Being Bayesian about Network Structure

1
Being Bayesian about Network Structure

• Nir Friedman Daphne Koller
• Hebrew Univ. Stanford Univ.

2
Structure Discovery

• Current practice model selection
• Pick a single model (of high score)
• Use that model to represent domain structure
• Enough data ? right model overwhelmingly likely
• But what about the rest of the time?
• Many high-scoring models
• Answer based on one model often useless
• Bayesian model averaging is Bayesian ideal

Feature of G, e.g., X?Y
3
Model Averaging

• Unfortunately, it is intractable
• of possible structures is superexponential
• Thats why no one really does it
• Our contribution
• Closed form solution for fixed ordering over
  nodes
• MCMC over orderings for general case
• Faster convergence, robust results.

Exceptions Madigan Raftery, Madigan York
see below
4
Fixed Ordering

• Suppose that
• We know the ordering of variables
• say, X1 gt X2 gt X3 gt X4 gt gt Xn
• parents for Xi must be in X1,,Xi-1
• Limit number of parents per nodes to k
• Intuition
• Order decouples choice of parents
• The choice of parents for X7 do not restrict the
  choice of parents for X12
• We can exploit this to simplify the form of P(D)

2knlog n networks
5
Ordering Computing P(D)

• Set of possible parent sets for Xi
• consistent with ?
• has size at most k

Independence of families
Small number of potential families per node
Efficient closed-form summation over exponential
number of structures
6
MCMC over Models

• Cannot enumerate structures, so sample structures
• MCMC Sampling
• Define Markov chain over BN models
• Run chain to get samples from posterior P(G D)
• Possible pitfalls
• huge number of models
• mixing rate (also required burn-in) unknown
• islands of high posterior, connected by low
  bridges

7
ICU Alarm BN No Mixing

• However, with 500 instances
• the runs clearly do not mix.

Score of cuurent sample
MCMC Iteration
8
Effects of Non-Mixing

• Two MCMC runs over same 500 instances
• Probability estimates for Markov features
• based on 50 nets sampled from MCMC process
• Probability estimates highly variable, nonrobust

Initialization
true BN vs random
true BN vs true BN
9
Our Approach Sample Orderings

• We can write
• Comment Structure prior P(G) changes
• uniform prior over structures ? uniform prior
  over orderings and on structures consistent with
  a given ordering
• Sample orderings and approximate

10
MCMC Over Orderings

• Use Metropolis-Hasting algorithm
• Specify a proposal distribution q(? ?)
• flip (i1 ij ik in) ? (i1 ik ij in)
• cut (i1 ij ij1 in) ? (ij1 in i1 ij)
• Each iteration
• Sample ? from q(? ?)
• go ? ?? with probability
• Since priors are uniform
• Efficient computation!!!


11
Why Ordering Helps

• Smaller space
• Significant reduction in size of sample space
• Better structured space
• We can get from one ordering to another in
  (relatively) small number of steps
• Smoother posterior landscape
• Score of an ordering is sum over many networks
• No ordering is horrendous ? no islands of
  high posterior separated by a deep blue sea

12
Mixing with MCMC-Orderings

• 4 runs on ICU-Alarm with 500 instances
• fewer iterations than MCMC-Nets
• approximately same amount of computation
• Process is clearly mixing!

Score of cuurent sample
MCMC Iteration
13
Mixing of MCMC runs

• Two MCMC runs over same 500 instances
• Probability estimates for Markov features
• based on 50 nets sampled from MCMC process
• Probability estimates very robust

1000 instances
100 instances
14
Computing Feature Posterior P(f?,D)

• Edges
• Markov Blanket
• IfY?Z or both Y and Z are parents of some X
• Posterior of these features are independent
• Other features (e.g., existence of causal path)
• Sample networks from ordering
• Estimate features from networks

15
Feature Reconstruction (ICU-Alarm) Markov Features
Reconstruct true features of generating network
False Negatives
False Positives
16
Feature Reconstruction (ICU-Alarm) Path Features
200
150
100
50
0
200
150
100
50
0
200
150
100
50
0
17
Conclusion

• Full Bayesian model averaging is tractable for
  known ordering.
• MCMC over orderings allows robust approximation
  to full Bayesian averaging over Bayes nets
• rapid and reliable mixing
• robust reliable estimates for probability of
  structural features
• Crucial for structure discovery in domains with
  limited data
• Biological discovery
