Data Types

1
Lecture 8

• Data Types

2
Chapter 6 Topics

• Introduction
• Primitive Data Types
• Character String Types
• User-Defined Ordinal Types
• Array Types
• Associative Arrays
• Record Types
• Union Types
• Pointer and Reference Types

3
Introduction

• A data type defines a collection of data objects
  and a set of predefined operations on those
  objects
• PL/1 first includes accuracy of decimal by
  integer, floating point and many other data types
• ALGOL 68 provided few basic types and operators
  to allow programmer for tailored user defined
  types
• User should be allowed to create a unique type
  for unique class of variables
• Improves readability and modifiability
• Extended to the concept of ADTs

4
Introduction

• Abstract Data Types Specification of data and
  operation whose use is separated from
  implementation
• expressed by using type operators (e.g, , (), ,
  etc)
• A descriptor is the collection of the attributes
  of a variable
• An object represents an instance of a
  user-defined abstract data type
• In Object Oriented language it is the instance of
  class
• One design issue for all data types What
  operations are defined and how are they
  specified?

5
Primitive Data Types

• Almost all programming languages provide a set of
  primitive data types
• Primitive data types Those not defined in terms
  of other data types
• Some primitive data types are merely reflections
  of the hardware
• Others require little non-hardware support

6
Primitive Data Types Integer

• Almost always an exact reflection of the hardware
  so the mapping is trivial
• There may be as many as eight different integer
  types in a language
• Javas signed integer sizes byte, short, int,
  long
• Ada SHORT INTEGER, INTEGER, LONG INTEGER
• C unsigned integer
• Represented by binary strings

7
Primitive Data Types Floating Point

• Model real numbers, but only as approximations
• One of the reasons is binary representation
• Languages for scientific use support at least two
  floating-point types
• float single precision and double double
  precision
• IEEE Floating-Point
• Standard 754

8
Primitive Data Types Decimal

• For business applications (money)
• Essential to COBOL
• C offers a decimal data type
• Store a fixed number of decimal digits
• Advantage accuracy
• Disadvantages limited range, wastes memory

9
Primitive Data Types Boolean

• Simplest of all
• Range of values two elements, one for true and
  one for false
• Could be implemented as bits, but often as bytes
• Advantage readability
• First introduced in ALGOL 60
• C uses numeric expression as a replacement
• Non zero values are true else false
• C and Java provides bool as primitive data type

10
Primitive Data Types Character

• Stored as numeric codings
• Most commonly used coding ASCII
• Uses 0 to 127 to code 128 different characters
• An alternative, 16-bit coding Unicode
• Includes characters from most natural languages
• First 128 characters are identical to ASCII
• Originally used in Java
• C and JavaScript also support Unicode

11
Character String Types

• Values are sequences of characters
• Design issues
• Is it a primitive type or just a special kind of
  array?
• Should the length of strings be static or dynamic?

12
Character String Type in Certain Languages

• C and C
• Not primitive
• Use char arrays and a library of functions that
  provide operations
• Character strings are terminated with a special
  character, null, which is represented with zero.
• The library operations simply carry out their
  operations until the null character being
  operated on. Library functions that produce
  strings often supply the null character.
• Common library functions
• strcpy, strcat, strcmp, strlen

13
Character String Type in Certain Languages

• C and C
• String manipulation functions of the C standard
  library is unsafe, as they dont guard against
  overflowing the destination. E.g.
• strcpy(dest,src)
• If the length of dest is 20 and the length of
  src is 50, strcpy will write over the 30 bytes
  that follow dest
• C programmer should use the string class from
  the standard library

14
Character String Types Operations

• Java
• Strings are supported as a primitive type by the
  String class string aabcd is the same as
  String a new String(abcd), whose values are
  constant strings (each time when the value is
  changed, a new String object is created).
• StringBuffer class values of a string is
  changeable.
• C
• Similar to Java
• C
• C-style strings and strings in its standard class
  library which is similar to that of Java
• Pattern matching

15
Character String Types Operations

• Pattern matching
• Fundamental character string operation
• Often called regular expressions
• E.g., /A-Za-zA-Za-z\d/ matches string that
  begin with a letter, followed by one or more
  letters or digits
• Perl, JavaScript and PHP have built-in pattern
  matching operations
• Java, C and C have pattern matching
  capabilities in the class libraries, e.g. Java
• Pattern p Pattern.compile("ab")
• Matcher m p.matcher("aaaaab")
• boolean b m.matches()

16
Character String Length Options

• Static Length COBOL, Javas String class
• Length is set when the string is created, fixed
  length
• Limited Dynamic Length C and C
• Length is set to have a maximum, varying length
• Dynamic Length(no maximum) Perl, JavaScript
• No length limit, varying length. Required
  overhead of dynamic storage allocation and
  deallocation but provides maximum flexibility
• Ada supports all three string length options
• String static
• Bounded_String limited dynamic
• Unbounded_String dynamic

17
Character String Type Evaluation

• Aid to writability
• As a primitive type with static length, they are
  inexpensive to provide
• Simple pattern matching and catenation are
  essential, should be included
• Dynamic length is most flexible, but overhead of
  implementation must be weighed. Often included
  only in languages that are interpreted.

18
Character String Implementation

• Static length compile-time descriptor
• Limited dynamic length may need a run-time
  descriptor for length (but not in C and C)

type of string
address of the first character
type of string
address of the first character
19
Character String Implementation

• Dynamic length need run-time descriptor
  allocation/de-allocation is the biggest
  implementation problem. Two approaches
• String is stored in a linked list, so when a
  string grows, the newly required cells can come
  from anywhere in the heap. Drawback extra
  storage occupied by the links in the list
  representation and the necessary complexity of
  string operations. But allocation and
  deallocation process is simple.
• Store complete strings in adjacent storage cells.
  When the storage for the adjacent cell is not
  available(when the string grows), a new area of
  memory is found to store the complete new string.
  Faster string operation and requires less
  storage, but slower allocation and deallocation
  process. This approach is typically used.

20
User-Defined Ordinal Types

• An ordinal type is one in which the range of
  possible values can be easily associated with the
  set of positive integers
• Examples of primitive ordinal types in Java
• integer
• char
• boolean
• Generally two kinds of user-define ordinal types
• enumeration
• subrange

21
Enumeration Types

• All possible values, which are named constants,
  are provided in the definition
• C example
• enum days mon, tue, wed, thu, fri, sat, sun
• The enumeration constants are typically
  implicitly assigned the integer values, 0, 1, ,
  but can be explicitly assigned any integer
  literal in the types definition
• Design issues
• Is an enumeration constant allowed to appear in
  more than one type definition, and if so, how is
  the type of an occurrence of that constant
  checked?
• Are enumeration values coerced to integer?
• Any other type coerced to an enumeration type?

22
Design

• In languages that do not have enumeration types,
  programmers usually simulate them with integer
  values. E.g. Fortran 77, use 0 to represent blue
  and 1 to represent red
• INTEGER RED, BLUE
• DATA RED, BLUE/0,1/
• Problem there is no type checking when they are
  used. It would be legal to add two together.
• They can be assigned any integer value thus
  destroying the relationship with the colors.

23
Design

• Pascal and C/C do not allow literal constants
  to be used in more than one enumeration type
  definition
• Ada allows overloaded literals
• Resolve overloading from context of its appearance

24
Design

• In C, we could have
• enum colors red, blue, green, yellow, black
• colors myColor blue, yourColor red
• The enumeration values are coerced to int when
  they are put in integer context. E.g. myColor
  would assign green to myColor.

25
Design

• In Java, all enumeration types are implicitly
  subclasses of the predefined class Enum. They can
  have instance data fields, constructors and
  methods
• Java ExampleEnumeration days Vector dayNames
  new Vector() dayNames.add("Monday")
  dayNames.add("Friday") days
  dayNames.elements() while (days.hasMoreElements(
  )) System.out.println(days.nextElement())

26
Design

• C enumeration types are like those of C except
  that they are never coerced to integer.
• Operations are restricted to those that make
  sense.
• The range of values is restricted to that of the
  particular enumeration type.

27
Evaluation of Enumerated Type

• Aid to readability, e.g., no need to code a color
  as a number
• Aid to reliability, e.g., compiler can check
• operations (dont allow colors to be added with
  integer)
• No enumeration variable can be assigned a value
  outside its defined range, e.g. if the colors
  type has 10 enumeration constants and uses 0 .. 9
  as its internal values, no number greater than 9
  can be assigned to a colors type variable.
• Ada, C, and Java 5.0 provide better support for
  enumeration than C because enumeration type
  variables in these languages are not coerced into
  integer types

28
Evaluation of Enumerated Type

• C treats enumeration variables like integer
  variables it does not provide the advantage of
  reliability.
• C is better. Numeric values can be assigned to
  enumeration type variables only if they are cast
  to the type of the assigned variable. Numeric
  values are checked to determine in they are in
  the range of the internal values. However if the
  user uses a wide range of explicitly assigned
  values, this checking is not effective. E.g.
• enum colors red 1, blue 100, green 100000
• A value assigned to a variable of colors type
  will only be checked to determine whether it is
  in the range of 1..100000.
• Java 5.0, C and Ada are better, as variables are
  never coerced to integer types

29
Subrange Types

• An ordered contiguous subsequence of an ordinal
  type
• Not a new type, but a restricted existing type
• Example 12..18 is a subrange of integer type
• Adas design
• type Days is (mon, tue, wed, thu, fri, sat, sun)
• subtype Weekdays is Days range mon..fri
• subtype Index is Integer range 1..100
• Day1 Days
• Day2 Weekday
• Day2 Day1 //legal if Day1 is not sat or sun
• Compatible with its parent type.

30
Subrange Evaluation

• Aid to readability
• Make it clear to the readers that variables of
  subrange can store only certain range of values
• Reliability
• Assigning a value to a subrange variable that is
  outside the specified range is detected as an
  error

31
Implementation of User-Defined Ordinal Types

• Enumeration types are implemented as integers
• Subrange types are implemented like the parent
  types with code inserted (by the compiler) to
  restrict assignments to subrange variables
• increase code size and execution time
• may help in compiler optimization
