Remote Network Monitoring (RMON)
2
RMON

• RMON specification is a definition of a MIB
• RMON-related RFCs

RFC Name 1513 Token Ring Extensions to the
remote Network Monitoring MIB 1757 Remote Network
Monitoring Management Information
Base 2021 Remote Network Monitoring Management
Information Base Version 2 2074 Remote Network
Monitoring MIB Protocol Identifiers
3
Design Goals for RMON

• Off-line operation
• Continue to collect fault, performance, and
  configuration information even if it is not been
  polled by a network manager
• Save communication cost
• A manager may cease to poll if there is a
  communication failure or if the manager fails
• Proactive monitoring
• Continuously run diagnostics and log network
  performance
• Problem detection and reporting
• Value-added data
• Perform analyses to the data collected
• Multiple managers
• To improve reliability
• To perform different functions
• To provide management capability to different
  RMON monitors

4
Example Configuration Using RMON
5
RMON Configuration the concept

• A RMON monitor needs to be configured for data
  collection
• Each group has
• One or more control tables read-write
• One or more data tables read-only
• A RMON monitor is configured by setting
  appropriate parameters in the control tables
• Objects that specify the source of data to be
  collected
• The type of data
• Collection timing
• etc.
• The information in the data tables are collected
  according to the parameters in the control tables

6
RMON Configuration relationship between control
tables and data tables

• A single row of a control table defines a
  specific data collection function
• A single row of a control table is associated
  with one or more rows in one or more data tables
• A control row and its associated data rows are
  tied together by interlocking pointers
• A control row includes an index object that can
  be used to access one or more data rows in one or
  more data tables
• Each data row includes an index that refers to
  the corresponding control row

7
RMON Configuration modification of control
parameters

• To modify any parameters in a control table, the
  control row need needs to be invalidated first
• When a control row is invalidated, the control
  row and all associated data rows are deleted
• A new control row needs to be created with the
  modified parameters

8
RMON Configuration action invocation

• SNMP does not provide specific mechanism for
  issuing a command to an agent to perform an
  action
• The SNMP set operation can be used to issue a
  command
• An object can be used to represent a command
• If the object is set to a specific value, a
  specific action is taken
• The object represent state, an action is
  performed if the management station changes a
  state
• Setting the object to its current value does not
  cause an action to be performed

9
Multiple Managers - issues

• Concurrent requests for the (storage) resources
  of a RMON monitor could exceed the capability of
  the monitor
• A management station could hold monitor resources
  for a long period of time, preventing other
  management stations from using the resources
• Resources could be assigned to a management
  station that crashed without releasing the
  resources

10
Multiple Managers - resolution

• A columnar object in each control table is used
  identifies the owner of a particular control row
• The ownership label can be used in the following
  ways
• A management station may recognize resources it
  owns and no longer needed
• A network operator can identify the management
  station that owns a particular resource and
  negotiate for the resource to be freed
• A network operator may have the authority to free
  resources owned by other network operators
• If a management station is reinitialized, it can
  recognize resources it had reserved in the past
  and free those it no loner needs

11
Multiple Managers ownership label

• The ownership label contains one or more of the
  following
• IP address
• Name of the management station
• Name, location, or phone number of the network
  manager
• The ownership label does not act as a password or
  access-control mechanism
• A control row should be altered or deleted only
  by its owner and read only by other management
  ststaions
• The enforcement of this convention is beyond the
  scope of SNMP or the RMON specification

12
Multiple Managers more

• Efficiency consideration
• When a management station wish to create a
  certain function in a monitor, it should scan the
  relevant control table to see if that function,
  or something close to that function, has already
  been defined by other management station
• A management station may share the function
  defined by other management statuions
• Default set of functions
• A monitor is often configured with a default set
  of functions that are set up when the monitor is
  initialized
• The value the ownership label is set to a string
  starting with monitor

13
Creation of a control row

• Conflict may occur when multiple management
  stations try to create a control row with the
  same parameters
• A state machine in the RMON MIB structure defined
  by the status object is used to arbitrate the
  conflict
• Only the request received first will succeed, the
  others will cause an error

14
Creation of a control row the state machine

• If a management station tries to create a new row
  with nonexistent value or values of the index
  object, the row is created with a status object
  value of create-request(2)
• Immediately after the row is created, the agent
  sets the status object value to underCreation(3)
• A row remains in the underCreation(3) state. When
  a management station finishes creating all of the
  rows for its configuration, the management
  station sets the status value in each of the
  created rows to valid(1)
• If a management station tries to create a new row
  with a create-request(2) status (i.e., the row
  already exists), an error will be returned

15
RMON MIB (RFC 1757)

• MAC layer (layer 2) monitoring

16
RMON MIB (RFC 1757)

• statistics packet size distribution and error
  conditions for each interface
• history periodically records basic statistics
  in the statistic group
• alarm set threshold and sampling interval for
  any counter or integer
• host counters of various types of traffic to
  and from hosts for each interface
• hostTopN sorted host statistics
• matrix information about the traffic between
  pairs of hosts in matrix form
• filter counts the number of packets that match
  a filter
• capture capture and store packets that match a
  filter
• event a table of events generated by the RMON
  probe
• tokenRing statistics and configuration
  information for token ring

17
statistics packet size distribution and error
conditions for each interface
18
etherStatsTable
etherStatsIndex This object uniquely identifies
this etherStats entry etherStatsDataSource This
identifies the interface and hence the subnetwork
that is the source of the data for samples
defined by this row. etherStatsDropEvents
Number of events in which packets were dropped by
the monitor due to lack of resources. This is not
necessarily the actual count of packets dropped,
but the number of times this condition has been
detected. etherStatsOctets Number of received
octets of data (including those in bad
packets). etherStatsPkts Number of received
packets, including bad packets, broadcast
packets, and multicast packets. etherStatsBroadca
stPkts Number of good broadcast packets
received. etherStatsMulticastPkts Number of
good multicast packets received. etherStatsCRCAli
gnErrors Number of packets received of the
proper size (between 64 and 1,518 octets) but
with either a CRC error or an alignment error
(not an integral number of octets). etherStatsUnd
ersizePkts Number of packets received that were
well formed but less than 64 octets
long. etherStatsOversizePkts Number of packets
received that were well formed but greater than
1,518 octets long.
19
etherStatsTable
etherStatsFragments Number of packets received
that were less than 64 octets long and with
either a CRC error or an alignment error (not an
integral number of octets) etherStatsJabbers
Number of packets received that were greater than
1,518 octets long and with either a CRC error or
an alignment error (not an integral number of
octets). etherStatsCollisions The best estimate
of the total number of collisions. etherStatsPkts
64Octets Number of packets (including bad
packets) received that were 64 octets in
length. etherStatsPkts65to127Octets Number of
packets (including bad packets) received that
were between 65 and 127 octets in
length. etherStatsPkts128to255Octets Number of
packets (including bad packets) received that
were between 128 and 255 octets in
length. etherStatsPkts256to511Octets Number of
packets (including bad packets) received that
were between 256 and 511 octets in
length. etherStatsPkts512to1023Octets Number of
packets (including bad packets) received that
were between 512 and 1,023 octets in
length. etherStatsPkts1024to1518Octets Number
of packets (including bad packets) received that
were between 1,024 and 1,518 octets in length.
20
history periodically records basic statistics
in the statistic group
21
historyControlTable historyControlIndex an
integer that uniquely identifies a row in the
historyControlTable. The same integer is also
used to identify corresponding rows in the
etherHistoryTable or another media-specific
table. historyControlDataSource This identifies
the interface and hence the subnetwork that is
the source of the data for samples defined by
this row. An object identifier that identifies
the instance of ifIndex in the interfaces group
of MIB-II. historyControlBucketsRequested the
requested number of discrete sampling intervals
over which data are to be saved in the part of
the media-specific data table associated with
this entry. A default value of 50 is assigned to
this object if it is not provided by the creator
of this row. historyControlBucketsGranted the
actual number of discrete sampling inter- vals
over which data will be saved. When the
associated historyControlBucketsRequested is
created or modified, the monitor should set this
object as closely to the requested value as
possible. historyControlInterval The interval
in seconds over which data are sampled for each
bucket. The interval can be set to any number
between 1 and 3,600 (1 hour). A default value of
1,800 is assigned to this object if it is not
provided by the creator of this row.
One row in the data table is called a bucket
22
etherHistoryTable etherHistoryIndex the history
of which this entry is a part. The history
identified by a particular value of this index is
the same as that identified by the same value of
historyControlIndex. etherHistorySampleIndex an
index that uniquely identifies the particular
sample this entry represents among all samples
associated with the same row of the
historyControlTable. This index starts at 1 and
increases by one as each new sample is
taken. etherHistoryIntervalStart This is the
value of sysUpTime (in the MIB-II systems group)
at the start of the interval over which this
sample was measured. etherHistoryUtilization
Two counters, etherStatsOctets and
etherStatsPkts, are used to measure the
utilization of the subnetwork
Packets etherStatsPkts(n) etherStatsPkts(n-1)
Octets etherStatsOctets(n)
etherStatsOctets(n-1)
Preamble 64 bits interframe gap 96 bits
23
(No Transcript)
24
Sampling scheme

• At the end of each sampling interval, the monitor
  adds a new row to the data table with the same
  Index and with a higher value of SampleIndex
• Once the number of rows in the data table with
  the same Index becomes equal to the
  BucketsGranted, the sets of rows with the same
  Index functions as a circular buffer.
• As each new row is added to the set, the oldest
  row is deleted

25

• host counters of various types of traffic to
  and from hosts for each interface

26
The host group consists of three tables one
control table and two data tables
hostControlTable hostControlIndex an integer
that uniquely identifies a row in the
hostControlTable. Each row in the control table
refers to a unique interface of the monitor
(unique subnetwork). The same integer is also
used to identify corresponding rows in the
hostTable and the hostTimeTable. hostControlDataS
ource This identifies the interface and hence
the subnetwork that is the source of the data for
data-table entries defined by this row.
hostControlTableSize the number of rows in
hostTable that are associated with this row. It
is also the number of rows in hostTimeTable that
are associated with this row. This is a read-only
object set by the monitor. hostControlLastDeleteT
ime the value of sysUpTime (in the MIB-II
systems group) corresponding to the last time
that an entry was deleted from the portion of the
hostTable associated with this row. The value is
zero if no deletions have occurred.
27
hostTable hostAddress This gives the MAC
address of this host. hostCreationOrder an
index that defines the relative ordering of the
creation time of hosts captured for a particular
hostControlEntry. This index takes on a value
between 1 and N, where N, is the value of the
associated hostControl-TableSize (for row i of
hostControlTable). hostlndex the set of
collected host statistics of which this entry is
a part. The value of this object matches the
value of hostControlIndex for one of the rows of
hostControlTable. Thus, all entries in hostTable
with the same value of hostIndex contain
statistics for hosts on a single subnetwork.
28
hostTable hostInPkts Number of good packets
transmitted to this address hostOutPkts Number
of packets, including bad packets, transmitted by
this address hostInOctets Number of octets
transmitted to this address, not including octets
in bad packets hostOutOctets Number of octets
transmitted by this address, including octets in
bad packets hostOutErrors Number of bad packets
transmitted by this address hostOutBroadcastPkts
Number of good broadcast packets transmitted by
this address hostOutMulticastPkts Number of
good multicast packets transmitted by this
address
29
hostTimeTable contains the exact same
information, row by row, as hostTable but is
indexed by the creation order rather than by the
host MAC address. (hostTable is
indexed by host MAC address) The organization
of hostTimeTable also supports efficient
discovery of new entries for a particular
interface, without having to download the entire
table. All of the information in the host group
is obtainable directly from the interfaces group
of MIB-II.
30
(No Transcript)
31
hostTopN Top N hosts for each subnetwork
32
hostTopNControlTable hostTopNControlIndex an
integer that uniquely identifies a row in the
hostTopNControlTable. Each row in the control
table defines one top-N report prepared for one
interface. hostTopNHostIndex This value matches
a value of hostControlIndex and hostlndex.
Therefore, this value specifies a particular
subnetwork. The top-N report defined by this row
of the control table is prepared using the
corresponding entries in hostTable. hostTopNRateB
ase specifies one of seven variables from
hostTable. The specified variable is the basis
for the hostTopNRate variable in the row of
hostTopNTable defined by this control row. The
type of this object is the following
INTEGER hostTopNInPkts (1) ,
hostTopNOutPkts (2) ,
hostTopNInOctets (3) ,
hostTopNOutOctets (4) ,
hostTopNOutErrors (5) ,
hostTopNOutBroadcastPkts (6) ,
hostTopNOutMulticastPkts (7)
33
hostTopNControlTable hostlopNTimeRemaining
This tells the number of seconds left in the
sampling interval for the report currently being
collected. hostTopNDuration This is the
sampling interval, in seconds, for this
report. hostTopNRequestedSize This gives the
maximum number of hosts requested for the topN
table for this report. hostlopNGrantedSize This
indicates the maximum number of hosts in the topN
table for this report. hostTopNStartTime The
value of sysUpTime (in the MIB-II systems group)
when this top-N report was last started. In other
words, this is the time when the associated
hostTopNTimeRemaining object was modified to
start the requested report
34
hostTopNTable hostTopNReport the report of
which this entry is a part. The report identified
by a particular value of this index is the same
report as that identified by the same value of
hostTopNControlIndex. hostTopNIndex an index
that uniquely identifies one row among all data
rows associated with this report. Each row
represents a unique host. hostTopNAddress This
gives the MAC address of this host. hostTopNRate
the amount of change in the selected variable
during this sampling interval. The selected
variable is specified by the value of
hostTopNRateBase for this report.
35
(No Transcript)
36
Preparation process of a TopN report

• A management station creates a row of the
  hostTopNControlTable to specify a new repot
• The sampling period value is stored in both
  hostTopNDuration and hostTopNTimeRemaining
• The value of hostTopNDuration is static
• The value of hostTopNTimeRemaining counts down
  while the monitor is preparing the report
• When hostTopNTimeRemaining reach 0, the monitor
  calculates the final results and creates a set of
  N data rows in the hostTopNTable, with the top N
  hosts listed in decending order of the calculated
  rates
• If the management station wish to generate
  another report for a new time period, it resets
  hostTopNTimeRemaining to the value in
  hostTopNDuration.
• Resetting hostTopNTimeRemaining causes the
  associated data rows to be deleted and a new
  report to be prepared

37
matrix information about the traffic between
pairs of hosts in matrix form
38
matrixControlTable matrixControlIndex an
integer that uniquely identifies a row in the
matrixControlTable. Each row in the control table
defines a function that discovers conversations
on a particular interface and places statistics
about them in the two data tables. matrixControlD
ataSource This identifies the interface and
hence the subnetwork that is the source of the
data in this row. matrixControlTableSize the
number of rows in the matrixSDTable that are
associated with this row. It is also the number
of rows in the matrixDSTable that are associated
with this row. This is a read-only object set by
the monitor. matrixControlLastDeleteTime the
value of sysUpTime (in the MIB-II systems group)
corresponding to the last time that an entry was
deleted from the portion of the matrixSDTable and
the portion of the matrixDSTable associated with
this row. The value is zero if no deletions have
occurred.
39
matrixSDTable is used to store statistics on
traffic from a particular source host to a number
of destinations. matrixSDSourceAddress the
source MAC address matrixSDDestAddress the
destination MAC address matrixSDIndex the set
of collected matrix statistics of which this row
is a part (The set identified by a particular
value of this index is the same as that
identified by the same value of
matrixControlIndex.) matrixSDPkts number of
packets transmitted from this source address to
this destination address, including bad
packets matrixSDOctets number of octets
contained in all packets transmitted from this
source address to this destination
address matrixSDErrors number of bad packets
transmitted from this source address to this
destination address
40
The matrixSDTable is indexed first by
matrixSDIndex, then by source address, and then
by destination address. The matrixDSTable
contains the same information as matrixSDTable
but is indexed first by matrixDSIndex, then by
destination address, and then by source address.
41
(No Transcript)
42
RMON - Alarms and Filters
43
alarm group The alarm group is used to define a
set of thresholds for network performance
44
alarmTable alarmlndex an integer that uniquely
identifies a row in the alarmTable. Each such row
specifies a sample at a particular interval for a
particular object in the monitor's
MIB. alarmlnterval This is the interval in
seconds over which the data are sampled and
compared with the rising and falling
thresholds. alarmVariable the object identifier
of the particular variable in the RMON MIB to be
sampled. The only object types allowed are
INTEGER, counter, gauge, and TimeTicks. These are
the only object types that resolve to ASN.l type
INTEGER. alarmSampleType the method of
calculating the value to be compared to the
thresholds. If the value of this object is
absoluteValue(1), then the value of the selected
variable will be compared directly with the
thresholds. If the value of this object is
deltaValue(2), then the value of the selected
variable at the last sample is subtracted from
the current value, and the difference is compared
to the thresholds.
45
alarmTable alarmValue This gives the value of
the statistic during the last sampling
period. alarmStartupAlarm has the value
risingAlarm(l), fallingAlarm(2), or
risingOrFallingAlarm(3). This dictates whether an
alarm will be generated if the first sample after
the row becomes valid is greater than or equal to
the risingThreshold, less than or equal to the
fallingThreshold, or both, respectively. alarinRi
singThreshold This is the rising threshold for
the sampled statistic. alarmFallingThreshold
This is the falling threshold for the sampled
statistic. alarmRisingEventIndex the index of
the eventEntry that is used when the rising
threshold is crossed. The eventTable is part of
the event group and is discussed
later alarmFallingEventIndex This is the index
of the eventEntry that is used when the falling
threshold is crossed.
46
(No Transcript)
47
Hysteresis mechanism is used to prevent small
fluctuations from generating alarms
48
filter group The filter group provides a means
by which a management station can instruct a
monitor to observe selected packets on a
particular interface Two kinds of filters data
filter allows the monitor to screen observed
packets on the basis of a bit pattern that a
portion of the packet matches (or fails to
match) status filter allows the monitor to
screen observed packets on the basis of their
status ( e.g., CRC error) Combination of
filters The filters can be combined using
logical AND and OR operations to form a complex
test to be applied to incoming packets
49
Variables in filter logic input
the incoming portion of a packet to be
filtered filterPktDataOffset a distance
from the start of the packet filterPktData
the bit pattern to be tested
for filterPktDataMask the relevant bits
to be tested for
0 irrelevant 1
relevant filterPktDataNotMask indication of
whether to test for a match or a

mismatch
0 a match is required 1 a mismatch is
required
50
Filter logic for data filter 1. TEST 1 As a
first test, the packet must be long enough so
that there are at least as many bits in the
packet following the offset as there are bits in
filterPktData. If not, the packet fails this
filter. 2. TEST 2 Each bit set to 0 in
filterPktDataNotMask indicates a bit position in
which the relevant bits of the packet portion
should match filterPktData. If there is a match
in every desired bit position, then the test is
passed otherwise the test is failed. 3. TEST 3
Each bit set to 1 in filterPktDataNotMask
indicates a bit position in which the relevant
bits of the packet portion should not match
filterPktData. In this case, the test is passed
if there is a mismatch in at least one desired
bit position. A packet passes this filter if and
only if it passes all three tests.
51
Test 1
Test 3
Test 2
52
Status filter The logic for the status filter
has the same structure as that for the data
filter The reported status of the packet is
converted into a bit pattern

Bit Error
0 Packet is longer than 1,518 octets 1
Packet is shorter than 64 octets 2
Packet experienced a CRC or alignment error
1
2
Therefore, an Ethernet fragment would have the
status value of 6 (2 2 ).
53
Channel A channel is defined as a set of
filters channelAcceptType INTEGER
acceptMatched(1), acceptFailed(2) if
channelAcceptType acceptMatched(1), packets
will be accepted for this channel if they pass
both the packet data and packet status matches of
at least one of the associated filters if
channelAcceptType acceptFailed(2), packets will
be accepted to this channel only if they fail
either the packet data match or the packet status
match of every associated filter If the packet
is accepted, then the counter channelMatches is
incremented
54
(No Transcript)
55
(No Transcript)
56
Several additional controls associated with a
channel channelDataControl determines whether
the channel is on or off channelDataControl
on enabled to generate an event

when a packet is matched If
channelDataControl is on, then an event will be
generated if two conditions are met (1) An
event is defined for this channel in
channelEventIndex, and (2) channelEventStatus
has the value eventReady or eventAlwaysReady
channelDataControl off not enabled to
generate an event channelEventIndex specifies
an associated event. channelEventStatus
indicates whether the channel is enabled to
generate an event when a packet is
matched channelEventStatus
eventReady(1),eventFired(2),eventAlwaysReady(3)

57
define acceptMatched 1 define
acceptFailed 2 define eventReady
1 define eventFired
2 define ON 1
int channelAcceptType, channelMatches,
channelDataControl int channelEventStatus,
channelEventIndex /
channel logic / void PacketDataMatch( int
result ) if ( ((result 1)
(channelAcceptType acceptMatched))
((result 0) (channelAcceptType
acceptFailed)) ) channelMatches
channelMatches 1 if (
channelDataControl ON )
if ( (channelEventStatus ! eventFired)
(channelEventIndex ! 0) )
GenerateEvent() if (
channelEventStatus eventReady)
channelEventStatus eventFired
FIGURE 9.6 Channel operation
logic

58
filter group The filter group consists of two
control tables
filterTable and
channelTable Each row of the channelTable
defines a unique channel. Associated with each
channel are one or more rows in the filterTable,
which define the associated filters
59
filter group
60
channelTable channellndex an integer that
uniquely identifies one row in the channelTable.
Each row defines one channel. channellfIndex
identifies the monitor interface, and hence the
subnetwork, to which the associated filters are
applied to allow data into this channel.
channelAcceptType controls the action of the
filters associated with this channel. If the
value of this object is acceptMatched(l), packets
will be accepted to this channel if they pass
both the packet data and packet status matches of
at least one of the associated filters. If the
value of this object is acceptFailed(2), packets
will be accepted to this channel only if they
fail either the packet data match or the packet
status match of every associated
filter. channelDataControl If this object has
the value on(l), the data, status, and events
will flow through this channel. If this object
has the value off(2), the data, status, and
events will not flow through this channel.
61
channelTable channelTurnOnEventIndex
identifies the event that is configured to turn
the associated channelDataControl from off to on
when the event is generated. If no such event
exists, then no association exists. If no event
is intended, this object has the value
0. channelTurnOffEvent Index identifies the
event that is configured to turn the associated
channelDataControl from on to off when the event
is generated. If no such event exists, then no
association exists. If no event is intended, this
object has the value 0. channelEventIndex
identifies the event that is configured to be
generated when the associated channelDataControl
is on and a packet is matched. If no such event
exists, then no association exists. If no event
is intended, this object has the value 0.
62

• channelTable
• channelEventStatus the event status of this
  channel.
• If the channel is configured to generate events
  when packets are matched, then the value of this
  object has the following interpretation
• When the value is eventReady(1), a single event
  will be generated for a packet match, after which
  this object is set to eventFired(2).
• In the eventFired(2) state, no events are
  generated.
• This allows the management station to respond to
  the notification of an event and then re-enable
  the object.
• While the value is eventAlwaysReady(3), every
  packet match generates an event.
• channelMatches a counter that records the number
  of packet matches. This counter is updated even
  when channelDataControl is set to off.
• channelDescription This gives a text
  description of the channel.

63
filterTable filterlndex an integer that
uniquely identifies a row in the filterTable
(Each such row defines one data filter and one
status that is to be applied to every packet
received on an interface.) filter-Channel Index
the channel of which this filter is a
part filterPktDataOffset offset from the
beginning of each packet where a match of packet
data will be attempted filterPktData the data
that is to be matched with the input
packet filterPktDataMask the mask that is
applied to the match process filterPktDataNotMask
the inversion mask that is applied to the data
match process filterPktStatus the status that
is to be matched with the input
packet filterPktStatusMask the mask that is
applied to the status match process filterPktStat
usNotMask the inversion mask that is applied to
the status match process
64
capture Group
65
capture Group Used to set up a buffering scheme
for capturing packets from one of the channels in
the filter group. It consists of two
tables bufferControlTable specifies the
details of the buffering function captureBufferTa
ble buffers the data.
66
bufferControlTable bufferControlIndex an
integer that uniquely identifies a row in the
bufferControlTable. The same integer is also used
to identify corresponding rows in the
captureBufferTable. bufferControlChannelIndex
identifies the channel that is the source of
packets for this row. The value matches that of
channellndex for one row of channelTable. bufferC
ontrolFullStatus If the value is
spaceAvailable(1), the buffer has room to accept
new packets. If the value is full(2), its meaning
depends on the value of bufferControlFullAction.
bufferControlFullAction If the value is
lockWhenFull(1), the buffer will accept no more
packets after it becomes full. If the value is
wrapWhenFull(2), the buffer acts as a circular
buffer after it becomes full, deleting enough of
the oldest packets to make room for new ones as
they arrive. bufferControlCaptureSliceSize
maximum number of octets of each packet, starting
with the beginning of the packet, that will be
saved in this capture buffer. If the value is 0,
the buffer will save as many octets as possible.
The default value is 100.
67
bufferControlTable bufferControlDownloadSliceSize
This is the maximum number of octets of each
packet in this buffer that will be returned in a
single SNMP retrieval of that packet. buff
erControlDownloadOffset This gives the offset of
the first octet of each packet in this buffer
that will be returned in a single SNMP retrieval
of that packet. bufferControlMaxOctetsRequested
the requested buffer size in octets. A value of
-1 requests that the buffer be as large as
possible. bufferControlMaxOctetsGranted the
granted buffer size in octets. This is
the maximum number of octets that can be saved,
including implementation-specific
overhead. bufferControlCapturedPackets This
indicates the number of packets currently in this
buffer. bufferControlTurnOnTime This gives the
value of sysUpTime (in the MIB-II systems group)
when this buffer was first turned on.
68
captureBufferTable captureBufferControlIndex
the buffer with which this packet is associated.
The buffer identified by a particular value of
this index is the same buffer as that identified
by the same value of bufferControlIndex. captureB
ufferIndex an index that uniquely identifies
this particular packet among all packets
associated with the same buffer. This index
starts at 1 and increases by one as each new
packet is captured. Thus, this variable serves as
a sequence number for packets in one
buffer. captureBufferPacketID an index that
describes the order of packets that are received
on a particular interface. Thus, this variable
serves as a sequence number for packets that are
captured from one subnetwork, regardless of which
buffer(s) they are stored in. captureBufferPacket
Data This gives the actual packet data stored
for this row. captureBufferPacketLength the
actual length of the packet as received (off the
wire). It may be that only a part of the packet
is actually stored in this entry. captureBufferPa
cketTime This indicates the number of
milliseconds that had passed from the time that
the buffer was turned on to the time that this
packet was captured. captureBufferPacketStatus
This indicates the error status of this packet.
69
(No Transcript)
70
event group
71

• event group supports the definition of events
• An event is triggered by a condition located
  elsewhere in the MIB
• An event
• can trigger an action defined elsewhere in the
  MIB
• may cause information to be logged in this group
• may cause an SNMP trap message to be issued
• An event that is defined in this group can be
  used to trigger activity related to another
  group. For example, an event can trigger turning
  a channel on or off.
• The event group consists of one control table
  and one data table
• control table
• eventTable contains event definitions. Each row
  of the table contains the parameters that
  describe an event to be generated when certain
  conditions are met.
• Data table logTable

72
eventTable eventlndex an integer that uniquely
identifies a row in the eventTable (The same
integer is also used to identify corresponding
rows in the logTable.) eventDescription a
textual description of this event eventType
takes on the value none(1), log(2), snmp-trap(3),
or log-and-trap(4) (In the case of log, an entry
is made in the log table for each event. In the
case of snmp-trap, an SNMP trap is sent to one or
more management stations for each
event.) eventCommunity specifies the community
of management stations to receive the trap if an
SNMP trap is to be sent eventLastTimeSent the
value of sysUpTime (in the MIB-II systems group)
at the time this event entry last generated an
event
73
logTable logEventIndex identifies the event
that generated this log entry. The value of this
index refers to the same event as identified by
the same value of eventlndex. loglndex an index
that uniquely identifies this particular log
entry among all entries associated with the same
event type. This index starts at 1 and increases
by one as each new packet is captured. logTime
This gives the value of sysUpTime when this log
entry was created. logDescription This is an
implementation-dependent description of the event
that activated this log entry.
