Designing User Interfaces Spring 1999

1
SE 746-NT Embedded Software Systems
Development Robert Oshana Lecture
27 For more information, please
contact NTU Tape Orders NTU Media
Services [phone]
oshana_at_airmail.net
tapeorders_at_ntu.edu
2
Developing efficient code
3
In line functions

• C keyword inline can be added to any function
  declaration
• Call to compiler to replace calls to indicated
  function with copies of the code that is inside
• Eliminates runtime overhead associated with the
  actual function call

4
Table lookups

• switch statement should be used with care
• Each test and jump requires overhead to prosecute

• To improve, put individual cases in order by
  their relative frequency of occurrence
• Most likely case first

5
Hand coded assembly

• Some modules best written in assembly
• Programmer can make very efficient
• Lack of portability, maintainability, etc
• Some projects have restrictions on overall
  percentage of use

6
Register variables

• Keyword register can be used to declare local
  variables
• Asks compiler to place the variable in a general
  purpose register instead of the stack
• Used for frequently used variables to enhance
  performance

7
Global variables

• More efficient to use a global variable than to
  pass a parameter to a function
• Eliminates the need to push the parameter onto
  the stack before function call and pop and back
  off
• Can have negative side affects wrt modularity and
  reentrancy

8
Polling

• IRSs used to improve program efficiency
• Some rare cases in which the overhead associated
  with the interrupts causes inefficiencies
• Might be better to use polling

9
Fixed point arithmetic

• Will pay large penalty for manipulating float
  data in the program
• Floating point library is a set of subroutines
  that emulate a floating point processor
• Can take a long time to execute

10
Decreasing code size
11
Avoid standard library routines

• Avoid using standard library routines
• These try to handle all possible cases
• Can implement a subset of this functionality with
  less code

12
Native word size

• Every processor has a native word size
• int must always map to that size (ANSI)
• Manipulation of smaller or larger data types
  sometimes requires use of additional machine
  language instructions

13
Goto statements

• Not a good software engineering technique
• Can be used to remove complicated control
  structures or to share a block of oft repeated
  code

14
C

• Not everything is expensive
• public and private are to determine which
  methods to call (made at compile time so no
  penalty at runtime)
• Default parameters penalty free
• Constructors and destructors have a slight
  penalty (good price to pay for fewer bugs)

15
C

• Constructors eliminate an entire class of C
  programming errors wrt uninitialized data
  structures

16
Other topics in optimization
17
The Problem

• Program is written completely in C

• You run it through the compiler

• Dont get the efficiency you need

How do you get this code to run faster without
rewriting the routines in assembly?
18
Our Goals Today

• Learn how to use tools to get more efficiency
• Learn guidelines to make code more optimal

• Learn how to get efficiency of assembly code
  without writing it yourself

So why do we have problems with C anyway?
19
The Trouble With C

• C code must be translated to the native
  instruction set of DSP

• DSPs resources are limited (i.e. registers), so
  compiler needs to figure out what goes where

• Compiler doesnt know exactly what you want to
  do, so it must interpret your code

What do I do to optimize my C code?
20
Flow for Optimization
More C Optimization?
Yes
No
No
To Assembly Optimizations
21
Flow for Optimization (contd)
22
Steps to Optimizing Code

• Run code through C Optimizer, using best
  combination of options
• Check your Coding Practices using Guidelines

• Examine code for places where you can use DSP
  instructions directly
• For common DSP routines, replace C functions with
  calls to DSP SW libraries

23
Using the Optimizer

• The optimizer is a powerful tool for creating
  efficient C code

• It must go through very complicated processes to
  figure out what your code is doing

• By providing extra information to the optimizer,
  we can help to get the best performance possible
  in our code

24
What Does the Optimizer Do?

• Cost-based register allocation
• Alias disambiguation
• Branch optimizations and control-flow
  simplification
• Data flow optimizations
• Copy propagation
• Common subexpression elimination
• Redundant assignment elimination
• Expression simplification

25
What Does the Optimizer Do?

• Inline expansion of runtime-support library
  functions
• Induction variable optimizations and strength
  reduction
• Loop-invariant code motion
• Loop rotation

26
Different Levels of Optimization
How do we control what the optimizer does?

• Different Optimizer levels
• o0 - register
• o1 - local
• o2- global
• o3- file
• Program Level (-pm)
• Combines all C files into one before optimizing

27
Optimization Levels
Register (-o0 (default))
Local (-o1)

• Performs local copy/constant propagation
• Removes unused assignments
• Eliminates local common expressions

• Simplifies control flow
• Allocates variables to registers
• Eliminates unused code
• Simplifies expressions and statements
• Expands calls to inline functions

Global (-o2)
File (-o3)

• Performs loop optimizations
• Eliminates global common sub-expressions
• Eliminates global unused assignments
• Performs loop unrolling

• Removes functions that are never called
• Simplifies functions with return values that are
  never used
• Inlines calls to small functions (regardless of
  declaration)
• Reorders functions so that attributes of called
  function are known when caller is optimized
• Identifies file-level variable characteristics

28
Program Level Optimization

• Combines all files into one before running
  optimizer
• Optimizer can see all C function inputs and
  outputs
• Allows further optimization
• If argument in function always has same value, is
  replaced with the value and value is passed
  instead of the argument
• Deletes code for unused return values
• Removes function code for uncalled functions

29
Program Level Optimization

• Better optimization of loops since compiler can
  determine loop counts that are passed as
  parameters
• Increases compilation time and rearranges code
  significantly, so is usually one of the last
  steps in optimization

30
Mixing C and Assembly

• To keep variables, have two methods
• Use volatile keyword
• Use different options
• To keep functions, have two methods
• Place FUNC_EXT_CALLED pragma before declaration
  or reference

31
Mixing C and Assembly

• Potential problems if also have assembly routines
• Optimizer is not aware of them and may cut out
  calls to them
• Optimizer may cut out variables accessed by them

32
Examples of Options

• Indicates if functions in other modules can call
  a modules external functions or modify the
  modules external variables

33
Inlining Code

• For small infrequently called functions it may
  make sense to paste them directly into code (i.e.
  inline)
• Eliminates overhead (register storage and
  parameter passing)
• Uses more program space, but speeds up execution

• When inlined, optimizer can optimize it in new
  context

34
Inlining Code

• Two types of inlining
• Static function only placed in code where used
• Normal also has function definition so it can
  be called
• Two ways to inline code
• Automatic compiler inlines if size is small
  enough
• Definition-Controlled you specify which
  functions to inline

35
Optimization Procedures
36
Cost-Based Register Allocation

• Allocates registers to user variables and
  compiler temporary values according to their
  type, use, and frequency
• Weights variables used within loops to have
  priority over others
• Variables whose uses dont overlap can be
  allocated to the same register

37
Alias Disambiguation

• Aliasing If two or more symbols, pointer
  references, or structure references refer to the
  same memory location
• Often prevents compiler from retaining values in
  registers because it cannot be sure that the
  register and memory continue to hold the same
  values over time
• Alias disambiguation is a technique that
  determines when two pointer expressions cannot
  point to the same location, allowing compiler to
  freely optimize such expressions

38
Branch Optimizations and Control-Flow
Simplification

• Rearranges linear sequences of operations (basic
  blocks) to remove branches or redundant
  conditions
• Unreachable code is deleted
• Branches to branches are bypassed
• Conditional branches over unconditional branches
  are simplified to single conditional branch
• Can delete conditional branches if able to
  determine condition at build time

39
Branch Optimizations and Control-Flow
Simplification

• Switch case lists are analyzed in the same way as
  conditional branches and are sometimes eliminated
  entirely.
• Some simple control flow constructs can be
  reduced to conditional instructions, totally
  eliminating need for a branch

40
Types of Data Flow Optimizations

• Copy propagation
• Replaces references to the variable with its
  value
• Value can be another variable, a constant, or a
  common subexpression
• Can result in increased opportunities for
  constant folding, common subexpression
  elimination, or total elimination of the
  variable.
• Common subexpression elimination
• When two or more expressions produce the same
  value, the compiler computes the value once,
  saves it, and reuses it.

41
Types of Data Flow Optimizations

• Redundant assignment elimination
• Copy propagation and common subexpression
  elimination optimizations often result in
  unnecessary assignments to variables (variables
  with no subsequent reference before another
  assignment or before the end of the function)
• Optimizer removes these dead assignments

42
Expression Simplification

• Simplifies expressions into equivalent forms,
  requiring fewer instructions or registers
• Operations between constants are folded into
  single constants
• For example, a (b 4) (c 1) becomes a b
  c 3

43
Data Flow Optimizations

• Replace expressions with less costly ones
• Detect and remove unnecessary assignments
• Avoid operations that produce values that are
  already computed
• Performed both locally (within basic blocks) and
  globally (across entire functions)

44
Inline Expansion of Functions

• Replaces calls to small functions with inline
  code
• Saves over-head associated with a function call
• Provides increased opportunities to apply other
  optimizations

45
Induction Variables and Strength Reduction

• Induction variables variables whose value within
  a loop is directly related to the number of
  executions of the loop
• Array indices and control variables of for loops
  are very often induction variables
• Strength reduction process of replacing
  inefficient expressions involving induction
  variables with more efficient expressions
• i.e. code that indexes into a sequence of array
  elements is replaced with code that increments a
  pointer through the array

46
Induction Variables and Strength Reduction

• Induction variable analysis and strength
  reduction together often remove all references to
  your loop control variable, allowing its
  elimination entirely

47
Loop-Invariant Code Motion

• Identifies expressions within loops that always
  compute the same value
• Moves computation in front of the loop
• Replaces each occurrence in the loop by a
  reference to the precomputed value

48
Loop Rotation

• Evaluates loop conditionals at the bottom of
  loops
• Saves an extra branch out of the loop
• In many cases, the initial entry conditional
  checkand the branch are optimized out

49
SE 746-NT Embedded Software Systems
Development Robert Oshana End of
lecture For more information, please
contact NTU Tape Orders NTU Media
Services [phone]
oshana_at_airmail.net
tapeorders_at_ntu.edu
