Handover for PMIPv6 Using MIH

1
Handover for PMIPv6 Using MIH

• KANG Joon-Suk
• ? ??

2
Contents

• Why Proxy MIPv6
• Fast HO procedure
• Fast HO Time line
• Problems to be solved
• Vertical Handover
• Problems to be solved
• Comments

3
Agenda

• Why Proxy MIPv6
• Fast HO procedure
• Fast HO Time line
• Problems to be solved
• Vertical Handover
• Problems to be solved
• Comments

4
Why Proxy MIPv6

• The provisioning of seamless mobility to moving
  nodes across homogeneous/heterogeneous access
  networks
• Theoretical Target
• IPv6 nodes
• PC, Mobile phone, PDA, Web camera, Home
  application, VoIP phone, Mobile router, etc..
• Mobile/Multimedia applications..
• But actually No current targets..

5
Why Proxy MIPv6

• Increasing number of Mobile node users..
• VoIP phone, PDA, Note book,
• During walking
• Voice/Video over IP phone
• During riding moving vehicles
• All devices to use Internet
• Mobile router is strongly needed

6
Why Proxy MIPv6

• Normal MIPv6 was already completed
• Leaded by mobile phone suppliers
• NOKIA
• Heavy overhead to MN
• Energy problem, Waste of air resources
• There are no charming points to the
  Telecommunication Operator(supporting commercial
  services).

7
Why Proxy MIPv6

• Many vendors and Standard organizations were
  concerned about alternative technology.
• CISCO, Juniper, WiMAX, 3GPP, IETF
• Proxy Mobile IPv6
• Proxy MIPv6 is good technology to support
  commercial service by Telecommunication Operators
  and router vendors.

8
Agenda

• Why Proxy MIPv6
• Fast HO procedure
• Fast HO Time line
• Problems to be solved
• Vertical Handover
• Problems to be solved
• Comments

9
Scenario
LMA

• LMA current home agent for the mn
• pMAG currently serving MAG
• MAG1MAG2 candidate MAGs for a next MAG

pMAG serving
MAG1
Handover
MN
10
Protocol stack
MAG
LMA
MN
TARGETIEEE 802.16IEEE 802.11
11
Procedure
LMA

• 1. MN is moving
• 2. Scan for Candidate Networks
• To make the list of candidate networks
• When the MN finds new network areas

pMAG serving
MAG1
1
2
Scan for Candidate Networks
MAG2
12
2- How to Scan for Candidate Networks

• Main method Automatic method
• Using Link_Detect event
• The Link Detected event is generated on the MN
  when a PoA(Point of Attachment) of an access
  network is detected for the first time.
• Automatically detected
• Complement Manual method
• Using MIH_Link_Actions(Link_Scan) command
• To get a list of discovered PoAs and related
  information.
• Manually trigger

13
2- How to Scan for Candidate Networks - Automatic

• During MN is moving, if the MN finds the new
  network area, Link_Detected event is generated on
  the MN
• The event comprise the information of PoA
• MN stores the PoA information
• Making a list

LMA
pMAG serving
MAG1
Scan for Candidate Networks
MAG2
14
2- How to Scan for Candidate Networks - Passive
MN
pMAG
nMAG
PMIPv6Client
MIHFProtocol
MAC
PoA(MAC)
PoS(MIHF)
PMIPv6Client
MIISServer
PoA(MAC)
PoS(MIHF)
PMIPv6Client
MIH_Event_Subscribe.requestLink_Detected
Link_Detected
Stores the link info.
Link_Detected
Link_Detected
Stores the link info.
15
2- How to Scan for Candidate Networks - Active

• 1. When Link_Going_Downoccures,
• 2. if the MN has no PoA informationor the
  confidence level of Link_Going_Down is low,
• 3. Start to scan for Candidate Networksgt Using
  MIH_Link_Actions(Link_Scan) command

LMA
pMAG serving
MAG1
2
1
MAG2
Link_Going_Down
16
2- How to Scan for Candidate Networks - Active
MN
pMAG
nMAG
MAC
PMIPv6Client
MIHFProtocol
PoA(MAC)
PoS(MIHF)
PMIPv6Client
PoA(MAC)
PoS(MIHF)
PMIPv6Client
MIISServer
Link Going Down withLow Confidence Level
Link_Going_Down.indication
MIH_Link_Going_Down.indication
Scan for Candidate Network
MIH_Scan.request
Link_Action.request (LINK_SCAN)
LINK_SCAN
Link_Action.confirm(ScanResult)
MIH_ScanResponse
Stores the link info.
17
Procedure contd.
LMA
3. Link_Going_Down event occurs with High
confidence level 4. Decision of Target MAG4-1.
MN send PoA list to pMAG4-2. pMAG selects
target MAG using the list.
4
pMAG serving
MAG1
1
2
3
Link_Going_Down(70)
18
4- Target Decision

• MIH_N2N_HO_Query_Resource command
• By what parameters?
• Signal strength?
• It must be considered more

19
4- Target Decision
MN
pMAG
nMAG
PMIPv6Client
MIHFProtocol
MAC
PoA(MAC)
PoS(MIHF)
PMIPv6Client
MIISServer
PoA(MAC)
PoS(MIHF)
PMIPv6Client
Resource Availability Check
MIH_N2N_HO_Query_Resource.request
MIH_N2N_HO_Query_Resource.request

MIH_N2N_HO_Query_Resource.request
MIH_N2N_HO_Query_Resource.response

MIH_N2N_HO_Query_Resource.response
20
Procedure contd.
LMA
7

• 5. pMAG makes MAG1 prepare handover
• Sending Trigger_L3_HOmessage
• 6. Virtual PBU
• 7. Setup virtual BCE and Tunnel with MAG1
• 8. Virtual PBA
• 9. Setup Tunnel and Routing

6
8
pMAG serving
MAG1
5
9
21
Procedure contd.
LMA

• 10. Inform that virtual PBU is finished
• 11. LMA sends packets to MAG1 by the new tunnel,
  and MAG1 forwards them to pMAG
• Because the MN is attaching to pMAG yet
• The packets from the MN can be transferred by pMAG

pMAG serving
10
MAG1
11
22
Procedure contd.

• ? In current stage
• pMAG is serving the MN yet
• LMA has two tunnels for the MN
• with pMAG
• with MAG1
• LMA has two cache entry for the MN
• with pMAG
• with MAG1
• Packet path from LMA to MN
• LMA -gt MAG1 (forwarding)-gt pMAG -gt MN
• Packet path from MN to LMA
• MN -gt pMAG -gt LMA

23
Why Use Forwarding Path for Packets from LMA to MN

• Forwarding path
• MN -gt pMAG -gt LMA
• Why?
• To prevent the HO latency between LMA and MAG
  after L2 handover

24
Why Use Forwarding Path for Packets from LMA to MN
LMA

• 1. LMA sends packets to MAG1 by the new tunnel,
  and MAG1 forwards them to pMAG
• Because the MN is attaching to pMAG yet
• The packets from the MN can be transferred by pMAG

pMAG serving
MAG1
1
25
Why Use Forwarding Path for Packets from LMA to MN

• 23. L2 HO
• The L2 connection with pMAG is closed
• New L2 connection is established with MAG1
• 4. Immediately, MAG1 can recognize that L2 HO was
  just finished.
• 5. MAG1 stops forwarding packets to pMAG at once
• 6. MAG1 starts to forward packets to MN directly

LMA
7
pMAG serving
5
4
MAG1
8
11
9
2
3
6
26
Why Use Forwarding Path for Packets from LMA to MN

• In case of normal PMIPv6, there must be time
  waste after L2 HO
• When MAG1 informs LMA that L2 HO was just
  finished.
• MAG1 has to send PBU to LMA, and then LMA has to
  send PBA to MAG1
• Total latency 2 x delay(LMA MAG1)
• Too long latency
• Its the most part of total HO latency
• In case of FMIPv6
• There is no time waste

27
Procedure contd.

• 12. pMAG triggers L2 HO using MIH command
• MIH_HO_Commit
• Until L2 HO is finished, pMAG caches packets
  which come from MN and MAG1 caches packets which
  come from LMA.
• During L2 HO, the MN stores packets destined for
  LMA

12
pMAG serving
LMA
MAG1
28
Procedure contd.
18
pMAG serving
LMA
MAG1
13. L2 HO is finished 14. RS 15. RA 16. IP set
up 17. pMAG sends the packets cached to MAG1 and
MAG1 forwards them to the MN 18. pMAG releases
all resources about the MN
17
14
15
16
13
29
Procedure contd.
pMAG
LMA
MAG1 serving
19. HO is totally finished
19
30
12- L2 HO procedure using MIH command
MN
pMAG
nMAG
PMIPv6Client
MIHFProtocol
MAC
PoA(MAC)
PoS(MIHF)
PMIPv6Client
PoA(MAC)
PoS(MIHF)
PMIPv6Client
MIISServer
MIH_N2N_HO_Commit.request
Resource Availability Check
MIH_N2N_HO_Commit Request
MIH_N2N_HO_Commit.indication

MIH_N2N_HO_Commit.response
MIH_N2N_HO_Commit Response

MIH_N2N_HO_Commit.confirm
MIH_Net_HO_Commit.request
MIH_Net_HO_CommitRequest
L2 HO
MIH_Net_HO_CommitResponse (Status Success)
MIH_Net_HO_Commit.confirm
31
12- L2 HO procedure using MIH command
MN
pMAG
nMAG
PMIPv6Client
MIHFProtocol
MAC
PoA(MAC)
PoS(MIHF)
PMIPv6Client
PoA(MAC)
PoS(MIHF)
PMIPv6Client
MIISServer
MIH_MN_HO_Complete.request
MIH_MN_HO_CompleteRequest
MIH_MN_HO_Complete.indication
MIH_MN_HO_Complete.response
MIH_MN_HO_CompleteResponse
MIH_MN_HO_Complete.confirm
32
Agenda

• Why Proxy MIPv6
• Fast HO procedure
• Fast HO Time line
• Problems to be solved
• Vertical Handover
• Problems to be solved
• Comments

33
Time Line 1. Preparing HO
MAGn
MAG1
LMA
MN
pMAG
Tunnel
Serving
Beacon / Response to a probe
Low
Link_detect
Stores the link info.
Link_Going_Down(Low confidence)
Link_Action(Link_Scan)
Link_Scan
Stores the link info.
Link_Going_Down(High confidence)
PoA List
Resource Query
Target Decisiongt MAG1
34
Time Line 2. make before breaking
MAG1
LMA
MN
pMAG
Trigger_L3_HO
Virtual PBU
BCE Update
Virtual PBA
Tunnel
Inform that virtual PBU is finished
Packet forwarding(destined for MN)
Packet forwarding(from MN)
35
Time Line3. Complete L2 HO
MAG1
LMA
MN
pMAG
Link_down
Link_down
Trigger_L2_HO
BCE Update
Packet caching
Packet caching
Tunnel
L2 HO
RS
RA
Serving
HO complete
release
BCE Release
36
Agenda

• Why Proxy MIPv6
• Fast HO procedure
• Fast HO Time line
• Problems to be solved
• Vertical Handover
• Problems to be solved
• Comments

37
Problems to be solved

• When does the scanning for Candidate Networks
  start?
• 1. After Link_Going_Down(Low confidence Level)
  message occurs ?
• It acts totally up to Link_Going_Down event
• But, Im not sure whether Link_Going_Down can be
  performed to my wishes.
• 2. Check the signal from serving MAG
  periodically. If it decreases to specific level,
  start scanning
• Additive technic is required.
• It Maybe become a burden to the MN

38
Agenda

• Why Proxy MIPv6
• Fast HO procedure
• Fast HO Time line
• Problems to be solved
• Vertical Handover
• Problems to be solved
• Comments

39
Vertical Handover
IPv6 Backbone
MAG1
MAG2
Wireless LAN Interface
3GPP Interface
..
..
..
MN
MN
MN
High speed wireless LAN
3GPP(Cellular)
L2 Link Detection Interface SWAP
Different Access Network Type
40
Why Vertical Handover

• Cost/Capacity/Coverage..
• If a laptop might be able to use both a high
  speed wireless LAN and a cellular technology for
  Internet access.
• Wireless LAN connections generally provide higher
  speeds
• benefit of utilizing the higher bandwidth and
  lower cost
• Cellular technologies generally provide more
  ubiquitous coverage.
• better mobility support and larger coverage
• The laptop user might want to use a wireless LAN
  connection whenever one is available, and to
  'fail over' to a cellular connection when the
  wireless LAN is unavailable.

41
Two Issues of V-Handover

• Multihoming problem.
• There are many types of access network(L2)
• Mobile Node Multiple Interfaced Node.
• Have to support unified signaling service between
  L2 and L3 regardless of L2 type
• MIH

42
Reuse of the Fast-handover method

• Fast-HO uses MIH events and commands between MAG
  and MN
• Those events and commands are applicable to
  various L2 techniques
• MIH_Event_Subscribe
• Link_Detect
• Link_Going_Down
• MIH_N2N_HO_Query_Resource
• MIH_Link_Actions(Link_Scan)
• MIH_HO_Commit .
• The process between MAG and LAM has only L3
  procedure
• Independent on L2

43
Multiple Ifs for MIPv6

• Scenarios and Motivations for Multihomed mobile
  nodes
• Need for ubiquitous access to the Internet
• Need to redirect established sessions
• Need to set up preferences
• Need to select the best access technology
• Need to dispatch traffic over distinct paths
• Need for reliability
• Need to accelerate transmission

44
IPv6 addressing methods

• Auto-configuration is recommended
• Stateless
• Network Prefix(from Router) unique If
  ID(from L2 address of If)
• Statefull
• DHCPv6 unique If ID(from L2 address of If)
• Manual-configuration
• It is not related with If ID
• Auto-configuration is strongly recommended
• To improve efficiency of network management

45
IP changing problem
MN
MN

• Session will break down after handover
• Because of IP address changing

Moving and Changing
IP Net Prefix IF ID from MAC2
IP Net Prefix IF ID from MAC1
46
IP changing problem

• To achieve seamless connection
• IP address must not be changed
• To get other advantages of multi-homing
• Each Interface must have unique IP address
• I will focus on Seamless connection

47
Using current RA method ?

• I did not want to modify normal addressing
  system.
• But, Router Advertisement message supports
  information about only auto-configuration.

48
Virtual Interface(Switch manager) ??
MN
MAG
RepresentativeIP address
RepresentativeInterface ID
MAG
MN
49
Simple Modification of Auto-configuration process

• MN must memorize representative Interface
• The interface by which the MN is attached to LMA.
• When the MN set up the IP address using
  auto-configuration method (by the information
  from RA)
• To get a Interface ID, the MN uses the MAC
  address of representative Interface, instead of
  actual interface.

50
Simple Modification of Auto-configuration process
MN
MN
Moving butno Changing
IP Net Prefix IF ID from MAC2
IP Net Prefix IF ID from MAC1
IP Net Prefix IF ID from MAC1
51
Procedure

• Almost same with fast-HandOver procedure
• But it is possible to set up the connection
  between MN and new MAG, before breaking the
  connection between MN and old MAG
• First part is same with fastHO procedure
• Stage 1 Stage 9

52
Procedure contd.
LMA
10. Trigger L2 connection setup(MAG1 and MNs new
IF) 11. Setup the L2 connection with MAG1
pMAG serving
10
MAG1
11
53
Procedure contd.
LMA

• 12. Inform that virtual PBU is finished
• 13. LMA sends packets to MAG1 by the new tunnel,
  and MAG1 forwards them to pMAG
• Because the MN is attaching to pMAG yet
• The packets from the MN can be transferred by pMAG

pMAG serving
12
MAG1
13
54
Procedure contd.

• 14. Change the connection
• Until L2 HO is finished, pMAG caches packets
  which come from MN and MAG1 caches packets which
  come from LMA.
• During L2 HO, the MN stores packets destined for
  LMA

LMA
14
pMAG serving
MAG1
55
Procedure contd.
20
pMAG serving
LMA
MAG1
15. L2 HO is finished 16. RS 17. RA 18. IP set
up 19. pMAG sends the packets cached to MAG1 and
MAG1 forwards them to the MN 20. pMAG releases
all resources about the MN
19
16
17
18
15
56
Procedure contd.
pMAG
LMA
MAG1 serving
21. HO is totally finished
21
57
Time Line 1. Preparing HO
MAGn
MAG1
LMA
MN
pMAG
Tunnel
Serving
Beacon / Response to a probe
Low
Link_detect
Stores the link info.
Link_Going_Down(Low confidence)
Link_Action(Link_Scan)
Link_Scan
Stores the link info.
Link_Going_Down(High confidence)
PoA List
Resource Query
Target Decisiongt MAG1
58
Time Line 2. make before breaking
MAG1
LMA
MN
pMAG
Trigger_L3_HO
Virtual PBU
BCE Update
Virtual PBA
Tunnel
L2 connection(new if)
Inform that virtual PBU is finished
Packet forwarding(destined for MN)
Packet forwarding(from MN)
59
Time Line3. Complete L2 HO
MAG1
LMA
MN
pMAG
Link_down
Link_down
Trigger_L2_HO
BCE Update
Packet caching
Packet caching
Tunnel
L2 HO
RS
RA
Serving
HO complete
release
BCE Release
60
Agenda

• Why Proxy MIPv6
• Fast HO procedure
• Fast HO Time line
• Problems to be solved
• Vertical Handover
• Problems to be solved
• Comments

61
Problems to be solved

• Complexity
• MIH signaling
• Rollback procedure
• Rapid and sudden movement of MN
• Have to consider unexpected actions

62
Ns-2 status

• Modification for MIH (NS-2.29)
• Link_detected
• Link_Going_Down
• Source analysis for MIPv6
• Mobiwan
• Based on NS2.26/NS2.27

63
Comments Questions
