ECE 552 Project Proposal Image Toolbox Implementation

1
ECE 552 Project ProposalImage Toolbox
Implementation

• Team BLUE
• Dilip Patlolla
• Praneeth Parla
• Abhimanyu Sulakhe
• Prachya Mruetusatorn

2
Proposal

• Implement various Image Processing methods in
  FPGA hardware
• Application
• Simulate the techniques using MATLAB/C compiler
  on the image.

3
Enhancement Techniques

• Contrast Enhancement Method
• Deblurring using Weiner Filter
• Smoothing of an Image.
• Negative to Positive Conversion

4
Contrast Enhancement Method

• An Image is taken and its contrast is
  increased or decreased as per the enhancement
  requirements of the Image.
• The required contrast enhancement is achieved
  applying the Power Law Transform on the Image.

Original Image
Contrast Enhancement
5
Deblurring using Weiner Filter
Original Image
Deblurred Image
6
Smoothing

• A noisy Image is taken and the noise removal
  is done by applying a smoothing technique.
• The noise removal is achieved by using a mask
  which enables neighborhood pixel processing.

Original Image Smoothened
7
Negative Image to Positive Image
An Original Image is developed from a negated
Negative Image
Positive Image
8
Project Flow
9
Implementation

• The main design will be implemented on Amirix
  board with VirtexIIPro FPGA
• ModelSim will be used to simulate and capture
  waveforms
• Implement the design following the Design for
  Test strategies
• Project will be designed such that it can be a
  reusable IP block

10
Thank you
