Title: The Software Matrix Simplifying Software Salvage


1
The Software MatrixSimplifying Software Salvage
  • Riddhiman Ghosh
  • Advisor Dr. James Fawcett

2
Introduction
  • Approximately 100 billion lines of source code at
    work in the world today.
  • Large fractions of code in systems are
    functionally equivalent.
  • However systems are often constructed without
    leveraging existing code bases less than 15 of
    new code serves an original purpose.
  • Reinvention of the wheel in the software
    industry.

3
Introduction
  • Software construction is needlessly error-prone
    and expensive.
  • Were maintaining multiple copies of essentially
    the same software.
  • Time and cost of developing, testing and
    documenting a piece of software is multiplied by
    the number of equivalent copies in existence.

4
Software Reuse
  • Study of reuse recycling of software assets
    has been an important branch in the software
    engineering discipline.
  • Effective reuse promises
  • Reduced development and maintenance costs
  • Gains in development schedule and quicker
    time-to-market
  • Increased robustness and quality
  • Not a new idea.

5
Software Reuse
  • Systematic Reuse an institutionalized
    organizational approach to product development in
    which software assets are intentionally created
    or acquired to be reusable
  • However, few organizations practice systematic
    reuse, in spite of a recognition of its potential
    benefits.
  • Reuse is hard!

6
Gap between theory and practice in Reuse

Not all the theoretical oriented and
sophisticated solutions presented by
researchers have ...thrilled the
practitioners... Zand, M. ...the reuse
community has worked on complex technologies and
methods with high ceremony, yet most of the
software community seems to be looking for
simpler solutions... High ceremony methods
require an organization with high process
maturity to achieve success. Griss, M.

7
Software Salvage
  • What we seen in the industry is not software
    reuse, but rather software salvage
  • Salvage lifting of a significant block of
    existing systems and inserting them into a newly
    developed system.
  • Radar Systems Department, General Electric
    Company (Syracuse, NY) routinely attempted
    salvage in the building of a new radar.

8
Reuse vs. Salvage
  • We make a distinction between the terms software
    reuse and software salvage.
  • Reuse connotes immutability
  • the individual pieces meant for reuse cannot be
    modified theyre designed and implemented to be
    adaptable but with no intent to change even a
    single character of source code.
  • Salvage makes no guarantee of immutability
  • very often source code of individual pieces being
    salvaged is modified.

9
Problem
  • Effective salvage is difficult to accomplish
  • The large pieces we want to recycle often have
    many dependencies on parts we dont want.
  • These dependencies usually require expensive
    changes to the part being salvaged.
  • Pulling out pieces from different systems, and
    getting these extricated pieces to work together
    is challenging.
  • Think of salvage as analogous to transplanting
    the heart from one living organism to another!
    Similar problems, when we pull out a part from a
    software system due to the connectedness inherent
    in typical software.

10
Problem
  • It is difficult to salvage existing parts
    systems and build new systems from them, with
    ease.

11
Goal
  • Enable leveraging of major parts of systems
  • Eliminate or reduce changes required by salvage
    so that salvage moves closer to the reuse model
    (immutability), without requiring high-process
    organization.
  • Simplify software salvage to make it a useful
    paradigm.

12
Prior Approaches
  • Two major (and fairly recent) approaches towards
    encouraging reuse have been
  • object-oriented reuse
  • component-oriented reuse.

13
Object-Oriented Reuse
  • Reuse has been one of the classic motivations of
    object-orientation
  • Object oriented theory
  • mandated discipline in writing code through
    best-practice guidelines such as separating
    interface from implementation
  • Encouraged reuse through inheritance,
    composition, parameterization

14
Object-Oriented Reuse
  • However OO technologies didnt quite engender the
    reuse revolution that was hoped for.
  • Perhaps the only OO libraries widely used
    user-interface frameworks (such as MFC) and
    libraries for data structures.
  • While OO techniques have made compiler libraries
    an effective means of reuse, business
    organizations have had a harder time getting
    leverage from their pre-existing software assets
    only through the creation and consumption of OO
    libraries.

15
Object-Oriented Reuse
  • The definition of an object is purely technical
  • Defined as an encapsulation of state and behavior
  • No direct mapping to the physical unit that is
    actually deployed, versioned and potentially
    reused.
  • Objects dont fit the salvage model well
  • In terms of granularity, they are of an
    inappropriate size to be mixed and matched.
  • They are the size of grains of sand, while what
    salvagers are typically looking for in building
    systems, are bricks.

16
Component-Oriented Systems
  • The logical next step was the notion of
    components
  • a coherent package of software implementation
    that can be independently deployed and composed
    with other components.
  • of coarser granularity than objects
  • independent and deployable implies executable or
    loadable code
  • The defining feature of component technology is
    that a system, which is composed of components,
    can be repaired or made better by updating
    components, without rebuilding the whole system.

17
Component-Oriented Systems
  • There are several component technology offerings
  • COM, CORBA, JavaBeans/EJB, .NET Components
  • Adopting a component-oriented approach (rather
    than only concentrating on programming language
    as in OO theory) is beneficial.
  • But the existence of these component technologies
    has not solved the problems that plague software
    salvage, discussed earlier
  • Packaging techniques alone are not enough

18
Our Approach
  • We are of the view that components are useful
    only if there is a framework that actively
    supports and promotes their reuse.
  • .NET and J2EE have framework support, however it
    is focused on generic industry problems (network
    communication, web publishing, application
    security, etc.)
  • We seek to support vertical, perhaps proprietary,
    applications, where building a huge framework is
    impractical from a return on investment point of
    view.

19
Our Approach
  • Make salvage easier by
  • viewing applications as compositions of different
    pieces
  • having a framework of collaborating pieces from
    which applications can be composed dynamically
  • Try to achieve benefits of the Software-IC
    model a plug-and-play approach to software
    construction.

20
Our Approach
  • We are limiting the hard problem of general reuse
    to a smaller domainof salvage within an
    organization, to be used in the construction of
    modest-sized systems (about 200,000 lines of
    code).
  • To address this domain would be to provide
    solutions of value to the small and medium-sized
    software shops that have been resistant to adopt
    systematic reuse.

21
Software Matrix
  • The Software Matrix is a framework that actively
    supports and promotes the salvage of components.
  • We focus on the reuse of major blocks of code
    rather than low-level components
  • By employing message-passing and mediator
    structures and by supporting the discovery of
    needed types, weve built a pluggable
    architecture that can gracefully adapt to salvage
    operations.

22
Software Matrix
  • In particular, the Matrix is a runtime
    infrastructure that acts as a substrate into
    which individual pieces of an application
    different blocks of code can plug.

23
Software Matrix
From these plugged-in individual pieces the
Matrix dynamically composes applications.
24
Software Matrix
  • This infrastructure was named the Software Matrix
    in order to connote a very structured pattern of
    building software.
  • System elements are embedded in this substrate
    a matrix /collection through which applications
    are dynamically composed.
  • The image of endless banks of incubators of
    humans in a matrix, as from The Matrix motion
    picture, isnt entirely unintentional, if
    somewhat flippant.

25
Cells
  • The individual blocks of code that plug-in to the
    Matrix are called Cells and are the building
    blocks out of which applications are built.

26
Cells
  • Cells represent the unit of composition and reuse
    in our system.

27
Cells
  • An application is built through the collaboration
    of Cells, and all Cells communicate with each
    other strictly through messages (we use XML
    encoded messages)

28
Cells
  • One of the problems of salvaging extracting
    parts of monolithic (or very tightly-coupled)
    applications.
  • By enforcing a separation of concern between
    Cells by inserting a message bus between them we
    are insisting on loose-coupling between different
    pieces of an application, which makes salvaging
    these pieces for use in future applications much
    easier.

29
A closer look at Cells
  • Every Cell contains
  • a message queue
  • holds request and response messages during
    collaboration with other cells.

30
A closer look at Cells
  • Every Cell contains
  • a capability list
  • used to advertise the capabilities of a cell to
    other cells, via the Matrix. (E.g.
    SU.Math.Convolution)
  • The capability list is used by the Matrix in
    order to discover the right cells for system
    construction.

31
A closer look at Cells
  • Every Cell contains
  • a globally unique identifier (GUID)
  • Cells can be uniquely identified using a GUID.
    This is used by the Matrix for several operations
    such as discovery and registration.

32
A closer look at Cells
  • Every Cell contains
  • functionality
  • Cells also contain the functionality that allows
    them to be considered as software assets with
    potential for reuse.

33
A closer look at Cells
  • All cells subscribe to a common protocol (ICell)
    that specifies how to
  • register and un-register with the Matrix
  • advertise capabilities
  • send and accept messages
  • collaborate with other cells (could be
    synchronous, asynchronous or one-way)

ICell
MyCell
34
A closer look at Cells
  • Every cell also has an entry-point (start), and
    is given a chance to execute once it is
    plugged-in.
  • This entry-point (empty/non-empty) decides
    whether a cell will be only a passive server,
    or itself actively seek collaboration from other
    cells.

35
Example
  • Sample application needs to read data samples
    from an input file, perform a signal processing
    operation on the a data (e.g., filtering), plot
    the results of the operations on the system
    display, and log the results to a file.
  • The major pieces of the application would be
    responsible for
  • file operations
  • signal processing
  • graphical plotting

36
Example
  • These would be written as cells and plugged-in to
    the Matrix.
  • The Matrix would then assume the responsibility
    of constructing the application from these
    individual cells.
  • In order to perform its task a cell may need
    services of another cell. But cells do not
    explicitly bind to other cells they only
    specify what message type they need handled, and
    the Matrix discovers cells capable of handling
    that message.
  • If no suitable cell found, a not supported
    message is generated.

37
Example
38
Example
Sequence of events in the construction of the
sample application
39
Example
  • So what we see here is dynamic composition we
    are building a system from pieces that exist on
    the Matrix at runtime. The compositional aspects
    (as opposed to only computational aspects) of
    software are being taken care of by the Matrix.
  • It automatically connects the right pieces at
    run-time without having to bind to anything
    explicitly at compile-time.
  • This method of software construction, with its
    dynamic nature and loosely coupled building
    blocks, is amenable to salvage operations. The
    very same Cells could be used to build other
    applications.

40
How do cells plug-in?
  • Cells are implemented as plug-in modules, and
    are realized using .NET components.
  • The Matrix uses the reflection and
    late-binding (Fusion) features of the .NET
    framework to discover and register plug-ins.
  • Given an .NET assembly, the Matrix will reflect
    over the contained types to determine which of
    them implement the ICell interface in order to
    recognize valid plug-ins.

41
How do cells plug-in?
  • Throughout its lifetime, the Matrix runtime
    infrastructure monitors a known location the
    plug-in directory, in order to discover if any
    new cells are present.
  • On detecting a valid cell, the Matrix registers
    the cell with itself. This newly registered cell
    (along with previously registered cells) is then
    available for system construction.

42
How do cells plug-in?
At periodic intervals the Software Matrix
interrogates a known location in order to
discover if any new Cells are present, and if so
registers them.
43
Steps to take advantage of the Matrix
  • In order to enable salvage, pieces of an
    application (at the time of writing it, or
    existing pieces) are wrapped in a Cell.
  • Create a wrapper that inherits from ICell (e.g.
    we wish to create FileManager Cell responsible
    for common file operations )
  • FileManager ICell
  • ...
  • ?

44
Steps to take advantage of the Matrix
  • The Capability List of this FileManager Cell is
    then populated to indicate the types of messages
    it is capable of handling.
  • ?

CapabilityList.Add(SU.FileManager.Files.Read) C
apabilityList.Add(SU.FileManager.Files.Write) C
apabilityList.Add(SU.FileManager.Files.Search)
CapabilityList.Add(SU.FileManager.Files.Compressi
on)
45
Steps to take advantage of the Matrix
  • Override the process method to add appropriate
    message processing
  • Basically you specify what is to be done in
    response to a particular message type delegate
    calls to your implementation.
  • ?

46
Steps to take advantage of the Matrix
  • Compile, and copy the resulting binary into the
    plug-in directory of the Software Matrix. The
    Matrix will automatically detect and register the
    cell, and it will be available for composition.
  • ?

47
Steps to take advantage of the Matrix
  • If a cell wishes to use other cells (or is a
    program executive for instance), it will probably
    say
  • ...
  • Result syncSend(
  • "SU.FileManager.Files.Search",
  • Params)
  • ...
  • Here it is trying to locate a cell that can
    handle the named message type.

48
Features
  • Fine-grained message-passing
  • Many problems associated with software salvage
    arise from extracting one of several
    tightly-coupled pieces of a system.
  • We are using message passing at a much finer
    level of granularity than is normally seen
  • The Matrix requires messages be the only mode of
    collaboration between different parts of an
    application, thereby decreasing the degree of
    coupling.
  • This loose coupling is critical to the success of
    salvage operations.

49
Features
  • Dynamic Composition
  • The Matrix takes care of the compositional
    aspects of software by automatically discovering
    and connecting the right pieces and building an
    application at runtime
  • By adding a few more cells into the Matrix if
    needed, we can build new applications by reusing
    existing cells.

50
Features
  • Support for System Evolution
  • Since the appropriate cell to serve a particular
    message type is selected at runtime, the Matrix
    supports evolution of software systems.
  • Evolving requirements can be accommodated easily
    by unplugging or modifying only those cells that
    represent the affected part of the system.
  • Easy to field-replace cells all one has to copy
    the new cell over the old cell in the plug-in
    directory.
  • Effective way to support program maintainability,
    bug fixes/upgrades.

51
Features
  • Simplicity
  • The Matrix is a supporting infrastructure that is
    lightweight (the bare infrastructure is roughly
    only 2000 lines of code)
  • Simple to use. The infrastructure comes with
    documented full source (if needed) and sample
    applications.
  • The underlying technology used is the .NET
    component model which is considered superior and
    less complex as compared to other models such as
    COM.

52
Assessment
  • Built applications in the regular style and
    using the Software Matrix.
  • Working on an assessment model with quantitative
    and qualitative criteria for effective
    comparison. How easy is salvage?
  • SLOC
  • Complexity
  • Changes necessitated, cognitive distance
  • Performance

53
Comparison with prior and related work
  • There exists a combination of middleware and
    component technologies such as COM and CORBA that
    have reusability as one of their goals.
  • COM, CORBA are considered highly complex,
    over-specified and require heavy-weight
    supporting infrastructures.
  • The Matrix was meant to address the specific
    problem of salvage and is lightweight (approx.
    2000 SLOC) and simple.

54
Comparison with prior and related work
  • Most middleware technologies use the
    procedure-call model of collaboration. Having
    components bind to exact function signatures is
    not flexible enough leads to the
    tightly-coupled systems that make salvage
    operations difficult.
  • The Matrix uses message-passing as the mode of
    collaboration between components. This leads to
    looser coupling of system elements resulting in
    potentially easier salvage in the future.

55
Comparison with prior and related work
  • Message Oriented Middleware (MOM) and to a
    certain extent Web Services also use
    message-passing (most web services use XML-RPC,
    though they support a message-passing interface)
  • The Matrix differs from them in the granularity
    and scale of message-passing, since we are
    focused on local compositions of cells
    (components) to build applications, rather than
    accessing remote functionality over the network.

56
Conclusion
  • The Software Matrix is a runtime substrate with a
    plug-in architecture that enables simpler
    software salvage.
  • Enforces loose coupling of system elements
  • Helps in the discovery and collaboration of
    components.
  • Easy to dynamically compose new applications from
    existing cells.
  • Provides support for product evolution and
    maintenance important in large systems.
  • Simplifying software salvage is a worthy goal and
    will have a positive impact on productivity in
    the software industry.

57
End of Presentation
Write a Comment
User Comments (0)
About PowerShow.com
