Beamline 12'2'2 refocus optics

1

Report on West Coast Activity COMPRES 6th Annual
Meeting, Lake Morey, VT Simon Clark Advanced
Light Source, LBNL, Berkeley, CA and Dept of
Earth and Planetary Science, Berkeley, CA June
19th 2007
2
Infra-red (bl 1.4)
BL1.4.3 Spectromicroscopy
Nicolet Magna 760 Nic-Plan microscope
3
Diffraction (bl 10.3.2)
E 17keV Spot size 100µm
4
Beamline 12.2.2
M. Kunz, A.A. MacDowell, W.A. Caldwell, D.
Cambie, R.S. Celestre, E.E. Domning, R.M. Duarte,
A.E. Gleason, J.M. Glossinger, N. Kelez, D.W.
Plate, T. Yu, J.M. Zaug, H.A. Padmore, R.
Jeanloz, A.P. Alivisatos, and S.M. Clark. A
beamline for high pressure studies at the
Advanced Light Source with a superconducting
bending magnet as the source, J. Synch. Rad.
12(5) 650-658 (2005).
5
End Station 1
Later
Now
6
End Station 2
7
12.2.2 problems last year

• IR laser breakdown
• (January 15th March 1st)
• Hutch retro-fit (8th March-August 3rd)
• IR laser breakdown (Oct 7th Dec 4th)
• ALS shutdown (Oct 16th Dec 31st)

8
High Pressure Lab.
9
People
Raymond Jeanloz Earth and Planetary Sciences UCB
Berkeley Principle Investigator
Simon Clark Advanced Light Source Calipso project
manager
Jinyuan Yan COMPRES Post-Doc Automation of data
analysis
Martin Kunz COMPRES Beamline Scientist
Sander Caldwell COMPRES Associate Beamline
Scientist
10
Beamtime requests
11
Publications
12
First Science Paper!
13
Williams Review
Quentin Williams UCSC Chair Wendy
Mao Stanford Jennifer Jackson Caltech Abby
Kavner UCLA Joe Smyth U Colorado Tom
Sharpe Arizona State
14
Williams report recommended priorities

• For the team
• Focus resources on exploiting beamline 12.2.2.
• Establish the ALS as the premier facility for
  powder diffraction from laser heated samples in
  diamond anvil cells with an emphasis on
  usability.
• Once this is completed start development of a
  single crystal facility.
• For the project manager
• Acquire a high-pressure gas loading apparatus.
• Expand the staff.

15
We should fully implement the Williams report
recommendations
16
Focus on bl12.2.2

• Reduce support of 1.4 and 11.3 to 10 for
  July-Dec 07 period
• Reduce support of 1.4 and 11.3 to 0 from January
  08

17
Fiber lasers
18
Improve laser heating

• New fiber lasers move current laser to HPlab
  for development system
• Move microscopes and micro-drills to a new
  microscope lab
• Utilize optics skills within LBNL
• Form a development task force
• Model existing system and proposed improved
  systems
• Rebalance skills in the HP team bring in more
  optics and laser skills
• Build optimized system

Aim to deliver before fall AGU
19
People
Simon Clark Advanced Light Source Calipso project
manager Co-PI
Raymond Jeanloz Earth and Planetary Sciences UCB
Berkeley Principle Investigator
Jason Knight Advanced Light Source Associate
Beamline Scientist
Advanced Light Source Beamline Scientist
Jinyuan Yan COMPRES Infrastructure
Post-Doc Automation of data analysis
Martin Kunz COMPRES Beamline Scientist
COMPRES Associate Beamline Scientist
ALS postdoctoral fellow
20
Gas loading system
GSE-CARS system Cost 80k plus installation at
ALS (5k)
21
Conclusions

• Beamlines working routinely and to specification.
• Implementing improvements recommended by
  Williams report
• Focus on beamline 12.2.2
• Improve laser heating system
• New fiber lasers
• Explore alternative optics
• Acquiring gas loading system
• Rebalancing skills in support team
• Developing single crystal facility
