Principle of Functional Verification Chapter 13

1
Principle of Functional Verification Chapter 13

• Presenter Fu-Ching Yang

2
Outline

• Chapter 1 Introduction
• Chapter 2 Definitions
• Abstraction levels
• Verification of a design
• Definition of a test
• Chapter 3 - Methods for Determining the Validity
  of a Model
• Stimulus generation methods
• Results analysis methods
• Conclusion

3
Introduction (cont.)

• The functional verification takes 70 of the
  total effort on a project
• Manufacturing verification ? Functional
  verification
• Why functional verification is needed?
• Most modern designs need a testing method that
  can be used before a prototype is built

4
Introduction

• The goal of functional verification
• To prove that a design will work as intended.
• 1. determine what the intent is
• Even the intent may not always be clear
• The spec. itself may have mistakes
• 2. determine what the design is
• A model may be built first
• 3. compare the two to ensure that they match
• 4. estimate the level of confidence

Test Stimulus
Design under Test
Response Check
Pass/Fail
Simulator
5
Outline

• Chapter 1 Introduction
• Chapter 2 Definitions
• Abstraction levels
• Verification of a design
• Definition of a test
• Chapter 3 - Methods for Determining the Validity
  of a Model
• Stimulus generation methods
• Results analysis methods
• Conclusion

6
Abstraction levels

• Behavioral Model
• To examine the basic operation
• There may not be any timing information
• May embed cycle information in code
• Register-Transfer-Level Model
• Detail function description
• Provide accurate cycle-level timing information
• No subcycle timing EX propagation delays
• Gate-Level Model
• Each individual logic element is specified
• Have subcycle timing information

Highest simulation speed
Most detail
7
Verification of a design

• White box model
• The test is aware of the inner workings
• Allow the test to directly monitor internal
  states
• Black box model
• Verify at the boundaries of the design
• Require more simulation cycle and more logic to
  verify
• Reasons of using
• A test is often focused on verifying the intent

Clock
State
State0
Reset
State2
Increment
State1
White Box
Clock
State
Reset
Increment
Black Box
8
Definition of a test

• Device under test test stimulus generation
  checking

Link
Stimulus Generation
Device Under Test
Stimulus Generation
Device Under Test
Checking
Checking
HDL Simulator
Verification Language
HDL Simulator
Different simulation language
Same simulation language
9
Outline

• Chapter 1 Introduction
• Chapter 2 Definitions
• Abstraction levels
• Verification of a design
• Definition of a test
• Chapter 3 - Methods for Determining the Validity
  of a Model
• Stimulus generation methods
• Results analysis methods
• Conclusion

10
Stimulus Generation Methods

• Test vector Generation
• Stimulus Capture
• Transactions
• Assertions

11
Test vector generation

• Specify exactly what values are to be sent to
  every input
• Advantage
• It is simple to understand and simple to use
• Disadvantage
• It can be only used in trivial design
• The vectors can be large for modern design
• Little modification to the spec. will have
  significant impact on the vectors.

12
Stimulus Capture

• When a device already exists that is similar to
  the design being created.
• One can capture vectors from existing device
• Advantage
• A large number of vectors can be easily captured

Real System
Existing Design
Results File
Stimulus File
13
Transactions (cont.)

• This allows a test to be written in a more
  abstract fashion
• Specify the transaction to be done
• Not all the details about how an operation is to
  be executed

Transactor
Test Core Write (Addr, data) Data Read (Addr)
Test Interface
Write Operation
Bus driver
Device Under test
Processor Bus
Read Operation
Other Operations
14
Transactions

• Aspects of transactor
• Encapsulation
• The transactor contains the knowledge of the
  protocol of the group of signals that make up the
  bus
• Abstraction
• The test is not involved in any lower-level
  issues
• User interface
• A standard set of routines that a test can call
• Modularity
• Ex Separate the processor bus transactor and the
  test

15
Assertions (cont.)

• An assertions is a statement about a design that
  is expected to be true.
• Logic component
• equation
• Temporal component
• Under what time constraints the equation is
  expected to hold true
• Ex
• When reset is asserted, state must be idle within
  four cycles
• Request without grant Grant must be asserted
  within n cycles of a request
• White box method is needed

16
Assertions

• Dynamic assertions
• Simulation-based environment
• Important
• If the assertion did not trigger, it may also
  mean that there was insufficient stimulus
  generation
• Static assertions
• Use a mathematical model
• Advantages
• Stimulus generation can be very time-consuming
• Engineer doesnt have to create operations to
  test certain rules
• Disadvantages
• Assertions about multiple block become much more
  complex
• Require too much computation power and time

17
Outline

• Chapter 1 Introduction
• Chapter 2 Definitions
• Abstraction levels
• Verification of a design
• Definition of a test
• Chapter 3 - Methods for Determining the Validity
  of a Model
• Stimulus generation methods
• Results analysis methods
• Conclusion

18
Result Analysis Methods

• Eyeballing
• Golden File
• Automated Result Analysis
• Assertions
• Monitors
• Predictors

19
Eyeballing

• Advantage
• It can be easily performed at first time
• Disadvantage
• Not suitable for any project greater than a few
  hundred gates
• It is difficult for humans to analyze the
  information
• It is no ability to perform an automatic
  regression test

20
Golden files

• Compare the output of a simulation to a stored
  version of the expect output
• Advantage
• perform an automatic regression test
• Disadvantage
• Modifications made to the design have great
  impact on the golden file
• Golden file produced by behavioral model is not
  always right

21
Automated Result Analysis (cont.)

• Assertions
• Self-checking
• Continue to check for an invalid condition as
  more tests are added
• Assertions are often not as well suited to follow
  data as it passes through a system as simulation
  methods might be.
• Defining a complete set of assertions for a more
  complex sequence is usually not practical for
  complex device
• Assertions alone are not the ideal way to verify
  a system

22
Automated Result Analysis (cont.)

• Monitors
• To check the bus protocols are being followed at
  all time
• May be simply a group of assertion statements
• It can also be used to record the bus
• Characteristic
• Encapsulation
• Abstraction
• User interface
• Modularity

23
Automated Result Analysis (cont.)

• Predictions
• Assertion cant deal with large complex systems
• How to predict result in simulation-based
  verification
• Reference model
• Cycle-accurate reference model
• The comparison is done at every cycle
• Take time to write the model in the first place
• The accuracy of the model is of critical
  importance
• Behavioral reference model
• Differences in the outputs between the behavioral
  model and the design may look quite different

24
Automated Result Analysis (cont.)

• Predictions (cont.)
• Self-checking Tests
• To embed the information directly into the test
• EX Store the right answers in memory and compare
  them with the result
• Advantage
• The test and the checking criteria are kept
  together

25
Outline

• Chapter 1 Introduction
• Chapter 2 Definitions
• Abstraction levels
• Verification of a design
• Definition of a test
• Chapter 3 - Methods for Determining the Validity
  of a Model
• Stimulus generation methods
• Results analysis methods
• Conclusion

26
Conclusion

• Assertions and simulation-based methods each have
  different strengths and weaknesses.
• The methods are not mutually exclusive
• The size of a project
• Availability of tools and resources
• No single best method
