Digital Libraries

1
Digital Libraries

• Carl Staelin

2
Motivation

• Enormous amounts of information
• 1GB email
• 100MB compressed papers
• Hundreds of bookmark/favorite web pages
• Internet and intranet (1.4G pages and counting!)
• ???
• BUT information is useless unless you can find
  it!

3
Disk space trends

• To a first approximation, the amount of data
  equals the amount of available disk space
• Disk capacity is growing exponentially
• /megabyte is decreasing exponentially
• Amount of data is growing exponentially
• Utilize cheap disk space for indexing!

4
How to search for information?

• Depends on what I know, or want to know
• I remember reading a paper which presented an
  algorithm for clustering documents I think it
  was by Sahami
• How soon might we have a cure for Diabetes?
• When did I last send Paul email?

5
Other applications

• Message routing
• Send spam email to Deleted Items folder
• Route customer queries to support engineers
• Message filtering
• Automatically send me copies of articles on
  training Support Vector Machines
• Document clustering
• Dynamic Yahoo-like topic hierarchies

6
Overview

• Terminology
• Current solutions
• Information retrieval technology
• Inverted indexes
• Machine learning

7
Terminology

• Corpus a set of documents
• Index a mapping of terms or topics to documents
• Dictionary list of terms appearing in corpus
• Relevance
• Precision fraction of retrieved documents that
  were relevant
• Recall fraction of relevant documents that were
  retrieved

8
Libraries

• Library A warehouse of information which has
  been indexed and cataloged to make retrieval of
  information easier in the future.
• Traditional paper-based catalog/indexes
• Author and title catalogs
• Library of Congress topic index
• Citation indexes

9
Modern Libraries

• Traditional paper-based catalogs/indexes
• Catalog/index databases
• Traditional catalogs/indexes
• Allow more extensive/sophisticated queries
• Do not contain content, only bibliographic data

10
Search Engines

• Information Retrieval technology
• Index all web content
• Keyword search over all content
• Relevance ranking of results
• Meta-search Engines
• Query several search engines
• Collate/merge query results

11
Other

• Yahoo
• Content-based catalog for internet
• Human-generated catalog
• Human-specified Categories
• Librarians assign pages to categories
• Nexus / Lexus
• Full text of newswire articles, legal rulings
• Indexed/cataloged content

12
Status Summary

• Lots of different information sources are
  available
• Balkanized information space
• Disjoint sources
• Disjoint indexes
• Disjoint search methods
• Some interesting technology

13
Information Retrieval

• Text indexing and retrieval
• Inverted indexes
• Vector space model
• Relevance ranking
• Classification
• Clustering

14
Inverted Indexes

• Used to rapidly locate documents containing a
  particular word
• Database of (nearly) all words appearing in any
  document
• Each word has a list of all documents containing
  it
• May contain frequency of appearance in document
• May contain location(s) in document
• Common words are often ignored
• a, and, the, are known as stop words

15
Example Inverted Index

• Document A The quick brown fox
• Document B crazy like a fox
• Inverted Index
• Brown A
• Crazy B
• Fox A, B
• Quick A

16
Dictionaries

• List of all words (or root words) appearing in
  any document
• Assigns a unique ID to each word (or root word)
• Example dictionary
• Brown 1
• Crazy 2
• Fox 3
• Quick 4

17
Dictionaries (contd)

• What is a word?
• Root word (word stemming)
• Computer, computes, computing,
• Synonyms (thesauri)
• Bewildered, confused, disoriented,
• Polynyms (multiple meanings)
• Last after all others (last in line), greatest
  (last degree), least important (last prize)

18
Vector-space Model

• Each document is represented by a vector
• Each vector has as many elements as the size of
  the dictionary
• Each element in the vector contains the frequency
  of appearance for that word in that document
• Most elements are usually zero
• Positional information is lost
• Example vectors
• Document A 1, 0, 1, 1
• Document B 0, 1, 1, 0

19
Vector-space Model

• Documents similarity may be measured!
• Euclidean distance
• Cosine of angle between vectors
• Enables nearly all aspects of information
  retrieval
• Relevance ranking
• Clustering
• Vectors are generally HUGE and SPARSE for any
  reasonable corpus

20
Relevance Ranking

• Methods for ranking the relative relevance of
  documents which satisfy query
• Most methods measure distance between query and
  document
• Some methods incorporate external information
• Relative importance of word within document
  (e.g., it is part of the title or is a keyword)
• Relative importance of the document (e.g., it is
  linked to by more web pages)

21
Machine Learning

• Basic tasks
• Regression
• Classification
• Clustering
• General approaches
• Supervised learning
• Knowledge discovery

22
Features

• Quantified aspects of problem
• Words are often features
• Problem-specific features
• Is this email from a domain I know?
• How many web pages link to this page?
• Success of solution depends on quality of
  features!

23
Regression

• Given examples (x,y), , predict yf(x)
• Sample algorithms
• Linear Regression
• Neural Networks
• Support Vector Machines

24
Classification

• What class does this item belong to?
• Email filtering is this junk mail?
• Sample algorithms
• Support Vector Machines
• Neural Networks
• Bayesian Networks
• K-Nearest Neighbor

25
Clustering

• Given a bag of items, create N bags of
  related items
• Hierarchy generation automatically determine
  sub-topics
• Sample algorithms
• Hierarchical Agglomerative Clustering
• Iterative k-Means Clustering
• Support Vector Clustering

26
Supervised Learning

• Input fixed-length vector of reals
• Output fixed-length vector of reals
• Training learn correlation between input and
  known output values
• Operation given an input vector predict
  correct output vector

27
Accuracy Analysis

• Need mechanisms to compare the effectiveness of
  various algorithms
• Recall the fraction of relevant documents that
  were retrieved
• Precision the fraction of retrieved documents
  that were relevant
• Usually, increased performance in one metric
  results in decreased performance in the other

28
Course Project

• Develop an information retrieval / digital
  library system
• Use standard components
• Python
• HTTP fetching, HTML parsing, mailbox,
• Extensibility MySQL, LAPACK interfaces
• MySQL database for inverted index
• LAPACK and ATLAS for array operations

29
Course Project (contd)

• Basic framework exists
• MySQL databases
• Dictionary
• Inverted Index
• Scooter (web crawler)
• Document Parser

30
Course Project (contd)

• Aspects that you will develop include
• Document relevance
• Document clustering
• Term creation (e.g., stemming)
• Feature selection
