Title: Using Timers for RealTime Programming


1
Lecture 5
  • Using Timers for Real-Time Programming

2
Recap
Covered in Detail
Covered with a few things missing
3
Timers
Max Value
pulse
Counter
zero
clk
  • Timers are on-chip logic structures intended
    mainly for generating the clock/timing signals
    for various peripherals, including serial ports,
    pulse-width-modulators, quadrature decoders, and
    interrupts.

4
Why Do We Need Timers?
  • Timers provide a tool for creating a
    (surprisingly) flexible, high-speed, real-time
    interface with the real world.
  • A prevalence of timers is generally a feature of
    microcontrollers (and DSPs) that differentiate
    them from general purpose microprocessors (i.e.,
    desktop processors).
  • When using event driven programming, some events
    are asynchronous to our system, and the embedded
    system reacts to them
  • For example, a button press on the Denon Home
    Theatre In a Box our embedded system
    controlling this would merely react to the button
    press
  • We would determine our latency requirements and
    program our system accordingly
  • However, many events that we face when performing
    embedded programming need to be (tightly)
    synchronized to a clock
  • Dont want the complexity of keeping track of
    elapsed time with a while(1) loop

5
Timer Example AGC
  • For example, consider Automatic Gain Control on a
    receiver
  • If the input power reaches the AGC set point,
    introduce attenuation
  • If the input power is an attenuation step below
    the set point after a timer period, remove
    attenuation
  • Set a timer to interrupt with the appropriate
    period to check if AGC should be removed uP
    then does no processing except for handling the
    interrupt

Attenuation
AGC Decay Time Constant
AGC Set Point
Measured Input Power
Time
input
uP
Avg Power Measure
RCVR Frontend
Peak Power Measure
int

ATTN
Rest of RCVR
set point
6
Timers for Event-Driven Operation
  • Many events that we face when performing embedded
    programming need to be synchronized to a clock
  • A/D conversion
  • Operating a motor
  • Serial ports
  • Timers allow us to perform event-driven
    operations on a on an accurate time-scale without
    tying up our processor (allow for hard RT systems
    i.e. deterministic performance)
  • Timers give us greater time resolution than we
    could accomplish (easily at least) using
    sequential programming techniques

7
Timer Example Serial Port
If synchronous serial port being used, must
provide this clock, else must provide a clock 16
times faster to sample
8
Timer for A/D Conversion
Startconversion
Startconversion
Startconversion
Startconversion
fs 1/t
A poorly timed convert signal would introduce
phase noise
9
Basic Timer Structure
  • Timer A
  • Simple
  • Generate baud clocks for serial ports
  • Interruptible
  • Chainable
  • Also handle Input Capture, PWM, and Quadrature
    Decode

mux
  • Timer B
  • Interruptible
  • Free-running (used to manually time events)
  • Clock parallel ports
  • More precise synthesis and measurement of events

10
Peripheral Clock
  • Peripheral clock can be set to same speed as
    processor or various multiples of it
  • Allows for lower power processing while still
    preserving timing resolution
  • May want to run faster if uP is slave to another
    device (need extra clock cycles to synchronize)
  • Note that peripherals cannot be clocked slower
    than processor

11
Timer A Structure
  • Timers A1 and A2A10 are 8-bit countdown
    registers
  • The reload register can contain any number in the
    range from 0 to 255. The counter divides by
    (n1).
  • For example, if the reload register contains 127,
    then 128 pulses (or clocks) enter on the left
    before a pulse exits on the right
  • If the reload register contains zero, then each
    pulse (or clock) on the left results in a pulse
    on the right, that is, there is division by one.

12
Timer A Phase
  • It is possible that an application would require
    multiple timers to be phase-locked (i.e., produce
    pulses at the same time)
  • Since the timer counters are all free-running and
    can not be reset, this must be accomplished in
    the following manner
  • Set the counter reload value to 0x0
  • Wait until the longest possible countdown has
    completed (this condition will be met when all
    counters with 0x0 value report an interrupt on a
    Timer A interrupt)
  • Reload the counters that need to be phase locked
    with the new value both timers will now be
    phase-locked

13
Timer A Registers
14
Timer A Interrupts
  • For seven of the counters (A1-A7), the terminal
    count condition is reported in a status register
    and can be programmed to generate an interrupt
  • There is one interrupt vector for Timer A and a
    common interrupt priority
  • TACSR has a bit for each timer that indicates if
    the output pulse for that timer has taken place
    since the last read of the status register.
  • When the status register is read, these bits are
    cleared. No bit will be lost. Either it will be
    read by the status register read or it will be
    set after the status register read is complete.
  • If a bit is on and the corresponding interrupt is
    enabled, an interrupt will occur when priorities
    allow.
  • A separate interrupt is not guaranteed for each
    bit with an enabled interrupt
  • It is possible that one bit will cause an
    interrupt, and then one or more additional bits
    will be set before the status register is read.
  • The proper rule to follow is for the interrupt
    routine to handle all bits that it sees set.

15
Timer A Interrupt Example (1)
void main() unsigned int cnt,
state //directive to setup interrupt at
compile time SetVectIntern(0x0A,
timera_interrupt) config_leds() config_timera
()
PCLK29.4 MHz
14.7 MHz
57.4 kHz
224.3 Hz
.0449 Hz
Timer A1 256
Timer A2 256
interrupt 5001
PCLK 2
Outputevery 22.3 s
16
Timer A Interrupt Example (2)
void config_timera() asm Timer A Control
Register ld a,0x05 bit2, Tmr A2 clocked by
A1 ioi ld (TACR),a bit0, ints are priority
1 Timer A Prescale Register ld a,0x1 bit
0, Timer A is periph clock / 2 ioi ld (TAPR),
a Timer A Time Constant 1 Register ld a,0xFF
load max value (divide by 256) ioi ld (TAT1R),
a Timer A Time Constant 2 Register ld a,0xFF
load max value (divide by 256) ioi ld (TAT2R),
a Timer A Control/Status Register
ld a,0x5 bit2, Tmr A2 int enabled ioi ld
(TACSR),a bit0, TmrA clock enabled endasm
17
Timer A Interrupt Example (3)
interrupt void timera_interrupt() asm ioi ld
a, (TACSR) read the status register endasm
intCnt if (intCnt gt 5000 ) intCnt
0 asm ld a,(PGDRShadow) use shadow register
to keep other bit values bit DS1,a
read the current value of the
LED jp z,turnOff1 if 0, jump to turnOff, if 1
fall through to On turnOn1 ld a,(PGDRShadow) u
se shadow register to keep other bit
values res DS1,a clear bit 7 only ioi ld
(PGDR),a write data to port g ld (PGDRShadow),
a update shadow register jp done1 turnOff1 l
d a,(PGDRShadow) use shadow register to keep
other bit values set DS1,a set bit 7
only ioi ld (PGDR),a write data to port
g ld (PGDRShadow),a update shadow
register done1 endasm
18
I/O Clocked on Timer A
  • With Rabbit, I/O can be clocked using a timer
    pulse as the clock
  • This allows for the precise generation of
    arbitrary output pulses
  • An interrupt based on the timer can set up the
    next output value, which is then clocked on the
    next timer pulse

19
Timer A Serial Ports
  • Topic of their ownwill talk about in later
    lecture.
  • Min and Max baud rate

20
Timer Related Function PWM
LUT pwm f(speed sensor, psi, temp, feedback,)
uP
PWM signal
BrakePedal
MasterCylinder
Brake
valve
PWMWaveform
50
25
75
95
21
Timer Related Functions PWM
PWM0
PWM1
10 bit Counter
PWM2
PWM3
22
Spread PWM
23
Timer Related Functions PWM
  • A new PWM interrupt can be set up to be requested
    on every PWM cycle, every other cycle, every
    fourth cycle, or every eighth cycle.
  • Options are available to suppress the PWM output
    for seven-of-eight, three-of-four and one-of-two
    iterations of the PWM counter
  • The one-of-eight option works nicely with R/C
    servos, which require a 1 ms to 2 ms pulse width
    and a 20 ms period
  • This option gives the full resolution for the
    pulse width while still meeting the period
    requirements

NOT OUR VERSION
24
Optical Incremental Encoder
Knob Interface The optically encoded knobs put
out two out of phase pulse trains which differ in
relative phase depending on the direction in
which the switch is turned.
25
Optical Incremental Encoder
  • Incremental rotary encoder provides information
    about the instantaneous position of a rotating
    shaft
  • It does this by producing one square wave cycle
    per increment of shaft movement
  • This increment is referred to as the resolution
    of the encoder and is built directly into the
    internal hardware of the device
  • A resolution of 360 means that 360 square wave
    cycles will be produced in one complete rotation
    of the shaft
  • By counting the number of cycles, one can tell
    the position of the shaft, relative to its
    starting position. In our example, 90 cycles
    means that the shaft is now at a position 90
    degrees from where it started
  • By adding a quadrature signal, we can measure the
    direction of the rotation, by reading which
    signal (A or B) we measured first)
  • Often a Zero signal is added so that the zero
    position can be known
  • Commercial (i.e., volume dial) and industrial
    (conveyor belt control, motor feedback) uses

26
Optical Incremental Encoder
Index slot, often called Z slot
Light source from above illuminates
  • Two photodiodes underneath produce a voltage when
    illuminated
  • The two photodiodes are mounted with a ¼ the
    pitch of the slots in between then, thus forming
    the 90 phase difference between the two detected
    signals

Better picture on Page 49 of text.
27
Quadrature Decoding (1)
Page 49 of text describes in terms of gray code
Signal A
Signal B
  • Write an interrupt that sums up the counter value
    on every interrupt
  • Periodically (when you want to know that state of
    the dial) request the summed value and read the
    current value of the quadrature counter

Up-Down Counter
Q. How could we use the Z or Index signal?
28
Quadrature Decoding (2)
  • Additional Information
  • Quadrature Decoders are clocked off of Timer A10
  • Both the I and the Q inputs go through a digital
    filter that rejects pulses shorter than two clock
    periods wide
  • Clock rate must be high enough so that I and Q
    input are sampled in different clock cycles
  • Presume 2 rps, 40 divisions 1/(804) 4.2 ms, 4
    times over-sampling would be 1.05 ms or 960 Hz

29
Quad Decoder Configuration
  • In R3000.lib
  • nodebug void qd_init(int iplevel)
  • SetVectIntern(0x19, qd_isr)
  • qd_zero(1)
  • qd_zero(2)
  • WrPortI(TAT10R, TAT10RShadow, QD_DIVISOR)
  • //set quad inputs to lower nibble of port F
  • WrPortI(QDCR, QDCRShadow, 0x88 iplevel)

30
quad_isr and qd_read()
  • quad_isr sums qd_count every time the quadrature
    decoder interrupt is thrown

nodebug long qd_read(int channel) auto long
temp_reading if(channel 1) while(1)
qd_isrflag 0 temp_reading qd_count0
RdPortI(QDC1R) if(qd_isrflag
0) return temp_reading else
while(1) qd_isrflag
0 temp_reading qd_count1
RdPortI(QDC2R) if(qd_isrflag
0) return temp_reading
31
HC12 Timers
  • Enhanced capture timer (ECT)
  • 16-bit main counter with 7-bit prescaler
  • 8 programmable input capture or output compare
    channels 4 of the 8 input captures with buffer
  • Input capture filters and buffers, three
    successive captures on four channels, or two
    captures on four channels with a capture/compare
    selectable on the remaining four
  • Four 8-bit or two 16-bit pulse accumulators
  • 16-bit modulus down-counter with 4-bit prescaler
  • Four user-selectable delay counters for signal
    filtering
  • 4 PWM channels with programmable period and duty
    cycle
  • 8-bit 4-channel or 16-bit 2-channel
  • Separate control for each pulse width and duty
    cycle
  • Center- or left-aligned outputs
  • Programmable clock select logic with a wide range
    of Frequencies
  • Serial interfaces
  • Two asynchronous serial communications interfaces
    (SCI)
  • Synchronous serial peripheral interface (SPI)

NEXT CLASS
32
HC12 PWM
33
Basic Timer Structure
  • Timer A
  • Simple
  • Generate baud clocks for serial ports
  • Interruptible
  • Chainable
  • Also handle Input Capture, PWM, and Quadrature
    Decode

mux
  • Timer B
  • More precise synthesis and measurement of events

34
Input Capture
  • The input capture peripheral is used to time
    input signals from various input ports
  • Baud rate detection
  • measure width of pulses to negotiate baud rate
  • Measure speed of quadrature decoder
  • Measure time between pulses to determine
    rotational speed
  • Use simply as four additional external interrupts

35
Input Capture HW
Latch register
Overflow latch
16-bit counter
Clk (Timer A8)
enable
Enable/LatchLogic
Start Detect(rising, falling, either)
mux
interrupt
Stop Detect(rising, falling, either)
mux
36
Major Modes of Operation
  • The counter starts counting at the Start
    condition and stops counting at the Stop
    condition
  • I.e., for pulse width measurement on a single pin
    or time delay between two signals
  • The counter runs continuously and the Start and
    Stop conditions merely latch the current count
  • Useful for time-stamping inputs to the counter
    (may need to keep track of overflow note there
    is not an overflow interrupt)
  • The counter runs continuously until the Stop
    condition occurs
  • measures the time from the software-defined
    counter Start until the Stop condition occurs on
    an input
  • Note that once the counter stops because of the
    Stop condition, it will not resume counting until
    re-enabled by software

37
Input Capture Registers
38
Input Capture Example
  • void main()
  • unsigned long time_start
  • unsigned int num_clocks, condition
  • config_leds()
  • config_timera()
  • config_input_capture()
  • while (1)
  • asm
  • ld a, 0x80
  • ioi ld (PGDR),a
  • endasm
  • WrPortI(PGDR, PGDRShadow, 0x00)
  • //pause
  • time_start SEC_TIMER

Capture this
39
Input Capture Example (2)
  • WrPortI(ICCSR, NULL, 0x0C) //bit 4, note no
    interrupts
  • //bit 3, reset IC2 counter/rollover latch
  • //bit 2, reset IC1 counter/rollover latch
  • asm
  • ld a, 0x80
  • ioi ld (PGDR),a
  • ld a, 0x00
  • ioi ld (PGDR),a
  • endasm
  • //pause
  • time_start SEC_TIMER
  • while (SEC_TIMER - time_start lt 1)
  • //turn off both lights
  • WrPortI(PGDR, PGDRShadow, 0xFF)
  • //report for assembly
  • num_clocks RdPortI(ICM1R) ltlt 8
    RdPortI(ICL1R)

Capture this
40
Input Capture Example (3)
  • void config_input_capture()
  • WrPortI(ICT1R, NULL, 0x5A) //bit 6, count from
    start to stop
  • //bit 4, latch count on stop
  • //bit 3, start on falling edge
  • //bit 1, stop at input falling edge
  • WrPortI(ICS1R, NULL, 0x01) //0x01 upper nibble,
    start with port C, bit1
  • // lower nibble, stop with port C, bit3
  • WrPortI(ICCR, NULL, 0x01) //bit 0, set
    priority 1 interrupt
  • WrPortI(ICCSR, NULL, 0x0C) //bit 4, note no
    interrupts
  • //bit 3, reset IC2 counter/rollover latch
  • //bit 2, reset IC1 counter/rollover latch

41
Input Capture Example
31 (31/2 15.5)
15 (15/2 7.5)
42
RST
43
Timer A Prescale
  • void config_timera()
  • asm
  • Timer A Control Register
  • ld a,0x00
  • ioi ld (TACR),a
  • Timer A Prescale Register
  • ld a,0x01 bit 0, Timer A is periph clock / 2
  • ioi ld (TAPR), a Timer A Time Constant 2
    Register
  • ld a,0x00 load min value (no divide)
  • ioi ld (TAT8R), a Timer A Control/Status
    Register
  • ld a,0x1 bit0, TmrA clock enabled
  • ioi ld (TACSR),a
  • endasm

This affects the debug interface!!!
44
Timer A Prescale
  • From the BIOS
  • Read the time constant for 19200 baud
    calculated by the BIOS...
  • ld a, (bios_divider19200)
  • ld b, a
  • ifdef USE_TIMERA_PRESCALE
  • enable timer A prescale if desired
  • xor a
  • ioi ld (TAPR), a
  • sla b if prescale
    enabled, multiply constant by two
  • endif

45
Timer A Prescale
  • // Timer A prescale information (Rabbit 3000
    only)
  • //define USE_TIMERA_PRESCALE // The Rabbit
    3000 has the ability to
  • // run the
    peripheral clock at the
  • // same
    frequency as the CPU clock
  • // instead of
    the standard CPU/2.
  • // Uncomment
    this macro to enable
  • // this feature.

Or
46
Timer B Structure
47
Timer B Registers
  • To Read Timer B
  • Read the lower 8 bits (read TBCLR register).
  • Read the upper 2 bits (read TBCMR register)
  • Read the lower 8 bits again (read TBCLR register)
  • If bit 7 changed from 1 to 0 between the first
    and second read of the lower 8 bits, there has
    been a carry to the upper 2 bits. In this case,
    read the upper 2 bits again and decrement those 2
    bits to get the correct upper 2 bits. Use the
    first read of the lower 8 bits.
  • This procedure assumes that the time between
    reads can be guaranteed to be less than 256
    counts. This can be guaranteed in most systems by
    disabling the priority 1 interrupts, which will
    normally be disabled in any case in an interrupt
    routine.

48
Timer B Uses
  • By setting the speed of the counter clock,
    precise, arbitrary, waveforms can be generated
  • Need to set the value on the output port
  • Minimum pulse width 5 us
  • 19 Clocks for interrupt (from manual)
  • (1/29.4e6)19 .64 us
  • Give yourself 15 instructions at 10 clocks each
  • (1/29e6)1510 5.1 us
  • Resolution
  • Determined by clock width possible to have PCLK
    at full clock speed (Timer A1 w/o division)
  • (1/29.4e6) 34 ns
  • Can measure SW events by reading the TIMER B
    Count Register
  • By setting the match register to 0, Timer B can
    behave like Timer A

49
Timer B Uses
  • If desired the capture counter can be
    synchronized with Timer B outputs used to
    synchronously load parallel port output registers
  • This makes it possible to generate an output
    signal precisely synchronized with an input
    signal
  • The count offset can be measured by outputting a
    pulse at a precise time using Timer B to set the
    output time and capturing the same pulse
  • Once the phase relationship is known between the
    counters it is then possible to output pulses a
    precise time delay after an input pulse is
    captured, provided that the time delay is great
    enough for the interrupt routine to processes the
    capture event and set up the output pulse
    synchronized by Timer B
  • The minimum time delay needed is probably less
    than 10 microseconds if the software is done
    carefully the clock speed is reasonably high.
Write a Comment
User Comments (0)
About PowerShow.com
