Title: Industrial Ethernet Basics October 2006


1
Industrial Ethernet Basics October 2006
2
Ethernet TCP/IP and ISO/OSI model
Formatting Presenting
Routing Addressing
66.249.66.138
Transmission Signaling
3
Transmission and Signaling Basics
  • Basic network arbitration is controlled by
    standard chips
  • Collision detection
  • Backoff mechanism
  • Re-transmits
  • Note this cannot be changed in software
  • Some Industrial Ethernets use special chips to
    alter this basic characteristic

4
Transmission Signaling Cable Types
  • Twisted Pair Category
  • Shielded and Unshielded variants
  • 4 and 8 conductor common
  • Also capable of transmitting power
  • Fiber Optic Category
  • Multi-mode
  • Single-Mode
  • Glass and Poly hybrid media

100? UTP (Unshielded Twisted Pair )
100? STP (shielded Twisted Pair )
62.5/125? optical fiber
NOTE Twisted pair has a recommended segment
limitation of 100 meters, Fiber is 2 Km
5
Transmission Signaling Cable Types
  • Coax cable
  • Only used in old installations
  • ControlNet hybrid systems

Coax cable
  • Key Choice Factors
  • Bandwidth
  • Distance
  • Noise Immunity
  • Cost

6
Physical Layer - Cable Types
  • Twisted Pair Category
  • Cat3 Transmission up to 16 MHz for use in
    10BaseT systems
  • Cat5 Transmission up to 100 MHz for use in
    10BaseT and 100BaseTX systems
  • Cat5e Enhanced, up to 360 MHz to better support
    100BaseTX systems

7
Physical Layer - Cable Types
  • Twisted Pair Category
  • Cat6 Specified now in some new commercial and
    industrial installs, up to 400 MHz and common
    speeds of 1000 Mbps
  • Twisted pair has a recommended segment limit of
    100 meters

8
Physical Layer - Cable Types
  • Stranded vs Solid Wire
  • Both UTP and STP come in stranded and solid wire
    varieties
  • Stranded is most common and flexible for bending
    around corners
  • Solid wire cable has less attenuation and can
    span longer distances, but is less flexible than
    stranded wire and cannot be repeatedly bent

9
Physical Layer - Wiring
  • RJ-45
  • EIA/TIA 568B specifies an 8 pin connection
  • 2 pairs for data, 2 for voice
  • 10BaseT systems use only the 2 data pairs
  • Straight-through or crossover
  • To connect devices together without going through
    a switch or router
  • Conductors 1 2 are a twisted pair
  • Conductors 3 6 are a twisted pair

10
Physical Layer - Wiring
  • M12 (D-coded connector)
  • Wiring is different
  • Typically 4 and sometimes 8-conductor versions
  • Straight-through or crossover

11
Fiber Media Basics
  • Selection of a cable depends on functions such as
  • Core material
  • Singlemode or multimode
  • Step or graded index
  • Wave length of the transmitter

12
Multimode Fiber
  • A multimode fiber has a dimension that affords
    space for several modes in a core
  • There are two multimode cable categories
  • Step index modes degrade or attenuate unevenly,
    resulting in lower bandwidth and distance
  • Graded index refractive index reduces gradually
    from the cores centre towards the
    cladding--overall effect keeps the pulse together

The most common dimension of multimode cable is a
62.5 µm core and 125 µm outer cladding (the
cable is then designated 62.5/125).
13
Singlemode Fiber
  • A singlemode fiber has such a fine core that it
    only supports one mode
  • The transmitted light pulse is not distorted when
    traveling through the cable
  • Long distance lack of attenuation gives superior
    performance
  • High cost glass only, thin core is expensive to
    buy and install

The most common singlemode cable dimension is 9
µm core and 125 µm cladding (9/125)
14
Standard Fiber Connectors
  • Common Fiber Connectors for Industrial
    Applications

15
Ethernet TCP/IP and ISO/OSI model
Formatting Presenting
Routing Addressing
66.249.66.138
Transmission Signaling
16
Ethernet Packet Basics
  • Minimum of 26 overhead bytes (30 if using VLAN)
    are required in a packet
  • Data can consume an additional 46 1500 bytes

IANA (Internet Assigned Numbers Authority) has
reserved the following three address blocks for
IP addresses in private networks 10.0.0.0 -
10.255.255.255 172.16.0.0 - 172.31.255.255 192.168
.0.0 - 192.168.255.255
17
Routing Addressing Topology
  • Bus
  • Ring
  • Point to Point
  • Mesh
  • Star

With Ethernet, each Station has a unique MAC ID
preset at the factory and an abstracted IP
address that can be altered on the device
18
Routing Addressing Transmit modes
  • Common Transmit modes

Combinations of Topology and Broadcast Modes can
cause severe network bandwidth reduction and
communications failure
19
Routing Addressing Enabling Equipment
  • Hub connects together two or more computers to
    form one Ethernet segment
  • Broadcasts packets out to all devices
  • Low intelligence and cheap
  • Also known as a repeater, concentrator, bridge

20
Routing Addressing Enabling Equipment
  • Switch capable of inspecting packets,
    determining the source and destination and
    greatly reducing traffic
  • Transmits packets only to intended devices
  • Prevents collisions from occurring
  • Can be used to diagnose network performance

21
Ethernet Switch Basics
  • Unmanaged Requires no intervention from the
    user or software configuration
  • also called Store and Forward or auto
    learning
  • low intelligence and cheap
  • Segments the network and prevents collisions
  • Managed Can be setup by the user for
    intelligent inspection of packets and diagnostics
    of through traffic
  • Can use rules to change packet pathways
  • Abstracts addresses, creates redundancy, filters
    traffic
  • Can be used to diagnose network

22
Key Managed Switch Functions
  • Simple Network Management Protocol (SNMP) a set
    of protocols for managing network performance,
    finding and solving network problems, and
    planning for network growth
  • Internet Group Management Protocol (IGMP)
    configures broadcast message behavior
  • Quality of Service (QoS) Allows prioritization
    of packets to occur to improve performance for
    key channels

23
Key Managed Switch Functions
  • Virtual LAN (VLAN) a network of computers that
    behave as if they are connected to the same wire
    even though they may actually be physically
    located on different segments of a LAN
  • Spanning Tree Protocol (STP) algorithm to
    prevent wiring topology mistakes or create
    redundancy in a network

24
Open Ethernet Redundancy IEEE 802.1
  • Rapid Spanning Tree Networks
  • Single Ring Ring Coupling

Recovery time typically less than 50 ms per hop
(link between 2 switch)
25
Routing Signaling Routers
  • Router joins multiple wired or wireless
    networks together
  • Uses "routing table," to filter traffic, either
    incoming or outgoing, based on the IP addresses
    of senders and receivers
  • Layer 3 Switch prioritize data on the MAC-level
    (layer 2) as above, or together with an IP
    header level i.e. as a router
  • Each packet is given priority based on the
    content of the field, Type of Service (ToS)

26
Gateways, Firewalls, Bridges and Repeaters
  • Repeater Forwards traffic between segments,
    often amplifying the signal in the process
  • Bridge A bridge functions at the MAC layer,
    routing traffic only based on its physical address

27
Gateways, Firewalls, Bridges and Repeaters
  • Firewall Used in security implementations,
    allowing intelligent routing of traffic across
    the bridge as programmed by authorized persons
  • Gateway allows for the translation and
    management of communication between networks that
    use different protocols or designs

28
Formatting Presenting Industrial Protocols
Formatting Presenting
Industrial Ethernet
SRTP
PCCC
Melsec A Melsec Q
Routing Addressing
FINS
Modbus Uni-TE
Transmission Signaling
Modbus TCP
29
Most Popular Industrial Ethernets(IEC/ PAS 62xxx)
  • EtherNet/IP PAS 62413, promoted by ODVA /
    Rockwell
  • Network Type Common CIP Object model transferred
    by standard UDP/IP
  • Topology All topologies are supported
  • Media Connectors RJ45/M12 Cable
    Fiber/Standard Ethernet cable
  • Specialties Common application layer with
    DeviceNet / ControlNet
  • Clock synchronization (IEC1588) for real-time
    application
  • Functional Safety specified with CIP safety
  • PROFINET PAS 62411, promoted by PNO / Siemens
  • Network Type Scalable TCP/UDP/IP based network
    for CBA and IO RT/IRT
  • Topolog All topologies are supported, 100 Mbit/s
  • Media Connectors RJ45/M12 Cable Fiber/
    Standard Ethernet cable
  • Specialties Hard Real time for IO with special
    time based communication (IRT) Redundancy based
    on Hyperring (Hirschmann/Siemens) Functional
    Safety with PROFISAFE

30
Most Popular Industrial Ethernets(IEC/ PAS 62xxx)
  • MODBUS TCP
  • PAS 62030, promoted by MODBUS-IDA / Schneider
  • Network Type Standard TCP/UDP/IP based
    Client/server protocol
  • Topology All topologies are supported Transfer
    speed up to 1 Gbit/s
  • Media Connectors RJ45/M12 Cable
    Fiber/Standard Ethernet cable
  • Specialties RTPS for real-time over UDP/IP
  • Determinism depends on network load and
    topology

31
Most Popular Industrial Ethernets (IEC/ PAS 62xxx)
  • EtherCAT PAS 62407, , promoted by Beckhoff
  • Network Type Token passing master/slave
  • Topology Trunk and Drop
  • Media Connectors RJ45/M12 Cable
    Fiber/Standard Ethernet
  • Specialties Standard master/scanner interface but
    custom slave/adapter
  • Clock synchronization for real time
    application
  • Powerlink PAS 62408, promoted by Bernecker
    Rainer
  • Network Type Scalable TCP/UDP/IP based network
    with parallel stack
  • Topology All topologies are supported 100
    Mbit/s
  • Media Connectors RJ45/M12 CableFiber/
    Standard Ethernet cable
  • Specialties Software upgrade to existing hardware
    enables real time performance with special
    time domain multiplexing

32
Most Popular Industrial Ethernets (IEC/ PAS 62xxx)
  • Foundation Fieldbus
  • PAS 62453-5, promoted by Fieldbus Foundation /
    Process
  • Network Type Standard TCP/UDP/IP based
    Client/server protocol
  • Topology All topologies are supported transfer
    speed up to 1 Gbit/s
  • Media Connectors RJ45/M12 Cable
    Fiber/Standard Ethernet cable
  • Specialties Can run over any media
  • Support for profiles, containers and remote
    initialization

33
Ethernet Real time Architectures
34
