Title: Introduction to CPL


1
(No Transcript)
2
Introduction to CPL
  • Jonathan Rosenberg
  • Chief Scientist

3
CPL Problem Statement
  • Would like to allow end users to
  • Define new services
  • GUI tools or web
  • Hand edit
  • Back and forth
  • Customize vanilla services
  • Have their services be enabled instantly
  • Service providers require
  • Platform independence
  • Decouple service creation tool from execution
  • Decouple service from signaling protocol
  • Assurances on safety

4
What are the Options?
  • Web interfaces populate customer profile data
  • Not cross platform
  • Not flexible
  • End users write Java applications and upload
  • Moving between GUI tools and hand editing is
    impossible
  • Safety issue still exists sandboxing helps but
    not completely
  • BIG IDEA - Define an XML based Call Processing
    Language (CPL)

5
Advantages of XML for call services
  • Easily edited by hand or by GUI tools
  • Cross platform
  • Allows us to define our own language primitives
  • Can engineer language to be safe
  • Can make it easy to build many common services
  • Can be manipulated by off the shelf XML tools
  • Readily transported in HTTP, SIP, FTP, other
    means
  • Small in size (compared to Java)
  • Fast operation

6
History of CPL
  • Concept originated as end user uploading of
    service logic in SIP REGISTER
  • JDR and HGS, 1997
  • Proposed as one of main work items for new IP
    Telephony (iptel) working group when it was
    formed in Nov 1997
  • Jonathan Lennox, Columbia U. took role as primary
    driver and author
  • Framework and Requirements done first
  • RFC2824 issued May 2000
  • CPL specification
  • First draft April 1999
  • Submitted for consideration as RFC Dec. 2000
  • Implementations
  • First one by JDR, mid 1999 at Bell Labs
  • Second by dynamicsoft
  • Numerous ones exist or are in progress now
  • Indigo Software
  • Ubiquity
  • Netcentrex

7
CPL FAQ
  • Where do CPLs get executed?
  • In network elements
  • SIP Proxies
  • SIP Application Servers
  • H.323 Gatekeepers
  • Can be used in clients, not designed for it
  • Who writes CPLs?
  • Engineered for end users to write
  • Can be written by administrators and third
    parties as well
  • How do CPLs get into the network?
  • Uploaded in REGISTER (next slide)
  • Uploaded in http POST
  • Sent through any other means
  • Direct database writes
  • FTP
  • etc.
  • What kinds of services are best suited for CPL?
  • Call routing services
  • Call screening services
  • Call logging services

8
Uploading CPL in REGISTER
REGISTER sipsip.example.com SIP/2.0 From Joe
User ltsipjoe_at_example.comgt To "J. User"
ltsipjoe_at_example.comgt CSeq 18 REGISTER Expires
1800 Call-ID 39485832_at_joespc.example.com Contact
sipjoe_at_joespc.example.com Accept
application/cplxml Authorization Basic
am9lOnBhc3N3b3JkAFBX Content-Type
application/cplxml Content-Length
137 Content-Disposition script Content-Action
add ltcplgt ltincominggt ltreject
status400/gt lt/incominggt lt/cplgt
  • Include CPL in body of REGISTER message
  • MIME type application/cplxml
  • Content-Disposition Header
  • Indicates purpose of bodies
  • Indicates that content contains call logic
  • Content-Action indicates what is desired
  • Add the CPL to the server
  • Delete CPL
  • CPLs DO NOT get refreshed

9
CPL Lifecycle
INV
INV
  • CPL Execution starts on arrival of INVITE message
    at a proxy
  • Governs operation of proxy for INVITE transaction
    ONLY
  • When final response is sent, CPL execution
    terminates
  • Does not stay in the call
  • This is why CPL is good at pre-call services like
    routing and screening

300
ACK
INV
600
ACK
600
CPL Lifecycle
Proxy
UA1
UA2
10
Proxies and CPL
CPLs for called user
CPLs for caller
  • SIP call setups traverse many paths
  • Which ones does a user need to put their CPL on?
  • CPL guides behavior of a single proxy
  • Incoming calls, CPL is generally on proxy that
    accesses registrations for that user
  • Outgoing calls, CPL is generally on local
    outbound proxy
  • CPLs can be put anywhere else
  • Up to user/system to decide where they need to go

11
CPL Structure
lt?xml version"1.0" ?gt lt!DOCTYPE cpl PUBLIC
"-//IETF//DTD RFCxxxx CPL 1.0//EN"
"cpl.dtd"gt ltcplgt ltsubaction
id"voicemail"gt SOME STUFF HERE
lt/subactiongt ltsubaction idemailgt
SOME STUFF HERE lt/subactiongt
ltincominggt SOME STUFF HERE
lt/incominggt ltoutgoinggt SOME STUFF
HERE lt/outgoinggt lt/cplgt
  • CPL represents a tree
  • Trees have nodes and links
  • Each corresponds to a tag in CPL
  • Nodes
  • Specify actions to take or decisions to make
  • Links
  • Specify results of actions
  • Specify which decision was made
  • CPL contains subroutines, each of which is a tree
  • Incoming - tree to execute for incoming calls
  • Outgoing - tree to execute for outgoing calls
  • Subroutines - can be used by either incoming or
    outgoing

12
Beginning a CPL
lt?xml version"1.0" ?gt lt!DOCTYPE cpl PUBLIC
"-//IETF//DTD RFCxxxx CPL 1.0//EN"
"cpl.dtd"gt ltcplgt ltsubaction
id"voicemail"gt SOME STUFF HERE
lt/subactiongt ltsubaction idemailgt
SOME STUFF HERE lt/subactiongt
ltincominggt SOME STUFF HERE
lt/incominggt ltoutgoinggt SOME STUFF
HERE lt/outgoinggt lt/cplgt
  • First line Specifies XML version
  • Next line Specifies DTD to be used for validation
  • All CPLs then followed by CPL tag
  • Within CPL tag, you can have
  • subactions
  • zero or one incoming
  • zero or one outgoing

13
Mapping Trees to CPLs
ltlookup sourceregistrationgt ltsuccessgt
ltproxy/gt lt/successgt ltotherwisegt
lttime-switchgt lttime dtstart20001001T000000
duration24H
freqweekly bydayMOgt
ltreject status400/gt lt/timegt
ltotherwisegt ltredirect/gt
lt/otherwisegt lt/time-switchgt
lt/otherwisegt lt/lookupgt
lookup
otherwise
success
What is the date?
proxy
Monday
otherwise
Reject
Redirect
14
CPL Execution Model
  • Processing begins at incoming or outgoing tag
  • Depends on system
  • Server traverses tree, making decisions or
    performing actions
  • Implicit global variable - the list of locations
  • Certain tags modify the location list
  • location, lookup, location-filter
  • Other tags use the location list
  • proxy, redirect

15
Available tags
  • Signaling Actions
  • proxy
  • redirect
  • reject
  • Decisions
  • address-switch
  • string-switch
  • time-switch
  • priority-switch
  • Other actions
  • mail
  • log
  • Location modifiers
  • location
  • lookup
  • remove-location
  • Subroutine calls
  • subaction
  • sub

16
Proxy tag
  • Node
  • Proxies to current location list
  • Outputs are result of proxy
  • busy (486)
  • noanswer (408 or timeout)
  • redirection (3xx)
  • failure (4xx,5xx,6xx)
  • Attributes
  • timeout how long to try before giving up
  • recurse whether to recurse or not
  • ordering sequential, parallel, first-only

ltproxy recurseyesgt ltbusygt ltreject/gt
lt/busygt ltnoanswergt ltreject/gt
lt/noanswergt lt/proxygt
17
Proxy tag Details
  • Tried elements are removed from global location
    list
  • for parallel and sequential, thats all sip URLs
  • for first only, thats the top sip URL
  • Default timeout
  • 20s if a no-answer tag is present
  • system defined otherwise
  • why? If there is a no-answer, there is something
    else to do
  • Default recurse is yes
  • Default ordering is parallel
  • Recursing
  • Contacts from 3xx are adding to implicit global
    location list
  • List is always kept in sorted order based on q
    value

18
Redirect tag
  • Node
  • Redirects to the current location list
  • Placed in Contact headers
  • OK if there are no locations
  • No outputs allowed script execution terminates
  • Single attribute permanent
  • yes or no
  • Indicates whether redirection is a permanent or
    temporary condition
  • For SIP, 301 in one case, 302 in other

ltlocation urlsipfoo_at_bargt ltredirect/gt lt/locat
iongt
19
Reject tag
  • Node
  • Rejects the call
  • Status code to use is provided as an attribute
  • busy,notfound, reject, error
  • SIP servers can also allow numeric codes
  • optional reason phrase can also be used
  • CPL processing terminates

ltreject statusbusy/gt
20
Switch Statements
  • Switch statements are the primary decision making
    components in CPL
  • They support a common structure
  • Start with X-switch, where X is the element to
    check
  • Subtags are all called X, and each of them
    represents a link with a specific value of the
    element
  • otherwise is defined as an allowed subtag of
    X-switch
  • not-present as well - when element is not in the
    message

ltfoo-switchgt ltfoo ishellogt ltreject/gt
lt/foogt ltfoo isgoodbyegt ltredirect/gt
lt/foogt ltotherwisegt ltproxy/gt lt/otherwisegt
ltnot-presentgt ltlog/gt lt/not-presentgt lt/foo-s
witchgt
21
Address-Switch
  • Used to make decisions based on the value of
    address fields in the message
  • Defines two attributes, field and subfield
  • Field is
  • origin (From field)
  • original-destination (To field)
  • destination (Request URI)
  • Subfield defines component of the URI in the
    field
  • address-type (scheme of URL)
  • user
  • Host
  • port
  • tel
  • If its a tel URL, or a sip URL with a telephone
    number, this element is defined
  • display
  • display name undefined for request URI
  • password

22
Address
  • Outputs of address-switch are address tags
  • Singe attribute, which can be one of is,
    contains, subdomain-of
  • is
  • used for exact match
  • case sensitivity depends on subfield
  • contains
  • substring match
  • case sensitivity depends on subfield
  • Subdomain-of
  • only defined for tel and for host
  • for host, it matches if the domain in the
    subfield is a subdomain of the listed domain
  • for tel, it matches if the telephone number
    contains the listed number as a prefix

23
Examples
ltaddress-switch fieldorigin
subfieldusergt ltaddress isruser/gt lt/address
-switchgt ltaddress-switch fielddestination
subfieldportgt ltaddress
is5060/gt lt/address-switchgt ltaddress-switch
fieldoriginal-destination
subfieldhostgt ltaddress subdomain-ofcom/gt lt
/address-switchgt ltaddress-switch fieldorigin
subfielddisplaygt ltaddress
containsFDisp/gt lt/address-switchgt
  • The given address tags to the right all match
  • Assume the request is

INVITE sipruser_at_rdomain.com SIP/2.0 From
FDisplay ltsipfuser_at_fdomain.comgt To TDisplay
ltsiptuser_at_tdomain.comgt
24
Address-Switch motivations
  • Older CPL drafts used string-switch for this
  • Motivations for change
  • Hard to match on specific fields through glob
    matching
  • Glob matching was hard to implement
  • Take advantage of inherent structure
  • Didnt work for H.323

25
String-Switch
  • String matching on textual fields in request
  • Mandatory attribute field indicates whats being
    matched
  • subject
  • user-agent
  • organization
  • language
  • Subtags of string-switch are string
  • String contains either is or contains for
    exact or substring matching

ltstring-switch fieldsubjectgt ltstring
isSalesgt ltlocation urlsipsales_at_foo.comgt
ltproxy/gt lt/locationgt lt/stringgt
ltstring containsmarketinggt ltlocation
urlsipmarketing_at_foo.comgt ltproxy/gt
lt/locationgt lt/stringgt ltotherwisegt
ltlocation urlsiprandom_at_foo.comgt
ltproxy/gt lt/locationgt lt/otherwisegt lt/string-s
witchgt
26
String Switch Details
  • Matching Issue
  • Want case insensitive
  • These fields are freeform UTF-8!
  • Case insensitivity depends on language and locale
  • Nearly impossible to do
  • Solution is a new Compatibility Composition form
    defined for Unicode
  • Language is Accept-Language header in SIP
  • Good for routing to operator based on language of
    caller
  • Only substring matching is useful
  • Accept language has parameters, commas, etc.

27
Priority-Switch
  • Allows matching based on priority of request
  • Subtags are priority tags, which have attribute
    less, equal, greater
  • Comparisons are against defined SIP values of
    emergency, urgent, normal, non-urgent
  • If nothing is in request, priority is normal
  • unknown priorities mapped to normal for greater,
    less comparisons

ltpriority-switchgt ltpriority equalsnewpriority
gt ltlocation urlsipnew_at_foo.comgt
ltproxy/gt lt/locationgt lt/prioritygt
ltpriority lessnormalgt ltlocation
urlsipwhocares_at_foo.comgt ltproxy/gt
lt/locationgt lt/prioritygt ltpriority
greaterurgentgt ltlocation
urlsipemergency_at_foo.comgt ltproxy/gt
lt/locationgt lt/prioritygt lt/priority-switchgt
28
Time Switch
  • Significantly different and more complex than
    initial version
  • Initially crontab based
  • Now iCal based
  • Why iCal?
  • Makes integration with calendaring programs
    easier
  • More complete, more modern
  • -03 based on an iCal subset proven to be
    implementable in O(1) time!
  • Powerful representation of repeating events
  • Every third Tuesday in February and March
  • First Monday of the month
  • etc.

29
Handling Timezones
  • User and server may be in different timezone
  • CPL times should refer to timezone of user
  • How to indicate timezone of user?
  • Offset from GMT not sufficient
  • Want scripts to be valid for years
  • Offset varies as DST comes and goes!!
  • Solution
  • time-switch contains either tzurl or tzid
  • tzurl refers to an object that defines the
    timezone
  • tzid refers to either a to-be-established
    registry, or a server specific name
  • names are things like EST and CST
  • Java has a standard set of names

30
Time tags
  • Time tags contain many attributes that define
    repeating events
  • Basic event description
  • dtstart event start date and time
  • dtend event end time
  • duration instead of dtend
  • Defining repititions through periodicity
  • freq frequency of occurrence
  • daily, weekly, monthly, yearly
  • interval how often recurrence repeats
  • Limiting repititions
  • until date/time when repititions end
  • Defining exceptions
  • byday List of days of the week
  • bymonthday List of days of the month
  • byyearday List of days of the year
  • byweekno List of weeks of the year
  • bymonth List of months of the year

31
Exceptions
  • Expansion
  • If frequency is a greater unit than largest
    exception
  • Adds more events
  • Example freqyearly bymonthjan,feb defines
    an event that repeats twice a year - once in jan,
    once in feb
  • Contraction
  • If frequency is a smaller unit than largest
    exception
  • Reduces number of events
  • Example freqdaily bydayMO,WE defines only
    Mondays and Wednesdays

32
Example time-switch
lttime-switch tzid"America/New-Yorkgt lttime
dtstart"20000703T090000" duration"8H"
freq"weekly" byday"MO,TU,WE,TH,FR"gt
ltlocation urlsipwork_at_foo.comgt ltproxy/gt
lt/locationgt lt/timegt lttime
dtstart20000703T170000
dtend20000703T210000 freqweekly
bydayMO,TU,WE,TH,FRgt ltlocation
urlsiphome-eve_at_foo.comgt ltproxy/gt
lt/locationgt lt/timegt lttime dtstart20000703T00
0000 duration24H freqweekly
bydaySA,SUgt ltreject reasonits the
weekend/gt lt/timegt lt/time-switchgt
  • Time of day forwarding/screening application
  • Proxy calls to work during 9-5 during the week
  • Proxy calls to home during the evening of the
    week
  • Reject calls on weekends

33
Location Addition
  • Location
  • Defines a location to be added to the global
    location list
  • Single attribute, URL, contains the URL to add to
    the list
  • Lookup
  • Obtains the URI to add through indirection
  • source attribute specifies place to go to
  • registration looks in registration DB
  • if source is a URL, fetches the URL and that
    contains a document with just a URL to add
  • success, failure, notfound outputs

ltlocation urlsipfoo_at_bargt ltredirect/gt lt/locat
iongt
ltlookup sourceregistrationgt ltsuccessgt
ltproxy/gt lt/successgt lt/lookupgt
34
remove-location
  • Allows for removal of locations from global
    location list
  • Based on caller preferences specification
  • Caller prefs
  • Associates parameters with contacts
  • Example mobilefixed, mediavideo
  • INVITEs contain headers that ask to reach
    specific contacts by parameter
  • Parameter filtering
  • two main attributes, param and value
  • both are comma separated lists
  • param contains the name of a parameter (e.g.,
    mobile)
  • value contains the value for that parameter
    (e.g., fixed)
  • same number of elements in param and value lists
  • causes matching contacts to be removed
  • Address filtering
  • location attribute contains a URL pattern to match

35
Example Parameter filtering
36
Mail tag
  • Allows CPL to send email
  • Single parameter, url, contains mailto URL to use
  • CPL server will
  • Set the From field to its own address
  • Set the body to contain information about the
    call, unless a body is specified by CPL
  • Set the Subject to something useful, unless
    subject is specified by CPL
  • Caveats
  • Ampersand must be with an entity!

ltmail urlmailtouser_at_host?subjectfoo
ampbodyhello20theregt
37
Log tag
  • Allows CPL to generate log output
  • How output is logged is system dependent
  • Two parameters
  • name specifies name of log to use
  • interpretation of name is system dependent
  • comment text to place in log
  • CPL should also generate time of day and other
    params in log

ltlog commentrejected callgt
38
Subroutines
ltsubaction idvmailgt ltlocation
urlsipvmail_at_foo.comgt ltproxy/gt
lt/locationgt lt/subactiongt ltincominggt ltlookup
sourceregistrationgt ltsuccessgt
ltproxygt ltnotfoundgt ltsub
refvmail/gt lt/notfoundgt lt/proxygt
lt/successgt ltotherwisegt ltsub
refvmail/gt lt/otherwisegt
lt/lookupgt lt/incominggt
  • CPL can call a subroutine defined by subaction
  • Subactions have an id
  • To call subroutine, use sub tag with that Id as
    the value of ref attribute
  • Subroutines can only be called if they are
    physically above in the CPL
  • Avoids loops!

39
Default Actions
  • What happens if a script reaches a point where
    there are no more tags?
  • Default Action is taken
  • Default action depends on how far script has
    gotten
  • No signaling actions, no locations defined,
    location set empty
  • lookup in database, proxy or redirect as normal
  • No signaling actions, no locations, location set
    non-empty
  • Happens for outgoing calls
  • Proxy to location set
  • locations or lookups performed, no signaling
  • proxy or redirect there
  • proxy action invoked, noanswer output not present
  • let phone ring forever, or until system defined
    timeout
  • proxy performed, responses received
  • forward best response upstream

40
CPL Extensions
  • Uses XML namespaces
  • Each extension defines its own namespace
  • Will render DTD validation useless!
  • General problem with namespaces

ltincominggt ltlookup sourceregistrationgt
ltsuccessgt ltproxy xmlnsfoohttp//bargt
ltfooscrewupgt ltsub refvmail/gt
lt/fooscrewupgt lt/proxygt
lt/successgt ltotherwisegt ltsub
refvmail/gt lt/otherwisegt
lt/lookupgt lt/incominggt
41
Information Resource
  • Jonathan Rosenberg
  • jdrosen_at_dynamicsoft.com
  • 1 973.952.5000
Write a Comment
User Comments (0)
About PowerShow.com
