Data and Database Administration

1
Data and Database Administration

• Chapter 13

2
Chapter Goals

• DA and DBA major functions/changing roles
• Functions and components of DBMS
• DB security and techniques to enhance
• DB recovery facilities
• Concurrency control pessimistic v. optimistic
• Data dictionaries and information repositories

3
Ineffective Administration

• Multiple definitions and inconsistent
  representation of data elements
• Missing key data elements that allow for
  integration
• Low data quality
• Inadequate familiarity with existing data,
  including what data are available, where, and
  what they mean.

4
Definitions

• Data Administration A high-level function that
  is responsible for the overall management of data
  resources in an organization, including
  maintaining corporate-wide definitions and
  standards.
• Database Administration A technical function
  that is responsible for physical database design
  and for dealing with technical issues such as
  security enforcement, database performance, and
  backup and recovery.

5
Data Administration Functions

• Data policies, procedures, standards.
• Planning understanding needs.
• Data conflict (ownership) resolution.
• Internal marketing of DA concepts.
• Managing the data repository.

6
Database Administration Functions

• Selection of hardware and software.
• Managing data security, privacy, and integrity.
• Data backup and recovery.
• Fig. 13-1 is a list of DA and DBA functions.

7
Changing Admin. Approaches

• Variation from one org. to another
• Blending of DA and DBA roles
• Quinlan
• DB Planning--Improve tech. Selection
• DB Analysis--Work on physical in parallel
• DB Design--Prioritize application transactions
• DB Implementation--modularize for rapid
  implementation
• Operation and Maintenance--review to see that
  quality has not been compromised

8
Modeling Enterprise Data

• Information Systems Architecture
• Similar to other complex product development and
  manufacturing processes.
• Zachman--ISA is that set of descriptive
  representations (models) that are relevant for
  describing an enterprise such that that
  enterprise can be produced to managements
  requirements and maintained over the period of
  its useful life.

9
Planning for Databases

• Design occurs within the constraints of the
  enterprise information system.
• What data, what processes, which locations, which
  work units and people, how will it fit with
  significant business functions?
• Must include continuing use of existing system.
• Initial assessment, operational feasibility,
  formal review.

10
Data Security

• Data Security Protection of the data against
  accidental or intentional loss, destruction, or
  misuse.

11
Possible locations of data security threats
12
Threats to Data Security

• Accidental losses attributable to
• Human error.
• Software failure.
• Hardware failure.
• Theft and fraud.
• Improper data access
• Loss of privacy (personal data).
• Loss of confidentiality (corporate data).
• Loss of data integrity.
• Loss of availability (through, e.g. sabotage).

13
Data Management Software Security Features

• Views or subschemas.
• Authorization rules.
• User-defined procedures.
• E.g. trigger an authorization procedure which
  asks additional identification questions.
• Encryption.
• Authentication schemes.
• Backup, journaling, checkpoint facilities

14
Authorization matrix
15
Backup and RecoveryBasic Recovery Facilities

• Backup Facilities
• Journalizing Facilities
• Transaction Log - time, records, input values.
• Database Change Log - before after images.
• Checkpoint Facility
• Quiet period for synchronizing files and journals
• Restart point after a failure.
• Recovery Manager

16
Database audit trail
17
Recovery and Restart Procedures

• Switch - Mirrored databases.
• Restore/Rerun - Reprocess transactions against
  the backup.
• Transaction Integrity - Commit or abort all
  transaction changes.
• Backward Recovery (Rollback) - Apply before
  images. Fig. 13-7.
• Forward Recovery (Roll Forward) - Apply after
  images (preferable to restore/rerun.)

18
Basic recovery techniques (a) Rollback
19
(b) Rollforward
20
Types of Database Failure

• Aborted transactions.
• Incorrect data.
• Backward recovery
• Compensating transactions
• Restart from checkpoint before error occurred
• System failure (database intact.)
• Database destruction

21
Concurrency Control

• Concurrency Control - The process of managing
  simultaneous operations against a database so
  that data integrity is maintained and the
  operations do not interfere with each other in a
  multi-user environment.
• Lost Update Problem - Fig. 13-8 13-9.
• Locking out other users--pessimistic
• Versioning--optimistic

22
Figure 13-8 Lost Update Problem
23
Figure 13-9 Updates with locking concurrency
control
24
Concurrency Control Techniques

• Serializability - Procedures that process
  transactions as if one transaction if finished
  before starting another. Achieved through
  different means.
• Locking Mechanisms
• Locking level (Granularity)
• Database
• Table
• Block or page
• Record
• Field

25
Concurrency Control Techniques

• Types of locks
• Shared lock - Read but not update permitted.
  Used when just reading to prevent another user
  from placing an exclusive lock on the record.
• Exclusive lock - No access permitted. Used when
  preparing to update.

26
Deadlock

• Deadlock - Transactions wait for each other to
  release needed resources. Fig. 13-10, 11.
• Deadlock prevention
• Lock all records required at the beginning of a
  transaction
• Two-phase locking protocol
• Growing phase.
• Shrinking phase.
• May be difficult to determine all needed
  resources in advance.

27
Figure 13-10 Problem of Deadlock
28
Figure 13-11 Another example of deadlock
29
Deadlock

• Deadlock Resolution
• Allow deadlocks to occur.
• Mechanisms for detecting and breaking them.
• Resource usage matrix.

30
Concurrency Control Techniques

• Versioning
• Optimistic approach to concurrency control.
• Assumption is that simultaneous updates will be
  infrequent.
• Each transaction can attempt an update as it
  wishes.
• The system will reject an update when it senses a
  conflict.

31
Figure 13-12 The use of versioning
32
Managing Data Quality

• Data Steward - Liaisons between IT and business
  units.
• Five Data Quality Issues
• Security policy and disaster recovery.
• Personnel controls.
• Physical access controls.
• Maintenance controls (hardware software.)
• Data protection and privacy.

33
Data Dictionaries and Repositories

• Passive data dictionary.
• Active data dictionary.
• System catalog.
• Repository (CASE tools).
• Information Repository Dictionary System (IRDS) -
  standards for dictionary storage and access.

34
More on the Repository

• Information repository
• Stores metadata that describe an organizations
  data and data processing resources. Manages the
  total information processing environment.
• Information Repository Dictionary System
• A computer software tool that is used to manage
  and control access to the information repository.

35
Repository System Components

• Information Model--Schema for information stored
  in system
• Repository Engine--Manages objects
• Object management
• Dynamic extensibility
• Relationship management
• Version management
• Configuration management
• Repository Database--Stores objects

36
Figure 13-13 Three components of repository
system architecture
