Self Organization: Hebbian Learning

1
Self Organization Hebbian Learning

• CS/CMPE 333 Neural Networks

2
Introduction

• So far, we have studied neural networks that
  learn from their environment in a supervised
  manner
• Neural networks can also learn in an unsupervised
  manner as well. This is also known as self
  organized learning
• Self organized learning discovers significant
  features or patterns in the input data through
  general rules that operate locally
• Self organizing networks typically consist of two
  layers with feedforward connections and elements
  to facilitate local learning

3
Self-Organization

• Global order can arise from local interactions
  Turing (1952)
• Input signal produces certain activity patterns
  in network lt-gt weights are modified (feedback
  loop)
• Principles of self organization
• Modification in weights tend to self-amplify
• Limitation of resources leads to competition and
  selection of the most active synapse and
  disregard of less active synapse
• Modifications in weights tends to cooperate

4
Hebbian Learning

• A self-organizing principle was proposed by Hebb
  in 1949 in the context of biological neurons
• Hebbs principle
• When a neuron repeatedly excites another neuron,
  then the threshold of the latter neuron is
  decreased, or the synaptic weight between the
  neurons is increased, in effect increasing the
  likelihood of the second neuron to excite
• Hebbian learning rule
• ?wji ?yjxi
• There is no desired or target signal required in
  the Hebbian rule, hence it is unsupervised
  learning
• The update rule is local to the weight

5
Hebbian Update

• Consider the update of a single weight w (x and y
  are the pre- and post-synaptic activities)
• w(n 1) w(n) ?x(n)y(n)
• For a linear activation function
• w(n 1) w(n)1 ?x2(n)
• Weights increase without bounds. If initial
  weight is negative, then it will increase in the
  negative. If it is positive, then it will
  increase in the positive range
• Hebbian learning is intrinsically unstable,
  unlike error-correction learning with BP algorithm

6
Geometric Interpretation of Hebbian Learning

• Consider a single linear neuron with p inputs
• y wTx xTw
• and
• ?w ?x1y x2y xpyT
• The dot product can be written as
• y wx cos(a)
• a angle between vectors x and w
• If a is zero (x and w are close) y is large. If
  a is 90 (x and w are far) y is zero.

7
Similarity Measure

• A network trained with Hebbian learning creates a
  similarity measure (the inner product) in its
  input space according to the information
  contained in the weights
• The weights capture (memorizes) the information
  in the data during training
• During operation, when the weights are fixed, a
  large output y signifies that the present input
  is "similar" to the inputs x that created the
  weights during training
• Similarity measures
• Hamming distance
• Correlation

8
Hebbian Learning as Correlation Learning

• Hebbian learning (pattern-by-pattern mode)
• ?w(n) ?x(n)y(n) ?xT(n)x(n)w(n)
• Using batch mode
• ?w(n) ?Sn1 Nx(n)xT(n)w(0)
• The term Sn1 Nx(n)xT(n) is sample approximation
  of the auto-correlation of the input data
• Thus Hebbian learning can be thought of learning
  the auto-correlation of the input space
• Correlation is a well-known operation in signal
  processing and statistics. In particular, it
  completely describes signals defined by Gaussian
  distributions
• Applications in signal processing

9
Ojas Rule

• The simple Hebbian rule causes the weights to
  increase (or decrease) without bounds
• The weights need to be normalized to one as
• wji(n 1) wji(n) ?xi(n)yj(n) /
• vSiwji(n) ?xi(n)yj(n)2
• This equation effectively imposes a constraint on
  the weights that the sum at a neuron be equal to
  1
• Oja approximated the normalization (for small ?)
  as
• wji(n 1) wjin) ?yj(n)xi(n) yj(n)wji(n)
• This is Ojas rule, or the generalized Hebbian
  rule
• It involves a forgetting term that prevents the
  weights from growing without bounds

10
Ojas Rule Geometric Interpretation

• The simple Hebbian rule finds the weight vector
  with the largest variance with the input data.
• However, the magnitude of the weight vector
  increases without bounds
• Ojas rule has a similar interpretation
  normalization only changes the magnitude while
  the direction of the weight vector is same
• Magnitude is equal to one
• Ojas rule converges asymptotically, unlike
  Hebbian rule which is unstable

11
(No Transcript)
12
The Maximum Eigenfilter

• A linear neuron trained with Ojas rule produces
  a weight vector that is the eigenvector of the
  input auto correlation matrix, and produces at
  its output the largest eigenvalue
• A linear neuron trained with Ojas rule solves
  the following eigen problem
• Re1 ?1e1
• R auto-correlation matrix of input data
• e1 largest eigenvector which corresponds to the
  weight vector w obtained by Ojas rule
• ?1 largest eigenvalue, which corresponds to the
  networks output

13
Principal Component Analysis (1)

• Ojas rule when applied to a single neuron
  creates a principal component in the input space
  in the form of the weight vector
• How can we find other components in the input
  space with significant variance ?
• In statistics, PCA is used to obtain the
  significant components of data in the form of
  orthogonal principal axes
• PCA is also known as K-L filtering in signal
  processing
• First proposed in 1901. Later developments
  occurred in the 1930s, 1940s and 1960s.
• Hebbian network with Ojas rule can perform PCA

14
Principal Component Analysis (2)

• PCA
• Consider a set of vectors x with zero mean and
  unit variance. There exist an orthogonal
  transformation y QTx such that the covariance
  matrix of y is ? EyyT
• ?ij ?i if i j and ?ij 0 otherwise
  (diagonal matrix)
• ?1 gt ?2 gt gt ?p eigenvalues of covariance
  matrix of x (C ExxT
• Columns of Q are the corresponding eigenvectors
• Vector y is the principal component that has the
  maximum variance with all other components

15
PCA Example
16
Hebbian Network for PCA
17
Hebbian Network for PCA

• Procedure
• Use Ojas rule to find the principal component
• Project the data orthogonal to the principal
  component
• Use Ojas rule on the projected data to find the
  next major component
• Repeat the above for m lt p (m desired
  components p input space dimensionality)
• How to find the projection onto orthogonal
  direction?
• Deflation method subtract the principal
  component from the input
• Ojas rule can be modified to perform this
  operation Sangers rule

18
Sangers Rule

• Sangers rule is a modification of Ojas rule
  that implements the deflation method for PCA
• Classical PCA involves matrix operations
• Sangers rule implements PCA in an iterative
  fashion for neural networks
• Consider p inputs and m outputs, where m lt p
• yj(n) Si1 p wji(n)xi(n) j 1, m
• and, the update (Sangers rule)
• ?wji(n) ?yj(n)xi(n) yj(n) Sk1 j
  wki(n)yk(n)

19
PCA for Feature Extraction

• PCA is the optimal linear feature extractor. This
  means that there is no other linear system that
  is able to provide better features for
  reconstruction.
• PCA may or may not be the best preprocessing for
  pattern classification or recognition.
  Classification requires good discrimination which
  PCA might not be able to provide.
• Feature extraction transform p-dimensional input
  space to an m-dimensional space (m lt p), such
  that the m-dimensions capture the information
  with minimal loss
• The error e in the reconstruction is given by
• e2 SiM1 p ?i

20
PCA for Data Compression

• PCA identifies an orthogonal coordinate system
  for the input data such that the variance of the
  projection on the principal axis is largest,
  followed by the next major axis, and so on
• By discarding some of the minor components, PCA
  can be used for data compression, where a
  p-dimension (bit) input is encoded in a m lt p
  dimensional space
• Weights are computed by Sangers rule on typical
  inputs
• The de-compressor (receiver) must know the
  weights of the network to reconstruct the
  original signal
• x WTy

21
PCA for Classification (1)

• Can PCA enhance classification ?
• In general, no. PCA is good for reconstruction
  and not feature discrimination or classification

22
PCA for Classification (2)
23
PCA Some Remarks

• Practical uses of PCA
• Data Compression
• Cluster analysis
• Feature extraction
• Preprocessing for classification/recognition
  (e.g. preprocessing for MLP training)
• Biological basis
• It is unlikely that the processing performed by
  biological neurons in, say perception, involves
  PCA only. More complex feature extraction
  processes are involved.

24
Anti-Hebbian Learning

• Modifying the Hebbian rule as
• ?wji(n) - ?xi(n)yj(n)
• The anti-Hebbian rule find the direction in space
  that has the minimum variance. In other words, it
  is the complement of the Hebbian rule
• Anti-Hebbian does de-correlation. It
  de-correlates the output from the input
• Hebbian rule is unstable, since it tries to
  maximize the variance. Anti-Hebbian rule, on the
  other hand, is stable and converges
