Quasi-free electron scattering from highly charged ions

1
Quasi-free electron scattering from highly
charged ions

• Theo J.M. Zouros
• University of Crete Heraklion
• GREECE

2
The Mediterranean
Crete
CIA map
3
The island of Crete
Area 8200 km2 (3200 mi2) Population
600 000 winter gt 1 000 000
summer
Two mountains 2450 m
Heraklion population 220 000
4
Crete
Heraklion
5
University of Crete - Heraklion
University Hospital
Physics Dept
UoC campus
Physics Biology
Medical school
From my living room
UoC 5000 students Physics Dept 600 under
grads 50 grads
30 faculty
6
Recent collaborators
J.R. Macdonald Lab Kansas State
Univ.
Dr. Manolis Benis PhD 2001 Univ. of Crete JRM
Prof. Tom Gorczyca Western Michigan
Univ. R-matrix calculations
Prof. Pat Richard
Prof. (Emeritus) Chander Bhalla
Pierre Auger 1899-1993 Auger effect 1923-1925
Teck Lee Grad Student
Mikhail Zamkov Grad Student
7
Ion atom/electron collisions
t -8
t -8
?t 10-17 s
Preparation
Relaxation
Interaction
Ionization Excitation Transfer combinations
e-
Non radiative Auger electrons Radiative Photon
decay
Atom/Molecule Target q 0 (neutral) Gas/Solid gs
or excited state n 1012-1020 /cm3
e-
e- beam Target q -1 I 1-50 µA n 106-108
/cm3
?
e-
Ion beam Z 1-12 I 1-100 nA q 1-12 E 0.5-2
MeV/u V 3-6 a.u. gs or metastable
Detectors projectile, recoil, photon,
electron coincidences ?O solid angle e -
efficiency
?
Black box?!
8
Ion-atom/electron interactions Investigation of
the Coulomb force

• Force is Coulomb
• Potential usually known - can write down a
  Hamiltonian
• Calculate emission or interaction cross sections
• Difficulties many particles, long range force,
  correlation effects
• Model calculations
• Develop theoretical and experimental techniques
• Test approximations

Mature field more than 40 years old negative
population growth!
9
Interest in ion-electron/atom collisions
Applications

• Tokomak and Astrophysical Plasmas
• Accelerator technology - Storage rings
• Radiation damage cancer therapy
• Basic atomic collisions

• Use HCI and simple targets few-electron
  systems
• Study ion excitation rather than target
  excitation
• Control charge state q of ion N number of
  electrons
• Isoelectronic sequence study same N different Z

Recent reviewElectron-Ion scattering, I.
Williams, Rep. Prog. Phys. 62 (1999) 1431
10
Presentation Summary

• Resonant electron scattering (RES)
• Long range short range potential treatment
• Electron ion collision techniques
• Impulse Approximation Electron scattering model
• Advantages of quasi-free electron scattering
• RES applications He-like and H-like ions, triply
  excited states isoelectronic sequence study
• Future plans

11
Electron - ion collisions Production and decay
of doubly excited states
radiative stabilization recombination DR or RTEX
Aq
capture of a (quasi-) free electron excitation
inverse autoionization
autoionization Resonant electron scattering RES
or RTEA
Ee Bn E1-E0
12
Electron-ion scattering two-amplitude formula
e-
VS short range potential
q
Ion

r
R
Rutherford
Short-range
Interference
13
Sum of Rutherford and Short Range amplitudes
Griffin Pinzola PRA42 (1990) 248
14
Elastic scattering Rutherford term
Non resonant scattering Binary Encounter Peak
15
Elastic scattering Rutherford Short-range
Resonant contributions
16
Elastic scattering All 3 terms
Resonant contributions
17
Elastic scattering Sum of 3 terms
Sum of resonant, non-resonant and interference
contributions
18
R-matrix results e- B3 (1s2) ? B2
(1s2l2l') ? B3 (1s2) e-
Differential scattering at large angles provides
the most stringent tests of theory
(all terms!)
19
Merged beam experiments at storage ring
16O7 H-like Eion 8.9 MeV/u Ee8-9keV
Eecm500 eV ?Eecm0.6 eV Iion 4 E7 ion stack 7
min
Kilgus et al PRL 1990
20
Differential electron scattering
e- beam
Ion beam
J. Phys. B29 (1996) 4443
21
UoC HEMISPHERICAL ANALYZER WITH 2-D PSD 0o
ELECTRON SPECTROMETER
Faraday Cup
Ion Beam
4-element lens
Inner hemisphere
Gas Cell
Pressure Gauge
Gas in
electrons
PSD X-Position Y- Position Timing
Outer hemisphere
e-
?
Resolution 0.1 ?O 1.8 x 10-4 sr
00 dgrs
Ion
22
Experimental setup at J R Macdonald Laboratory
23
Electron Scattering Model/Impulse Approximation
Free e--Ion ?? Bound e--Ion
Vp gtgt v
24
Sliding the Compton profile across the resonances
RES
?e ??
Compton profile
Changing the ion velocity Vp slides the Compton
profile across the doubly-excited states bringing
them into resonance!
Auger decay
RES
??
Ee 184 eV (4.0 MeV)
Ee
25
Comparison of signal ratesR (/s) NI ne L s
Merged beams (Heidelberg TSR) Crossed Beams (CEA Grenoble) Quasi-free e- beams (UoC - JRM)
Electrons ne (/cm3) 1 E 7 (1 A) 1.2 ? 8 (4 µ?) 3 ? 14 (10 mTorr)
Overlap L (cm) 150 0.20 5
Ions NI (/s) 3.7 E 12 (50 µA) 8.9 E 12 (10 µA) 7.8 E 10 (100 nA)
R (/s) 5.5 E 21 s 2.1 E 20 ds/dO ?O 1.3 E 26 ds/dO ?O
Electron beam ??e (eV) 0.004 0.500 120
Chamber Vacuum (Torr) 1 E -11 1 E -10 1 E -7
e- Analyzer ?Oe (sr) Resolution () Only ions measured 4 E -4 2 1.8 E -4 0.1
26
Whats the use of a quasi-free electron?

• gt106 higher luminosity compared to
• crossed electron-ion beam experiments!
• Measure scattering at 1800 (very sensitive)!
• Include also resonances
• (e- energy dependence d2?/dEd?)!
• No UHV
• Spectrum in 30 minutes!

Sounds great but is it really electron-ion
scattering???
27
Elastic scattering of quasi-free electrons on B4
ions
Elastic scattering of quasi-free electrons on B4
ions
Doubly Excited states
Zouros et al PRA 2003 RC
28
Elastic scattering of quasi-free electrons on B3
ions
Doubly Excited states
Zouros et al PRA 2003 RC
29
First Z-dependence study of a triply-excited
state
Benis et al JPBL submitted 2003
30
Summary and Conclusion

• Large-angle differential electron ion
  scattering provides some of the most stringent
  tests of both atomic structure and collision
  dynamics

• State-of-the-art DDCS calculations (R-matrix)
  for free electron
• scattering from He-like and H-like ions are in
  excellent agreement with
• quasi-free electron experiments involving
  ion-H2 collisions over a wide
• energy region and many resonances

quasi-free electron scattering is
real electron scattering! (remember Compton
scattering electrons there also really
quasi-free!)

• quasi-free electron scattering provides the only
  way to presently observe differential RES!
  (particularly at the large scattering angles)

31
Future

• Improve apparatus add first stage and double
  differential target
• Use Li vapor target that has narrower Compton
  profile (Laser-excited) Rydberg Li target?
• Expand studies to include
• many electron targets
• higher Z ions or L shells
• Incorporate zero-degree electron spectrometer
  system in a storage ring??!!

32
Comparison of Compton Profiles
H2 target
Li vapor target
33
H2 target
34
He target
35
Ar target
36
The EndMany thanks to all my colleagues and
friends for making my sabbatical such a fun and
exciting experience!
37
Summary and conclusions

• 1800 Elastic e--Ion Scattering measurements
• First differential observation of RES for He-like
  ions
• First isoelectronic sequence study of
  triply-excited state
• R-matrix calculations
• Overall good agreement with the measurements
• ESM seems to be a very good approximation
• Quasi-free e- scattering provides unique data
• Not impaired by broad Compton profile!!!
• No problem with convolution of Compton profile!!!

38
Determination of the metastable 1s2s 3S
fraction
Method 1s2 1S ? 1s2p2 2D RTE 1s2s 3S ?1s2s2p
4P Capture
Two successive measurements at the same
production energy
E.P. Benis et al, PRA 65, 064701 (2002)
39
1s2s 3S Metastable fraction
Foil stripping
Gas stripping
40
e- scattering on ion
bjgtajLjMLjSjMSjgt
kili
De
e-
kflf
q
DEi
DEf
LSP
DEi
DEf
bf
Ione-
De
bi
Ion
Ion
Energy conservation De0 LS-coupling total
DLDSDMLDMSDP0
41
Absolute doubly differential cross section
determination
Determine the overall efficiency Use BEe/elastic
non-resonant scattering peak
Determine the metastable fraction Use capture to
RTE lines ratio
B3(1s2 1S, 1s2s 3S) H2
42
Elastic scattering of quasi-free electrons on B3
ions
Triply Excited States !
43
Elastic scattering of quasi-free electrons on B3
ions
Triply Excited States
44
B3 (1s2s 3S) ? B3 (2s2p 3P) ? B4 (1s)
eA
45
Elastic scattering of quasi-free electrons on
ions(more open channels)
46
Scattering of free electrons on HCI
Scattering of quasi-free electrons on HCI
Atom
47
Compton Profiles
x
F(p)2
z
y
probability to find e- with component pz
48
Highest Sensitivity at large-angle scattering
d?/d? 70 eV e- Li 1 1S? 2
3P DW Distorted Wave UDWUnitarized DW CC5
5-state close coupling CC11 11-state close
coupling
Largest differences between theories at 1800!!
49
Resolution dependence study
50
Electron scattering processes
51
Summary
The impulse approximation provides

• simplification of ion-atom collisions by
  separating target-electron interactions from
  target-nucleus interactions.
• unifying view-point for treating electron
  scattering in ion-atom, e-ion and Compton.

52
(No Transcript)
53
Differential Electron-ion scattering measurements
Recent reviewElectron-Ion scattering, I.
Williams, Rep. Prog. Phys. 62 (1999) 1431
54
Kinematic Broadening
F. Fremont et al 1997
55
The zero-degree Auger Projectile Spectroscopy
setup
56
Sum of Rutherford and Short Range amplitudes
Griffin Pinzola PRA42 (1990) 248
57
Differential e--ion scattering cross section
Griffin Pinzola PRA42 (1990) 248
58
1800 differential scattering S ? S cross
sections
59
Efficiency Determination ? Normalization to the
bare ion BEe peak
Normalize to the Non-bare BEe peak!
60
Results

• R-matrix excellent agreement with measurements

• Impulse Approximation Valid down to VP/v t 3.5

• Resonant Excitation Strength for 2p2 1D

61
Resonant Transfer Excitation
62
Recombination of He-like ions
Kilgus et al PRA 1993
