Large scale IDS

1
Large scale IDS

• Network Intrusion Detection
• Deployment, Data Mining, and Management on a
  large scale

2
Who are we?

• Jeff Nathan
• jeff_at_snort.org
• Contributing Snort Developer
• IDS Researcher

• Brian Caswell
• bmc_at_snort.org
• Snort Signature Maintainer
• Corporate IDS Team Leader

Opinions expressed are our own and do not
reflect any employer
3
What are we discussing?

• No IDS is perfect
• Deployment concepts
• Sensor management
• Real-time IDS
• Data Management
• Data Mining
• Data Fusion
• Cost

4
No IDS is perfect

• Even ID systems have had problems
• Snorts ICMP Payload printing issue
• BlackICEs ICMP DoS/Kernel level overflow
• Dragons SNMP decoding DoS
• And we haven't started talking about
• detecting attacks yet

5
ID Systems are still evolving

• Resolving the ambiguities of passive detection
• Drawbacks of using a single detection mechanism
• Inline technologies
• Scalability is still not proven

6
No love between the children

• Vendors have unique detection capabilities
• Some ID systems will not integrate with others at
  all
• Correlating events between different systems is
  difficult

7
Wait, what about CVE?

• Does not cover everything an IDS looks at
• porno-fantastico,GOL! Busca el lubrificante
• CIEL Project
• CVE Sub-Project for IDS mappings
• Descriptions of detected attacks vary between
  vendors

8
Pre-deployment discussion

• How many people will view the output?
• What are their skill levels?
• Where should we place our IDS?
• How do I train my analysts?

9
Deployment mechanics

• IDS Technologies
• Gigabit ID systems
• http//www.cs.um.edu.mt/ssrg/Wallace.htm
• Considering multiple systems
• Managing a large number of sensors

10
Mechanics - Taps

• Misunderstood technology
• Currently designed for network analyzers

• Good
• Ideal for monitoring critical pipes
• Fail open
• Nothing to manage
• Nothing to configure

• Bad
• Copper taps require high end switches
• Requires more rack space
• Cost

11
Mechanics - Switches

• Good
• Can be used inline
• Provides some degree of buffering
• Remotely managed
• High end switches can aggregate multiple tapped
  segments together

• Bad
• Fail Closed
• Insufficient back plane bandwidth really hurts
• Over subscription between mixed media and in
  overloaded switches

12
Mechanics - Spans

• Good
• Copy Ethernet frames from one physical port to
  another
• Can be used for both tap switch-only
  deployments
• Can be modified by switch configuration (instead
  of moving cables)

• Bad
• Used for both tap switch-only deployments
• Computationally expensive to the switch
• May deliver more data to a port than the media
  can handle

13
Mechanics - Load Balancing

• Good
• Allow for practical deployment into high-speed
  networks
• Easiest mechanism for deploying multiple sensors
  at the same location

• Bad
• Tap vendors dont work with load balancer vendors
• Little practical documentation for enterprise
  environments
• Introduce a possible point of data mangling
• Limited port density
• Requires taps
• expensive

14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
Mechanics - Sensor Management

• Number of solutions, most are very expensive
• Tivoli
• NSH
• Cfchange
• Rsync
• CVS

18
Mechanics Sensor management with rsync

• Master server pushes configuration data to IDS
  sensors

• Bad
• Difficult to scale push
• Each configuration requires a separate rsync
  directory

• Good
• Centrally managed
• Remote sensors cant log in to the master

19
Mechanics Sensor management with CVS

• IDS sensors pull configurations from CVS server

• Good
• Centrally managed
• Pull generally scales better than push
• Multiple configurations managed together
• Entire operating systems can be managed via CVS

• Bad
• Difficult to manage
• Abuses CVS
• Management of OS adds much more complexity

20
Real-time IDS doesnt scale

• On a typical SDSL line
• 5 alerts per minute
• 300 alerts per hour
• 7200 alerts per day
• On a typical T1
• 50 alerts per minute
• 3000 alerts per hour
• 72000 alerts per day

• On a highly utilized DS3
• 8 alerts per second
• 480 alerts per minute
• 28800 alerts per hour
• 691200 alerts per day

21
A non-scaleable approach

• If each alert takes 30 seconds to examine, you
  need 120 analysts that work around the clock
• When will they eat?
• When will they sleep?
• When will they use the bathroom?

22
Stuck on the non-scaleable?

• Better stock up on Red Bull and catheters for
  your SOC
• Look into purchasing stock in Red Bull GMBH

23
Data Management

• Data Format
• IDMEF
• Security MIBS
• Syslog
• Something that scales

24
Security MIBS

• Divides the alert space into different spaces
• IP Layer
• Transport Layer
• Protocol Layer

25
Security MIBS - Example

• TCP SYN flood attack
• tcpSYNFlood OBJECT Identifier iso
  3.6.1.5.1.3.1.1
• Sub-objects for additional information
• tcpSYNFlood.src OBJECT Identifier
• iso 3.6.1.5.1.3.1.1.1
• tcpSYNFlood.dest OBJECT Identifier
• iso 3.6.1.5.1.3.1.1.1.2

26
Security MIBS good bad

• Good
• ASN1 is widely supported
• Widely documented
• SNMP is a standard

• Bad
• ASN1 is difficult to implement
• Difficult to read
• SNMP is still immature
• SNMP v3 implementations are rare

27
CIDF Common Intrusion Detection Framework

• Initial DARPA Research by Teresa Lunt and Stuart
  Staniford-Chen among others
• S-Expressions
• Actually use Generalized Intrusion Detection
  Objects (GIDO)
• Encoded version of an S-expression
• Work spurred on the Intrusion Detection Working
  Group (IDWG)

28
CIDF - Example

• (Delete
• (Context
• (HostName first.example.com)
• (Time 164032 Jun 14 1998)
• )
• (Initiator
• (UserName joe)
• )
• (Source
• (FileName /etc/passwd)
• )
• )

29
CIDF good bad

• Good
• Very extensible in S-expression form
• Easily readable in S-expression form

• Bad
• Work stopped in 99
• Not actually implemented anywhere
• Difficult to parse
• Not as efficient as other reporting formats

30
IDMEF Intrusion Detection Message Exchange
Format

• Unanswered questions
• Storage
• Viewing Data
• COTS implementations?

• Primary usage
• Sensor to console
• Console to console
• Actual Implementations
• libidmef Beep
• snort-idmef
• prelude
• stat (www.cs.ucsb.edu/rsg/STAT/)

31
IDMEF - Example

• ltIDMEF-Message version"0.3"gt
• ltAlert ident"abc123456789"
  impact"attempted-dos"gt
• ltAnalyzer analyzerid"bc-sensor01"gt
• ltNode category"dns"gt
• ltnamegtsensor.bigcompany.comlt/namegt
• lt/Nodegt
• lt/Analyzergt
• ltCreateTime ntpstamp"0x12345678.0x98765432
  "gt
• 2000-03-09T100125.93464Z
• lt/CreateTimegt
• ltSource ident"a1a2" spoofed"yes"gt
• ltNode ident"a1a2-1"gt
• ltAddress ident"a1a2-2
• category"ipv4-addr"gt
• ltaddressgt222.121.111.112lt/addressgt

32
IDMEF Example (continued)

• lt/Addressgt
• lt/Nodegt
• lt/Sourcegt
• ltTarget ident"b3b4"gt
• ltNodegt
• ltAddress ident"b3b4-1"
  category"ipv4-addr"gt
• ltaddressgt123.234.231.121lt/addressgt
• lt/Addressgt
• lt/Nodegt
• lt/Targetgt
• ltTarget ident"c5c6"gt
• ltNode ident"c5c6-1" category"nisplus"gt
• ltnamegtlollipoplt/namegt
• lt/Nodegt
• lt/Targetgt

33
IDMEF Example (still going)

• ltTarget ident"d7d8"gt
• ltNode ident"d7d8-1"gt
• ltlocationgtCabinet B10lt/locationgt
• ltnamegtCisco.router.b10lt/namegt
• lt/Nodegt
• lt/Targetgt
• ltClassification origin"cve"gt
• ltnamegtCVE-1999-128lt/namegt
• lturlgthttp//www.cve.mitre.org/lt/urlgt
• lt/Classificationgt
• lt/Alertgt
• lt/IDMEF-Messagegt

34
Syslog

• Bastard stepchild of IDS alert delivery
• Unreliable
• No guarantee of delivery
• ASCII only format

35
Syslog good bad

• Good
• Easy to parse
• Human readable
• Widely supported
• Already deployed in your infrastructure

• Bad
• Difficult to secure
• Unreliable
• No guarantee of delivery

36
Data Exchange A practical approach

• Requirements
• Portable
• Small
• Flexible
• Handles the data you need
• Readable by your end system
• Compressible
• Human readable

37
Data Exchange - CSV

• How about CSV?
• Natively supported by most of the ID systems
• In the format we need for our data warehouse
  anyway

38
Data Storage

• Star Schema
• Single "fact table"
• Multiple decode tables
• Why should we use this schema?
• Maximum flexibility
• Low maintenance
• Best performance for the most needed
• information

39
(No Transcript)
40
Data Storage Good Bad

• Good
• Saves the needed data, links to the rest
• Very fast searching
• Limited space required
• Puts that expensive DBA you have to work

• Bad
• Packets/Session Logs/URL Information must be
  stored elsewhere
• Hard to insert data live
• Alerts can be involved in only one incident
• Requires a production quality database

41
Data Mining

• Association
• Clustering
• Deviation Analysis
• Link or Tree abduction
• Neural Abduction
• Rule Abduction
• Statistical Analysis

42
Data Mining - Implementations

• Spade (Snort Preprocessor Plugin)
• Deviation Analysis
• Cyber wolf
• Semi real-time rule abduction

43
Spade

• Deviation Analysis on TCP SYN history

• Bad
• Limited scope
• Only looks at TCP SYN packets
• Anomalies happen

• Good
• Semi Real-time
• Distributed Computation

44
CyberWolf

• Semi Real-time Rule Abduction
• User defined rules that create incident trouble
  tickets
• Currently deployed at FEMA and AFRL
• Example
• A connects to B on dstport 80
• A attacks B with NIMDA
• if (B attacks with NIMDA)
  generate_incident()

45
Data Fusion

• Unified data view
• Enterprise wide view
• Plug Play IDS
• Vulnerability Correlation

46
Alert Fusion

• RealSecure HTTP_IE_BAT
• Snort WEB-IIS .bat? access
• Apache GET /args.bat?dir HTTP/1.0
• If multiple alerts have generally the same time,
  with the same SRC, DST, SRCPORT, and DSTPORT, its
  probably the same thing

47
Ooh, Alert Fusion Good

• Provides integrity checking
• Sensor A caught this, sensor B didnt. Why?
• Vendor A caught this, sensor B didnt. Why?
• Implemented by ARIS and Tivoli Risk Manager
• Can anyone say CIEL?

48
Vulnerability Correlation

• 300PM - .ida buffer overflow attempt against IP
• A previous vulnerability scan says may be
  vulnerable to .ida buffer overflow
• foreach my cve (sigsevent)
• if (vulnsdstipcve
  vulnssrcipcve)
• priority
• Implemented by
• Enterasys provides addon for Nessus Correlation
• ISS's SiteProtector Security Fusion Module

49
Wait, what about ip360?

• Get an alert? Scan to see if you are vulnerable
• Not scalable
• Scan your network, only look for things you are
  vulnerable to
• Dont you want to know if you are being attacked,
  even if you are not vulnerable?
• Scan your network, change priorities of alerts
  if you are vulnerable
• Dont ignore data because your scanner told
  you so, but raise the priority if you need to

50
Cost

• IDS is expensive
• Providing visibility into large networks requires
  a well implemented system (with lots of expensive
  hardware)
• Post processing of alert data and data mining
  techniques require commercial databases
• Large networks require many more sensors
• It costs money to protect money
• A poorly implemented solution adds little to
  the overall security

51
Conclusion

• Prioritization of alert data is critical
• Effectively deploying IDS is complicated
• Effectively deploying IDS on a large scale is
  much more complicated
• Integrating multiple vendors products will
  remain difficult until CIEL takes hold and we
  (the users) push the vendors to add support

52
Concluding the Conclusion

• Effectively managing IDS output requires trained
  analysts
• Dynamic reprioritization of alert data before its
  pasted to the alerting mechanism is important
• Vendors need to investigate data mining
  mechanisms for post processing of alert
  information
• Large scale deployments of various ID systems
  requires an incredible amount of work
