Multidatabase and Distributed Manipulations Part 1

1
Multidatabase and Distributed ManipulationsPart 1

• Witold Litwin

2
Plan

• Introduction
• Technical problems
• Origin of the concept
• Approach Centralized DB (ANSI-SPARC)
• Approach DDB (top-down)
• Approach Global Schema (bottom-up)
• Reference architectures
• Multidatabase architecture
• Federated architecture
• Autonomy, semantic heterogeneity , common model

3
Multidatabase Model

• Single database model ANSI-SPARC
• The real universe is modeled as one DB
• The real universe is modeled as multiple dbs

• Autonomous
• Semantically heterogeneous
• Manipulated through a multibase language
• "Multidatabase interoperability". Litwin, W.
  Abdellatif, A. Multidatabase systems An advanced
  solution for global information sharing. Hurson,
  A., R., Bright, M., W., Pakzad, S., H., (Ed.).
  IEEE press, 1993

4
Multidatabase Model
Autres BDs sur Internet
Rest.
Cours étudiants
Mes-amis
Bibliothèque
Privé
Paris 9
Employés
Folio
Cine
Teletel
5
Problems

• Reference architecture
• Semantic heterogeneity in presence of local
  autonomy
• Common data model
• Fonctions of MDB langage
• Transactions
• Protocols standards
• Performance

6
Reference Architectures

• Multidatabase architecture
• Generalization of the ANSI-SPARC architecture
• Federated dbs architecture
• Generalization of the federated DB architecture
• Others

7
ANSI-SPARC Architecture Centralized Integrated
BD (1960-70)
ES - External Schema
CS - Conceptual Schema
PS - Physical or Internal Schema
8
Distributed DB

• Origin of the concept (years 1970)
• WAN development ( 20 kb/s)
• Overload of centralized dbs

9
Ddb

• Idea distribution of functions other than local
  communication ("top-down" approach)
• Which ones ?
• Distr. Execution (OS)
• File access
• The DB
• Then, what data model for CS ?
• Network (codasyl) ?
• Relational

10
Relation Fragmentation
Hotels (H, Ville, Cat, Chambres)
1 Fragment
(H, Ville)
(H, Cat, Chambres)
11
Problems

• GS scalability
• GS utility for a local user
• Query performance (bad case)
• Data migration from ldbs
• IMS, IDMS, Socrate
• Local applications

12
Problemes With the "Bottom-up" Approach
ES
ES

• Creation of GS
• Semantic heterogeneity
• Time for the integration / local restructuring
  autonomy
• In other words scalability of GS
• Updates
• Performance
• Heterogeneos views

GS
CS
CS
CS
PS
PS
PS
GS Approach ("bottom-up")
13
MDB Architecture Absence
of (GS)
ES
ES

• User may have data in multiple dabs ANSI-SPARC
  compatibles
• One may face multiple css
• In general, it will be impossible to create a
  GS

GS
CS
CS
CS
PS
PS
PS
GS Approach ("bottom-up")
14
MBD Architecture Concept of the MDB Language

• Language for definition and manipulation of
  collections of dbs (multidatabases)
• Definition of MDB ESs
• Perhaps GSs
• Definition of MDB dependancies
• Semantics, integrity, security, manipulation...
• Formulation of MDB queries (explicitly)
• Referencing DB names
• With MDB joins...
• Find in DB michelin and in DB gaumont all
  restaurants '' and cinemas at the same street

15
MBD Architecture Multibases

• A multidatabase (MDB) is a collection of dbs
  with MDB language
• E.G. MSQL
• A collection of dbs without MDB langage is not
  an MDB, but just a collection of dbs
• As a collection of flat files (tables) without a
  DB language , SQL for example, is not a DB

16
Potential Multibases
Other DBs sur Internet
Rest.
Cours étudiants
Mes-amis
Bibliothèque
Privé
Paris 9
Employés
Folio
Cine
Teletel
17
MDB Architecture Concept of Internal Logical
Sublayer

• The legacy data models can be heterogeneous
• Different SQL dialects
• Relational, hierarchical, network
• OO and object-relational
• It is preferable to have one model at MDB
  layer
• One needs a sub-layer for translations
• Also local DBA may wish not to show some of the
  data at MDB layer
• Solution ILS - internal logical schema
• Unknown of ANSI-SPARC
• Called also gateway

18
Multibase Architecture Result of All This
(W. Litwin Al, Années 1980)
Req. MDB
ES multibase
19
Federated Architecture (Hambiger Mcleod,
Années 1980)

• Every DB should be autonomous
• In general, there will be no GS
• Global integration is against the autonomy
• The dbs used in common should form a federation
  of autonomous dbs
• Every DB in a federation should be provided
  with three schemes
• ES export schema
• IS import schema
• PS private schema for all the private data,
  of ES and of IS included
• There should be some federation dictionary (FD)

20
Federated Architecture (Hambiger Mcleod,
Années 1980)
21
Comparison

• MDB architecture focuses on the concept of MDB
  language
• Federated architecture focuses on the concept
  of autonomy
• No MDB language
• But there is the notion of autonomy also in MDB
  arch.
• MDB architecture is decentralized
• No equivalent of FD
• Several DSs
• Both architectures are popular

22
Comparison MDB lt-gt Fed.
23
DB Autonomy(local autonomy)

• Capability to control local DB data by the DBA
• Naming
• Value Types
• Data Structures
• Physical Structures
• Query Execution
• Security
• Priority to local queries

24
Multidatabase Autonomy

• Capability to controle multiple DBs by a DBA
• Same aspects as for the local autonomy
• Naming...
• May create a conflict with a DB autonomy
• Priority to local autonomy

B1
B2
B3
25
Semantic Heterogeneity

• Differences in representations of the same real
  properties
• Names André ??Andrew
• Value Types
• Representations
• units of measure cm/s ??pied/h
• precision 1 g ?? 1 Kg
• Data Structures
• One table in 2 NF ??several tables in 3 NF

26
Solutions (partial)

• Schemas descriptive
• Protocols descriptive
• Data Dictionaries
• Thesaurus
• Automatic Representation Conversions
• Automatic Unit Conversion
• Implicit Joints
• Higher level models and manip. languages
• IDL (Krishnamourthy, Litwin, Kent, ACM-Sigmod 92

27
Common Models

• Ext. Relational
• EDA-SQL
• MSQL (research)
• ODBC Microsoft SQL
• Object-Relational
• SQL 3
• CCS language for inf. retr. DBs
• Numerous gateways towards SQL
• IMS ??SQL
• Codasyl ??SQL

28
UniSQL/M
UniSQL/M
IMS
UniSQL
Sybase
Oracle
29
Other gateways
UniSQL/M
IMS
UniSQL
Sybase
Oracle
30
Yet other gateways
UniSQL/M
IMS
UniSQL
Sybase
Oracle
EDA-SQL
31
The future (ODBC, JDBC, UDA)
ODBC x
32
Conclusion

• Modern DBMSs are in general MDBMSs
• UniSQL/M, Oracle, Sybase, MsAccess, SQL Server,
  InterBase, DB2...
• MDB access requires new functions for the
  management of
• autonomy
• semantic heterogeneity
• physical distribution of data

33
Conclusion

• technical solutions are basd on
• new reference architectures
• multidatabase architecture
• federated architecture
• common data models
• relational and object-relational
• Gateways in rapid development
• Any DBMS towards any other using ODBC, JDBC
• Relational or XML wrappers

34
Conclusion

• MDB Languages
• MSQL et SQL-x x gt 2
• New transaction models
• Protocoles et Standards
• ODBC, JDBC
• All this is dealt with more in depth
• later on
• in the class books several others

35
Exercises Research Problems

• All these already in the text
• Difference between the concepts of a DB, DDB,MDB
  and FDB.
• What does it mean   reference architecture ,
  as ANSI-SPARC for example ?
• Differences between the architectures
   top-down   bottom-up , multibase et
  federated.
• Comment on the actual architecture of federated
  DBs in DB2 V. 6 and later (see DB2 Help or
  RedBooks at the IBM web site).
• Comment on the actual architecture of federated
  DBs in SQL Server 2000 (see SQL Server 2000 Help
  or the papers at the MS web site).
• Design SQL SELECT statements realizing the
  fragmentation of the Hotels DB.
• Can you propose then how to deal with the
  updates ?
• Comment on the concept of ILS, of gateway and
  of mediator
• What multidatabase common model is most used
  today ?
• Comment the concept of local autonomy (what,
  why, how)
• Provide examples of various types of semantic
  heterogeneity
• Prove that usual associability of equijoints
  does not hold if units of measure of values to
  join may have different precisions
• What are consequences for relational DBMSs ?
• Propose an extension to SQL for units of measure
  and the corresponding query optimization (PH.D
  Thesis).
