Browser Security: A New Research Territory

1
Browser Security A New Research Territory

• Shuo Chen
• Cybersecurity and Systems Management Group
• Microsoft Research, Redmond, WA

2
Outlines

• Preamble
• A little marketing about our research group
• Two browser security projects that I am working
  on
• Browser visual spoofing (with Jose Meseguer, Ralf
  Sasse, Helen J. Wang and Yi-Min Wang)
• Cross domain security violation (a brief
  introduction)
• Conclusion Browser/web security research is
  exciting

3
A little marketing about our research group

• Cybersecurity and Systems Management Group
• http//research.microsoft.com/csm/
• Current security projects
• HoneyMonkey client-side honeypots to find
  malicious websites
• SearchRanger finding spam websites that try to
  promote junk pages into top positions in search
  engines.
• Browser security (this talk)
• Current systems management projects
• FDR (Flight Data Recorder) always-on tracing of
  all interactions between Windows apps and
  configurations. Deployed on MSN production
  servers.
• WARDEN machine learning analysis of HTTP logs to
  troubleshoot Internet connectivity problems.
• AjaxScope remote monitoring/runtime analysis of
  web apps on end-user desktops.

4
A little marketing about our research group
(cont.)

• Manager/primary contact Yi-Min Wang
• Recruiting
• Researchers
• actively looking for candidates
• Ph.D. or graduating Ph.D. with good research
  record
• Research developers
• actively looking for candidates
• interested in research prototyping
• strong development skills
• Regular Ph.D. student interns
• strong passion is required!
• look for students who have good chance to be
  hired by MSR when they graduate.

5
Outlines

• Preamble
• A little marketing about our research group
• Two browser security projects that I am working
  on
• Browser visual spoofing (with Jose Meseguer, Ralf
  Sasse, Helen J. Wang and Yi-Min Wang)
• To appear in IEEE Symposium on Security and
  Privacy 2007
• Cross domain security violation (a brief
  introduction)
• Conclusion Browser/web security research is
  exciting

6
Visual Spoofing A Serious Security Problem
20 inches, Untrusted
Web server
1000 miles, trusted

• A simple equation
• 1000 miles trusted
• 20 inches untrusted
• untrusted
• Examples status bar spoofing and address bar
  spoofing
• IE, Firefox and Netscape all have security flaws
  in GUI.

7
Research motivation

• GUI behaviors are driven by complex logic
• E.g., how to handle mouse messages and update the
  status bar, how to update the address bar during
  navigations
• What are the GUI states that are spoofing
  states?
• Need formal definitions.
• Goal to develop a systematic approach to
• Check the GUI logic against the definitions of
  spoofing states
• Using the Maude rewriting engine as the reasoning
  tool
• Uncover GUI logic flaws that can cause spoofing.

8
Overview of Our Approach
Real spoofing scenarios
Source code of browser GUI
Visual invariant
(b)
Real world
Formal world
(a)
Program Logic (pseudo code)
(d)
(f)
Users action sequence
violation
Potential spoofing scenarios
Program invariant
(e)
(c)
Execution context
System state
The modeled system
Reasoning Engine
9
Case study status bar spoofing basic concepts
Document Object Tree (DOM Tree)
lthtmlgt ltheadgtlttitlegtPagelt/titlegtlt/headgt
ltbodygt lta href"http//paypal.com"gt
ltimg src"a.jpg"gt lt/agt
ltbuttongt My button lt/buttongt lt/bodygt lt/htmlgt
lthtmlgt
ltbodygt
ltheadgt
ltagt
ltbuttongt
lttitlegt
ltimggt
Page layout
Element stacks
Toward the user
ltbuttongt
ltimggt
ltbuttongt
ltimggt
ltbodygt
ltagt
ltbuttongt
ltagt
ltbodygt
status bar
10
Case Study status bar spoofing mouse handling
logic

• In status bar spoofing, only three raw mouse
  messages are relevant
• MouseMove, LeftButtonDown, LeftButtonUp
• Each HTML element has three virtual methods
• HandleMessage, DoClick, ClickAction
• Pseudo code in the paper
• Every element has different behavior about
  updating the status bar (SetStatusText) and
  navigating to the target URL (FollowHyperlink).
• Message bubbling (passing the mouse message to
  the parent element)
• Every element can decide whether to continue the
  bubbling or cancel the bubbling
• We used Maude to model the source code of the
  mouse handling logic

11
Case Study status bar spoofing finding attacks

• System state
• status bar URL, user memorized URL
• User action sequence
• MouseMove, MouseMove, Inspection,
  LeftButtonDown, LeftButtonUp
• (only need two MouseMoves because status
  bar is memoryless, a sequence of MouseMoves is
  equivalent to one MouseMove) (canonicalized)
• Execution context
• DOM tree structures (canonicalized)
• (at most two branches, corresponding to
  two MouseMoves)
• Program invariant
• at the time of the function call
  FollowHyperlink(targetURL),
• targetURL user memorized URL
• Use Maude to search for spoofing scenarios

12
Examples of Status Bar Spoofs
Element stack Element layouts
Element stack Element layouts
input field
paypal.com
paypal.com
button
anchor
form
form
form target foo.com image target paypal.com
form target foo.com anchor target paypal.com
label
label
anchor
imgs target paypal.com labels target
foo.com
labels target foo.com anchors target
paypal.com

• All because of unexpected combinations of element
  behaviors

13
Case Study address bar spoofing basic
concepts(browser, renderer, frame, markup)
http//MySite.com
.
14
Case Study Address Bar Spoofing

• Program invariant
• The address bar should display the URL
  of the current markup of the primary frame.
• User action sequence
• Page loading, history traveling and window
  opening
• Execution context
• A set of Boolean conditions affecting
  the execution path
• System state
• PrimaryFrame, other frames, current
  markups, pending markups, address bar URL ...

15
Pseudo code model loading a new page
Posting an event
SetAddressBar
Calling a function
Invoking a handler
FrameSwitchMarkup
NavigationComplete
FollowHyperlink
MarkupSetInteractive
ViewRenderView
ViewEnsureView
PostParser
Eventqueue
start navigation
ready
onPaint
ensure
16
Pseudo code model history travel
Posting an event
SetAddressBar
Calling a function
Invoking a handler
FrameSwitchMarkup
NavigationComplete
LoadHistory
ViewRenderView
MarkupSetInteractive
Travel
ViewEnsureView
PostParser
History_Back
Eventqueue
start navigation
ready
onPaint
ensure
17
Pseudo code model opening a page in a new window
InitDocHost
LoadFromInfo
SwitchMarkup
CreateMarkup
SetClientSite
LoadFromInfo
InitNew
SetAddressBar
Load
ViewRenderView
CreatePendingDocObject
LoadDocument
PostParser
FollowHyperlink
download-content
Eventqueue
start-loading
onPaint
18
Discovered Address Bar Spoof (An Atomicity Bug)
https//evil.comxxxxx...xxxxxxx
https//paypal.com
19
Discovered address bar spoof (a race condition)
https//paypal.com
https//evil
c\windows\system32\shdoclc.dl l?http
20
Summary of the GUI logic project

• Found many new scenarios for the status bar
  spoofing, filed them as 9 bugs against IE.
• All fixed before IE7 RC 1 (release candidate 1).
• 4 new scenarios of the address bar spoofing
• Non-atomic update of the address bar (2 bugs)
• Non-atomic update of the content area
• Race condition multiple frames compete to be the
  primary
• IE team has fixed two, and proposed the fixes for
  the other 2 to go into the next version.

21
Outlines

• Preamble
• A little marketing about our research group
• Two browser security projects that I am working
  on
• Browser visual spoofing (with Jose Meseguer, Ralf
  Sasse, Helen J. Wang and Yi-Min Wang)
• Cross domain security violation (a brief
  introduction)
• Conclusion Browser/web security research is
  exciting

22
Browser cross-domain attacks

• Browsers need to implement isolation mechanism to
  make sure that scripts from http//a.com cannot
  access the DOM tree from http//b.com
• Seemingly simple policy, surprisingly hard to
  enforce in current browser implementations
• Many bugs have been found in IE, Firefox, Opera,
  Netscape
• Serious consequences
• As long as you visit a malicious site, the script
  can steal your personal information in your
  hotmail, payroll, bank pages, and/or actively
  transfer your money.
• See some demos on Windows XP
• Due to async navigation, aliasing, user event
  semantics, interactions with non-browser
  components,
• Very difficult for developers to anticipate all
  these scenarios.

23
The proposed idea script accenting

• The basic idea is analogous to the accent in
  human languages
• The accent is essentially an identifier of a
  persons origin that is carried in communications
• We slightly modified a few functions at the
  interface of the script engine and the HTML
  engine so that
• each domain is associated with a random accent
  key,
• scripts and DOM object names are in their
  accented forms at the interface.
• A nice security property
• Without needing an explicit check for the
  domains, the accenting mechanism naturally
  implies that two frames cannot communicate/interfe
  re if they have different accent keys.

24
Evaluations of the script accenting mechanism

• Prototyped on IE
• Protection effectiveness
• All cross-domain attacks that we reproduced are
  defeated
• Transparency
• Tested on many complex web applications
• Virtual earth, Google map, Hotmail, Citi bank,
  CNN.com, Slashdot, YouOS.com, etc
• Completely transparent to existing IE
  functionalities
• Performance
• Near zero performance overhead in real browsing
  experiences

25
Outlines

• Preamble
• A little marketing about our research group
• Two browser security projects that I am working
  on
• Browser visual spoofing (with Jose Meseguer, Ralf
  Sasse, Helen J. Wang and Yi-Min Wang)
• Cross domain security violation (a brief
  introduction)
• Conclusion Browser/web security research is
  exciting

26
Conclusion browser/web security research is
exciting

• The territory is new, real and big.
• Script, AJAX, blog, search engine, web OS,
• Attacks phishing, spamming, click fraud,
  cross-site scripting, cross-domain attack,
• The threats are not well understood
• Opportunity to do great analysis work
• The browser security models are not strictly
  specified
• Opportunity to propose clearer security models
• Opportunity to examine existing security models
• Browser implementations are still ad-hoc
• Opportunity to apply program analysis techniques
• Opportunity to invent implementation-level
  primitives and constructs
• Many other emerging security problems for us to
  catch
