Capriccio: Scalable Threads for Internet Service

1
Capriccio Scalable Threads for Internet Service
2
Introduction

• Internet services have ever-increasing
  scalability demands
• Current hardware is meeting these demands
• Software has lagged behind
• Recent approaches are event-based
• Pipeline stages of events

3
Drawbacks of Events

• Events systems hide the control flow
• Difficult to understand and debug
• Eventually evolved into call-and-return event
  pairs
• Programmers need to match related events
• Need to save/restore states
• Capriccio instead of event-based model, fix the
  thread-based model

4
Goals of Capriccio

• Support for existing thread API
• Little changes to existing applications
• Scalability to thousands of threads
• One thread per
• execution
• Flexibility to address
• application-specific
• needs

Threads
Ideal
Ease of Programming
Events
Threads
Performance
5
Thread Design Principles

• Kernel-level threads are for true concurrency
• User-level threads provide a clean programming
  model with useful invariants and semantics
• Decouple user from kernel level threads
• More portable

6
Capriccio

• Thread package
• All thread operations are O(1)
• Linked stacks
• Address the problem of stack allocation for large
  numbers of threads
• Combination of compile-time and run-time analysis
• Resource-aware scheduler

7
Thread Design and Scalability

• POSIX API
• Backward compatible

8
User-Level Threads

• Performance
• Flexibility
• - Complex preemption
• - Bad interaction with kernel scheduler

9
Flexibility

• Decoupling user and kernel threads allows faster
  innovation
• Can use new kernel thread features without
  changing application code
• Scheduler tailored for applications
• Lightweight

10
Performance

• Reduce the overhead of thread synchronization
• No kernel crossing for preemptive threading
• More efficient memory management at user level

11
Disadvantages

• Need to replace blocking calls with nonblocking
  ones to hold the CPU
• Translation overhead
• Problems with multiple processors
• Synchronization becomes more expensive

12
Context Switches

• Built on top of Edgar Toernigs coroutine library
• Fast context switches when threads voluntarily
  yield

13
I/O

• Capriccio intercepts blocking I/O calls
• Uses epoll for asynchronous I/O

14
Scheduling

• Very much like an event-driven application
• Events are hidden from programmers

15
Synchronization

• Supports cooperative threading on single-CPU
  machines
• Requires only Boolean checks

16
Threading Microbenchmarks

• SMP, two 2.4 GHz Xeon processors
• 1 GB memory
• two 10 K RPM SCSI Ultra II hard drives
• Linux 2.5.70
• Compared Capriccio, LinuxThreads, and Native
  POSIX Threads for Linux

17
Latencies of Thread Primitives
18
Thread Scalability

• Producer-consumer microbenchmark
• LinuxThreads begin to degrade after 20 threads
• NPTL degrades after 100
• Capriccio scales to 32K producers and consumers
  (64K threads total)

19
Thread Scalability
20
I/O Performance

• Network performance
• Token passing among pipes
• Simulates the effect of slow client links
• 10 overhead compared to epoll
• Twice as fast as both LinuxThreads and NPTL when
  more than 1000 threads
• Disk I/O comparable to kernel threads

21
Linked Stack Management

• LinuxThreads allocates 2MB per stack
• 1 GB of VM holds only 500 threads

Fixed Stacks
22
Linked Stack Management

• But most threads consumes only a few KB of stack
  space at a given time
• Dynamic stack allocation can significantly reduce
  the size of VM

Linked Stack
23
Compiler Analysis and Linked Stacks

• Whole-program analysis
• Based on the call graph
• Problematic for recursions
• Static estimation may be too conservative

24
Compiler Analysis and Linked Stacks

• Grow and shrink the stack size on demand
• Insert checkpoints to determine whether we need
  to allocate more before the next checkpoint
• Result in noncontiguous stacks

25
Placing Checkpoints

• One checkpoint in every cycle in the call graph
• Bound the size between checkpoints with the
  deepest call path

26
Dealing with Special Cases

• Function pointers
• Dont know what procedure to call at compile time
• Can find a potential set of procedures

27
Dealing with Special Cases

• External functions
• Allow programmers to annotate external library
  functions with trusted stack bounds
• Allow larger stack chunks to be linked for
  external functions

28
Tuning the Algorithm

• Stack space can be wasted
• Internal and external fragmentation
• Tradeoffs
• Number of stack linkings
• External fragmentation

29
Memory Benefits

• Tuning can be application-specific
• No preallocation of large stacks
• Reduced requirement to run a large numbers of
  threads
• Better paging behavior
• StacksLIFO

30
Case Study Apache 2.0.44

• Maximum stack allocation chunk 2KB
• Apache under SPECweb99
• Overall slowdown is about 3
• Dynamic allocation 0.1
• Link to large chunks for external functions 0.5
• Stack removal 10

31
Resource-Aware Scheduling

• Advantages of event-based scheduling
• Tailored for applications
• With event handlers
• Events provide two important pieces of
  information for scheduling
• Whether a process is close to completion
• Whether a system is overloaded

32
Resource-Aware Scheduling

• Thread-based
• View applications as sequence of stages,
  separated by blocking calls
• Analogous to event-based scheduler

33
Blocking Graph

• Node A location in the program that blocked
• Edge between two nodes if they were consecutive
  blocking points
• Generated at runtime

34
Resource-Aware Scheduling

• 1. Keep track of resource utilization
• 2. Annotate each node with resource used and its
  outgoing edges
• 3. Dynamically prioritize nodes
• Prefer nodes that release resources

35
Resources

• CPU
• Memory (malloc)
• File descriptors (open, close)

36
Pitfalls

• Tricky to determine the maximum capacity of a
  resource
• Thrashing depends on the workload
• Disk can handle more requests that are sequential
  instead of random
• Resources interact
• VM vs. disk
• Applications may manage memory themselves

37
Yield Profiling

• User threads are problematic if a thread fails to
  yield
• They are easy to detect, since their running
  times are orders of magnitude larger
• Yield profiling identifies places where programs
  fail to yield sufficiently often

38
Web Server Performance

• 4x500 MHz Pentium server
• 2GB memory
• Intel e1000 Gigabit Ethernet card
• Linux 2.4.20
• Workload requests for 3.2 GB of static file data

39
Web Server Performance

• Request frequencies match those of the SPECweb99
• A client connects to a server repeated and issue
  a series of five requests, separated by 20ms
  pauses
• Apaches performance improved by 15 with
  Capriccio

40
Resource-Aware Admission Control

• Consumer-producer applications
• Producer loops, adding memory, and randomly
  touching pages
• Consumer loops, removing memory from the pool and
  freeing it
• Fast producer may run out of virtual address space

41
Resource-Aware Admission Control

• Touching pages too quickly will cause thrashing
• Capriccio can quickly detect the overload
  conditions and limit the number of producers

42
Programming Models for High Concurrency

• Event
• Application-specific optimization
• Thread
• Efficient thread runtimes

43
User-Level Threads

• Capriccio is unique
• Blocking graph
• Resource-aware scheduling
• Target at a large number of blocking threads
• POSIX compliant

44
Application-Specific Optimization

• Most approaches require programmers to tailor
  their application to manage resources
• Nonstandard APIs, less portable

45
Stack Management

• No garbage collection

46
Future Work

• Multi-CPU machines
• Profiling tools for system tuning
