Water Services National Training Group

1
Water Services National Training Group

• 11th Annual Conference
• 6th September 2007

2
Septic Tank Effluent Drainage
System STEDS Matt Shortt Director of
Services North Tipperary County Council
3

• Background
• Project description
• Current status
• Preliminary results

4
Alternative wastewater treatment systems for
small rural communities

• Requirements
• Sustainability
• Maintenance
• Risk of failure
• Process performance
• Low energy costs
• Low operating costs
• Renewable energy options

5
Approach

• Literature search
• Short list of options
• Real life applications
• Evaluate whole life costs

6

• Alternative collection systems
• Alternative treatment systems

7
STEDS vs Gravity Sewer
8
Septic Tank Effluent Drainage System (STEDS)

• Septic Tank Effluent Pumping
• Septic Tank Effluent Gravity

9
STEDS Components

• Fibreglass Reinforced Tank
• Primary treatment in interceptor tanks
• 1000- or 1500-gallon tank per residence
• 70 removal of fats, oils, and greases
• 24-hour emergency storage
• 12-year pumpout with 95 confidence
• Abuses stay in interceptor tank
• Chemical sources easier to identify

10
Components, cont.

• Pump vault
• High-head effluent pump
• Filter cartridge
• Float assembly
• Discharge assembly

11
Collection System

• Shallow burial depth
• Laid to contour of land
• No minimum velocities
• No oversized designs
• Low operation and maintenance costs

12
Secondary Treatment

• Packed bed filter
• Engineered textile material
• Appropriate tankage and timed dosing
• Complete, premanufactured package
• Highly stable, reliable
• Operates in an unsaturated condition (not
  submerged)
• Employs intermittent dosing
• Uses filtration and biological/chemical reduction

13
Advantages

• Flexible in design
• Adaptable to varying site conditions
• Allows for phased development, modular
• Can be integrated into existing sewer
  infrastructure
• Can be integrated into existing treatment system
• Design includes storage/reserve in the event of
  power outages or need to repair mainline break
• Low-impact construction
• Minimal disruption to community

14
Advantages

• Cost-effectiveness
• Low initial costs
• No manholes
• No pumping stations
• Low operating costs
• Low maintenance costs
• Low and gradual repair/replacement costs

15
Benefits

• Allows the construction of houses in areas where
  standard sewers or septic systems cannot be used
• Has affordable installation costs and low
  maintenance costs
• Has little visual impact

16
Householders Play an Important Role
17

• Current Status
• Performance
• Costs

18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
60mm Ø main
43mm Ø service
22
Advantex Unit
23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
(No Transcript)
28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
Non typical costs

• Shipping
• Retrofit project
• Reconfiguration of existing connections
• Ground conditions
• Telemetry/data capture
• Sampling/monitoring
• Additional connections
• Additional single unit treatment system

32

• End

33
(No Transcript)
34
(No Transcript)
35
(No Transcript)
36
(No Transcript)
37
(No Transcript)
38
(No Transcript)
