Jerry Held

1
(No Transcript)
2
All About Encryption
3
Encryption Overview

• Two main types we are concerned with
• Data in motion, over the network
• Data at rest, datafiles, backups, redo, exports
• We will be concentrating on data at rest
• Question Discussion
• What is the goal behind encrypting data?
• Why do we do it?
• What doesnt it do for us? What can it NOT
  protect us from?

4
Encryption Overview

• Data in motion is easily done with SQLNet and
  ASO
• Network traffic entirely encrypted, snoop proof
• Encrypted checksum as well to prevent replay
  attacks (eg lets do that bank transfer twice)
• And to prevent modification (eg lets change the
  leading 1 to a 9 in that transaction)

5
Encryption Overview

• Data at rest options
• DBMS_OBFUSCATION_TOOLKIT
• 8i-9iR2
• Would not use this anymore
• Will not talk about it beyond this slide
• Lets have a quick talk about wrapper packages
• DBMS_CRYPTO
• 10gR1 and above
• Would not use this unless I had to (because of
  the next two bullets)
• Column Level Encryption
• 10gR2 and above (ASO)
• Tablespace Encryption
• 11gR1 and above (ASO)

6
DBMS_CRYPTO

• Encrypt/Decrypt data procedurally
• DES, 3DES
• AES
• RC4
• Hash functions
• MD5, SHA-1, MD4
• Can use secret key as well
• Random functions
• Raw keys
• Number and Integers as well

7
DBMS_CRYPTO

• The major problem KEY MANAGEMENT
• Do you store the key in the application?
• How do you secure it there?
• You need to retrieve it and transmit it
• Do you store the key in the database?
• If I steal your database, I have your keys
• You will have code that retrieves the key, I will
  find out how
• There are no good answers to this problem.

8
DBMS_CRYPTO

• API driven.
• You code it, definitely not transparent.
• Definite performance impact (compared to column
  and/or tablespace encryption)
• Supports as inputs
• RAW
• CLOB
• BLOB
• And always returns binary output
• You will use BLOB or RAW to store
• If you use varchar2, you need to round up to
  multiple of 16 and double the length and RAWTOHEX
  or base64 encode the data.
• Discuss legacy obfuscation toolkit and varchar2
  flaw

9
DBMS_CRYPTO

• Simple Examples
• Input raw after converting
• Specify typ the stream or block cipher type.
  Block cipher is what we use for storing data
  persistently
• Key the encryption key
• Use varchar2 interface and the CLOB
• Performance
• What impact will this have? (it will be different
  for everyone)
• How to measure it?

Encrypt1.sql Encrypt2.sql Encrypt3.sql
10
DBMS_CRYPTO

• In review
• Labor intensive
• Key management is hard
• Keys are likely very easy to compromise
• Definitely not transparent
• Adds a lot to the runtime

11
Column and Tablespace Encryption

• Designed to be transparent
• Uses a wallet
• Must steal database and
• Steal wallet and
• Kidnap the DBA in order to make use of the data
• As opposed to dbms-crypto, where I likely just
  need your database and some intelligence
• Or Hardware Security Modules (HSM)
• Physical device that stores keys
• Provides protected memory space to
  encrypt/decrypt so keys are never visible
• 11g

12
Column Level Encryption

• Data is cached encrypted in the SGA
• Decrypted only when you dereference it
• Encrypted every time you modify it
• Undo generated is encrypted
• Redo generated is encrypted
• You can index it, but the index is indexing
  encrypted data (not sorted!)

13
Column Level Encryption

• Example
• Setup
• Functionality
• Performance impact on modification retrieval
• Sizing (20 byte checksum, padded out and salted)
• Indexing Issues, check out cardinality

column1.sql
14
Column Level Encryption

• Restrictions
• Must not salt if you index
• Cannot be used with foreign keys
• Issues with exp/imp (clear text issues)
• In 11g, datapump can handle encryption,
  preserving the protection.

15
Tablespace Level Encryption

• Data is stored on disk encrypted
• Data is cached in the SGA unencrypted
• Undo generated is encrypted
• Redo generated is encrypted
• Data is stored on block in clear text and
  encrypted on way out to disk
• So, index has clear text in it
• Range scan solved
• Foreign key solved

16
Tablespace Level Encryption

• Example
• Setup
• Functionality
• Performance impact on modification retrieval

tablespace1.sql
17
Tablespace Level Encryption

• Restrictions
• You cannot alter an existing tablespace to be
  encrypted
• You create a new encrypted tablespace and move
  segments into it
• You can alter a column to be encrypted
• But you probably dont want too!
• Itll leave old copies of itself

18
Questions
