WS TRUST

1
WS - TRUST

• by Bugrahan AKCAY

2
Goals

• Enable applications to construct trusted message
  exchanges
• Provide a flexible set of mechanisms that can be
  used to support a range of security protocols

3
Requirements

• Requesting and obtaining security token
• Managing trusts and establishing trust
  relationships
• Establishing and assessing trust relationships
• From Web Service Trust Language Version 1.1 May
  2004

4
WS-Trust

• WS-Trust defines standard interfaces for
• Security token creation, management and exchange
• Dissemination of credentials within different
  trust domains
• Specifically WS-Trust builds upon WS-Security to
  provide
• Methods for issuing and exchanging security
  tokens,
• Ways to establish and access the presence of
  trust relationships
• Defined using WSDL

5
WS-Trust

• Requesting and obtaining security tokens,
  Deriving Keys
• The current specification defines three possible
  actions issue a new token, renew a token or
  validate a token
• Managing trusts and establishing trust
  relationships

6
The position of WS-Trust
WS-Secure Conversation
WS-Authorization
WS-Federation
WS-Policy
WS-Trust
WS-Privacy
WS-Security
In progress
SOAP Foundation
proposed
promised
7
Terms

• Trust - Trust is the characteristic that one
  entity is willing to rely upon a second entity to
  execute a set of actions
• Direct Trust - Direct trust is when a relying
  party accepts as true all (or some subset of) the
  claims in the token sent by the requestor.
• Direct Brokered Trust Direct Brokered Trust is
  when one party trusts a second party, who, in
  turn, trusts or vouches for, a third party.
• Indirect Brokered Trust Indirect Brokered Trust
  is a variation on direct brokered trust where the
  second party negotiates with the third party, or
  additional parties, to assess the trust of the
  third party.

8
Trust Model

• Messages MAY be required to prove a set of
  claims (e.g., name, key, permission, capability,
  etc.).
• Messages without having the required proof of
  claims, SHOULD be ignored/rejected.
• Requester MAY contact an appropriate authority
  (Security Token Service) which may require their
  own set of claims.
• Security token services form the basis of trust.
• A challenge response protocol MAY be required for
  freshness and proof-of-possession.

9
Trust Model Diagram
10
Security Token Issuance, Validation and Exchange

• Requesting a Security Token
• Basic elements for requesting specific token
  types
• Scope Requirements
• Key and Encryption Requirements
• Delegation, Forwarding, and Proxy Requirements
• Lifetime and Renewal Requirements
• Policies
• Returning Tokens
• Basic element to determine specific token type
  retuned
• Scope Requirements
• Key and Encryption Requirements

11
Some Token Characteristics

• WS-Trust allows various characteristics of the
  requested token to be specified in the request
• A validity period or lifetime for a token can be
  specified as can information concerning key
  length, key types and token issuer information
  amongst other things.

12
Management of Trust Models

• Fixed trust roots Simple fixed set of trust
  relationships between requestor and recipient.
• Trust hierarchies Builds on fixed trust roots
  but allows hierarchies of trust between requestor
  and recipient.
• Authentication service Essentially a fixed
  trust root where the recipient only trusts the
  authentication service.

13
Basic Trust Structure

• I want to have secure communication with you
• I ask the trust service for a token to allow me
  to talk to you
• The trust service sends two copies of a secret
  key
• One encrypted for me (proof token)
• One encrypted for you (requested token)

14
Trust Engine/Security Token Service

• A security token service is also, depicted, from
  which the sender Web Service will request a
  security token to be used for its interaction
  with the receiver Web service.

15
Request Structure

• Request Header
• Defines the type of security token requested
• The action that is being requested
• References tokens that are used to validate the
  authenticity of a request
• References the supporting tokens used to
  authorize request

ltRequestSecurityTokengt
ltTokenTypegt...lt/TokenTypegt
ltRequestTypegt...lt/RequestTypegt
ltBasegt...lt/Basegt ltSupportinggt...lt/Supporti
nggt lt/RequestSecurityTokengt
16
Request Example
17
Response Structure

• Response Header
• Defines the type of security token requested
• Specifies the type of key used in the token
• Specifies the size of the key returned
• Specifies the scope to which this security token
  applies
• Requested security token
• Proof-of-possession token

ltRequestSecurityTokenResponsegt
ltTokenTypegt...lt/TokenTypegt
ltKeyTypegt...lt/KeyTypegt ltKeySizegt...lt/KeySi
zegt ltwspAppliesTogt...lt/wspAppliesTogt
ltRequestedSecurityTokengt...
lt/RequestedSecurityTokengt
ltRequestedProofTokengt...
lt/RequestedProofTokengt lt/RequestSecurityTokenRespo
nsegt
The proof token contains information that the
receiver needs in order to prove it is able to
use the returned token.
18
Response Example
19
Example
1
Security Token Proof token
20
Brokered Example

• Service and STS exchange shared secret.
• Client make RST and signs according STS policy.
• STS enforces policy
• Creates token and encrypts with clients
  encryption key
• Create proof token and encrypts with shared
  secret
• Signs and returns RSTS
• Client decrypts token
• Client propagates proof token to service
• Service decrypts proof token

STS (Security Token Service)
Client
Service
21
Challenges

• In some cases, a security token service may
  choose to challenge the requestor of a security
  token.
• This may occur if the security token service does
  not trust the nonce and timestamp (for example,
  the freshness) in the message.
• The security token service may challenge the
  signature within the message

22
Challenges

• Allows extensible/custom challenges and responses

23
Summary

• Using these extensions, applications can engage
  in secure communication designed to work with
• General Web Services framework including WSDL
• UDDI businessServices
• bindingTemplates
• SOAP messages
• The Web Services Enhancements Toolkit Version 2.0
  implements the latest version of the WS-Trust
  specification. (According to MS and it needs .NET
  Environment)
