Care of the Patient with a Pacemaker

1
Care of the Patient with a Pacemaker

• Becca Maddox
• NURS 2205
• Spring 2002

2
Pacemakers

• Provides repetitive electrical stimuli to the
  heart muscle in order to control the heart rate
• Can be temporary or permanent
• Consist of a pulse generator and electrodes
  (leads)

3
Temporary Pacemakers

• Types
• Transcutaneous external pacemaker
• Epicardial pacemaker
• Transthoracic thoracic pacemaker
• Transvenous endocardial pacemaker

4
Temporary Pacemakers

• Indications
• Conduction disorders
• Rate disorders
• Prophylaxis

5
Temporary Pacemakers

• Components
• Pulse generator
• Leads
• External
• Epicardial
• Transthoracic
• Transvenous

6
Temporary Pacemakers

• Pacing systems
• Unipolar
• Bipolar
• Pacing cables
• Black Negative, pacing terminal
• Red Positive, ground terminal

7
Temporary Pacemakers

• Insertion
• External - applied emergently at the bedside
• Epicardial - leads are placed by the cardiac
  surgeon in the operating room
• Transthoracic - Usually attempted emergently, as
  a last resort, after other temporary pacing
  methods have failed. Physician inserts a
  pericardial needle through the subxyphoid area of
  the thorax into the right ventricle and advances
  the lead wire through the needle in order to
  achieve contact with the endocardium
• Transvenous - May be inserted at the bedside,
  preferably under fluroscopy. Usually inserted
  into the subclavian or jugular vein, but can be
  inserted into the antecubital or femoral vein

8
Temporary Pacemakers

• Settings
• Rate
• Fixed (Asynchronous)
• Stimulus is provided at a preset rate
• Rate is set greater than the patients inherent
  rate to avoid competition
• Demand (Synchronous)
• Stimulus is provided when the patients heart
  rate drops below at predetermined rate
• Must have adequate sensing

9
Temporary Pacemakers

• Sensitivity Threshold
• Sensitivity
• Set in millivolts (mV)
• Allows pacemaker to detect the patients inherent
  R wave
• Sense Indicator
• Flashes when inherent R wave is detected
• Senses if pacing is in the demand mode
• Threshold
• The minimum R wave amplitude needed to be
  detected by the pulse generator
• Once the sensitivity threshold is determined, the
  sensitivity is set 2-3 times lower

10
Temporary Pacemakers

• Stimulation Threshold
• Output/mA
• Stimulus current is measured in milliamperes (mA)
• Adjusted based on the amount of current needed to
  elicit myocardial depolarization and contraction
• variables - position of electrode contact with
  viable myocardial tissue level of energy
  delivered through wire presence of hypoxia,
  acidosis or electrolyte imbalances and other
  medications being used
• Pace indicator
• Flashes each time a pacing stimulus is generated
• Does not necessarily indicate that a cardiac
  contraction occurred
• Pacing Threshold
• The minimum amount of mAs needed to achieve 100
  capture
• The output is then doubled

11
Temporary Pacemakers

• Pacing Modes
• Atrial asynchronous pacing - atrial fixed pacing
• Impulse initiated via the atria
• Pathway similar to normal conduction
• Can be initiated via epicardial atrial leads
• Can result in competition
• Used for asystole or symptomatic sinus
  bradycardia
• Contraindicated for atrial fibrillation or
  flutter and for person with conduction delays

12
Temporary Pacemakers

• Ventricular synchronous pacing - ventricular
  demand pacing
• Impulse is sent to the ventricle when the
  patients inherent rate drops below the preset
  rate on the pulse generator
• No harmony between atria and the ventricle
• Used as a back up system for sinus bradycardia,
  heart blocks, atrial fibrillation/atrial flutter
  with SVR, junctional rhythm

13
Temporary Pacemakers

• AV sequential asynchronous pacing - dual
  chambered fixed rate pacing
• Impulses sent to atria and ventricle at a
  predetermined rate and at a predetermined AV
  interval regardless of patients own rhythm
• Normal conduction through the heart
• Used for asystole, symptomatic sinus bradycardia,
  and for varying degrees of heart block to
  maintain AV conduction
• AV sequential synchronous pacing - dual chambered
  demand pacing
• Impulses sent to atria and ventricles when the
  patients rated drops below the preset rate on
  the pulse generator
• Normal conduction through the heart
• Used for asytole, symptomatic sinus bradycardia
  and heart block

14
Temporary Pacemakers

• Special Considerations
• External Transcutaneous Pacing
• Cleanse skin with soap and water prior to
  applying patches
• Avoid using flammable skin preps such as alcohol
  or tincture of benzoin
• If hairy chest, clip hair instead of shave to
  avoid nicks
• Select a lead that maximized the R-wave amplitude
• Set pacemaker settings as prescribed or follow
  PP for the institution
• May need analgesics or sedatives to minimize pain

15
Temporary Pacemakers

• Epicardial pacing
• Connect the negative pacing terminal to the
  epicardial lead electrode that is attached to the
  heart chamber to be paced
• Connect the positive ground terminal to another
  epicardial lead electrode, subcutaneous pacing
  wire, subcutaneous needle or skin patch electrode
• Determine sensitivity threshold and pacing
  threshold
• Set pacemaker settings
• Initiate pacing
• Be sure to follow hospital PP for initiating and
  adjusting pacemaker settings

16
Temporary Pacemakers

• Transthoracic pacing - usually a last resort
• After emergency insertion is completed, assist
  with additional attempts to insert another type
  of temporary pacing or prepare family for
  insertion of a permanent pacemaker
• Transvenous pacing
• Obtaining pulmonary artery wedge pressures may be
  contraindicated if being paced via a pulmonary
  artery catheter
• If initiated through antecubital or femoral vein,
  limit mobility of the extremity
• Determine sensitivity and pacing thresholds
• Set pacemaker settings
• Initiate pacing
• Follow hospital PP for initiating and adjusting
  pacemaker settings

17
Temporary Pacemakers

• Troubleshooting
• Failure to fire - cant see pacemaker spikes
  during periods of asystole or bradycardia
• Loose connections in the pacing system
• Failure of pacemaker battery or pulse generator
• Fracture of the pacing lead wire
• Lead wire dislodgement
• Failure to capture - pacemaker spike is not
  followed by a P wave or QRS as appropriate
• Loose connections in the pacing system
• Increased pacing threshold
• Fracture of the pacing lead wire
• Lead wire dislodgement
• Failure of pacemaker battery or pulse generator

18
Temporary Pacemakers

• Undersensing - pacemaker fires with no regard to
  the patients own rhythm. Dangerous because it
  may lead to ventricular tachycardia and/or
  ventricular fibrillation
• Inadequate QRS signal
• Myocardial ischemia, fibrosis, electrolyte
  imbalances, bundle branch block, or a poorly
  positioned lead
• Oversensing - pacemaker thinks it detects a QRS
  complex, inhibits itself and doesnt fire
• Tall or peaked P waves or T waves
• Myopotentials (electrical signals produced by
  skeletal muscle contraction as with shivering or
  seizures)

19
Temporary Pacemakers

• Patient Management
• ECG monitoring
• Hemodynamic monitoring
• Assess pacemaker function
• Electrical safety
• Reassess functioning after defibrillation
• Pacing insertion site care
• Assure pacemaker controls are protected from
  accidental adjustment
• Provide information regarding pacemaker therapy
  to the patient and family

20
Permanent Pacemakers

• Lead Placement
• Epicardial
• Usually placed during heart surgery
• Leads placed in contact with epicardium
• Pulse generator in a subcutaneous pocket in
  abdomen
• Endocardial (Transvenous)
• Most common
• Pacing catheter inserted percutaneously via
  subclavian vein and advanced to the right atrium
  or apex of right ventricle
• Leads placed in contact with endocardium
• Pulse generator in subcutaneous pocket in the
  subclavian area

21
Permanent Pacemakers

• Indications
• Symptomatic bradycardia
• Acquired atrioventricular block (including A-V
  block from an MI)
• Chronic bifasicular or trifasicular block
• Sinus node dysfunction, including sick sinus
  syndrome
• Hypersensitive carotid sinus disease
• Conduction system trauma (accident or cardiac
  surgery)
• Congenital anomalies
• Non reversible drug toxicities

22
Permanent Pacemakers

• Components
• Pulse generator - consists of lithium batteries
  and electrical micro circuitry encased in
  titanium. Lithium batteries last about 5-10years,
  depending on how much the pacemaker is used
• Lead wire - a catheter with electrodes at the
  tip. Ventricular wires are easier to secure than
  atrial wires
• Electrode(s) - remember the negative electrode is
  the one that paces
• Unipolar electrode - negative electrode at the
  tip of the wire is in contact with the heart, the
  metal casing around the pulse generator acts as
  the positive pole, creates a large spike on ECG
  paper
• Bipolar electrode - negative electrode is at the
  tip and positive electrode is a few millimeters
  above it, creates a small spike on ECG paper

23
Permanent Pacemakers

• Identification Code - 5 letters
• 1st - Chamber(s) paced
• 2nd - Chamber(s) sensed
• 3rd - Response to sensing
• 4th - Rate Modulation Programmability
• 5th - Antitachycardia Pacing Function

24
Permanent Pacemakers

• Types
• Demand or synchronous - has a sensing circuit
  that monitors cardiac activity
• All permanent pacers with a lead wire in the
  ventricle are this type to avoid pacing during
  ventricular repolarization
• Fixed rate or asynchronous - does not have a
  sensing circuit

25
Permanent Pacemakers

• Terminology
• Heart rate - often expressed in milliseconds (ms)
  rather than beats per minute
• Pacemaker timing
• Escape interval - interval from last intrinsic
  beat to next paced beat
• Pacing interval - interval from last paced beat
  to next paced beat
• AV interval - corresponds to PR interval,
  programmed in milliseconds, usually set within
  the normal PR interval range (125 ms, 150 ms, 175
  ms, or 200 ms)

26
Permanent Pacemakers

• Examples
• Single Chamber VVI Pacemakers
• Advantages - simple one lead system where the
  lead wire is placed in the right ventricle
• Limitations - loss of AV synchrony, lack of rate
  variability
• usually placed in patients who have chronic
  atrial fibrillation with SVR
• VVIR pacers were developed to achieve rate
  variability - there is a sensor in the pulse
  generator that senses skeletal muscle activity

27
Permanent Pacemakers

• Dual Chamber DDD Pacemakers
• Advantages - two lead system with one lead wire
  in the atrium and one lead in the ventricle,
  capable of pacing the atria and ventricles,
  preserves AV synchrony,
• Limitations -
• Patients with atrial fibrillation or atrial
  flutter - it cant capture the atrium. Pacer is
  confused by the atrial activity. This will not
  cause harm to the patient, but will deplete the
  batteries faster. Should be reprogrammed.
• Lack of rate variability - DDDR pacers were
  developed to achieve rate variability. As the
  sensor picks up skeletal muscle activity, the
  DDDR pacer will increase the atrial pacing rate.

28
Permanent Pacemakers

• Programmable Features
• Lower rate limit (LRL) - Atrial pacing will only
  occur at the LRL. Ventricular pacing can occur
  anywhere between the lower rate limit and the
  upper rate limit
• AV interval
• Upper rate limit (UPR) - the fastest rate at
  which the ventricles can be paced in response to
  atrial activity
• VA interval - the length of time from an
  intrinsic or paced ventricular event to the next
  atrial event. This is not directly programmable
  but changes as other programmable parameters are
  changed. (LRL - AV interval)

29
Permanent Pacemakers

• Modes of Operation
• Patient in sinus rhythm - atrial and ventricular
  pacers are inhibited
• Patient in atrial pacing only - atrial pacing
  occurs because patient cant initiate a sinus
  rate faster than the LRL of the pacer.
  Ventricular pacing is inhibited patient is able
  to conduct the impulse to the ventricles before
  the AV timer expires
• Patient in ventricular pacing only - atrial pacer
  is inhibited because of patients ability to
  initiate a sinus impulse faster than the LRL.
  Ventricular pacer is triggered because patient is
  not able to get the impulse to the ventricles
  before the AV timer expires
• Patient in AV pacing - atrial pacing occurs
  because of the patients inability to initiate a
  sinus impulse faster than the LRL and the
  ventricular pacer fires because the AV timer
  expires before impulse can travel to the
  ventricles

30
Permanent Pacemakers

• Troubleshooting
• Failure to capture
• Reasons
• Lead dislodgement
• Lead fracture
• Loose connections between pulse generator and
  lead wire
• Fibrosis at the tip of the lead causing changes
  in the pacing threshold
• Treatment
• Obtain a chest x-ray to determine lead position
• Reposition or replace lead if dislodged or
  fractured
• Reprogram pacer if fibrosis is cause of failure
  to capture
• SQ pocket may need to be reopened to check
  connections
• Have atropine and external pacemaker at bedside
  in case patient develops a symptomatic bradycardia

31
Permanent Pacemakers

• Failure to sense
• Reasons
• Electromagnetic interference
• Lead fracture
• Loose connections between the pulse generator and
  the lead wire
• Battery failure
• Treatment
• Move away from magnetic field
• Obtain a chest x-ray to determine lead position
• Reposition or replace lead if dislodged or
  fractured
• SQ pocket may need to be reopened to check
  connections
• Replace generator if needed
• If undersensing or oversensing and generator is
  programmable, need to reprogram

32
Permanent Pacemakers

• Failure to fire
• Reasons
• Electromagnetic interference
• Lead fracture
• Loose connections between the pulse generator and
  the lead wire
• Circuitry or battery failure
• Treatment
• Move away from magnetic field
• Obtain a chest x-ray to determine lead position
• Reposition or replace lead if dislodged or
  fractured
• SQ pocket may need to be reopened to check
  connections
• Replace generator if needed
• Have atropine and external pacemaker at bedside
  in case patient develops a symptomatic
  bradycardia

33
Permanent Pacemakers

• Patient Management
• Pre-op
• Avoid placing ECG monitoring electrodes over the
  right or left subclavian areas
• Patient and family teaching
• NPO after midnight
• Where procedure will be done and about how long
  it will take
• Pre-op medications - sedative and antibiotic
• Local anesthesia rather than general

34
Permanent Pacemakers

• Immediate Post-op
• Patient and family teaching
• Frequent vital signs
• Bedrest up to 24 hours (depending on hospital)
• Limited range of motion in the affected arm
  Administration of antibiotics
• Pain at incision site
• Encourage coughing and deep breathing

35
Permanent Pacemakers

• Post-op Nursing Management
• Document type of pacer and settings
• Run an initial strip and then one at least every
  4 hours - more often if pacing in noted on
  monitor
• Obtain a 12 lead ECG upon return
• Observe for appropriate pacemaker functioning
• Observe pressure dressing for signs of infection
• Administer antibiotics as prescribed
• Offer pain medicine at regular intervals

36
Permanent Pacemakers

• Discharge Teaching
• Watch insertion site for signs of infection
• If sutures, they will be removed in one week. If
  steristrips, they will gradually fall off
• Return to activities gradually
• How to take a pulse
• Transtelephonic monitoring of pacemaker function
• Importance of follow-up visit
• Life of batteries
• New medications

37
Permanent Pacemakers

• Pacemaker wallet identification card
• Medic alert bracelet application
• Avoid electromagnetic interference
• all household appliances, including microwave
  ovens, are OK to use
• avoid welding equipment power transmitters
  large generators radio, television, and radar
  towers - antennas at home are safe, but not CB
  and ham operator antennas
• avoid leaning directly over any running engines
  or motors - can create magnetic fields
• Bingo wands used in bingo halls and stereo
  speakers contain magnets. These devices should
  not come in contact with the pacemaker generator
  in the shoulder for any period or time

38
Permanent Pacemakers

• avoid electrocautery and diathermy
• no MRI scan performed for other medical
  conditions
• inform other physician that they have a
  pacemaker, particularly dentists
• have wallet card available at airport metal
  detectors. Need to inform them to be careful of
  hand-held wands as they may have magnets in them
  and should therefore not be held over the
  pacemaker generator for a long period of time

39
Permanent Pacemakers

• Rhythm Strip Interpretation
• If possible, find out what kind of pacemaker the
  patient has
• Look for presence of an underlying rhythm
• Look closely for the presence of a pacer spike
• Look for the presence of P waves (intrinsic or
  paced) and their rate and relationship to the QRS
  complexes
• Examine QRS complexes to determine if they are
  paced or intrinsic
• If ventricular pacing, note whether each beat is
  preceded by a P wave (paced or intrinsic) and
  whether the AV(PR) interval is constant before
  the ventricular paced beats
• Observe for fusion beats
