The West 7th Urban Village Strategic Plan

1
The West 7th Urban Village Strategic Plan
Fort Worth, TX November 15, 2005
2
Strategic Plan
University
Transition Area
The Study Area is broken down into Sub-Districts.
Each District defines building height, density,
and overall intensity of development.
Buffer Area
7th
Commercial Corridor
Village Center
Camp Bowie
Lancaster
Park/Open Space
River/Park Edge
3
Commercial Corridors
4
Commercial Corridors

• Commercial Focused Mixed Use
• 10 Story Maximum Building Height
• No Ground Floor Residential Facing Major Streets
• 80 100 Residential Units / Acre

5
Village Center
6
Village Center

• Residential Focused Mixed Use
• 10 Story Maximum Building Height
• Ground Floor Residential Allowable
• 80 100 Residential Units / Acre

7
Transition Area
8
Transition Area

• Residential Focused Mixed Use Utilizing
  Small Scale Commercial Uses
• 4 Story Maximum Building Height
• Ground Floor Residential Allowable
• 40 - 60 Residential Units / Acre

9
Buffer Area
10
Buffer Area

• Residential Focused Mixed Use Utilizing
  Live/Work Neighborhood Commercial
• 3 Story Maximum Building Height
• Ground Floor Residential Allowable
• 15 - 30 Residential Units / Acre

11
River / Park Edge

• Commercial Focused Mixed Use Utilizing
  Entertainment Retail / Restaurant Uses
• 10 Story Maximum Building Height
• No Ground Floor Residential Facing Park Areas
• 80 - 100 Residential Units / Acre

12
River / Park Edge

• Commercial Focused Mixed Use Utilizing
  Entertainment Retail / Restaurant Uses
• 10 Story Maximum Building Height
• No Ground Floor Residential Facing Park Areas
• 80 - 100 Residential Units / Acre

13
Parks Open Space

• Focus on Neighborhood Parks and Urban Plazas
• No Additional Recreational Park Spaces Because
  Study Area is Close to Trinity Park System

14
Parks Open Space

• Focus on Neighborhood Parks and Urban Plazas
• No Additional Recreational Park Spaces Because
  Study Area is Close to Trinity Park System

15
Gateways
16
Gateways

• Building Form, Public Art, Signage, and Enhanced
  Lighting Create Gateways Into the District

17
Major Streets
18
Major Streets

• Street Trees, On-street Parking, Landscaped
  Median Create Pedestrian Zone and Breaks Down
  Scale of Streets

19
Minor Streets
20
Minor Streets

• Narrow Traffic Lanes in Order to Create
  Additional Space for Widened Sidewalks, Enhanced
  Landscape, and On-street Parking

21
Transportation

• Ultra-Light Rail System That Shares the Outside
  Traffic Lane Increases Connectivity Within Study
  Area and Improve Connections to Downtown

22
Transportation

• Ultra-Light Rail System That Shares the Outside
  Traffic Lane Increases Connectivity Within Study
  Area and Improve Connections to Downtown

23
Parking Plan

• Parking Garages That are Screened from Public
  View
• Maximize On-street Parking

24
Parking Plan

• Parking Garages That are Screened from Public
  View
• Maximize On-street Parking
