the Blat Rap

1
the Blat Rap
the ins and outs of going blat

• by Jim Kent

2
Blat Rap Outline

• What blat is good at.
• How it compares to other tools.
• How it works.
• How best to use it.
• When its free and when its not.

3
The Need for Speed

• 10 billion bases of genome, more to come.
• 15 million ESTs publicly available.
• BLAST queues at NCBI are 15 minutes.
• What works well for searching a 10 million amino
  acid database does not work well for searching a
  20 billion nucleotide database.

4
BLAT is Good At

• Aligning mRNA and ESTs to the genome.
• Extremely fast and accurate
• Aligns whole mRNA, not just separate exons
• Handles introns splice sites
• Easy to parse native output format. Also outputs
  blast compatible format.
• Translated alignments between species
• Still quite fast.
• Sensitive enough for human/mouse and other
  vertebrate/vertebrate comparisons.

5
BLAT is not the best tool for

• Untranslated DNA alignments between species
  further than monkey/human.
• We use blastz for mouse/human DNA alignments.
• Protein/Protein alignments generally
• The protein databases are small enough, blastp is
  still an excellent choice for fast searches
• We use SAM and PSIBLAST for detecting remote
  protein homologies.

6
Other Good Uses of BLAT

• Aligning reads against the genome to find SNPs
  and other polymorphisms.
• Clustering together redundant protein, mRNA or
  EST records from Genbank.
• Mapping annotations from one version of the human
  genome to another version of the human genome.
• Looking for recent duplication in the human
  genome that may cause cross-hybridization
  problems in microarrays and PCR experiments.

7
Blat Rap Outline

• What blat is good at.
• How it compares to other tools.
• How it works.
• How best to use it.
• When its free and when its not.

8
mRNA/Genome Alignments
Remapping Sanger Chromosome 22 mRNAs to genome
and comparing to Sanger annotated exon/intron
structure.
9
Translated Mouse/Human Alignments
WU-TBLASTX and BLAT in translated mode (-tdnax
-qprot) aligning mouse 3x coverage whole genome
shotgun reads vs. Human Chromosome 22.
WU-TBLASTX was run with word-size of 5.
10
Web Search Usp18 vs Genome
11
Blat Rap Outline

• What blat is good at.
• How it compares to other tools.
• How it works.
• How best to use it.
• When its free and when its not.

12
The Alignment Problem

• Figuring out how to position two strings with
  some insertions so as to maximize where two
  strings agree.

aca--gacacactattatg-g-gc-caga-ac-cac
acacacagacacact-tt
atgtgtgctcacacacacacgct
mRNA vs. genomic alignments are an important
special case
13
Introns in Alignments
ATGGAGGGGCAGAGCGGCCGCTGCAAGATCGTGGTGGTGGGAGACGCAGA
GTGCGGCAAGACGGCGCTGCTGCAGGTGTTCGCCAAGGACGCCTATCCC
G GGgtgagggacctgcgtcttgggagggggacgctaaggctgctggggg
gt gggtgacaggggccctggcgacggatgggaatgggtactcgggtaac
cag ggacaagagacagggggtcggaggacgcggggaggccttgagggct
cagg aaggactgcagaggattggggtgggaggaattagggagcagggtg
agata gatggggtttgggagaaccagagcatccgggagggagggcgagg
ggaatg tcggaggtcctgggcaatggagaggggaagaactagggggctg
aagggac cagaagggaacaggaggaggtcttggagcttagcagagattc
tccggggg ggggggggggggggcaggagctcccgggatctcccctttgc
ccaatccca gaccaacttgtgtccaggggctgggctggacggggtgtgg
gagtgaggag ggcatttatctggggtgaggacttggagagatgatctca
tctggatccat ccgtgtctgcagAGTTATGTCCCCACCGTGTTTGAGAA
CTACACTGCGAG CTTTGAGATCGACAAGCGCCGCATTGAGCTCAACATG
TGGGACACTTCAG
14
Perfect Matches Serve as Seeds

• Computers can look for exact matches very
  quickly.
• Finding inexact matches is slow
• Inexact matches should contain some short exact
  matches.
• Inexact matches should contain multiple even
  shorter exact matches.

15
ggagaatagggcatgctctgaggtctgctggaacccatcc 1 12
123456 12 12 12345 1 12 12345
1 gtggattagggcttgttccgaggttatcgggttcccatac
ttcttgtctcgctccagggcaccgtgcaggaaatcccggg 2345 1
123 1 12 1234567 1234567 1234 ttctgggctctcgcccgg
gcacctagcaggaatacccgat acacctcctcattctcatccagccac
tggatgacgaaggg 123 123456 123 123 12345
12345 ggacccgctcattaccatacagtaaacggatggcgaagac Di
stribution of identical matches length 1 2 3
4 5 6 7 8 number 5 5 4 1 5 2 2 0
16
Steps in Fast cDNA Alignments

• 1. Break cDNA into 500 base chunks.
• 2. Use an index to find regions in genome similar
  to each chunk of cDNA.
• 3. Do a detailed alignment between genomic
  regions and cDNA chunk.
• 4. Use dynamic programming to stitch together
  detailed alignments of chunks into detailed
  alignment of whole.

17
Indexing

• Within an exon there should be some K-mers that
  align perfectly.
• Build an index which contains positions of each
  K-mer in genome. K is typically between 8 and
  13.
• Step through each K-mer in cDNA chunk and look it
  up in index.
• Get list of hits - positions in cDNA and in
  genome that match for K bases.

18
Genome cacaattatcacgaccgc 3-mers cac aat tat
cac gac cgc Index aat 3 gac 12 cac
0,9 tat 6 cgc 15 cDNA
aattctcac 3-mers aat att ttc tct ctc tca cac
0 1 2 3 4 5 6 hits aat 0,3
-3 cac 6,0 6 cac 6,9 -3 clump
cacAATtatCACgaccgc
19
Detailed Alignments

• Smith-Waterman technique based on dynamic
  programming.
• Banded Smith-Waterman faster but doesnt
  tolerate long inserts
• Recursive seed and extend faster yet, handles
  large gaps, but only works on very similar
  sequences.

20
Recursive Seed and Extend

• Find perfect matches that are too long to occur
  reasonably by chance in a region.
• Extend through short mismatches.
• Extend through short gaps.
• Existing matches divide sequence into regions.
• Recurse to align unaligned regions at reduced
  stringency.

21
acataxxxxxxxxxxxxxxxxxxgatta xxxxxx cctgax

yacatayyyyyyyyyyyyyyyyyygattayyyyyyyycctgayy
yy
acatacgxxxxxxxxxxxxxxxxgatta xxxxxx cctgaa

yacatacgyyyyyyyyyyyyyyyygattayyyyyyyycctgaa
yyy
acatacgxxxxxxxxxxxxxcctgatta-ccggxx cctgaa

yacatacgyyyyyyyyyyyyyccagattaaccggyyycctgaa
yyy
acatacgxxxxcatgxxxxxcctgatta-ccggxx cctgaa

yacatacgyyyycatgyyyyyccagattaaccggyyycctgaa
yyy
acatacg catg cctgatta-ccgg cctgaa

yacatacg catg ccagattaaccgg
cctgaa
22
Stitching Together Alignments
23
Repeats Complicate Things
24
Solution Dynamic Programming

• Define block of alignment as a region with no
  insertions or deletions.
• Each block can be represented by 4 coordinates
  cStart, cEnd, gStart, gEnd
• Each block has a score match-mismatch
• Each gap between blocks has score
  -log(gSize) - cSize
• Pick maximal scoring set of blocks where one
  block must follow another in both c g

25
(No Transcript)
26
Blat Rap Outline

• What blat is good at.
• How it compares to other tools.
• How it works.
• How best to use it.
• When its free and when its not.

27
Standalone vs. Client/Server

• Standalone - best for batch queries. Executable
  is called blat.
• Client/Server - best for interactive queries.
  Executables are called gfClient/gfServer.

28
Standalone

• Advantages
• 2x as fast
• More sensitive for protein/translated searches
• Runs well on computer clusters
• Runs effectively in 256 meg of RAM.
• Disadvantages
• Cant process complete genome at once unless have
  8 gig of RAM.
• Must combine sort results of multiple runs.
• Wait for index to be built before first query is
  processed

29
Client/Server

• Advantages
• Can process entire genome in 1.2 Gb of RAM
• Process translated genome in 2.5 Gb of RAM
• Index is prebuilt. Response to first query is
  typically lt 2 s.
• No need to sort results.
• Disadvantages
• Ties up lots of memory in server machine
• 1/2 as fast as standalone

30
Standalone mRNA/DNA Searches

• blat target query output -ooc11.ooc
• Target (aka database) can be a fasta file, nib
  file or a text file containing a list of fasta
  and nib files. Target is typically a chromosome.

• For nucleotide queries no need to mask.
• Query can be a fasta file or list of fasta files.
  Typically query is a large batch of mRNA or EST
  sequences.
• Output by default is in a tab-separated format.
  Recently -outblast option and other output
  options added.
• ooc11.ooc tells blat which 11-mers occur to
  often to be useful. It greatly increases
  blats speed.

31
Standalone translated searches

• blat target query output -tdnax -qprot
• This aligns proteins vs translated genome
• blat target query output -tdnax -qrnax
• Aligns translated RNA vs translated genome
• blat target query output -tdnax -qdnax
• Aligns translated genome vs. translated genome
  (best to chop query into 4kb or less pieces)
• For translated searches its best to used masked
  target DNA.

32
Client/Server Setup

• Convert each chromosome into its own .nib file
  with faToNib.
• Start up gfServer on a machine with enough
  memory. It will take 10 minutes to build an
  index.
• Run gfClient, telling it query sequence, machine
  and port number that server is on.
• Parse gfClient output into your own interactive
  systems.

33
Translated Client/Server

• Mask chromosomes before converting to nib.
• Index will take 30 minutes to generate and
  require 2.5 gig
• For human genome both nucleotide and translated
  servers fit on one Linux box with 4 Gb of RAM.
• In general one gfServer can support about 8
  gfClients. (I put as much of the work as
  possible on the client side.)

34
short matches

• To find perfect 21-mers
• minMatch1
• minScore21
• minIdentity100
• For perfect 19-mers
• tileSize10
• minMatch1
• minScore19
• minIdentity100
• For 21-mers with one mismatch
• minMatch1
• oneOff
• minScore21

35
For Nucleotide Extra Sensitivity

• tileSize10
• minIdentity0
• minScore0
• Add 5 Ns at start of target and rerun
• Try blastz

36
Fast Near Perfect Long Matches

• Use tileSize12, ooc12.ooc
• Try -fastMap
• -minIdentity98
• -minScore100

37
Blat Rap Outline

• What blat is good at.
• How it compares to other tools.
• How it works.
• How best to use it.
• When its free and when its not.

38
BLAT is Free For

• Non-profit organizations
• Students and educational institutions
• For interactive use on the web.
• Limited program driven use on the web (less than
  2 hits/minute, less than 1,000 hits/day).
• For the first 30 days after downloading.

39
Commercial Licenses
Jim Kent jim_kent_at_pacbell.net
Heidi Brumbaugh heidi_b_at_pacbell.net
40
THE END
