Information Systems describing resources

1
Information Systemsdescribing resources

• Grid Middleware 4
• David Groep, lecture series 2005-2006

2
Outline

• Taxonomy of information systems
• hierarchies and republishers
• Grid Monitoring Architecture
• push and pull, subscriptions
• Performance of an IS
• collecting information
• sensors
• IS content schemas and approaches

3
Grid Information Systems

• Concerns data
• shared between administrative domains
• for use by multiple people or VOs
• So it does not include things like
• cluster temperature monitoring
• debugging streams
• accounting history

4
Classification of information systems

• Which monitoring systems types are suitable for
  grid?
• Paper
• http//www.cs.man.ac.uk/zanikols/fgcs05.pdf
• Different types are
• Level 0
• self-contained not accessible by programs (but
  only e.g. web)
• Level 1
• events are accessible remotely at the single
  producer level
• Level 2
• includes republishers with fixed functionality
• Level 3
• supports hierarchies of republishers

5
System taxonomy levels of systems

• Components used in information systems
• and taxonomy levels

graphics and concept from S. Zanikolas et al.,
FGCS 21 (2005) 163-188
6
Information system classes

• Level 2 or 3 system are suitable
• Reference architecture GMA
• Grid Monitoring Architecture requirements
• (performance) information with relatively short
  lifetime
• frequent updates
• (should) carry quality-of-information status as
  well
• but when you get down to it, almost anything
  fits in this architecture
• including directories with
• relatively static information
• suitable mainly for resource state

7
Grid Monitoring Architecture

• Definition of terms and roles (GWD-GP-16-2)
• Functions
• Registry (directory)
• Add, Update, Remove, Search
• Producer
• Maintain Registration, Accept Query, Accept
  (Un)subscribe, Locate Consumer, Notify,
  Initiate (Un)subscribe
• Consumer
• Locate Producer, Initiate Query, (Un)subscribe,
  Maintain Registration, Accept Notification,
  (Un)subscribe, Locate Event Schema

8
GMA Intermediaries

• Also referred to as republishers
• make it a level-3 system
• Examples
• Latest Producer
• return the last value of an event
• Archiver (history producer)
• storage of historical monitoring data
• e.g. accounting records

9
Directories

• Information providers publish information to a
  directory
• Directories may be linked in networked
  hierarchies
• Information is usually also in a DIT-like
  structure(Directory Information Tree)
• Typical implementation LDAP

10
Approaches to sending information

• Orthogonal to the topology is the information
  flow model
• Push model
• information gets published regardless of its use
• bet its there (in higher-level aggregators) when
  its needed
• e.g. Condor Hawkeye, LCG BDII
• Hybrid
• information location gets published
• consumers can subscribe to information and from
  then on continuously get it
• e.g. R-GMA, (MDS4?)
• Pull model
• information is retrieved on-demand, and you
  cannot subscribe
• e.g. MDS-2

11
Information Systems

• Examples shown in this lecture
• Monitoring and Discovery Service (MDS)
• Relational Grid Monitoring Arch (R-GMA)
• Hawk eye
• Berkeley-DataBase Information Index (BDII)

12
1 MDS2

• Part of GT2.x
• Typical use resource selection by brokers
• Architecture
• decentralized
• hierarchical
• soft-state protocols with timeouts
• supports caching in index servers
• Security GSI (optional)

13
MDS2 Architecture
graphic J. Schopf, GFNL masterclass 2005
Distributed Monitoring and Information Services
for the Grid
14
MDS2 information flow

• Soft-state registration of GRISes with GIISes
• time out on the registration (TTL and nextUpdate)
• Data retrieved on-demand from underlying GRIS
• timeout on the answer
• resources silently drop out if they fail
• GRISes collect information using scripts
• GIISes can be collated in arbitrary hierarchies

15
2 R-GMA

• straight implementation of the GMA
• uses a relational representation of the data
• notification/subscription directly from the
  source
• implementation in Java
• developed in EU DataGrid and EGEE JRA1
• UK cluster, Steve Fisher (RAL), et al.

16
R-GMA Archirecture
17
MON Box

• Every site has a MON box to proxy information
• local cache of info in memory
• through-channel to systems behind a firewall
• producers/consumers connect actively to the MON
  box
• Multiple producers can publish in the same table
• joins can be done, but only via a secondary
  producer
• Usually deployed with a single registry

18
R-GMA plain SQL interface

• bosuidavidg1001 rgma
• Welcome to the R-GMA virtual database for Virtual
  Organisations.
•

• Your local R-GMA server is
• https//eg.nikhef.nl8443/R-GMA
• You are connected to the following R-GMA Registry
  services
• https//lcgic01.gridpp.rl.ac.uk8443/R-GMA/Regis
  tryServlet
• You are connected to the following R-GMA Schema
  service
• https//lcgic01.gridpp.rl.ac.uk8443/R-GMA/Schem
  aServlet
• Type "help" for a list of commands.
• rgmagt show tables
• ------------------------------------------
• Table Name
• ------------------------------------------
• ArchiverTestTable
• ...
• GlueCE
• ...

19
Queries

• rgmagt select UniqueID,Name,TotalCPUs from GlueCE
  WHERE UniqueID LIKE 'ulakbim'
• -------------------------------------------------
  ---------------------
• UniqueID
  Name TotalCPUs
• -------------------------------------------------
  ---------------------
• ce.ulakbim.gov.tr2119/jobmanager-lcgpbs-seegrid
  seegrid 126
• ce.ulakbim.gov.tr2119/jobmanager-lcgpbs-trgrida
  trgrida 126
• ce.ulakbim.gov.tr2119/jobmanager-lcgpbs-lhcb
  lhcb 126
• ...

20
3 Hawkeye

• Condor information system
• publishes class-ads for
• matchmaking
• fault detection
• periodic updates to the agents by the modules
• information kept in the agents

21
Hawkeye architecture
graphic J. Schopf, GFNL masterclass 2005
Distributed Monitoring and Information Services
for the Grid
22
4 BDII GIP

• BDII conceptually similar to Hawkeye
• but data is pulled rather than pushed
• mentioned here because of its wide-spread
  deployment in EGEE/LCG, OSG, c
• Generic Information Providers (GIP)
• scripting framework to produce LDIF
• static values overridden by output from scripts
• periodically, LDAP queries sent to subordinate
  directories
• with time-out on the answer
• previous answer is persistent for a defined
  amount of time
• contrary to MDS2, BDII will never forget
• Paperhttp//indico.cern.ch/materialDisplay.py?co
  ntribId126sessionId23materialIdpaperconfId0

23
BDII organisation
BDII
Site BDII
24
BDII scaling

• OpenLDAP update (write) is not optimized
• with SleepyCat Berkeley DB, simultaneous
  read/write lead to timeouts
• So, put in a forwarder service that redirects to
  a pool of OpenLDAP/DB backends that swap roles

25
WS style information systems

• MDS4
• based on WS-RF, WS-Notification mechanisms
• provides a common aggregator framework for
• index service (republisher)
• trigger service (send events, mails, execute
  programs)
• archive service
• NAREGI Distributed Information Service
• Aggregator collect information from various
  sources
• put these as CIM objects in a database
• OGSA-DAI front-end to the database with CIM
  objects
• PS OGSA-DAI (Data Access Integration) is a
  system for providing uniform grid access to
  database resources

26
MDS4 Aggregator Framework
27
NAREGI Distributed Information Service
graphicSatoshi Matuoka, Tokyo Institute of
Technology NII, NAREGI
28
Status

• Both developed and available
• neither been tested yet at the very large scale
• i.e. O(1000) resources, thousands of simultaneous
  queries

29
Hierarchies and Views
30
Views on the information system

• For resource information
• information view on those resources to which the
  viewer potientially has access
• a single global root is neither feasible nor
  needed
• a per-VO or per-infrastructure view is sufficient
• For application level monitoring
• fine-grained access control needed
• at the VO or user level
• attributes in the schema may have different
  privacy levels
• requires view management like in regular databases

31
Typical hierarchical top levels today

• per-infrastructure
• e.g. EGEE/LCG, OSG, NAREGI
• used by many VOs
• needs support at the infrastructure level
• per-VO view
• prevalent in grass-roots deployment
• all systems can support both
• although not all in the same wayR-GMA works
  with per-site mon boxes that (today) use a
  central registry -gt one per infrastructure

32
Performance

• an example of a grid performance study

33
Performance analysis

• Best paper so far X. Zhang, J. Freschl, J.
  Schopf, A performance study of monitoring and
  information services for distributed systems,
  in Proceedings of the 12th IEEE High
  Performance Distributed Computing (HPDC-12 2003),
  IEEE Computer Society Press, Seattle, WA, USA,
  2003, pp. 270282.
• Perf results on R-GMA are outdated, but basics
  still do hold
• MDS2 has since been replaced with MDS4 (in GT4)
• The three systems selected are indicative of the
  different classes, and thus its a very valuable
  comparison!
• Data in the next slides by Jennifer Schopf
• from the GridForum NL/ISOC NL Masterclass 2005

34
Roles of components in the comparison
ideas, graphics, results J. Schopf, GFNL
masterclass 2005 Distributed Monitoring and
Information Services for the Grid
35
Performance analysis

• Three characteristics systems
• MDS2 (pull system, with and without caching)
• R-GMA (hybrid, straight GMA implementation
  w/Relational IF)
• Hawkeye (push system, from Condor)
• Tests done on a small test bed (7 systems)
• scaling has not been tested
• but results are at least comparable

ideas, graphics, results J. Schopf, GFNL
masterclass 2005 Distributed Monitoring and
Information Services for the Grid
36
Performance analysis other facts

• Keep in mind that MDS2 Hawkeye are programmed
  in C
• R-GMA is in Java
• This R-GMA version relied heavily on threads
• i.e. implementation was straight translation of
  architecture
• JVM and Linux kernel 2.4 dont like too many
  O(500) threads

37
Model for evaluation

• paper attempts to compare similar properties in
  the three systems
• deploy in a standard mode (as depicted)

ideas, graphics, results J. Schopf, GFNL
masterclass 2005 Distributed Monitoring and
Information Services for the Grid
38
Experiments in Zhang et al.

• How many users can query an information server at
  a time?
• How many users can query a directory server?
• How does an information server scale with the
  amount of data in it?
• How does an aggregator scale with the number of
  information servers registered to it?

ideas, graphics, results J. Schopf, GFNL
masterclass 2005 Distributed Monitoring and
Information Services for the Grid
39
Experiments
ideas, graphics, results J. Schopf, GFNL
masterclass 2005 Distributed Monitoring and
Information Services for the Grid
40
Comparing Information Systems

• We also looked at the queries in depth -
  NetLogger
• 3 phases
• Connect, Process, Response

Response
Process
Connect
ideas, graphics, results J. Schopf, GFNL
masterclass 2005 Distributed Monitoring and
Information Services for the Grid
41
Testbed

• Lucky cluster at Argonne
• 7 nodes, each has two 1133 MHz Intel PIII CPUs
  (with a 512 KB cache) and 512 MB main memory
• Users simulated at the UC nodes
• 20 P3 Linux nodes, mostly 1.1 GHz
• R-GMA has an issue with the shared file system,
  so we also simulated users on Lucky nodes
• All figures are 10 minute averages
• Queries happening with a one second wait between
  each query (think synchronous send with a 1
  second wait)

ideas, graphics, results J. Schopf, GFNL
masterclass 2005 Distributed Monitoring and
Information Services for the Grid
42
Metrics

• Throughput
• Number of requests processed per second
• Response time
• Average amount of time (in sec) to handle a
  request
• Load
• percentage of CPU cycles spent in user mode and
  system mode, recorded by Ganglia
• High when running small number compute intensive
  aps
• Load1
• average number of processes in the ready queue
  waiting to run, 1 minute average, from Ganglia
• High when large number of aps blocking on I/O

ideas, graphics, results J. Schopf, GFNL
masterclass 2005 Distributed Monitoring and
Information Services for the Grid
43
Information Server Throughputvs. Number of Users
(Larger number is better)
ideas, graphics, results J. Schopf, GFNL
masterclass 2005 Distributed Monitoring and
Information Services for the Grid
44
Query Times
400 users
50 users
(Smaller number is better)
ideas, graphics, results J. Schopf, GFNL
masterclass 2005 Distributed Monitoring and
Information Services for the Grid
45
Experiment 1 Summary

• Caching can significantly improve performance of
  the information server
• Particularly desirable if one wishes the server
  to scale well with an increasing number of users
• When setting up an information server, care
  should be taken to make sure the server is on a
  well-connected machine
• Network behavior plays a larger role than
  expected
• If this is not an option, thought should be given
  to duplicating the server if more than 200 users
  are expected to query it

ideas, graphics, results J. Schopf, GFNL
masterclass 2005 Distributed Monitoring and
Information Services for the Grid
46
Directory Server Throughput
(Larger number is better)
ideas, graphics, results J. Schopf, GFNL
masterclass 2005 Distributed Monitoring and
Information Services for the Grid
47
Directory Server CPU Load
(Smaller number is better)
ideas, graphics, results J. Schopf, GFNL
masterclass 2005 Distributed Monitoring and
Information Services for the Grid
48
Query Times
400 users
50 users
(Smaller number is better)
ideas, graphics, results J. Schopf, GFNL
masterclass 2005 Distributed Monitoring and
Information Services for the Grid
49
Experiment 2 Summary

• Because of the network contention issues, the
  placement of a directory server on a highly
  connected machine will play a large role in the
  scalability as the number of users grows
• Significant loads are seen even with only a few
  users, it will be important that this service be
  run on a dedicated machine, or that it be
  duplicated as the number of users grows.

ideas, graphics, results J. Schopf, GFNL
masterclass 2005 Distributed Monitoring and
Information Services for the Grid
50
Information Server Scalabilitywith Information
Collectors
(Larger number is better)
ideas, graphics, results J. Schopf, GFNL
masterclass 2005 Distributed Monitoring and
Information Services for the Grid
51
Experiment 3 Load Measurements
(Smaller number is better)
ideas, graphics, results J. Schopf, GFNL
masterclass 2005 Distributed Monitoring and
Information Services for the Grid
52
Experiment 3 Query Times
80 Info Collectors
30 Info Collectors
(Smaller number is better)
ideas, graphics, results J. Schopf, GFNL
masterclass 2005 Distributed Monitoring and
Information Services for the Grid
53
Sample Query
Note log scale
ideas, graphics, results J. Schopf, GFNL
masterclass 2005 Distributed Monitoring and
Information Services for the Grid
54
Experiment 3 Summary

• The more the data is cached, the less often it
  has to be fetched, thereby increasing throughput
• Search time isnt significant at these sizes

ideas, graphics, results J. Schopf, GFNL
masterclass 2005 Distributed Monitoring and
Information Services for the Grid
55
Aggregate Information Server Scalability
(Larger number is better)
ideas, graphics, results J. Schopf, GFNL
masterclass 2005 Distributed Monitoring and
Information Services for the Grid
56
Load
ideas, graphics, results J. Schopf, GFNL
masterclass 2005 Distributed Monitoring and
Information Services for the Grid
57
Query Response Times
400 Info Servers
50 Info Servers
(Smaller number is better)
ideas, graphics, results J. Schopf, GFNL
masterclass 2005 Distributed Monitoring and
Information Services for the Grid
58
Experiment 4 Summary

• None of the Aggregate Information Servers scaled
  well with the number of Information Servers
  registered to them
• When building hierarchies of aggregation, they
  will need to be rather narrow and deep having
  very few Information Servers registered to any
  one Aggregate Information Server.

ideas, graphics, results J. Schopf, GFNL
masterclass 2005 Distributed Monitoring and
Information Services for the Grid
59
Overall Results

• Performance can be a matter of deployment
• Effect of background load
• Effect of network bandwidth
• Performance can be affected by underlying
  infrastructure
• LDAP/Java strengths and weaknesses
• Performance can be improved using standard
  techniques
• Caching multi-threading etc.

ideas, graphics, results J. Schopf, GFNL
masterclass 2005 Distributed Monitoring and
Information Services for the Grid
60
Observations on the performance study

• Measures performance, not stability
• test bed size is only 7 machines and 10 clients
• local cluster, i.e. latency is well controlled
• In a real-life deployment, complexity is
  determining factor in success
• simple systems are more likely to survive
• systems with soft-state registration timeouts
  (like MDS) are more prone to instabilities than
  systems based on a persistent elephant-style
  memory (like BDII) (c.f. sypical signal
  processing issues)

61
Assorted Issues
62
Access Control

• AuthN is simple
• keeps out 99 of the rogue information
• doesnt do a bit for privacy preservation
• not every cert owner is a grid user for a
  specific infrastructure
• course grained ACLs better
• grid-mapfile, ACLs on access to service
• keeps known bad guys out
• still no privacy
• fine-grained acls
• support within the DB engine is actually
  requiredas its too hard to retro-fit otherwise

63
Timeout issues

• differences in timeouts in information providers
  lead to phase difference effects in the system
• temporary amnesia of aggregate information
  indices
• cumulative delays
• Timeouts
• registration period for GRIS with a GIIS
• time to bind to GRIS (defines if a resource is up
  or down)
• time to produce information entries
• cache TTL in the GIIS
• timeout before removing stale information from
  GIIS
• essentially its feed-back signal theory -)

64
Content of the Information System
65
Approaches to resource information

• Resource description
• GLUE
• CIM
• and similar but slightly different schemas for
  ARC and GT2
• Job description
• Unicores AJO

66
Information Schemas GLUE

• Describes resource availability information
• Common for various middleware suites
• Known limitations
• not even all specified info is actually used
• contains lots of info that are un-used
• cannot express information needed for brokering
  at the appropriate granularity level (this is
  fundamental for all such information schemas)
• More specifics discussed with each component
• See http//infnforge.cnaf.infn.it/glueinfomodel/

67
Glue Abstractions

• Core Entities
• Site name, contact info, latitude/longitude,
  sponsor
• Service type, version, endpoint, status, WDSL
  URL, Semantics URN, StartTime
• Cluster
• ComputingElement Info, State, Policy, ACBRule,
• VOView ACBRule, Running, Waiting, Free, ERT,
  WRT,
• SubCluster HostOperatingSystem, HostAppSWRTEnv,
• StorageElement

68
GLUE Core Schema
69
GLUE Cluster
70
GLUE Storage
71
GLUE Linking compute and storage

• Useful is storage is accessible via POSIX, or via
  faster networks
• position of such a binding is difficult
• abused for pure-SE info as this is the only place
  where the file path to the storage was specified

72
Alternative schemas with the same viewpoint

• Original GT2 schema (obsolete)
• NorduGrid ARC

73
CIM Common Information Model

• object oriented abstraction of information (DMTF)
• uses abstractions, dependencies, inheritance
• goes beyond a mere information model by
• defining methods for standard object behaviour
• trying to solve every possible problem (and solve
  the perpetuum mobile issue in the process )
• information components of CIM can use used to
  represent resources

74
Common Information Model (CIM)

• Object-oriented schema developed by the DMTF
• representation in different formats (such as XML)
• See http//www.dmtf.org/standards/cim/
• Extended for grid elements by the GCS-WG
• BatchService, c
• The NAREGI grid is main user of this system

75
Example CIM Job Submission Interface
76
The Unicore information model

• Describe the resource requests(so opposite
  viewpoint compared to GLUE)
• the resources themselves need not be described,
  since they will bid on the job requests
• we will deal with this one in the Brokering CE
  lecture

77
Summary

• Information systems used across multiple
  organisations and by multiple people or VOs
• taxonomy classiciation (republishing data flow)
• Any grid information system needs
• programmatic access via producer/consumer APIs
• compositional IS freedom (VO or infrastructure
  hierarchies)
• focus has been on resource selection
• used for brokering decisions, either by people or
  programs
• needs a common information schema or translators
• for application-level information systems
• user-defined schema and a schema registry (like
  R-GMA)
