Security issues related to HMIPv6

• H.Soliman_at_flarion.com

2
Current Security scheme

• Current scheme relies on IPsec
• Static or dynamic keying possible Dynamic is
  more realistic
• MN picks an RCoA and binds it with the LCoA.
• MAP makes sure that no other MN is using the RCoA
  (check list of used addresses during IKE policy
  check).
• MN need not pick a specific RCoA (NOT like the
  HoA).

3
Issues raised

• Technically there is no problem with current
  solution.
• Use of Certificates on the host is difficult.
  Reasons not clear, some guesses below
• Configuration and renewal of Certs on host does
  not use standard mechanisms (?)
• Some operators might want to reuse existing
  security credentials (e.g. AAA credentials).

4
Different trust models for deployment

• Authentication only model
• Authentication and Authorisation model
• Both models addressed in the current draft.

5
Different HMIPv6 deployment scenarios
Authentication only
MAP
IKE/IPsec
Only Mutual authentication required. All MNs are
authorised to use the MAP and get an RCoA.
6
Different HMIPv6 deployment scenarios
Authentication and authorisation (A)
Home
CA-MN
MAP
Local
IKE/IPsec
MAP needs to authorise the MN for the service.
In the current scheme Authorisation is done based
on MN Cert.
7
Different HMIPv6 deployment scenarios
Authentication and authorisation (B)
Home
AAAH
EAP-RADUS/Diameter
AAAL
MAP
IKEv2 (EAP)/IPsec
MAP needs to authorise the MN for the service. MN
AAA credentials are used over EAP with AAAL or
AAAH. IKEv2 used to setup IPsec SA after EAP is
done.
8
Sumary of solution set

• Authentication only
• IKE/IPsec
• Possible new solution gt CGAs
• Authentication and Authorisation
• IKE/IPsec if CAs are applicable. Allows for
  roaming based on trust between different CAs.
• IKEv2(EAP)/IPsec if there is a need to reuse AAA
  credenticals.

9
Way forward

• Keep the current mechanism in HMIPv6 as default.
• Propose new mechanism for nomad scenario
  (Authentication only).
• Work started on CGAs for HMIPv6
• Move curent HMIPv6 to PS after a little cleanup.
• Another possible area of improvement for new
  specs
• Improving inter-MAP domain handovers.
