM Lookups on TX

• Key
• VLAN(16b)
• TxMI(16b)
• Result
• The Lookup Result for TX will consist of several
  parts
• Lookup Result
• Constant fields
• Calculated fields
• Fields that can be stored in Local Memory
• Some of these are common across all SL Types
• Other fields are specific to each SL Type
• Common across all SL Types (96b)
• From Result (48b)
• SL Type(4b)
• Port(8b)
• MLI(16b)
• QID (20b)
• Local Memory (48b)
• Eth Hdr SA (48b) tied to Port

21
LC TCAM Lookups on TX

• Key
• VLAN(16b)
• TxMI(16b)
• Result
• Common across all SL Types (96b)
• From Result (48b)
• SL Type(4b)
• Port(8b)
• MLI(16b)
• QID (20b)
• Local Memory (48b)
• Eth Hdr SA (48b) tied to Port
• SL Type Specific Headers
• P2P-DC Hdr (64b)
• Constant (16b)
• EtherType (16b) Substrate
• Calculated (0b)
• From Result (48b)
• Eth DA (48b)

22
LC TCAM Lookups on TX

• Key
• VLAN(16b)
• TxMI(16b)
• Result
• Common across all SL Types (96b)
• From Result (48b)
• SL Type(4b)
• Port(8b)
• MLI(16b)
• QID (20b)
• Local Memory (48b)
• Eth Hdr SA (48b) tied to Port
• SL Type Specific Headers
• MA Hdr (64b)
• Constant (16b)
• EtherType (16b) Substrate
• Calculated (0b)
• ARP Lookup on NhAddr (Is ARP cache another
  database in TCAM?) (48b)
• Eth DA (48b)

23
LC TCAM Lookups on TX

• Key
• VLAN(16b)
• TxMI(16b)
• Result
• Common across all SL Types (96b)
• From Result (48b)
• SL Type(4b)
• Port(8b)
• MLI(16b)
• QID (20b)
• Local Memory (48b)
• Eth Hdr SA (48b) tied to Port
• SL Type Specific Headers
• MA with VLAN Hdr (96b)
• Constant (32b)
• EtherType1 (16b) 802.1Q
• EtherType2 (16b) Substrate
• Calculated (0b)
• ARP Lookup on NhAddr (Is ARP cache another
  database in TCAM?) (48b)

24
LC TCAM Lookups on TX

• Key
• VLAN(16b)
• TxMI(16b)
• Result
• Common across all SL Types (96b)
• From Result (48b)
• SL Type(4b)
• Port(8b)
• MLI(16b)
• QID (20b)
• Local Memory (48b)
• Eth Hdr SA (48b) tied to Port
• SL Type Specific Headers
• P2P-VLAN0 Hdr (80b)
• Constant (16b)
• EtherType1 (16b) 802.1Q
• EtherType2 (16b) Substrate
• Calculated (0b)
• From Result (64b)

25
LC TCAM Lookups on TX

• Result (continued)
• Common across all SL Types (96b)
• From Result (48b)
• SL Type(4b)
• Port(8b)
• MLI(16b)
• QID (20b)
• Local Memory (48b)
• Eth Hdr SA (48b) tied to Port
• SL Type Specific Headers
• P2P-Tunnel Hdr for IPv4 Tunnel (224b)
• Constant (64b)
• Eth Hdr EtherType (16b) 0x0800
• IPHdr Version(4b)/HLen(4b)/Tos(8b) (16b) All can
  be constant?
• IP Hdr Flags(3b)/FragOff(13b) (16b) what is our
  stance on Fragments? If never used, these are
  constants, if it is possible we will have to use
  them, then this has to be calculated. Either way,
  shouldnt be in Result
• IP Hdr TTL (8b) ???
• IP Hdr Proto (8b) Substrate
• Calculated (48b)
• IP Hdr Len(16b) needs to be calculated for each
  packet sent, so shouldnt be in Result.

26
LC TCAM Lookups on TX

• Key
• VLAN(16b)
• TxMI(16b)
• Result
• Common across all SL Types (96b)
• From Result (48b)
• SL Type(4b)
• Port(8b)
• MLI(16b)
• Ignored for Legacy Traffic
• QID (20b)
• Local Memory (48b)
• Eth Hdr SA (48b) tied to Port
• SL Type Specific Headers
• Legacy (IPv4) with VLAN Hdr (96b)
• Constant (16b)
• EtherType1 (16b) 802.1Q
• Calculated (0b)
• ARP Lookup on NhAddr (Is ARP cache another
  database in TCAM?) (48b)

27
LC TCAM Lookups on TX

• Key
• VLAN(16b)
• TxMI(16b)
• Result
• Common across all SL Types (96b)
• From Result (48b)
• SL Type(4b)
• Port(8b)
• MLI(16b)
• Ignored for Legacy Traffic
• QID (20b)
• Local Memory (48b)
• Eth Hdr SA (48b) tied to Port
• SL Type Specific Headers
• Legacy (IPv4) without VLAN Hdr (64b)
• Constant (0b)
• Calculated (0b)
• ARP Lookup on NhAddr (Is ARP cache another
  database in TCAM?) (48b)
• Eth DA (48b)

28
SUMMARY LC TCAM Lookups

• Rx Key 72 bits
• Rx Result Size 61 bits
• 61 bits if there is no need for NhAddr
• Multiple results if there is a need for NhAddr,
  see earlier discussion.
• Tx Key Size 32 bits
• Tx Result Size 128 bits
• We need to watch out for the Tx Result for
  Tunnels. If we introduce anything else we want in
  there then we go beyond the 128 bits supportable
  through the TCAMs Associated memory.

29
Databases on LC

• Rx
• 0000 DC
• 0001 IPv4 Tunnel
• 0010 VLAN0
• 0011 MA (with or without VLAN)
• 0100 Legacy (non-substrate) with or without VLAN
• TX
• 1000 all TX lookups use one database

30
Extra

• The next set of slides are for templates or extra
  information if needed

31
Text Slide Template
32
Image Slide Template
33
OLD

• The rest of these are old slides that should be
  deleted at some point.

34
LC TCAM Lookup Keys on RX

• P2P-DC(28b) SL_Type(4)/Port(8)/MLI(16)
• P2P-Tunnel(IPv4)(76b) SL_Type(4)/Port(8)/EtherTyp
  e(16)/IPSrc(32)/MLI(16)
• P2P-VLAN0(76b) SL_Type(4)/Port(8)/EthSAddr(48)/ML
  I(16)
• MA(28b) SL_Type(4)/Port(8)/MLI(16)
• Legacy(28b) SL_Type(4)/Port(8)/EType(16)
• Fields
• SL_Type (4b) Substrate Link Type
• 0000 DC
• 0001 IPv4 Tunnel
• 0010 VLAN0
• 0011 MA
• 0100 Legacy (non-substrate) without VLAN
• 0101 Legacy (non-substrate) with VLAN
• Port(8b) Physical Interface number
• MLI(16b) Meta Link Identifier
• Ethertype(16b) Ethernet Header Type field
• IPSrc(32b) IP Source Address
• EthSAddr(48b) Ethernet Header Source Address

35
Databases on LC

• Rx
• 0000 DC
• 0001 IPv4 Tunnel
• 0010 VLAN0
• 0011 MA
• 0100 Legacy (non-substrate) without VLAN
• 0101 Legacy (non-substrate) with VLAN
• TX
• 1000 all TX lookups use one database
• Do we really need to use the TCAM for TX Lookups?
• VLAN(16b)/TxMI(16b) is the lookup key.
• Really only 4K VLANs support 12 bits
• How many VLANs (i.e. MRs) should be supported per
  LC?
• How many MIs should be supported per MR?
• 8MB per SRAM/(16B per Lookup) ? 512K Entries

36
LC TCAM Lookup Results on RX

• Standard Fields (64b/128b)
• Type (4b) Probably dont need this since there
  is a size in MnFlags.
• 0000 Default, not Pass Through, ignore MnFlags
• 1000 Pass Through with no extra lookup needed
  for NhAddr(nB), MnFlags(8b) should be 0x00
• 1001 Pass Through with extra lookup needed for
  NhAddr(nB)
• VLAN (16b)
• MI (16b)
• Blade Eth Hdr (8b)
• Only needs to have the DAddr.
• We can control the MAC Addresses of the Blades,
  so lets say that 40 of the 48 bits are fixed and
  8 bits are assigned and stored in the Lookup
  Result. Even 8 bits is overkill but it leaves us
  some flexibility.
• SAddr can be configured and constant per LC
• First EtherType can be constant 802.1Q
• Second EtherType can be constant Substrate
• QID (20b)
• MnFlags(8b) If needed
• NhAddr(56b) If needed

37
SUMMARY LC TCAM Lookups

• Rx Key Size 128 bits
• If We dropped the SL Type field and just made
  each SL Type a separate Database then we could
  get the RX Key down to 72 bits
• Rx Result Size 64/128 bits
• Depends on whether we need to support MA on other
  end of pass through MetaLink and on what size the
  NhAddr needs to be.
• Tx Key Size 32 bits
• Tx Result Size 128 bits
• We need to watch out for the Tx Result for
  Tunnels. If we introduce anything else we want in
  there then we go beyond the 128 bits supportable
  through the TCAMs Associated memory.
• If we find we cant use the 128 bit Result size
  for Tx, we might as well include the Local Memory
  result in the TCAM lookup.
• The Local Memory result was going to be the data
  that was only dependent on the Physical Interface
  id and was going to go into Local memory to try
  to keep the TCAM result below 128 bits.

38
LC TCAM Lookup Keys on RX
SL(4b) 0000
Port(8b)
MLI(16b)
PAD(100b)
SL (4b) 0001
Port (8b)
MLI (16b)
PAD (52b)
IP SAddr (32b)
EtherType (16b) 0x0800
SL (4b) 0010
Port (8b)
MLI (16b)
PAD (52b)
Ethernet SAddr (48b)
SL(4b) 0011
Port(8b)
MLI(16b)
PAD(100b)
SL (4b) 0100
Port (8b)
PAD (100b)
EtherType (16b) 0x0800

• Blue Shading Determine SL Type
• Black Outline Key Fields from pkt

DstAddr (6B)
DstAddr (6B)
SrcAddr (6B)
SrcAddr (6B)
Type802.1Q (2B)
Type802.1Q (2B)
TCI ? VLAN0 (2B)
TCI ? VLAN0 (2B)
DstAddr (6B)
DstAddr (6B)
TypeIP (2B)
TypeIP (2B)
Ver/HLen/Tos/Len (4B)
Ver/HLen/Tos/Len (4B)
SrcAddr (6B)
SrcAddr (6B)
ID/Flags/FragOff (4B)
ID/Flags/FragOff (4B)
TTL (1B)
Type802.1Q (2B)
TTL (1B)
Type802.1Q (2B)
ProtocolSubstrate (1B)
TCI?VLAN0 (2B)
Protocol (1B)
TCIVLAN0 (2B)
Hdr Cksum (2B)
Hdr Cksum (2B)
TypeSubstrate (2B)
TypeSubstrate (2B)
Src Addr (4B)
MLI (2B)
Src Addr (4B)
MLI (2B)
LEN (2B)
Dst Addr (4B)
LEN (2B)
Dst Addr (4B)
Meta Frame
Meta Frame
MLI (2B)
IP Payload
LEN (2B)
Meta Frame
PAD (nB)
PAD (nB)
PAD (nB)
PAD (nB)
CRC (4B)
CRC (4B)
CRC (4B)
CRC (4B)
P2P-DC Configured
P2P-VLAN0
Multi-Access
P2P-Tunnel
Legacy
39
TCAM Issues

• Global Mask Register Usage Examples
• IPv4 Route Lookup Database (Longest Prefix Match)
• 32-bit Entries and Keys
• Uses a core database size of 36 bits
• 31 available GMRs
• Entries of the form
• Prefix/prefix length
• Each Entry would use a GMR corresponding to the
  prefix length
• Prefix length24 ? GMR with a value of 0xFFFFFF00
• The number of different values of prefix length
  used in the database defines the number of used
  GMRs.
• A Mae West database that we once used in our PI
  Mtg Demo had 24 different prefix lengths (8-30,
  32)
• Using this database would only leave 7 GMRs in
  its half of the GMR space.
• So, we basically have to set aside half of the
  GMRs for Route Lookup.

40
TCAM Issues

• Global Mask Register Usage Examples
• IPv4 General Match Filter Database (Best/Range
  Match)
• 116-bit Entries and Keys
• Uses a core database size of 144 bits
• 32 available GMRs
• Entries of the form
• DAddr/prefix_length
• SAddr/prefix_length
• DPort Range(min, max)
• Sport Range(min, max)
• Protocol
• Protocol Wildcard
• TCP Flags/Mask
• Example
• Entry for catching all X-windows packets FROM a
  24-bit subnet
• DAddr 0.0.0.0/0 (dont care)
• SAddr 192.168.40.0/24
• DPort 6000-6063 (X-Windows TCP and UDP Port
  Numbers)
• Sport , (dont care, lets assume it is just the
  Destination Port that matters)

41
TCAM Issues

• Global Mask Register Usage Examples
• IPv4 General Match Filter Database (Best/Range
  Match)
• GMR bits for SAddr (192.168.40.0/24.
  0xC0A82800/24)
• 1111 1111 1111 1111 1111 1111 0000 0000
  (SAddrMask)
• GMR bits for DAddr()
• 0000 0000 0000 0000 0000 0000 0000 0000
  (DAddrMask)
• GMR bits for Port range of 6000-6063
• 1111 1111 1111 with a value of 0x1770
  (DPortMask-1)
• 1111 1111 111 with a value of 0x1780
  (DPortMask-2)
• 1111 1111 1111 with a value of 0x17A0
  (DPortMask-1)
• GMR bits for SPort()
• 0000 0000 0000 0000 (SPortMask)
• GMR bits for Protocol (6 or 17)
• 1111 1111 (ProtocolMask)
• With an entry each for 6 and 17
• GMR bits for TCP Flags
• 0000 0000 0000 (TCP_Mask)
• Masks we have two Masks
• Mask-1 with SAddrMask, DAddrMask, DPortMask-1,
  SPortMask, ProtocolMask, TCP_Mask)
