Aaron Newman CTO/Founder

1
Oracle Forensics Collecting Evidence after an
Attack
Aaron NewmanCTO/Founder Application Security,
Inc.
2
Agenda

• Overview of Database security
• Forensics in the Database
• Forensic DEMO Buffer overflow
• Forensics in the Listener
• Forensic DEMO tnscmd attack
• Forensic DEMO Listener Password attack
• Oracle Root Kits
• Forensic DEMO
• SQL Injection
• Forensic DEMO
• Resources, Conclusion, and Wrap Up

3
Overview of Database Security
4
Database Vulnerabilities

• A decade ago, databases were
• Physically secure
• Housed in central data centers not distributed
• External access mediated
• Security issues rarely reported
• Now, databases are externally accessible
• Suppliers directly connected
• Customers directly connected
• Customers and partners directly sharing data
• Data is the most valuable resource in application
  stack
• Value increases with greater integration and
  aggregation
• But so does the threat of data theft,
  modification, or destruction

5
Barrier Defense Is No Longer Enough
Web Proxy
Firewall
Main Office Network
Business Partners Network
Firewall
VPN
Firewall
VPN
Remote Employees
Remote Office Network
6
Forrester on Database Security
Source Comprehensive Database Security Requires
Native DBMS Features And Third-Party Tools,
Forrester Research, Inc., March 29, 2005
7
Attackers focusing on databases
http//news.softpedia.com/news/Toying-with-Microso
ft-s-breaches-is-no-longer-fun-for-hackers-1603.sh
tml .. until now the hackers have mostly
targeted Microsofts software products, starting
with this year, it seems their attention has been
draw to other products and services ... According
to a recently published study, ...its clear they
are exploring new territories besides the old
Windows .. the software products developed by
Oracle Corp ... have started to be more and more
targeted by hackers.
8
External threats

• Exposing a database to the Internet
• DO NOT DO THIS!
• Behind a firewall
• Recommend data be served through web app
• Still vulnerable to application level attacks
• Still vulnerable to internal attacks

9
Internal threats

• Need to focus less on people getting through
  perimeter
• Need to focus more on securing data at the source
• Attacks from DBAs, sysadmins, and legitimate
  users
• Need to focus not only on vulnerabilities
• Be able to see who is doing what in your
  applications
• Providing auditing and accountability for users
  and database administrators
• Being able to identify malicious activity
• http//www.thesmokinggun.com/archive/0623042aol1.h
  tml
• JUNE 23--An AOL software engineer was arrested
  today for stealing the company's entire
  subscriber list--totaling 92 million screen
  names--and selling it to a 21-year-old Las Vegas
  spammer.

10
Forensics in the Database
11
After the Attack

• You have discovered you have been attacked
• Now what???
• Need to collect as much data about attack as
  possible
• When did it occur
• How did it occur
• Where did it come from
• Databases write auditing data in numerous
  locations
• Collect all those locations into a single
  repository
• Correlate events to get a better picture of what
  happened

12
Forensics of an Oracle database

• First consideration
• We dont want to lose any forensic evidence
• Be prepared to restore to a state before forensic
  work was started
• Backup everything you can
• Operating system including the ORACLE_HOME
  directory
• Database system
• Before doing anything else
• Take a snapshot of dynamic memory
• Shutting down database clears this information
• Save copy of vsql table particularly if attack
  was recent
• Contains a copy of latest SQL statements executed

13
What To Look For

• Attacks typically require multiple tries
• Look for evidence of trial or error
• Normalize all you data
• Find what is typical and then eliminate that
• Look through what is not typical
• Typically find clusters of errors reflecting an
  attack
• Narrow down time period attack most likely
  occurred
• Focus in on event around that time/date
• Look at events from multiple source to piece
  together what might have happened
• Determine most likely source of the attack
• Hacker using a password attack or buffer overflow
• Customer using privilege escalation
• Employee using special access
• Do not rule out any attack vector out

14
Files with Forensics Evidence

• Within ORACLE_HOME/admin/ltSIDgt
• pdump/alert_ltSIDgt.log -
• cdump/ltSIDgtcore.log raw stack dumps resulting
  form buffer overflow attacks
• Look for malicious payload in this file
• Groupings of attacks
• udump/ltSIDgt_s001_4382.trc user trace file might
  contain user errors
• Within ORACLE_HOME/network/log
• Listener.log file contains connections to the
  listener service
• Agntsvrc.log, etc contains logs on components of
  database
• Files may be anywhere on the system
• Sqlnet.log files show network traffic from the
  client
• SQLNet trace files cli_3736.trc

15
Do you have some form of auditing enabled?

• Best case scenario - you have auditing enabled
• One type - Native Oracle auditing
• Records data in system tables or operating system
  files
• Configured using AUDIT_TRAIL in the init.ora file
• Need to appropriately set what to audit
• Check AUDIT_SYS_OPERATIONS enabled
• Records all activities of the SYS account
• Equivalent of the root account
• Written to value of AUDIT_FILE_DEST in the
  init.ora file
• Audits everything SYS does

16
Advantages of Off-database Auditing

• Native Oracle auditing has its disadvantages
• Incurs overhead in the database
• No separation of controls Can use new Vault
  features
• Native auditing
• Can be disabled or deleted by attacker in the
  database
• Most databases have NO auditing configured still
• 3rd-party security tools provide improved
  auditing
• Network-based auditing and monitoring
• Host-based auditing and monitoring

17
Forensic DemoBuffer overflow
18
Forensics in the Listener
19
Forensic Demotnscmd
20
Easily-guessed Passwords

• Passwords can be guessed
• Attacking a single account with 100k passwords
• Attacking many accounts with a few very common
  passwords
• People leave test/test or password same as
  username
• Password dictionaries
• http//www.openwall.com/passwords/wordlists/
• The wordlists are intended primarily for use with
  password crackers
• Third-party default passwords
• http//www.petefinnigan.com/default/default_passwo
  rd_list.htm
• List of 600 default usernames/passwords

21
Password Management features

• It is important that you have all the proper
  safeguards against password crackers
• Listener does not have Account Lockout
• Listener.log activity is seldom monitored
• Scripts and Tools for exploiting weak
  identification control mechanisms and default
  passwords are widely available

22
Forensic DemoListener Password Attack
23
Oracle Root Kits
24
What is a root kit?

• Creates a back door on a computer system
• Have been used on operating system for many years
• Create a copy of a system command
• Place hackers commands in new replacement system
  commands
• Root kit is used after breaking into a system
• Allows the hacker to come back later
• And to stay totally cloaked
• Change system to
• not show that the hacker is logged in
• not log what the hacker does
• to allow hacker to do anything

25
Oracle Root Kits

• Apr 2005 demonstrated at BlackHat Security
  conference
• By Alexander Kornbrust
• Introduced the idea of creating root kits for
  Oracle
• Full copy of presentation available at
• http//www.red-database-security.com/wp/db_rootkit
  s_us.pdf
• Demonstrated hiding users granted DBA
• Modified the DBA_USERS and ALL_USERS views
• Demonstrated hiding connection
• Modified the vsession view

26
Forensic Demo Root kit
27
SQL Injection
28
Can attacks go through a firewall?

• YES!!!
• Firewall configuration
• Block access to any database port
• Only allow traffic to port 443, 80
• Block UDP as well as TCP
• SQL Injection
• Not specific to Oracle
• a web programming problem

29
How Does It Work?

• Try to modify the query
• Change
• Select from my_table where column_x 1
• To
• Select from my_table where column_x 1
• UNION select credit_card_number from orders
  where qq

30
Example JSP Page
Package myseverlets String sql new
String(SELECT FROM WebUsers WHERE Username
request.getParameter(username) AND
Password request.getParameter(password)
stmt Conn.prepareStatement(sql) Rs
stmt.executeQuery()
31
Valid Input

• If I set the username and password to
• Username Bob
• Password Hardtoguesspassword
• The SQL statement is
• SELECT FROM WebUsers WHERE UsernameBob AND
  PasswordHardtoguess

32
Hacker Input

• Instead enter the password
• Aa OR AA
• The SQL statement now becomes
• SELECT FROM WebUsers WHERE UsernameBob AND
• PasswordAa OR AA
• The attacker is now in the database!

33
SELECT from other tables

• SELECT arbitrary data
• Name the tables to SELECT against
• UNION statement
• Adds/executes second SQL statement
• Column types and number must match

34
Sample ASP Page
Dim sql Sql SELECT ProductName FROM Products
WHERE ProductCategory request.formproduct_c
ategory Set rs Conn.OpenRecordset(sql)
return the rows to the browser
35
Valid Input

• Set the product_category to
• DVD Player
• The SQL Statement is now
• SELECT ProductName FROM Products WHERE
  ProductCategoryDVD Player

36
Hacker Input

• Set the product_category to
• test UNION select credit_card_number from
  CUSTOMERS where a a
• The SQL Statement is now
• SELECT ProductName FROM Products WHERE
  ProductCategorytest UNION select
  credit_card_number from CUSTOMERS where aa

37
Reverse Engineering Database Schema

• Hacker doesnt know the database schema
• Can they figure it out?
• Yes!!!
• UNION SQL statement with objects from system
  catalog
• Retrieving the list of tables
• UNION select object_name from sys.all_objects
• Retrieving the list of columns
• UNION select column_name from sys.all_tab_columns


38
Preventing SQL Injection

• Bind variables dont concatenate SQL strings
• Right way
• String sql new string(
• UPDATE EMPLOYEE SET BONUS?)
• Wrong way
• String sql new string(
• UPDATE EMPLOYEE SET BONUS
  request.getParameter(bonus))

39
Forensic Demo SQL Injection
40
Resources, Conclusion, and Questions
41
How Do You Address These Vulnerabilities?

• Stay Patched
• Stay on top of all the security alerts and
  bulletins
• Defense in Depth
• Multiple Levels of Security
• Regularly perform audits and penetration tests on
  your database
• Encryption of data-in-motion / data-at-rest /
  data-in-use
• Monitor database activity log files
• Implement database intrusion detection and
  auditing
• Especially if you cant stay patched!

42
Questions?

• Thank you
• Questions on
• Forensics
• Vulnerabilities
• Locking down the database
