The SCORM Data Model 2

1
Lecture 10

• The SCORM Data Model (2)

2
cmi.objectives.n.id

• Usage
• Way of identifying an objective.
• Supported API calls
• LMSGetValue()
• LMSSetValue()
• LMS Mandatory No
• Data Type CMIIdentifier
• LMS Behavior
• Initialization
• Initialized to an empty string (""). The SCO is
  responsible for setting this value. If an
  LMSGetValue() is requested before the SCO has set
  this value, then the LMS should return an empty
  string ()

3
cmi.objectives.n.id (cont.)

• LMSGetValue()
• Returns the objectives id stored in the LMS. The
  returned value must match the associated data
  type.
• LMSSetValue()
• Sets the data model element to the supplied
  value. Value must match the data type for this
  element.

4
cmi.objectives.n.score.raw

• Usage
• Raw score after each attempt for an objective.
• Supported API calls
• LMSGetValue()
• LMSSetValue()
• LMS Mandatory No
• Data Type CMIDecimal or CMIBlank
• LMS Behavior
• Initialization
• Element should be initialized to an empty string
  (""). The SCO is responsible for setting this
  value. If an LMSGetValue() is requested before
  the SCO has set this value, then the LMS should
  return an empty string ().

5
cmi.objectives.n.score.raw (cont.)

• LMSGetValue()
• The LMS should return the objectives raw score
  identified by the request. The returned value
  must match the associated data type.
• LMSSetValue()
• Sets the data model element to the supplied
  value. Value must match the data type for this
  element.

6
cmi.objectives.n.score.max

• Usage
• Max score after each attempt for an objective.
• Supported API calls
• LMSGetValue()
• LMSSetValue()
• LMS Mandatory No
• Data Type CMIDecimal or CMIBlank
• LMS Behavior
• Initialization
• Element should be initialized to an empty string
  (""). The SCO is responsible for setting this
  value. If an LMSGetValue() is requested before
  the SCO has set this value, then the LMS should
  return an empty string ().

7
cmi.objectives.n.score.max (cont.)

• LMSGetValue()
• The LMS should return the objectives max score
  identified by the request. The returned value
  must match the associated data type.
• LMSSetValue()
• Sets the data model element to the supplied
  value. Value must match the data type for this
  element.

8
cmi.objectives.n.score.min

• Usage
• Min score after each attempt for an objective.
• Supported API calls
• LMSGetValue()
• LMSSetValue()
• LMS Mandatory No
• Data Type CMIDecimal or CMIBlank
• LMS Behavior
• Initialization
• Element should be initialized to an empty string
  ("").The SCO is responsible for setting this
  value. If an LMSGetValue() is requested before
  the SCO has set this value, then the LMS should
  return an empty string ().

9
cmi.objectives.n.score.min (cont.)

• LMSGetValue()
• The LMS should return the objectives min score
  identified by the request. The returned value
  must match the associated data type.
• LMSSetValue()
• Sets the data model element to the supplied
  value. Value must match the data type for this
  element.

10
cmi.objectives.n.status

• Usage
• Used to keep track of the students statuses for a
  given objective.
• Supported API calls
• LMSGetValue()
• LMSSetValue()
• LMS Mandatory No
• Data Type CMIVocabulary (Status), ex "passed"
  "completed" "failed" "incomplete" "browsed" "not
  attempted.
• LMS Behavior
• Initialization
• Handled by the SCO.
• LMSGetValue()

11
cmi.objectives.n.status (cont.)

• The LMS should return the objectives status
  identified by the request. The returned value
  must match the associated data type.
• LMSSetValue()
• Sets the data model element to the supplied
  value. Value must match the data type for this
  element.

12
cmi.student_data.mastery_score

• Usage
• For an LMS system to support mastery_score, it
  must be able to change the lesson_status based on
  the score passed to if from the SCO. Just passing
  a mastery_score to a SCO does not constitute full
  support for this feature.
• Supported API calls
• LMSGetValue()
• LMS Mandatory No
• Data Type CMIDecimal
• LMS Behavior
• Initialization

13
cmi.student_data.mastery_score (cont.)

• LMS is responsible value obtained from manifest
  (adlcpmasteryscore) item elements.
• LMSGetValue()
• Returns the current value stored by the LMS.

14
cmi.student_data.max_time_allowed

• Usage
• Used to present the SCO with the maximum amount
  of time that the student is allowed to be in the
  SCO.
• Supported API calls
• LMSGetValue()
• LMS Mandatory No
• Data Type CMITimespan
• LMS Behavior
• Initialization
• LMS is responsible value obtained from manifest
  (adlcpmaxtimeallowed) item elements.
• LMSGetValue()
• Returns the current value stored by the LMS.

15
cmi.student_data.time_limit_action

• Usage
• Used to indicate to the SCO what the action
  should be when the maximum time allowed in the
  SCO has been exceeded.
• Supported API calls
• LMSGetValue()
• LMS Mandatory No
• Data Type CMIVocabulary (Time Limit Action),
  ex exit ,message exit, no message continue,
  message continue, no message.
• LMS Behavior
• Initialization
• LMS is responsible value obtained from manifest
  (adlcptimelimitaction) item elements.

16
cmi.student_data.time_limit_action (cont.)

• LMSGetValue()
• Returns the current value stored by the LMS.

17
cmi.student_preference.audio

• Usage
• Used by the SCO to both set and obtain from the
  LMS audio preferences of the student.
• Supported API calls
• LMSGetValue()
• LMSSetValue()
• LMS Mandatory No
• Data Type CMISInteger
• LMS Behavior
• Initialization
• If supported, the LMS should initialize this
  value to 0. It is the responsibility of the SCO
  to set this value. If an LMSGetValue() is
  requested before the SCO has set this

18
cmi.student_preference.audio (cont.)

• value, then the LMS should return an empty string
  ().
• LMSGetValue()
• Returns the current value stored by the LMS.
• LMSSetValue()
• Sets the LMS data item to the value passed in as
  a parameter.

19
cmi.student_preference.language

• Usage
• Used by the SCO to both set and obtain from the
  LMS language preferences for the student.
• Supported API calls
• LMSGetValue()
• LMSSetValue()
• LMS Mandatory No
• Data Type CMIString255
• LMS Behavior
• Initialization
• If supported the LMS should initialize this value
  to an empty string (). It is the
  responsibility of the SCO to set this value. If
  an LMSGetValue() is requested before the SCO has
  set

20
cmi.student_preference.language (cont.)

• this value, then the LMS should return an empty
  string ()
• LMSGetValue()
• Returns the current value stored by the LMS.
• LMSSetValue()
• Sets the LMS data item to the value passed in as
  a parameter.

21
cmi.student_preference.speed

• Usage Used by the SCO to both set and obtain
  from the LMS speed preferences of the student.
• Supported API calls
• LMSGetValue()
• LMSSetValue()
• LMS Mandatory No
• Data Type CMISInteger
• LMS Behavior
• Initialization
• If supported by the LMS, this element should be
  initialized to 0. It is the responsibility of
  the SCO to set this value. If an LMSGetValue()
  is requested before the SCO has set this value,
  then the LMS should return an empty string ().


22
cmi.student_preference.speed (cont.)

• LMSGetValue()
• Returns the current value stored by the LMS.
• LMSSetValue()
• Sets the LMS data item to the value passed in as
  a parameter

23
cmi.student_preference.text

• Usage
• Used by the SCO to both set and obtain from the
  LMS text preferences of the student.
• Supported API calls
• LMSGetValue()
• LMSSetValue()
• LMS Mandatory No
• Data Type CMISInteger
• LMS Behavior
• Initialization
• If supported by the LMS, this element should be
  initialized to 0. It is the responsibility of
  the SCO to set this value. If an LMSGetValue()
  is requested before the SCO has set this

24
cmi.student_preference.text (cont.)

• value, then the LMS should return an empty string
  ().
• LMSGetValue()
• Returns the current value stored by the LMS.
• LMSSetValue()
• Sets the LMS data item to the value passed in as
  a parameter.

25
cmi.interactions.n.id

• Usage
• Used to set a unique interactions id. SCO
  specific.
• Supported API calls
• LMSSetValue()
• LMS Mandatory No
• Data Type CMIIdentifier
• LMS Behavior
• Initialization
• Value is controlled by the SCO.
• LMSSetValue()
• Sets the data model element to the supplied
  value. Value must match the data type for this
  element.

26
cmi.interactions.n.objectives.n.id

• Usage
• Used to identify the objective that the
  interaction is for.
• Supported API calls
• LMSSetValue()
• LMS Mandatory No
• Data Type CMIIdentifier
• LMS Behavior
• Initialization
• Value is controlled by the SCO.
• LMSSetValue()
• Sets the data model element to the supplied
  value. Value must match the data type for this
  element.

27
cmi.interactions.n.time

• Usage
• Used as a timestamp for the interaction.
• Supported API calls
• LMSSetValue()
• LMS Mandatory No
• Data Type CMITime
• LMS Behavior
• Initialization
• Value is controlled by the SCO.
• LMSSetValue()
• Sets the data model element to the supplied
  value. Value must match the data type for this
  element.

28
cmi.interactions.n.type

• Usage
• To indicate the type of interaction that is
  taking place.
• Supported API calls
• LMSSetValue()
• LMS Mandatory No
• Data Type CMIVocabulary (Interaction), ex
  "true-false" "choice" "fill-in" "matching"
  "performance" "sequencing" "likert" "numeric.
• LMS Behavior
• Initialization
• Value is controlled by the SCO.
• LMSSetValue()
• Sets the data model element to the supplied
  value. Value must match the data type for this
  element.

29
cmi.interactions.n.correct_responses.n.pattern

• Usage
• This is the correct response to the interaction
  provided by the SCO.
• Supported API calls
• LMSSetValue()
• LMS Mandatory No
• Data Type CMIFeedback, ex depend on
  cmi.interactions.n.type.
• LMS Behavior
• Initialization
• Value is controlled by the SCO.
• LMSSetValue()
• Sets the data model element to the supplied
  value. Value must match the data type for this
  element.

30
cmi.interactions.n.weighting

• Usage
• An interaction may have a weight, and similarly,
  individual actions or responses inside a complex
  interaction may have a weight.
• Supported API calls
• LMSSetValue()
• LMS Mandatory No
• Data Type CMIDecimal
• LMS Behavior
• Initialization
• Value is controlled by the SCO.
• LMSSetValue()
• Sets the data model element to the supplied
  value. Value must match the data type for this
  element.

31
cmi.interactions.n.student_response

• Usage
• This is the actual student response to the
  interaction. This value then can be compared with
  the cmi.interactions.n.correct_responses.n.pattern
  .
• Supported API calls
• LMSSetValue()
• LMS Mandatory No
• Data Type CMIFeedback
• LMS Behavior
• Initialization
• Value is controlled by the SCO.
• LMSSetValue()
• Sets the data model element to the supplied
  value. Value must match the data type for this
  element.

32
cmi.interactions.n.result

• Usage This is the actual result from the
  student_response.
• Supported API calls
• LMSSetValue()
• LMS Mandatory No
• Data Type CMIVocabulary (Result), ex "correct"
  "wrong" "unanticipated" "neutral" "x.x"
  (CMIDecimal).
• LMS Behavior
• Initialization
• Value is controlled by the SCO.
• LMSSetValue()
• Sets the data model element to the supplied
  value. Value must match the data type for this
  element.

33
cmi.interactions.n.latency

• Usage
• If latency is recorded, there can be a latency
  figure for each response.
• Supported API calls
• LMSSetValue()
• LMS Mandatory No
• Data Type CMITimespan
• LMS Behavior
• Initialization
• Value is controlled by the SCO.
• LMSSetValue()
• Sets the data model element to the supplied
  value. Value must match the data type for this
  element.

34
Data types and Controlled Vocabulary

• There exists a data type definition (used to
  describe the format of each data element) or
  predefined bounded vocabularies for each element
  in the AICC CMI Data Model.
• These definitions further define how the API and
  data model must be implemented.
• All of the data types have the first three
  characters of CMI to clearly indicate that
  they are data types that may be unique to the
  AICC CMI Data Model.

35
(No Transcript)
36
(No Transcript)
37
(No Transcript)
38
(No Transcript)
39
(No Transcript)
40
(No Transcript)
41
(No Transcript)
42
The End of Lecture 10
