Hashing

1
Hashing

• 8 April 2003

2
Example

• Consider a situation where we want to make a list
  of records for students currently doing the BSU
  CS degree, with each student uniquely identified
  by a student number.
• The student numbers currently range from about
  1,000,000 to above 9,999,999 therefore an array
  of 10 million elements would be enough to hold
  all possible student numbers. Given each student
  record is at least 100 bytes long we would
  require an array size of 1,000 Megabytes to do
  this.

3
Example - 2

• There are fewer than 400 students enrolled in CS
  at present
• There must be a better way
• We could have a sorted array of 400 elements and
  retrieve students using a binary search.
• We want our access to be as fast as possible. In
  this situation we would use a hash table.

4
Example - 3

• Find some way to transform a student number from
  the several million values to a range closer to
  400 but avoiding (as much as possible) the case
  where two numbers transform (or hash) to the same
  value.
• We place the records according to their
  transformed key into a new array (or hash table)
  containing at least 400 elements.

5
Example - 4

• Make the size of the hash table 479 elements
  long.
• A popular method for transforming keys is to use
  the mod operator (take the remainder upon integer
  division of the original key by the size of the
  hash table)

6
Example - 5

• For example, consider student number 949,786,456

• 949786456 479 348
• Therefore we should place this student in array
  element 348 in the hash table (note the mod
  operator is effective because it can only have
  values in the range 0 - 478).

7
Direct Access Table

• If we have a collection of n elements whose keys
  are unique integers in (1,m), where m gt n,then
  we can store the items in a direct address table,
  Tm, where Ti is either empty or contains one of
  the n elements. Searching a direct address table
  is an O(1) operation
• for a key, k, we access Tk,
• if it contains an element, return it,
• if it doesn't then return NULL.
• There are two constraints
• the keys must be unique, and
• the range of the keys must be severely bounded.

8
Direct Access Table
9
Using Linked Lists

• If the keys are not unique, then we can construct
  a set of m lists and store the heads of these
  lists in the direct address table.
• The time to find an element will still be O(1).
• If the maximum number of duplicates is ndupmax,
  then searching for a specific element is
  O(ndupmax).

10
Using Linked Lists

• If duplicates are the exception rather than the
  rule, then ndupmax is much smaller than n and a
  direct address table will provide good
  performance.
• But if ndupmax approaches n, then the time to
  find a specific element approaches O(n) and some
  other structure such as a tree will be more
  efficient.

11
Using Linked Lists
12
Analysis

• The range of the keys determines the size of the
  direct address table and may be too large to be
  practical.
• For instance its not likely that youll be able
  to use a direct address table to store elements
  which have arbitrary 32-bit integers as their
  keys for a few years yet!
• Direct addressing is easily generalized to the
  case where there is a function, h(k) gt (1,m)
  which maps each value of the key, k, to the range
  (1,m). In this case, we place the element in
  Th(k) rather than Tk and we can search in
  O(1) time as before.

13
Mapping Fuctions

• The direct address approach requires that the
  function, h(k), is a one-to-one mapping from each
  k to integers in (1,m). Such a function is known
  as a perfect hashing function it maps each key
  to a distinct integer within some manageable
  range and lets us build an O(1) search time
  table.
• Finding a perfect hashing function is not always
  possible.
• Sometimes we can find a hash function which maps
  most of the keys onto unique integers, but maps a
  small number of keys onto the same integer.
• If the number of collisions is sufficiently
  small, then hash tables work well and give O(1)
  search times.

14
Handling Collisions

• In cases where multiple keys map to the same
  integer, then elements with different keys may be
  stored in the same slot of the hash table.
• There may be more than one element which should
  be stored in a single slot of the table.
• Techniques used to manage this problem are
• chaining
• overflow areas
• re-hashing
• using neighboring slots (linear probing)
• quadratic probing
• random probing

15
Chaining

• One simple scheme is to chain all collisions in
  lists attached to the appropriate slot.
• Allows an unlimited number of collisions to be
  handled and doesn't require a priori knowledge
• The tradeoff is the same as with linked lists
  versus array implementations of sets linked
  lists incur overhead in space and, to a lesser
  extent, in time.

16
Chaining
17
How Chaining Works

• To insert a new item in the table, we hash the
  key to determine
• which list the item goes on
• insert the item at the beginning of the list (For
  example, to insert 11, we divide 11 by 8 giving a
  remainder of 3. Thus, 11 goes on the list
  starting at HashTable3)
• To find an item, we hash the number and then
  follow links in the chain down the list to see if
  it is present.

18
How Chaining Works-2

• To delete a number, we find the number and remove
  the node from the appropriate linked list.
• Entries in the hash table are dynamically
  allocated and entered on a linked list associated
  with each hash table entry.
• Alternative methods, where all entries are stored
  in the hash table itself, are known as direct or
  open addressing.

19
Re-hashing

• Re-hashing schemes use a second hashing operation
  when there is a collision. If there is a further
  collision, we re-hash until an empty slot in
  the table is found.
• The re-hashing function can either be a new
  function or a re-application of the original one.
  As long as the functions are applied to a key in
  the same order, then a sought key can always be
  found.

20
Re-Hashing
21
Linear probing

• One of the simplest re-hashing functions is 1
  (or -1), i.e., on a collision, look in the
  neighboring slot in the table.
• It calculates the new address extremely quickly.

22
Open Addressing

• 1. Linear Probing
• In linear probing, when a collision occurs, the
  new element is put in the next available spot
  (essentially doing a sequential search).
• Example
• Insert 49 18 89 48
• Hash table size 10, so 49 10 9,
• 18 10 8,
• 89 10 9,
• 48 10 8

23
Open Addressing
24
Problems

• In linear probing records tend to cluster around
  each other. (once an element is placed in the
  hash table the chances of its adjacent element
  being filled are doubledeither filled by a
  collision or directly).
• If two adjacent elements are filled then the
  chances of the next element being filled is three
  times that for an element with no neighbor.

25
Animation from the Web

• The animation gives you a practical demonstration
  of the effect of linear probing it also
  implements a quadratic re-hash function so that
  you can see differences.
• http//ciips.ee.uwa.edu.au/morris/Year2/PLDS210/h
  ash_tables.html

26
Clustering

• Linear probing is subject to a clustering
  phenomenon.
• Re-hashes from one location occupy a block of
  slots in the table which grows towards slots
  and blocks to which other keys hash.
• This exacerbates the collision problem and the
  number of re-hashes can become large.

27
Quadratic Probing

• Better behavior is usually obtained with
  quadratic probing, where the secondary hash
  function depends on the re-hash index
• address h(key) c i2
• On the ith re-hash. (A more complex function of i
  can be used.)
• Quadratic probing is susceptible to secondary
  clustering since keys which have the same hash
  value also have the same probe sequence
• Secondary clustering is not nearly as severe as
  clustering caused by linear probing.

28
Overflow area

• When a collision occurs, a slot in an overflow
  area is used for the new element and a link from
  the primary slot established as in a chained
  system.
• This is essentially the same as chaining, except
  that the overflow area is pre-allocated and thus
  may be faster to access.
• As with re-hashing, the maximum number of
  elements must be known in advance, but in this
  case, two parameters must be estimated the
  optimum size of the primary and overflow areas.

29
Overflow Area
30
Comparison
31
Hash Functions

• If the hash function is uniform (equally
  distributes the data keys among the hash table
  indices), then hashing effectively subdivides the
  list to be searched.
• Worst-case behavior occurs when all keys hash to
  the same index. Why?
• It is important to choose a good hash function.

32
Choosing Hash Functions

• Choice of h hx
• must be simple
• must distribute (spread) the data evenly
• Choice of m m approximates n (about 1
  item/linked list) where n input size

33
Mod Function

• Choice of a three digit hash for phone numbers
  e.g. 398-3738
• x is an integer value.hx x mod m.
• Choosing last three digit(738) is more
  appropriate than the first three digits (398) as
  it distributes the data more evenly.
• To do this take mod function
• x mod m
• hx x mod 10k gives last k digitshx x
  mod 2k gives last k bits

34
Middle Digits of an Integer

• This often yields unpredictable (and thus good)
  distributions of the data.
• Assume that you wish to take the two digits three
  positions from the right of x.
• If x 539872178then hx 72
• This is obtained byhx (x/1000) mod 100Where
  (x/1000) drops three digits and (x/1000) mod 100
  keeps two digits.

35
Order Preserving Hash Function

• x lt y implies hxlt hy
• Application Sorting

36
Perfect Hashing Function

• A perfect hashing function is one that causes no
  collisions.
• Perfect hashing functions can be found only under
  certain conditions.
• One application of the perfect hash function is a
  static dictionary.
• hx is designed after having peeked at the data.

37
Retrieval

• To retrieve a record is the same as insertion.
• Take the key value, perform the same
  transformation as for insertion then look up the
  value in the hash table.

38
Issues

• There are two basic issues when designing a hash
  algorithm
• Choosing the best hash function
• Deciding what to do with collisions

39
Hash Function Strategies

• If the key is an integer and there is no reason
  to expect a non-random key distribution then the
  modulus operator is a simple (and efficient) and
  effective method.
• If the key is a string value (e.g. someones name
  or C reserved words) then it first needs to be
  transformed to an integer.
